Operating Manual
To ensure the best performance from your
camera, please read the Operating Manual
before using the camera.
Introduction 1
2
Getting Started
3
Shooting
4
Playback
5
Sharing
6
Settings
SLR Digital Camera
7
Appendix
Model No. R06010
We have paid close attention to the safety of this camera. When using this
camera, we request your special attention regarding items marked with the
following symbols.
Warning
Do not disassemble or modify the camera. High voltage areas are
present inside the camera, with the risk of electric shock.
If the camera interior is exposed due to dropping or otherwise damaging
the camera, never touch the exposed portion. There is a risk of electric
shock.
Do not aim the camera at the sun or other strong light sources when
taking pictures or leave the camera sitting in direct sunlight with a lens
cap off. Doing so may cause the camera to malfunction or cause a fire.
Do not look at the sun or other strong light sources through a lens. Doing
so may lead to a loss of eyesight or cause vision to be impaired.
If any irregularities occur during use, such as smoke or a strange odor,
stop using the camera immediately, remove the battery or the AC
adapter, and contact your nearest service center. Continued use can
cause a fire or electric shock.
Caution
Do not place your finger over the flash when discharging the flash. You
may burn yourself.
Do not cover the flash with clothing when discharging the flash.
Discoloration may occur.
Some portions of the camera heat up during use. There is a risk of low
temperature burns when holding such portions for long periods.
Should the monitor be damaged, be careful of glass fragments. Also, be
careful not to allow the liquid crystal to get on your skin or in your eyes
or mouth.
Depending on your individual factors or physical condition, the use of the
camera may cause itching, rashes or blisters. In case of any
abnormality, stop using the camera and get medical attention
immediately.
Warning
Always use the battery charger and AC adapter exclusively developed
for this camera, with the specified power and voltage. Using a battery
charger or AC adapter not exclusive to this camera, or using the
exclusive battery charger or AC adapter with an unspecified power or
voltage can cause a fire, electric shock, or camera breakdown. The
specified voltage is 100 - 240V AC.
Do not disassemble or modify the product. This can cause a fire or
electric shock.
If the generation of smoke or strange odor from the product or other
abnormality occurs, immediately discontinue using and consult your
nearest service center. Continued use can cause a fire or electric shock.
If water should happen to get inside the product, consult your nearest
service center. Continued use can cause a fire or electric shock.
If you see a lightning flash or hear thunder during use of the battery
charger or AC adapter, unplug the power plug and discontinue using.
Continued use can cause damage to the product, fire or electric shock.
Wipe off the power plug if it should become covered with dust.
Accumulated dust may cause a fire.
To reduce the risk of hazards, use only CSA/UL certified power supply
cord set, cord is Type SPT-2 or heavier, minimum NO.18 AWG copper,
one end with a molded-on male attachment plug cap (with a specified
NEMA configuration), and the other is provided with a molded-on female
connector body (with a specified IEC nonindustrial type configuration) or
the equivalent.
Caution
Do not place or drop heavy objects on or forcefully bend the AC plug
cord. Doing so may damage the cord. Should the AC plug cord be
damaged, consult your nearest service center.
For Using Your Camera Safely
Warning This symbol indicates that ignoring this item could
cause serious personal injuries.
Caution This symbol indicates that ignoring this item could
cause minor or medium personal injuries, or loss
of property.
About the Camera
About the Battery Charger and AC Adapter
1
Do not touch or short-circuit the terminal area of the AC plug cord while
the cord is plugged in.
Do not handle the power plug with wet hands. This can cause an electric
shock.
Do not drop the product, or subject it to violent impact. This can cause
the product to breakdown.
Do not use the battery charger D-BC186 to charge batteries other than
the rechargeable lithium-ion battery D-LI109. Attempting to charge other
types of batteries may cause an explosion or heating, or may damage
the battery charger.
Warning
Wipe off the power plug if it should become covered with dust.
Accumulated dust may cause a fire.
Do not handle the power plug with wet hands. This can cause an electric
shock.
Always grip the plug section when disconnecting the power plug. Do not
pull the power cord. This can damage the power cord and result in a fire
or electric shock.
If the generation of smoke or strange odor from the adapter or other
abnormality occurs, immediately remove the power plug from the outlet
and contact your nearest dealer or service center for repair. Do not use
the adapter until it is repaired.
If you see a lightning flash or hear thunder during use of the adapter, do
not touch the power plug. This can cause an electric shock.
Caution
Securely insert the power plug into the outlet. Failure to observe this
precaution may cause a fire.
Warning
If any leakage from the battery should come in contact with your eyes,
do not rub them. Flush your eyes with clean water and get medical
attention immediately.
Caution
Only use the specified battery with this camera. Use of other batteries
may cause an explosion or fire.
Do not disassemble the battery. Disassembling the battery may cause
an explosion or leakage.
Remove the battery from the camera immediately if it becomes hot or
begins to smoke. Be careful not to burn yourself during removal.
Keep wires, hairpins, and other metal objects away from the + and -
contacts of the battery.
Do not short the battery or dispose of the battery in fire. This can cause
an explosion or fire.
If any leakage from the battery should come in contact with skin or
clothing, it may cause irritation to the skin. Wash the affected areas
thoroughly with water.
Avoid the following actions regarding the battery:
- Replacement of the battery with an incorrect type that can defeat a
safeguard (for example, in the case of some lithium battery type)
- Disposal of the battery into fire or a hot oven, or mechanically crushing
or cutting of the battery, that can result in an explosion
- Leaving the battery in an extremely high temperature surrounding
environment that can result in an explosion or leakage of flammable
liquid or gas
- Subjecting the battery to extremely low air pressure that may result in
an explosion or leakage of flammable liquid or gas
Precautions for D-LI109 Battery Usage:
- USE SPECIFIED CHARGER ONLY.
- DO NOT INCINERATE.
- DO NOT DISASSEMBLE.
- DO NOT SHORT CIRCUIT.
- DO NOT EXPOSE TO HIGH TEMP. (140°F / 60°C)
Warning
Do not place the camera and its accessories within the reach of small
children.
1. If the product falls or is operated accidentally, it may cause serious
personal injuries.
2. Wrapping the strap around a neck may cause suffocation.
3. To avoid the risk of a small accessory such as the battery or memory
cards from being swallowed by mistake, keep them out of the reach
of small children. Seek medical attention immediately if an accessory
is accidentally swallowed.
