QT4090, QT4070

6 7

8 9 10

11 12 13

14 15 16

17 18 19

20 21 22

23 24 25

26 27 28

Introduction

Congratulations on your purchase and welcome to

Philips! To fully benet from the support that Philips offers,

This maintenance-free Philips vacuum beard trimmer

combines innovative technology and outstanding comfort

of use. It is excellently suited for cutting and contouring

your beard and sideburns.

The integrated vacuum system absorbs cut-off hairs

during use and gives you a cleaner washbasin after use.

The trimming comb, the self-sharpening cutting unit

and the adjustment ring to select hair lengths from 1 to

18mm ensure excellent cutting results and time-saving

operation. The ergonomic shape of the appliance allows

pleasant and comfortable handling.

QT4075, QT4070 comes with a trimming comb that has

been specially designed to offer you a better view when

you want to create a stubble look.

QT4090 comes with a contour-following trimming comb

that has been specially designed to trim longer beards. It

also has a high-quality precision trimmer that guarantees a

precise and dened cut.

General description (Fig. 1)

A Detachable cutting unit

B Lid of hair collection chamber

C Hair-collection chamber & lter

D Adjustment ring (Precision Zoom Lock ) `

E Hair length indicator

F Charge level indicator

G Travel lock indicator

H On/off button

I Turbo button

J Socket for appliance plug

K Storage pouch (QT4090 only)

L Appliance plug

M Adapter (2.5V/1500mA)

N Cleaning brush

O Precision trimmer (QT4090 only)

P Contour-following trimming comb (QT4090)

Q Trimming comb (QT4075, QT4070)

Important

Read this user manual carefully before you use the

appliance and save it for future reference.

Danger

- Make sure the adapter does not get wet.

Warning

- Check if the voltage indicated on the appliance

corresponds to the local mains voltage before you

connect the appliance.

- The adapter contains a transformer. Do not cut

off the adapter to replace it with another plug, as

this causes a hazardous situation.

- This appliance is not intended for use by persons

(including children) with reduced physical, sensory

or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision

or instruction concerning use of the appliance by a

person responsible for their safety.

- Children should be supervised to ensure that they

do not play with the appliance.

Caution

- Charge, use and store the appliance at a temperature

between 5°C and 35°C.

- Do not charge the appliance in the storage pouch

supplied.

- Do not immerse the appliance in water or any other

liquid, nor rinse it under the tap. (Fig. 2)

- Only use the adapter supplied.

- If the adapter, the cutting unit or one of the trimming

combs is damaged, always have it replaced with one

of the original type in order to avoid a hazard.

- The adapter transforms 220-240 volts to a safe low

voltage of less than 24 volts.

- Do not use the appliance if one of the trimming

combs or the cutting unit is damaged or broken, as

this may cause injury.

- This appliance is only intended for trimming the

human beard. Do not use it for any other purpose.

- Noise level: Lc = 65 dB(A).

Electromagnetic elds (EMF)

- This Philips appliance complies with all standards

regarding electromagnetic elds (EMF). If handled

properly and according to the instructions in this

user manual, the appliance is safe to use based on

scientic evidence available today.

Preparing for use

Charging

Charge the appliance fully before you use it for the rst

time and after a long period of disuse.

Charging takes about 60 minutes if the appliance is

completely empty.

1 Make sure the appliance is switched off.

2 Insert the appliance plug into the appliance and put

the adapter in the wall socket (Fig. 3).

,When you start charging the empty appliance,

the bottom segment of the charge level indicator

ashes orange. When the battery contains enough

power for one trimming session of approx. 7

minutes, the bottom segment starts ashing blue.

,First the bottom segment of the charge level

indicator ashes blue, then the second segment and

so on, until the appliance is fully charged. (Fig. 4)

,When the appliance is fully charged, all segments of

the charge level indicator light up blue continuously.

,If the fully charged appliance is still connected to

the mains after 1 hour, the segments of the charge

level indicator go out.

Battery low

When the battery is almost empty (when there are

approx. 7 or fewer trimming minutes left), the bottom

segment of the charge level indicator turns orange. When

you switch off the trimmer, the bottom segment ashes

for a few seconds.

Corded trimming

When the rechargeable battery is low, you can also run

the appliance from the mains.

To use the appliance connected to the mains:

1 Switch off the trimmer and connect it to the mains.

2 Wait a few seconds and then switch on

the appliance.

Note: If the battery is completely empty, wait a few minutes

before you switch on the appliance.

Using the appliance

Display indications

The display is activated when you press the on/of button

and when you turn the adjustment ring.

