Kauai 1.8 Shower System
Model #1077
-CH
Owner's Manual
KAUAI 1.8
2
6.38
in. -
162 mm
5 in. -
127mm
**When using optional 4 inch shorter pipe.
~26
1/8 1/8 in. - 664 mm [ ~22 in. - 562 mm**]
27
5/16 5/16 [ in. - 694 mm 23 in. - 592 mm**]
33
5/16 in. - 846 mm [ 29 5/16 in. - 562 mm**]
33
5/16 5/16in. - 846 mm [ 29 ]in. - 562 mm**
16
1/4 in. - 413 mm
20
in. - 508 mm
24
in. - 610 mm
36
1/4 1/4 [ in. - 920 mm 32 in. - 819 mm**]
9
in. - 228 mm
3.62 in. -
92 mm
Finish Wall Line
**
2.1
Kauai 1.8 Parts Legend
1. ½" x 2" NPT Nipple
2. Inlet Fitting
2.1) Check Valve/Flow Restrictor– 1
2.2) Screen– 1
2.3) Retaining Clip – 1
3. Top Escutcheon
4. Top Tee
5. Shower Arm
6. Shower Head
7. Shower Pipe**
8. Soap Dish
9. Hand Shower Holder
10. Hand Shower
11. Stainless Steel Hose
12. Diverter Body
13. Bottom Escutcheon
14. Lower Mount Screw ..............(2)
15. Lower Mount (w/ Tape)
16. Wall Anchor ...........................(2)
17. Set Screw - 2.5mmX4mm......(1)
18. Swivel Joint
19. Check Valve
20. Set Screw - 2.5X8mm......(4)
21. Rubber Washer (2) .............
22. Diverter Handle
23. 2.5mm Hex Wrench
24. PTFE Thread Sealant Tape
25. Soap Dish Support Ring
26. Tapered Rubber Seal
27. Set Screw - 2.5mmX7mm...(2)
**4” s P shorte r HOWER IPE (7) .P s s .available f o r Purch ase at w w w ul se ho we r Pa s com
3
Installation Instructions
Thank you for choosing the Kauai 1.8 Shower System by PULSE ShowerSpas!
Assembly and installation of the Kauai 1.8 Shower System is
designed to be quick and easy. If you have installation questions
or performance problems, visit www.pulseshowerspas.com for
customer support.
Please read instructions carefully, become familiar with all parts,
installation procedures and tools required. Follow steps in order
presented to help avoid mistakes.
FOR NEW CONSTRUCTION OR
COMPLETE REMODEL
• A hot/cold mixing valve is required (NOT INCLUDED)
• Nipple should extend
1
⁄
2
" past nished wall surface.
TOOLS REQUIRED
Adjustable wrench, Phillips screwdriver, pencil and
2.5mm hex wrench
ASSEMBLY
1. Determine length of brass NPT nipple (1) needed:
a. Place mark on existing shower arm at wall surface.
Unscrew shower arm from elbow in wall.
b. Measure distance from mark on shower arm to end of
shower arm threads. Add
1
⁄
2
" to this measurement, and
then round to nearest
1
⁄
2
".
Example 1: If measurement = 1
1
⁄
4
", add
1
⁄
2
" = 1
3
⁄
4
",
rounded = 2" NPT nipple—this is the length needed.
Example 2: If measurement = 1
5
⁄
8
", add
1
⁄
2
" = 2
1
⁄
8
",
rounded = 2" NPT nipple—this is the length needed.
IMPORTANT: If shower arm is located above tile/berglass
wall surface you must add distance from sheetrock to face
of tile/berglass shower wall to the above measurement.
NOTE: If supplied 2" nipple (1) is not correct length based on
above formula, you must obtain correct size NPT brass
nipple (sold separately), available at most hardware stores.
2. Apply generous amount of PTFE Thread Sealant Tape (24)
to both ends of nipple (1).
3. Hand tighten inlet tting (2) onto nipple (1), then nipple
to tting in wall. Use adjustable wrench on inlet tting to
tighten both connections simultaneously until both are
secure with no leaks.
4. Slide hand shower holder (9) o shower pipe (7).
5. Slide soap dish support ring (25) onto shower pipe
to desired position. Slide dish onto shower pipe and
support ring.
CAUTION
—DO NOT OVERTIGHTEN
6. Reinstall hand shower hanger (9).
CAUTION
—DO NOT OVERTIGHTEN
7. Apply small amount of grease to o-rings on bottom swivel
joint (18) and secure onto bottom of diverter body (12) with
set screw. Swivel joint should move freely side to side.
8. Rotate shower pipe (7) and top tee (4) for correct
alignment. Secure with set screw (17).
9. Slide top escutcheon (3) over top tee (4).
HINT—Lubricate escutcheon o-ring; a small amount of
soapy water will do the trick.
10. Slide bottom escutcheon (13) over diverter body (12).
HINT—Lubricate escutcheon o-ring; a small amount of
soapy water will do the trick.
11. Loosen set screw (20) on diverter and slide lower mount (15)
into diverter body (12).
12. Push top tee (4) over inlet tting (2) until ush against
tting. Position diverter body (12) so shower pipe is plumb
(vertical).
13. Mark location of lower mount with pencil.
14. Wall surface must be clean of any residue and completely
dry. Remove covering of two-face tape and reposition
lower mount (15) to mark with optional mounting holes.
Ensure optional mounting holes are horizontal.
15. Apply pressure to mount for 30 seconds by pushing rmly
against the diverter. To ensure proper adhesion, allow one
hour before using your ShowerSpa and keep area around
the mount as dry as possible for the rst 24 hours. Tape will
be fully cured after 24 hours.
OPTIONAL: Secure lower mount with permanent wall an-
chors. Mark hole locations in lower mount (15). Drill 1
1
⁄
4
"
deep holes using 6mm (
1
⁄
4
") masonry/tile drill bit. Insert wall
anchors (16) and secure lower mount with screws (14).
CAUTION—LIVE PLUMBING IN WALL
16. Position shower pipe (7) parallel to wall by sliding diverter
body (12) on lower mount (15). Secure diverter to lower
mount with set screw (20).
17. Insert rubber washer (21) into both ends of hose (11).
Connect hex head end to swivel joint (18) and tapered end
to hand shower (10). Place hand shower (10) into adjustable
hanger (9).
18. Insert rubber washer (21) in shower head (6) and tighten
securely to shower arm (5).