About the USB Power Adapter
About the Rechargeable Lithium-ion Battery
Keep the Camera and its Accessories out of the
Reach of Small Children
2
Checking the Contents of the Package
Hot shoe cover FK
(Installed on camera)
Eyecup FR
(Installed on camera)
Body mount cover
(Installed on camera)
Rechargeable lithium-ion
battery D-LI109
Battery charger
D-BC186
USB power adapter
AC-U1 or AC-U2*
*
Differs depending on the region.
Power plug USB cable
I-USB166
Strap
O-ST132
Software (CD-ROM)
S-SW186
Start Guide
Lenses you can use
Lenses that can be used with this camera are DA, DA L, D FA, FA J, and FA lenses and lenses that have an 9 (Auto) position
on the aperture ring. To use any other lens or accessory, see p.113.
3
1
2
3
4
5
6
7
Introducing the KF
Getting Started
Taking Pictures
Playback Functions
Sharing Images
Changing the Settings
Appendix
How to Use This Manual
4
Names and Functions of the Working Parts
.......................................................................p.9
Display Indicators .......................................p.12
How to Change Function Settings ............. p.20
Menu List ......................................................p.24
Attaching the Strap .....................................p.36
Attaching a Lens .........................................p.36
Using the Battery and Charger ..................p.37
Inserting a Memory Card ............................p.40
How to Open the Monitor ............................p.41
Initial Settings ..............................................p.42
Basic Shooting Operation ..........................p.45
Reviewing Images .......................................p.47
Configuring the Capture Settings ..............p.49
Taking Still Pictures ....................................p.50
Recording Movies .......................................p.54
Setting the Exposure ..................................p.56
Using the Built-in Flash ..............................p.59
Setting the Focus Method ..........................p.61
Setting the Drive Mode ...............................p.65
Setting the White Balance .......................... p.72
Controlling the Image Finishing Tone .......p.75
Correcting Images .......................................p.78
How to Use This Manual
1
Introducing the KF ................................p.9
Gives you an overview of the KF.
Read this and get to know your KF!
2
Getting Started........................................p.36
Explains how to get your KF ready for shooting as
well as basic operations.
3
Taking Pictures.......................................p.49
Once you’ve confirmed that the camera works
properly, try out the camera and take lots of pictures!
How to Use This Manual
5
Playback Mode Palette Items .....................p.83
Changing the Playback Method ................. p.84
Editing and Processing Images ................. p.88
Copying an Image to a Computer .............. p.94
Using the Camera with a Communication
Device ...........................................................p.95
Camera Settings ..........................................p.98
File Management Settings ..........................p.106
Restrictions on Each Capture Mode ..........p.110
Functions Available with Various Lenses
.......................................................................p.113
Functions when Using an External Flash
.......................................................................p.117
Using the GPS Unit .....................................p.118
Troubleshooting ..........................................p.121
Main Specifications .....................................p.125
Index .............................................................p.133
Care to be Taken During Handling ............p.138
WARRANTY POLICY ...................................p.143
There is a possibility that the illustrations and the display screen
of the monitor in this manual are different from the actual ones.
4
Playback Functions..............................p.83
Explains various operations for playing back and
editing images.
5
Sharing Images.......................................p.94
Explains how to connect your KF to a computer or
communication device to operate the camera and
use images in the camera.
6
Changing the Settings ........................p.98
Explains how to change other settings.
7
Appendix....................................................p.110
Provides other resources to get the most from your
KF.
6
Contents
Checking the Contents of the Package ..............2
How to Use This Manual .........................4
Introducing the KF ...................................9
Names and Functions of the Working Parts ......9
Operating Controls ....................................................... 10
Display Indicators ...............................................12
Monitor ......................................................................... 12
Viewfinder .................................................................... 18
Electronic Level ........................................................... 19
How to Change Function Settings .................... 20
Using the Direct Keys .................................................. 20
Using the Control Panel ............................................... 20
Using the Menus .......................................................... 22
Menu List .............................................................24
Rec. Mode Menus ........................................................ 24
Movie Menus ............................................................... 29
Playback Menu ............................................................ 30
Set-up Menus .............................................................. 31
Custom Setting Menus ................................................ 34
Getting Started .......................................36
Attaching the Strap ............................................36
Attaching a Lens .................................................36
Using the Battery and Charger .......................... 37
Charging the Battery .................................................... 37
Inserting/Removing the Battery ................................... 38
Using the AC Adapter .................................................. 39
Inserting a Memory Card ...................................40
How to Open the Monitor ...................................41
Initial Settings .....................................................42
Turning the Camera On ............................................... 42
Setting the Display Language ...................................... 42
Setting the Date and Time ........................................... 43
Setting the LCD Display ............................................... 44
Formatting a Memory Card .......................................... 44
Basic Shooting Operation ................................. 45
Shooting with the Viewfinder ........................................ 45
Shooting while Viewing the Live View Image ............... 47
Reviewing Images .............................................. 47
Taking Pictures ......................................49
Configuring the Capture Settings .....................49
Image Capture Settings ............................................... 49
Movie Capture Settings ................................................ 49
Taking Still Pictures ........................................... 50
Scene Modes ............................................................... 50
Exposure Modes .......................................................... 51
Recording Movies ...............................................54
Playing Back Movies .................................................... 56
Setting the Exposure ..........................................56
Sensitivity ..................................................................... 56
EV Compensation ........................................................ 58
AE Metering ................................................................. 58
Using the Built-in Flash ..................................... 59
Contents
Contents
8
Appendix...............................................110
Restrictions on Each Capture Mode ............... 110
Restrictions on the Combinations of Special
Functions ................................................................... 112
Functions Available with Various Lenses ......113
Using the Aperture Ring ............................................ 115
Performing Catch-in Focus Shooting ......................... 116
Setting the Focal Length ............................................ 117
Functions when Using an External Flash ......117
Using the GPS Unit ........................................... 118
Shooting Celestial Bodies (ASTROTRACER) ........... 119
Troubleshooting ............................................... 121
Sensor Cleaning ........................................................ 122
Error Messages ......................................................... 123
Main Specifications .......................................... 125
Operating Environment for USB Connection and
Provided Software ..................................................... 132
Index ..................................................................133
Care to be Taken During Handling ..................138
WARRANTY POLICY ........................................143
Regarding copyrights
Images taken with this camera that are for anything other
than personal enjoyment cannot be used without permission
according to the rights as specified in the Copyright Act.
Please take care, as there are cases where limitations are
placed on taking pictures even for personal enjoyment during
demonstrations, performances or of items on display. Images
taken with the purpose of obtaining copyrights also cannot be
used outside the scope of use of the copyright as laid out in
the Copyright Act, and care should be taken here also.