- During trimming, the display provides the following

information: (Fig. 5)

,’-’ when no comb is attached to the appliance.

,The selected hair length (i.e. the remaining hair

length after trimming) in millimetres.

,The remaining charge level.

,Travel lock indicator if the appliance is locked (see

section ‘Travel lock’ in this chapter).

,’E’ if the cutting unit is blocked.

Beard trimming

Always comb your beard or moustache with a ne

comb before you start trimming.

Trimming with trimming comb

The hair length settings are indicated in millimetres on the

display of the appliance. The settings correspond to the

remaining hair length after cutting.

The trimming comb cuts hair to a length of 1-18mm.

If you trim for the rst time, start with the maximum

hair length setting (18mm).

1 Slide the trimming comb onto the appliance (Fig. 6).

2 Turn the adjustment ring (Precision Zoom Lock ) `

to the desired hair length setting. (Fig. 7)

,The display shows the selected hair length.

3 Switch on the appliance (Fig. 8).

Note: During trimming, you can use the turbo function for

extra suction power and trimming speed (see section ‘Turbo

function’ below).

4 To trim most effectively, move the appliance against

the direction of hair growth (Fig. 9).

Note: Make smooth and gentle movements and make sure

the surface of the trimming comb always stays in contact

with the skin.

Note: Do not move the appliance too fast.

5 Switch off the appliance after use and clean it (see

chapter ‘Cleaning’).

Creating a stubble look

- Use the trimmer with the trimming comb set to a

hair length of 1mm to create a stubble look (Fig. 10).

- If you want even shorter stubble of 0.5mm, use the

trimmer without the trimming comb attached.

Trimming without trimming comb

Use the trimmer without trimming comb to trim full

beards and single hairs.

1 Remove the trimming comb (Fig. 11).

Note for QT4090: Never pull at the exible top of the

trimming comb. Always pull at the bottom part.

2 Make well-controlled movements and touch the

hair lightly with the cutting unit.

Shaping with the precision trimmer

(QT4090 only)

You can use the precision trimmer to shape your

moustache and sideburns, to dene contours and to cut

single hairs.

1 Remove the trimming comb (Fig. 11).

Note: Never pull at the exible top of the trimming comb.

Always pull at the bottom part.

2 Pull the cutting unit off the appliance (Fig. 12).

3 Place the precision trimmer on the

appliance (Fig. 13).

4 When you use the precision trimmer, hold the

appliance in such a way that the trimmer points

upwards and make downward strokes (Fig. 14).

Turbo function

You can use the turbo function for greater suction power

and increased cutting speed.

1 Switch on the appliance (Fig. 8).

2 Press the turbo button (Fig. 15).

When you switch off the appliance, the turbo function is

deactivated automatically.

Absorbing cut hairs

The vacuum system is activated automatically as soon as

you switch on the appliance. It absorbs cut hairs during

every kind of use, i.e. trimming with and without trimming

comb and contouring.

We advise you to empty the hair-collection chamber after

each trimming session. When you trim long, dense beards,

it may also be necessary to empty the hair-collection

chamber during the trimming session in order to maintain

optimal suction performance (see chapter ‘Cleaning’,

section ‘Hair-collection chamber’).

Note: To ensure optimal functioning of the vacuum system,

do not cut off more than approx. 7mm of your overall beard

length at a time. If you want to cut your beard shorter,

repeat the process one or more times.

Travel lock

You can lock the appliance when you are going to

travel. The travel lock prevents the appliance from being

switched on by accident.

Activating the travel lock

1 Press and hold the on/off button for at least 6

seconds.

,The display counts down from 3 to 1. Then the

travel lock indicator appears on the display to

indicate that the appliance is locked (Fig. 16).

Deactivating the travel lock

1 Press and hold the on/off button for at least 6

seconds.

,The display counts down from 3 to 1.

Then the travel lock indicator disappears from

the display to indicate that the appliance is

unlocked (Fig. 16).

Note: The travel lock is deactivated automatically when you

connect the appliance to the mains.

ENGLISH

4222.002.8110.1

Cleaning

Never use scouring pads, abrasive cleaning agents or

aggressive liquids such as alcohol, petrol or acetone to

clean the appliance.

Do not immerse the appliance in water or any other

liquid, nor rinse it under the tap.

Hair-collection chamber

1 Switch off the appliance.

2 Open the lid of the hair-collection

chamber (Fig. 17).

3 Shake the hairs out of the hair-collection chamber

and/or remove them with the cleaning brush

supplied (Fig. 18).

