Seite 1/15
E
N
G
L
I
S
H
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
What’s in the Box? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Transit USB Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Transit USB Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Software Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Windows XP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Windows 2000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Windows Me . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Windows 98SE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Mac OS 9.2.2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Mac OS X . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Transit USB Audio Connnections . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Output Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Input Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Transit USB’s Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Operating Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Latency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Transit USB and the Windows Media Drivers . . . . . . . . . . . . . . . . . .26
WDM/MME . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
ASIO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Transit USB and Macintosh Audio . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Mac OS 9.2.2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Mac OS X . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Contact Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
3
E
N
G
L
I
S
H
2
E
N
G
L
I
S
H
Technical Features:
• Supports the following sampling frequencies (in Hz):8000, 9600, 11025,12000, 16000, 22050,
24000, 32000, 44100, 48000, 88200*, 96000
• Supports 16 & 24-bit Linear PCM I/O, 16-bit AC-3 and 16-bit DTS output over S/PDIF
TOSLink
• Supports the following audio protocols: ASIO,WDM, MME, SoundManager, CoreAudio
• Unique hybrid optical/analog input jack automatically detects whether input is analog or
optical digital
• 1/8” mic input provides power for electret condenser mics
• software-controlled input and output levels, using standard Windows or MacOS
volume controls
* Transit USB does not support analog recording at 88200 Hz.
Audio Performance Specifications:
•Input: Dynamic Range 100 dB (typical –60 dB input,A-weighted);
Signal-to-Noise Ratio 100 dB (typical,A-weighted); THD+N –90 dB = 0.00316% (typical)
•Output: Dynamic Range 104 dB (typical –60 dB input, A-weighted); Signal-to-Noise
Ratio 104 dB (typical,A-weighted); THD+N –94 dB = 0.00316% (typical)
System Requirements, Windows:
Minimum:
• Pentium II 350 MHz • 64 MB RAM
• CD-ROM drive • Available USB 1.1 port
• Windows 98SE, Me, 2000 (SP4) or XP (SP1)
Recommended:
• Pentium III 500 MHz or faster • 128 MB RAM or more
• DVD-ROM drive and DVD player application (for AC-3 & DTS pass-through)
Introduction
Thanks for choosing the Transit USB by M-Audio.Transit USB is your compact, professional
audio solution for any Windows or Macintosh computer*, using the convenience of USB
connectivity – no need to disassemble your computer, no bulky external power supplies.
Transit USB gives you full 24 bit digital audio at sampling rates from 8 kHz to 96 kHz, with
the flexibility of both analog and optical digital connectors in a lightweight form factor you
can carry with you anywhere.
Please take the time to read this concise Users’ Guide. It will explain how to install the
Transit USB on your computer, and tell you how to get the best performance out of your
Transit USB audio interface.
* must meet minimum system requirements
What’s in the Box?
The following items are included with your Transit USB:
• Transit USB audio interface
• One (1) standard USB cable
• One (1) TOSLink to 1/8” Optical plug adapter
• M-Audio Driver CD (includes driver installation software)
• Users’ Guide and Warranty Card
Transit USB Specifications
Product and Operational Features:
• Single USB 1.1 connection for input and output
• S/PDIF 1/8” mini Optical In or 1/8” mini Analog Mic/Line In
• S/PDIF optical out and 1/8” mini Analog Line Out
• Sleek, slim plastic case with blue power LED.
• Completely USB powered (no power supply needed)
• One year warranty
5
E
N
G
L
I
S
H
4
E
N
G
L
I
S
H
3. Optical/Analog Mic/Line Input Jack - This hybrid digital/analog jack accepts either analog
input via a standard 1/8" stereo mini plug, or optical S/PDIF digital input via an included
mini-optical adapter. The input jack automatically senses whether the input is analog or
digital.The analog input can also accept mic-level inputs, and provides plug-in power for
electret condenser microphones.
4. Optical Digital-Output Connector - This is a standard optical S/PDIF connector for
digital audio (sometimes called a TOSLink connector) that accepts a standard optical
digital cable. This port can output either PCM stereo digital audio or digitally-encoded
AC-3 or DTS pass-through. The output comes with a plastic cover that should be
removed and stored for use when transporting the Transit USB.
5. Line-Output Jack - This 1/8" mini-jack accepts a standard stereo plug, such as those used
for connection with portable audio devices and powered computer speakers. If you need
to connect the Transit to a home stereo system, you may obtain a cable or adapter with
a 1/8” stereo plug on one end and two male RCA plugs on the other. This output also
boasts an enhanced current drive for use with a pair of headphones.
Software Installation
Your Transit USB comes with driver software that allows it to communicate with your particular
computer (Mac or PC) and operating system.Please locate the section for your computer type and
operating system and follow the instructions for installing the driver software.
Your Transit USB comes with a standard USB cable. The squared end of the cable connects
to the Transit USB; the flat end connects to your computer’s USB port. Do NOT connect the
Transit USB to your computer until instructed to do so.
Windows XP
1. Place the Transit USB CD into your CD-ROM drive. Do NOT connect the Transit USB
to your computer’s USB port at this time. Browse the CD content and double click the
Transit USB folder.Then double click the Transit USB Icon.
System Requirements, Macintosh:
Minimum:
• G3, G4*, iMac, iBook or Powerbook with native USB support
• 64 MB RAM • CD-ROM drive
• Mac OS version 9.2.2,MacOSX version 10.1.5 or MacOSX “Jaguar” version 10.2.6 or later
Recommended:
• G3, G4*, iMac, iBook or Powerbook with native USB support
• 128 MB RAM
• DVD-ROM drive
• MacOSX “Jaguar” version 10.2.4 or later
* G3 and G4 accelerator cards not supported; AC-3 & DTS pass-throughsupported only with OS X 10.3 or higher
Transit USB Features
This diagram is an illustration of your Transit USB, with descriptions and information about
its physical f es, which areatur e described here.
1. USB Connector – Connect the squared “device” end of the supplied USB cable here.
2. Power LED – This LED lights bright blue when Transit USB receives power from your
computer’s USB port.This will occur when Transit USB sees a valid USB connection to
your computer, and the computer is powered on and the USB port enabled.