To users of this camera
Do not use or store this camera in the vicinity of equipment
that generates strong electromagnetic radiation or magnetic
fields. Strong static charges or the magnetic fields produced
by equipment such as radio transmitters could interfere with
the monitor, damage the stored data, or affect the camera’s
internal circuitry and cause camera misoperation.
The liquid crystal panel used for the monitor is
manufactured using extremely high precision technology.
Although the level of functioning pixels is 99.99% or better,
you should be aware that 0.01% or fewer of the pixels may
not light up or may light up when they should not.
However, this has no effect on the recorded image.
In this manual, the generic term “computer(s)” refers to
either a Windows PC or a Macintosh.
In this manual, the term “battery(ies)refers to any type of
batteries used for this camera and its accessories.
Regarding User Registration
In order to better serve you, we request that you complete
the user registration on our website.
Thank you for your cooperation.
https://www.ricoh-imaging.com/registration/
1
9
Introduction
Names and Functions of the Working Parts
Strap lug
Card access lamp
USB terminal (micro B)
Terminal cover
Diopter adjustment lever
HDMI terminal (type D)
Viewfinder
Microphone
Card slot for SD
Memory Card
Tripod socket
Battery cover
Remote control receiver
AF coupler
Mirror
Lens unlock button
Lens information
contacts
Strap lug
Hot shoe
Lens mount index
Speaker
AF assist light
Microphone
Image plane indicator
Vari-angle monitor
Built-in flash
Connection cable cover
Battery cover unlock lever
Microphone/cable release terminal
1
Introduction
10
1EV Compensation button (J)
Press to change the exposure compensation value. (p.58)
In playback mode, press to save the last JPEG image taken
also in RAW format. (p.48)
2Green button (M)
Resets the value being adjusted.
3Shutter release button (0)
Press to capture images. (p.46)
In playback mode, press halfway to switch to capture mode.
4Main switch
Turns the power on or off, or switches to C (movie) mode.
(p.42, p.54)
When the camera is turned on, it enters A (still picture)
mode and the indicator lamp lights green. When the switch
is turned to C, the camera enters C mode and the lamp
lights red.
5Front e-dial (Q)
Changes the values for camera settings such as exposure.
(p.52)
You can change the menu category when a menu screen is
displayed. (p.22)
In playback mode, use this to select a different image.
6Flash pop-up button (1)
Press to pop up the built-in flash. (p.59)
7RAW/Fx1 button (X)
You can assign a function to this button. (p.98)
By default, the function that temporarily changes the file
format (One Push File Format) is assigned.
8Focus mode switch
Changes the focus method. (p.61)
Operating Controls
1
0
8
c
e
b
6
4
3
5
9
f
g
h
2
7
a
d
1
Introduction
11
9Live View/Delete button (K/ )L
Displays the Live View image. (p.47)
In playback mode, press to delete images. (p.48)
0Rear e-dial (R)
Changes the values for camera settings such as exposure.
(p.52)
You can change the menu tabs when a menu screen is
displayed. (p.22)
You can change camera settings when the control panel is
displayed. (p.20)
In playback mode, use this to magnify the image or display
multiple images at the same time. (p.48, p.84)
aFour-way controller (ABCD)
Displays the Sensitivity, White Balance, Flash Mode or
Drive Mode setup menu. (p.20)
When a menu or the control panel is displayed, use this to
move the cursor or change the item to set.
Press B in single image display of the playback mode to
display the playback mode palette. (p.83)
bINFO button (G)
Changes the style of the display on the monitor. (p.12, p.16)
cMode dial
Changes the capture mode. (p.45, p.50)
dWi-Fi/Fx2 button (Y)
You can assign a function to this button. (p.98)
In playback mode, press to turn the Wi-Fi™ function on or
off. (p.96)
eAF/AE Lock button (f)
Available for adjusting focus, instead of pressing 0
halfway, and for locking the exposure value before shooting.
(p.53, p.61)
fPlayback button (3)
Switches to playback mode. (p.47) Press the button again to
switch to capture mode.
gOK button (E)
When a menu or the control panel is displayed, press this
button to confirm the selected item.
Press and hold this button when [AF Active Area] is set to
9 8 or , or to 0 h or to switch the function of the arrow
keys to the AF area change mode or the direct key operation
mode. (p.62, p.64)
hMENU button (F)
Displays a menu. Press this button while the menu is
displayed to return to the previous screen. (p.22)
About the Main Switch Lamp
The main switch lamp turns off in the following situations.
From the time when 0 is pressed halfway until the
end of shooting
During Interval Shooting
During Optical Preview
During playback mode
While a menu is displayed
During Auto Power Off
You can set the lamp illumination setting in [Other Indicator
Lamps] of [Indicator Lamps] in the D2 menu. (p.102)
About the Four-way Controller
In this manual, each button of the four-
way controller is indicated as shown in
the illustration on the right.
1
Introduction
12
With this camera, you can take pictures while looking through
the viewfinder or while viewing the image on the monitor.
When using the viewfinder, you can take pictures while
checking the status screen displayed on the monitor and looking
through the viewfinder. (p.45) When not using the viewfinder,
you can take pictures while viewing the Live View image
displayed on the monitor. (p.47)
The camera is in “standby mode” when it is ready to shoot, such
as when the status screen or Live View image is displayed.
Press G in standby mode to display the “control panel” and
change settings. (p.20) You can change the type of information
displayed in standby mode by pressing G while the control
panel is displayed. (p.15)
t Memo
You can set the display color of the status screen, control
panel, and menu cursor in “Initial Settings” (p.42).
Display Indicators
Monitor
Capture Mode
G
G
9
9
9
99
9
9
99
9
9
99
9
9
99
9
9
999 99 9
9
9
9
99
9
9
99
9
9
99
9
9
99
9
9
999 99 9
AUT
AUT
AUT
AUTO
O
O
OAUTO
5
5
5
5.
.
.