4 Clean the lter inside the hair-collection chamber

with the cleaning brush supplied (Fig. 19).

Never use sharp or hard objects to clean the lter, to

avoid damaging it.

5 Close the lid of the hair-collection chamber.

Appliance

1 Pull the trimming comb off the appliance (Fig. 11).

2 Pull the cutting unit off the appliance (Fig. 12).

3 Clean the cutting unit and the inside of the

appliance with the cleaning brush supplied (Fig. 20).

4 Put the cutting unit and the trimming comb back

onto the appliance (‘click’) (Fig. 21).

Storage

1 QT4090 only: Put the appliance in the storage

pouch supplied.

2 Store the appliance in a safe and dry place.

Environment

- Do not throw away the appliance with the normal

household waste at the end of its life, but hand it in

at an ofcial collection point for recycling. By doing

this, you help to preserve the environment (Fig. 22).

- The built-in rechargeable battery contains substances

that may pollute the environment. Always remove

the battery before you discard and hand in the

appliance at an ofcial collection point. Dispose of

the battery at an ofcial collection point for batteries.

If you have trouble removing the battery, you can

also take the appliance to a Philips service centre.

The staff of this centre will remove the battery for

you and will dispose of it in an environmentally safe

way. (Fig. 23)

Removing the rechargeable battery

Do not connect the appliance to the mains again after

you have opened it.

Follow the steps below to remove the rechargeable

battery.

1 Disconnect the appliance from the mains and let

the appliance run until the motor stops.

2 Open the lid of the hair-collection

chamber (Fig. 17).

3 Remove the 4 screws inside the hair chamber with

a screwdriver (Fig. 24).

4 Pull the hair-collection chamber out of the

appliance with some force (Fig. 25).

5 To remove the front panel, wedge a screwdriver

between the front panel and the inside of the

appliance (Fig. 26).

6 Remove the 4 screws on the inside of the

appliance (Fig. 27).

7 Remove the inner panel (Fig. 28).

8 Remove the printed circuit board with the

rechargeable battery connected to it (Fig. 29).

9 Cut the wires between the printed circuit board

and the rechargeable battery.

Guarantee and service

If you need service or information or if you have a

problem, please visit the Philips website at

www.philips.com or contact the Philips Consumer

Care Centre in your country (you nd its phone number

in the worldwide guarantee leaet). If there is no

Consumer Care Centre in your country, go to your local

Philips dealer.

4222.002.8110.1

Produktspezifikationen

Marke:	Philips
Kategorie:	Bartschneider
Modell:	Series 7000 QT4090

Brauchst du Hilfe?

Wenn Sie Hilfe mit Philips Series 7000 QT4090 benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten

Ihren Namen*

Deine E-Mail*

Schreiben Sie hier Ihre Frage

Bedienungsanleitung Bartschneider Philips

Philips Series 5000 BT5502 Bedienungsanleitung

11 September 2024

Philips Series 7000 BT7501 Bedienungsanleitung

8 September 2024

Philips Series 9000 MG9540 Bedienungsanleitung

4 September 2024

Philips Series 9000 MG9530 Bedienungsanleitung

4 September 2024

Philips Norelco MG7910 Bedienungsanleitung

1 September 2024

Philips Norelco MG7900 Bedienungsanleitung

1 September 2024

Philips Norelco BT7515 Bedienungsanleitung

31 August 2024

Philips BT3232 Bedienungsanleitung

31 August 2024

Philips BT1210 Bedienungsanleitung

31 August 2024

Philips Series 3000 X3003 Bedienungsanleitung

31 August 2024

Bedienungsanleitung Bartschneider

Neueste Bedienungsanleitung für -Kategorien-

Coline PSA-227RICEP Bedienungsanleitung

7 Oktober 2024

Scarlett SC-263 Bedienungsanleitung

5 Oktober 2024

Stihl FSA 200 Bedienungsanleitung

3 Oktober 2024

Rowenta Wet & Dry TN5140F0 Bedienungsanleitung

29 September 2024

BaByliss For Men E876E Bedienungsanleitung

29 September 2024

BaByliss Wtech Precision Plus T830E Bedienungsanleitung

28 September 2024

Domo DO7033 Bedienungsanleitung

21 September 2024

BaByliss Japanese Steel 7865U Bedienungsanleitung

11 September 2024

BaByliss Graphite Precision T987U Bedienungsanleitung

11 September 2024

BaByliss Super-X Metal S996U Bedienungsanleitung

11 September 2024