.6
6
6
65.6
10
10
10
10 :
:
:
:2
2
2
23
3
3
310:23
9
9
9
99
9
9
99
9
9
99
9
9
99
9
9
99 9 9 9 9
Status Screen
Status Screen
Status Screen
Status Screen
Status ScreenStatus Screen
Outdoor View Setting
Outdoor View Setting
Outdoor View Setting
Outdoor View Setting
Outdoor View SettingOutdoor View Setting
07
07
07
07 /
/
/
/0
0
0
07
7
7
7/
/
/
/2
2
2
20
0
0
02
2
2
22
2
2
207/07/2022
Standby mode
(Status screen)
Shooting Info Display
selection screen
Control panel
1
Introduction
13
Status Screen
1Capture mode (p.50) 16 EV Compensation
(p.58)/Bracketing (p.68)
2AE Lock
3Focus Method (p.61) 17 EV bar scale
4Custom Image (p.75) 18 Flash Mode (p.59)
5Clarity (p.80)/Skin Tone
(p.80)/Digital Filter
(p.77)/HDR Capture
(p.79)/Pixel Shift
Resolution (p.81)
19 Focusing area (AF point)
(p.62)
20 Drive Mode (p.65)
21 White Balance (p.72)
22 Flash Exposure
Compensation (p.59)
6AA Filter Simulator (p.81)
7GPS positioning status
(p.118)
23 White Balance fine-
tuning (p.73)
8Wi-Fi™ connection
status (p.95)
24 External Input Devices
(p.55)
9AE Metering (p.58) 25 File Format (p.49)
10 Shake Reduction/
Horizon Correction
26 Memory card
27 Number of recordable
still pictures/Movie
recordable time
11 Battery level
12 E-dial guide
13 28Shutter speed Number of shots during
Multi-exposure or
Interval Shooting
14 Aperture value
15 Sensitivity (p.56)
29 Operation guide
1 2 3 11
12
12
12
12 13
15
17
16
14
18 20 21
29
24
18 2019
15
21
22 23
27 282526
4 5 6 7 8 9 10
1
1
1
1/
/
/
/1/
2
2
2
25
5
5
50
0
0
0250
5
5
5
51
1
1
12
2
2
20
0
0
00
0
0
051200
F
F
F
FF
5
5
5
5.
.
.
.6
6
6
65. 6
9
9
9
99
9
9
99
9
9
99
9
9
99
9
9
99 9 9 9 9 2
2
2
20
0
0
00
0
0
00
0
0
02 0 0 0
+
+
+
+1
1
1
1.
.
.
.0
0
0
0+ 1 . 0
G
G
G
G1
1
1
1A
A
A
A1
1
1
1G1 A1
Live View
1Capture mode (p.50) 15 Electronic Level
(horizontal tilt) (p.19)
2Flash Mode (p.59)
3Drive Mode (p.65) 16 Electronic Level (vertical
tilt) (p.19)
4White Balance (p.72)
5Custom Image (p.75) 17 EV Compensation (p.58)
6Clarity (p.80)/Skin Tone
(p.80)/Digital Filter
(p.77)/HDR Capture
(p.79)/Pixel Shift
Resolution (p.81)
18 EV bar scale
19 Operation guide, and
number of shots during
Multi-exposure or
Interval Shooting
7Wi-Fi™ connection
status (p.95)
20 AE Lock
21 Shutter speed
8AE Metering (p.58) 22 Aperture value
9Shake Reduction/
Horizon Correction/
Movie SR
23 Sensitivity (p.56)
24 File Format (p.49)
25 Memory card
10 26Battery level Number of recordable
still pictures/Movie
recordable time
11 External Input Devices
(p.55)
12 GPS positioning status
(p.118)
27 Face detection frame
(when [AF Active Area] is
set to [Face Detection])
(p.63)
13 Temperature warning
14 Histogram
+
+
+
+1
1
1
1.
.
.
.7
7
7
7
EV
EV
EV
EV
+1. 7
EV
1/
1/
1/
1/
2
2
2
20
0
0
00
0
0
00
0
0
0
1/
20 00
F
F
F
F2
2
2
2.
.
.
.8
8
8
8
F2.8
1
1
1
10
0
0
02
2
2
24
4
4
40
0
0
00
0
0
0
10 2400
9999
9999
9999
9999
9999
±
±
±
±0
0
0
0E
E
E
EV
V
V
V
±0EV
1/
1/
1/
1/
2
2
2
20
0
0
00
0
0
00
0
0
0
1/
2000
F
F
F
F2
2
2
2.
.
.
.8
8
8
8
F2.8
1
1
1
16
6
6
60
0
0
00
0
0
0
1600
9999
9999
9999
9999
9999
1 2 3 4 5 6 8 10
11
25
97
19
18
20
16
17
26 2721 22 23 24
12
13
14
15
1
Introduction
14
t Memo
In [Live View] of the
A
5 and
C
2 menus, you can change the
display settings of Live View. (p.26, p.30)
The following functions are displayed with the default setting.
Control Panel
1Function name 11 Skin Tone (p.80)
2Setting 12 Digital Filter (p.77)
3Memory card 13 HDR Capture (p.79)
4Number of recordable
still pictures/Movie
recordable time
14 Pixel Shift Resolution
(p.81)
15 AF Mode (p.62)
5Outdoor View Setting
(p.102)
16 AF Active Area (p.62,
p.64)
6Custom Image (p.75) 17 AF Assist Light (p.62)
7Highlight Correction
(p.78)
18 AE Metering (p.58)
19 AA Filter Simulator (p.81)
8Shadow Correction
(p.78)
20 File Format (p.49)
21 JPEG Recorded Pixels
(p.49)/Movie Recorded
Pixels (p.49)
9High-ISO NR (p.57)
10 Clarity (p.80)
10
10
10
10 :
:
:
:2
2
2
23
3
3
310:23
1
2
3 4
98
11
16
21
10
15
20
12
65 7
17
22
13
18
23 24
14
19
28 3029
9
9
9
99
9
9
99
9
9
99
9
9
99
9
9
99 9 9 9 9
Custom Image
Custom Image
Custom Image
Custom Image
Custom ImageCustom Image
Bright
Bright
Bright
Bright
BrightBright
07
07
07
07 /
/
/
/0
0
0
07
7
7
7/2
/2
/2
/2 0
0
0
02
2
2
22
2
2
207/07/2022
10
10
10
10 :
:
:
:2
2
2
23
3
3
310:23
1
2
12865 7
28 3029
9
9
9
9:
:
:
:5
5
5
59
9
9
9
5
5
5
59
9
9
9
9 : 5 9 ’ 5 9 ”
3 4
16
26
15
21
17
27
18
23
25
Highlight Correction
Highlight Correction
Highlight Correction
Highlight Correction
Highlight CorrectionHighlight Correction
Auto
Auto
Auto
Auto
AutoAuto
07
07
07
07 /
/
/
/0
0
0
07
7
7
7/2
/2
/2
/2 0
0
0
02
2
2
22
2
2
207/07/2022
C mode
A mode
1
Introduction
15
t Memo
Refer to “Using the Control Panel” (p.20) for how to use the
control panel.
The functions displayed on the control panel can be
customized. (p.21)
You can change the type of
information displayed in standby
mode by pressing G while the
control panel is displayed. Use CD
to select the type and press E.
When shooting with the viewfinder
22 27JPEG Quality (p.49) Recording Sound Level
(p.55)
23 Shake Reduction/Movie
SR 28 Current date and time
24 29Horizon Correction Destination (p.105)
25 External Input Devices
(p.55)
30 Operation guide for the
control panel
customization (p.21)
26 Framerate (p.49)
Shooting Info Display
Status
Screen
Displays the settings for shooting with the
viewfinder. (p.13)
Electronic
Level
Displays the camera
angle.
A bar scale indicating
the horizontal camera
angle appears at the
center of the screen,
and a bar scale
indicating the vertical
camera angle
appears on the right
side. When the angle exceeds the range that
can be displayed in each scale, the indicator
segments of the scale are displayed in red.
Display Off Nothing is displayed on the monitor.
Electronic
Compass
Displays the current
latitude, longitude,
altitude, direction,
Coordinated Universal
Time (UTC), capture
mode, and exposure
value. Turn the
camera off and on
again to return to the status screen.
Available only when the optional GPS unit is
attached to the camera and is operating. (p.118)
99999
1/
250
F
5.6
Status Screen
1/
1/
1/
1/
25
25
25
250
0
0
0
1/
250 F5
F5
F5
F5.
.
.
.6
6
6
6F5.6 16
16
16
160
0
0
00
0
0
01600 0.
0.
0.
0.0
0
0
00. 0
Example:
Tilted 1.5° to the left (yellow)
Vertically level (green)
1/
1/
1/
1/
25
25
25
250
0
0
0
1/
250 F5
F5
F5
F5.
.
.
.6
6
6
6F5.6 16
16
16
160
0
0
00
0
0
01600 0.
0.
0.
0.0
0
0
00. 0
10
10
10
10:
:
:
:0
0
0
00
0
0
0:
:
:
:0
0
0
00
0
0
010:00:00
0°
N
N
N
N
36
36
36
36°
°
°
°4
4
4
45
5
5
5.
.
.
.4
4
4
41
1
1
10'
0'
0'
0'N
36°45.410'
W1
W1
W1
W14
4
4
40
0
0
0°
°
°
°0
0
0
02
2
2
2.
.
.
.00
00
00
000
0
0
0'
'
'
'W140°02.000'
89
89
89
89m
m
m
m89m
07
07
07
07/
/
/
/0
0
0
07
7
7
7/
/
/
/2
2
2
20
0
0
022
22
22
2207/07/2022
1
Introduction
16
When shooting with Live View
t Memo
The status screen is displayed when the camera is turned off
and on again. If [Shooting Info Display] is set to Z (On) in
[Memory] of the A5 menu, the screen selected on the
Shooting Info Display selection screen appears when the
camera is turned off and on again. (p.105)
The captured image and shooting information are displayed in
single image display of the playback mode.
Press G to change the type of information displayed in
single image display. Use CD to select the type and press E.
t Memo
You can set overexposed areas to blink red in Standard
Information Display, Histogram Display, and No Information
Display. Set in [Highlight Alert] of [LCD Display] in the B1
menu.
The screen selected in the Playback Info Display selection
screen is displayed in playback mode when the camera is
turned off and on again. If [Playback Info Display] is set to Y
(Off) in [Memory] of the A5 menu, the Standard Information
Display always appears first when the camera is turned on.
(p.105)
Standard
Information
Display
The Live View image and the settings for
shooting with Live View are displayed. (p.13)
Electronic
Level
The same electronic level as when shooting
with the viewfinder is displayed.
No Information
Display
Certain icons, such as those for the capture
mode and drive mode, are not displayed.
Playback Mode
Single image display
(Standard Information Display)
Playback Info Display selection
screen
1/
1/
1/
1/
20
20
20
200
0
0
00
0
0
0
1/
2000 F2
F2
F2
F2.
.
.
.8
8
8
8F2.8 20
20
20
200
0
0
0200 +0
+0
+0
+0.
.
.
.3
3
3
3+0.3
10
10
10
100
0
0
0-
-
-
-0
0
0
000
00
00
001
1
1
1100-0001
1/
1/
1/
1/
20
20
20
200
0
0
00
0
0
0
1/
2000 F2
F2
F2
F2.
.
.
.8
8
8
8F2.8 20
20
20
200
0
0
0200 +0
+0
+0
+0.
.
.
.3
3
3
3+0.3
10
10
10
100
0
0
0-
-
-
-0
0
0
000
00
00
001
1
1
1100-0001
G
Standard Information Display
Standard Information Display
Standard Information Display
Standard Information DisplayStandard Information Display
Standard
Information
Display
Captured image, file format, exposure
parameters, and operation guide indicators
are displayed.
Detailed
Information
Display
Detailed information on how and when the
image was taken is displayed. (p.17)
Histogram
Display
Captured image and brightness histogram
are displayed. (p.18)
Not available during movie playback.
RGB
Histogram
Display
Captured image and RGB histogram are
displayed. (p.18)
Not available during movie playback.
No Information
Display Only the captured image is displayed.
1
Introduction
17
Detailed Information Display
1 6Captured image Folder number-File
number (p.107)
2 Rotation information
(p.86) 7 Drive Mode (p.65)
3 8Capture mode (p.50) Flash Mode (p.59)
4 Wi-Fi™ connection
status (p.95)
9 Flash Exposure
Compensation (p.59)
5 Protect setting (p.106) 10 Focus Method (p.61)
1
3
3
4
9
14
18
24 25 26
33
41
40
40
40
41
34 35
32 33 44
36 37
27 28 29 30 31
32
19 20 21 22
23
15 16
17
1817
10
812
13
1413
38
39
38
39
11
65
4 5
4 5
6
6
46
47
45
4549
50
51 52
48
43
11
3
7
42
15 16
19
28 29 31
37
7
2
2
1
1
+
+
+
+1.
1.
1.
1.0
0
0
0+1.0
1/
1/
1/
1/2
2
2
200
00
00
000
0
0
0
1/2000 F
F
F
F2
2
2
2.8
.8
.8
.8F2.8
5
5
5
55.
5.
5.
5.0
0
0
0m
m
m
mm
m
m
m55.0mm
1
1
1
102
02
02
024
4
4
40
0
0
00
0
0
0102400
5
5
5
500
00
00
000
0
0
0K
K
K
K5000K
1
1
1
100
00
00
00-
-
-
-0
0
0
000
00
00
001
1
1
1100-0001
+
+
+
+1.
1.
1.
1.5
5
5
5+1.5
±
±
±
±
0
0
0
0
±
0
±
±
±
±
0
0
0
0
±
0
±
±
±
±
0
0
0
0
±
0
±
±
±
±
0
0
0
0
±
0
±
±
±
±
0
0
0
0
±
0
1
1
1
10:
0:
0:
0:3
3
3
30
0
0
010:30
1
1
1
10'
0'
0'
0'1
1
1
10
0
0
0"
"
"
"10'10"
G
G
G
G1A
1A
1A
1A1
1
1
1G1A1
1
1
1
100
00
00
00-
-
-
-0
0
0
000
00
00
001
1
1
1100-0001
0
0
0
0m
m
m
m0m
1
1
1
123
23
23
23°
°
°
°123°
N
N
N
N
3
3
3
3
4
4
4
45
5
5
5.4
.4
.4
.41
1
1
10
0
0
0'
'
'
'N
36°45.410'
1
1
1
10:
0:
0:
0:0
0
0
00
0
0
0:0
:0
:0
:00
0
0
010:00:00
W
W
W
W14
14
14
140
0
0
0°
°
°
°02
02
02
02.
.
.
.0
0
0
00
0
0
00'
0'
0'
0'W140°02.000'
1/
1/
1/
1/1
1
1
125
25
25
25
1/125 F8
F8
F8
F8.
.
.
.0
0
0
0F8.0
5
5
5
55.
5.
5.
5.0
0
0
0m
m
m
mm
m
m
m55.0mm
1
1
1
160
60
60
600
0
0
01600
5
5
5
500
00
00
000
0
0
0K
K
K
K5000K
1
1
1
100
00
00
00-
-
-
-0
0
0
000
00
00
001
1
1
1100-0001
+
+
+
+1.
1.
1.
1.5
5
5
5+1.5
±
±
±
±
0
0
0
0
±
0
±
±
±
±
0
0
0
0
±
0
±
±
±
±
0
0
0
0
±
0
±
±
±
±
0
0
0
0
±
0
±
±
±
±
0
0
0
0
±
0
1
1
1
10:
0:
0:
0:3
3
3
30
0
0
010:30
G
G
G
G1A
1A
1A
1A1
1
1
1G1A1
0
0
0
07/
7/
7/
7/0
0
0
07
7
7
7/2
/2
/2
/20
0
0
02
2
2
22
2
2
207/07/2022
0
0
0
07/
7/
7/
7/0
0
0
07
7
7
7/2
/2
/2
/20
0
0
02
2
2
22
2
2
207/07/2022
0
0
0
07/
7/
7/
7/0
0
0
07
7
7
7/2
/2
/2
/20
0
0
02
2
2
22
2
2
207/07/2022
Still pictures
Movies
Page 2 B A
11 31AE Metering (p.58) Shake Reduction/
Horizon Correction/
Movie SR
12 Focusing area (AF point)
(p.62)
13 32Shutter speed File Format (p.49)
14 33Aperture value JPEG Recorded Pixels
(p.49)/Movie Recorded
Pixels (p.49)
15 Sensitivity (p.56)
16 EV Compensation (p.58)
17 34White Balance (p.72) JPEG Quality (p.49)
18 White Balance fine-
tuning (p.73)
35 Color Space (p.49)
36 Color Moiré Correction
(p.89)19 Digital Filter (p.77)
20 HDR Capture (p.79)/
Pixel Shift Resolution
(p.81)
37 Lens focal length
38 Custom Image setting
(p.75)
21 39Clarity (p.80) Custom Image
parameters
22 Skin Tone (p.80)
23 Distortion Correction
(p.80)
40 Operation guide
41 Shooting date and time
24 Peripheral Illumination
Correction (p.80)
42 Length of time of the
recorded movie
25 Lateral Chromatic
Aberration Adjustment
(p.80)
43 Recording Sound Level
(p.55)
44 Framerate (p.49)
26 Diffraction Correction
(p.80)
45 Tampered image
warning
27 Color Fringe Correction
(p.93)
46 Photographer (p.109)
47 Copyright Holder (p.109)
28 Highlight Correction
(p.78)
48 Altitude
49 Lens direction
29 Shadow Correction
(p.78)
50 Latitude
51 Longitude
30 AA Filter Simulator (p.81) 52 Universal Coordinated
Time
1
Introduction
18
Use AB to switch between the brightness histogram and RGB
histogram. When shooting with the viewfinder, information appears in the
viewfinder.
Histogram Display
1 Histogram (Brightness)
2 RGB histogram/
Brightness histogram
3 Protect setting
4 Folder number-File
number
5 Save RAW Data
6 File Format
7 Shutter speed
8 Aperture value
9 Sensitivity
10 EV Compensation
11 Histogram (R)
12 Histogram (G)
13 Histogram (B)
10
10
10
100
0
0
0-
-
-
-00
00
00
000
0
0
01
1
1
1
100-0001
1/
1/
1/
1/
20
20
20
200
0
0
00
0
0
0
1/
2000
F2
F2
F2
F2.
.
.
.8
8
8
8
F2.8
20
20
20
200
0
0
0
200
+0
+0
+0
+0.
.
.
.3
3
3
3
+0.3
10
10
10
100
0
0
0-
-
-
-00
00
00
000
0
0
01
1
1
1
100-0001
1/
1/
1/
1/
20
20
20
200
0
0
00
0
0
0
1/
2000
F2
F2
F2
F2.
.
.
.8
8
8
8
F2.8
20
20
20
200
0
0
0
200
+0
+0
+0
+0.
.
.
.3
3
3
3
+0.3
1 3 4
5
2
11
12
13
6 7 8 9 10
3 4251
6 7 8 109
Brightness histogram
RGB histogram
B A
Viewfinder
1 AF frame (p.46) 10 ISO/ISO AUTO
2 Spot metering frame
(p.58)
11 Sensitivity (p.56)/
Exposure compensation
value
3 AF point (p.62)
4 Flash indicator (p.59) 12 AE Lock
5 Focus Method (p.61) 13 Change AF Area (p.62)
6 Shutter speed/Exposure
time for timed exposure
in M mode/Number of
shots for Bracketing
14 Multi-exposure (p.70)
15 AE Metering (p.58)
16 Shake Reduction
17 Flash Exposure
Compensation (p.59)
7 Aperture value/Bracket
value for Bracketing 18 EV Compensation
(p.58)/Bracketing (p.68)8 Focus indicator (p.46)
9 EV bar scale/Electronic
Level (p.19)
19 File Format (p.49)
1
4
19181716151413
6 10 11 12
2
1
3
5 7 8 9
1
Introduction
19
t Memo
The information is displayed in the viewfinder when 0
is pressed halfway, or during the meter operating time
(default setting: 10 sec.).
The AF point in use for autofocus appears in red
(Superimpose AF Area) when 0 is pressed halfway.
You can turn this function off in [Superimpose AF Area] of
[Viewfinder Overlay] in the A5 menu. (p.26)
You can adjust the viewfinder
image sharpness using the diopter
adjustment lever. If it is difficult to
move the diopter adjustment lever,
lift up and remove the eyecup.
Adjust the diopter setting until the
AF frame in the viewfinder looks
sharp and clear.
You can check whether the camera is tilted by displaying
electronic levels. The electronic level for the horizontal camera
angle can be displayed in the viewfinder, and the electronic
levels for the vertical and horizontal camera angles can be
displayed on the Live View screen. (p.13)
Select whether to display the electronic levels in [Viewfinder
Overlay] and [Live View] of the A5 menu. (p.26)
Examples of Electronic Level in the Viewfinder
t Memo
When [Electronic Level] is assigned to X or Y in [Button
Customization] of the A5 menu, you can turn the electronic
level display on or off by a simple button operation. (p.98)
Electronic Level
When level (at 0°)
When tilted 5° to the left
When held vertically and tilted 3° to the right
1
Introduction
20
Press ABCD in standby mode.
Press G in standby mode.
t Memo
The functions that can be selected vary depending on the
current camera setup.
If no operations are made within approximately 1 minute
while the control panel is displayed, the camera returns to
standby mode.
How to Change Function Settings
Using the Direct Keys
A Sensitivity p.56
B White Balance p.72
C Flash Mode p.59
D Drive Mode p.65
Using the Control Panel
9
9
9
99
9
9
99
9
9
99
9
9
99
9
9
999999
9
9
9
99
9
9
99
9
9
99
9
9
99
9
9
999999
1
1
1
10:
0:
0:
0:2
2
2
23
3
3
310:23
File Format
File Format
File Format
File FormatFile Format
Cancel
Cancel
Cancel
CancelCancel OK
OK
OK
OKOK
0
0
0
07/
7/
7/
7/0
0
0
07/
7/
7/
7/2
2
2
202
02
02
022
2
2
207/07/2022
File Format
File Format
File Format
File Format
File FormatFile Format
Use ABCD to select an item.
Use R to change
settings.
Press F to cancel
the setting operation.
Press E to confirm the
selected item and return to
the control panel.
Press E to make
detailed settings.
1
Introduction
21
The functions displayed on the control panel can be
customized.
Some functions in the A, C, and D menus can be saved on
the control panel. Refer to “Menu List” (p.24) for details on the
functions that can be saved.
1Press G in standby mode.
The control panel appears.
2Press J.
The customization screen appears.
3Use ABCD to select the
function to change.
Press M to reset to the default
settings.
4Press E.
Selectable functions are displayed in the pop-up menu.
5Use AB to select the
function to save.
Select [--] if you do not want to
save any function.
6Press E.
The screen of Step 3 reappears.
7Press J.
The control panel reappears.
8Press F.
The camera returns to standby mode.
Customizing the Control Panel
Select the location of the
Select the location of the
Select the location of the
Select the location of the
Select the location of the
Select the location of the
item you want to change
item you want to change
item you want to change
item you want to change
item you want to change
item you want to change
Reset
Reset
Reset
Reset
Reset
OK
OK
OK
OK
OK
Outdoor View Setting
Outdoor View Setting
Outdoor View Setting
Outdoor View Setting
Outdoor View Setting
Outdoor View Setting
Custom Image
Custom Image
Custom Image
Custom Image
Custom Image
Custom Image
Cancel
Cancel
Cancel
Cancel
Cancel
OK
OK
OK
OK
OK
1
22
Introduction
Most functions are set from the menus.
Using the Menus
1
3
3
1
AF with Viewfinder
AF with Viewfinder
AF with Viewfinder
AF with ViewfinderAF with Viewfinder
AF Assist Light
AF Assist Light
AF Assist Light
AF Assist LightAF Assist Light
AE Metering
AE Metering
AE Metering
AE MeteringAE Metering
Custom Image
Custom Image
Custom Image
Custom ImageCustom Image
AF with Live View
AF with Live View
AF with Live View
AF with Live ViewAF with Live View
Exit
Exit
Exit
ExitExit
Skin T
Skin T
Skin T
Skin Tone
one
one
oneSkin Tone
Clarity
Clarity
Clarity
ClarityClarity
HDR Capture
HDR Capture
HDR Capture
HDR CaptureHDR Capture
Digital Filter
Digital Filter
Digital Filter
Digital FilterDigital Filter
Pixel Shift Resolution
Pixel Shift Resolution
Pixel Shift Resolution
Pixel Shift ResolutionPixel Shift Resolution
ASTROTRACER
ASTROTRACER
ASTROTRACER
ASTROTRACERASTROTRACER
Skin T
Skin T
Skin T
Skin Tone
one
one
oneSkin Tone
Clarity
Clarity
Clarity
ClarityClarity
HDR Capture
HDR Capture
HDR Capture
HDR CaptureHDR Capture
Digital Filter
Digital Filter
Digital Filter
Digital FilterDigital Filter
Pixel Shift Resolution
Pixel Shift Resolution
Pixel Shift Resolution
Pixel Shift ResolutionPixel Shift Resolution
ASTROTRACER
ASTROTRACER
ASTROTRACER
ASTROTRACERASTROTRACER
Exit
Exit
Exit
ExitExit
Cancel
Cancel
Cancel
CancelCancel OK
OK
OK
OKOK
Exit
Exit
Exit
ExitExit
AF Active Area
AF Active Area
AF Active Area
AF Active AreaAF Active Area
Focus Peaking
Focus Peaking
Focus Peaking
Focus PeakingFocus Peaking
AF with Live View
AF with Live View
AF with Live View
AF with Live ViewAF with Live View
AF
AF
AF
AF.S Setting
.S Setting
.S Setting
.S SettingAF.S Setting
AF with Viewfinder
AF with Viewfinder
AF with Viewfinder
AF with ViewfinderAF with Viewfinder
AF Assist Light
AF Assist Light
AF Assist Light
AF Assist LightAF Assist Light
AE Metering
AE Metering
AE Metering
AE MeteringAE Metering
Custom Image
Custom Image
Custom Image
Custom ImageCustom Image
AF with Live View
AF with Live View
AF with Live View
AF with Live ViewAF with Live View
Use AB to select an item.
Use R to switch
between menu tabs.
Press F to exit the
menu screen.
Menu tabs
Press D to display the
pop-up menu.
Press D to display
the submenu.
Press E to confirm the
selected item.
Press F to cancel the
pop-up menu.
Press F to return to the previous screen.
Use AB to select an item.
Use Q to change the menu category.
1
23
Introduction
t Memo
For the Custom Setting menus (E menus), you can show the setting screen of the next item in order of the menus on the monitor
by turning R while the submenu of the currently selected item is displayed.
Press F to display the first tab of the most appropriate menus for the camera settings at that time. To display the menu tab last
selected first, set in [21 Save Menu Location] of the E3 menu.
The settings changed with the A menus, menus, C B menu, D menus, direct keys, control panel, and playback mode palette
are returned to their default values with [Reset] of the D5 menu. To reset the settings in the Custom Setting menus to the defaults,
use [Reset Custom Functions] of the E4 menu. (Some settings do not apply.)
1
24
Introduction
Menu List
Rec. Mode Menus
Menu Item Function Default Setting Page
A1
Custom Image *1 *2 Sets the image finishing tone such as color and contrast
before shooting an image. Bright p.75
Scene Mode *1 *3 Selects the scene mode that best suits the situation. (S
mode) Portrait p.50
AF with
Viewfinder
AF Mode *1 Selects the AF mode for shooting with the viewfinder. z p.62
AF Active Area *1 Selects the area to adjust the focus for shooting with the
viewfinder.
Auto
(11 AF Points) p.62
AF.S Setting Sets the action priority for when the autofocus mode is set to
x and 0 is fully pressed. Focus-priority p.61
1st Frame Action in
AF.C
Sets the action priority for the first frame when the autofocus
mode is set to y and 0 is fully pressed. Auto p.61
Action in AF.C Cont. Sets the action priority during Continuous Shooting when the
autofocus mode is set to y. Auto p.61
Hold AF Status
Maintains the focus for a certain amount of time when the
subject happens to move out of the selected focusing area
after being focused.
Low p.61
AF with
Live View
AF Active Area *1 Selects the area to adjust the focus for shooting with Live
View. Face Detection
p.63
Focus Peaking *1 Emphasizes the outline of the subject in focus and makes it
easier to check the focus. Off
AF.S Setting Sets the action priority for when 0 is fully pressed. Focus-priority
AF Assist Light *1 Discharges the assist light when autofocusing in dark
locations. On p.62
1
25
Introduction
A1
AE Metering *1 Selects the part of the sensor to use for measuring brightness
and determining the exposure. Multi-segment p.58
Exposure Mode *4 Temporarily changes the exposure mode when the mode dial
is set to one of the modes from O to Q. – p.104
A2
Capture
Settings
File Format *1 Sets the file format of images. JPEG
p.49
JPEG Recorded
Pixels *1 Sets the recording size of JPEG images. q
JPEG Quality *1 Sets the quality of JPEG images. m
RAW File Format Sets the RAW file format. PEF
Color Space Sets the color space to use. sRGB
D-Range
Settings
Highlight
Correction *1
Expands the dynamic range and prevents overexposed
areas from occurring. Auto
p.78
Shadow
Correction *1
Expands the dynamic range and prevents underexposed
areas from occurring. Auto
Noise
Reduction
Slow Shutter Speed
NR *1
Sets the Noise Reduction setting when shooting with a slow
shutter speed. Auto p.52
High-ISO NR *1 Sets the Noise Reduction setting when shooting with a high
ISO sensitivity. Auto p.57
A3
Clarity *1 Changes the clarity of images using an image processing
program. ±0 p.80
Skin Tone *1 Enhances the skin tone of the subject in the image using an
image processing program. Off p.80
Digital Filter *1 Applies a digital filter effect when taking pictures. No Filter p.77
HDR Capture *1 Sets the type of high dynamic range shooting. Off, ±2EV, On p.79
Pixel Shift Resolution *1 Merges four images shifted pixel by pixel and outputs a high-
definition image. Off p.81
ASTROTRACER *1 Makes settings to track and capture celestial bodies. Off p.119
Menu Item Function Default Setting Page
1
26
Introduction
A4
AA Filter Simulator *1 Applies a low-pass filter effect using the Shake Reduction
mechanism. Off p.81
Shake Reduction *1 Activates the Shake Reduction function. On
Horizon Correction *1 Corrects horizontal tilt when in A mode. Off
Lens
Correction
Distortion
Correction *1 Reduces distortions occurring due to lens properties. Off
p.80
Peripheral Illumin.
Corr. *1
Reduces peripheral light fall-off occurring due to lens
properties. Off
Lat-Chromatic-Ab
Adj *1
Reduces lateral chromatic aberrations occurring due to lens
properties. On
Diffraction
Correction *1
Corrects blur caused by diffraction when using a small
aperture. On
Input Focal Length *1 Sets the focal length when using a lens of which focal length
information cannot be obtained. 35mm p.117
A5
Viewfinder
Overlay
Electronic Level *1 Displays the electronic level at the bottom of the viewfinder. Off p.19
Superimpose AF
Area Displays the active AF point in red in the viewfinder. On p.19
Live View
Grid Display *1 Sets the type and color of the grid lines displayed during Live
View. Off, Black
p.13
Electronic Level *1 Displays the electronic level during Live View. On
Histogram Display Displays the histogram during Live View. Off
Highlight Alert Sets overexposed areas to blink red during Live View. Off
Flicker Reduction Cuts down on the Live View screen flicker by setting the
power frequency. 50Hz
Menu Item Function Default Setting Page
1
27
Introduction
A5
Instant
Review
Display Time Sets the Instant Review display time. 1sec.
p.46
Zoom Review Displays the magnified image during Instant Review. On
Save RAW Data Saves the RAW data during Instant Review. On
Delete Deletes the displayed image during Instant Review. On
Histogram Display Displays the histogram during Instant Review. Off
Highlight Alert Sets overexposed areas to blink red during Instant Review. Off
Other
Display
Settings
Guide Display Displays operation guides when the capture mode is
changed. On p.45
Display Color Sets the display color of the status screen, control panel, and
menu cursor. 1p.44
Button
Customi-
zation
Fx1 Button Sets the function for when X is pressed. One Push
File Format p.98
Fx2 Button Sets the function for when Y is pressed. Wi-Fi
AF/AE-L Button Sets the function for when f is pressed. Enable AF1
E-Dial
Program-
ming
G
Sets the Q R M / / operation for each exposure mode.
I J G, , X
p.101
H–, ISO, –
II, –, –
J–, J, –
KI
,
J
,
G
LINE
LI
,
J
,
G
LINE
Rotation
Direction Reverses the effect obtained when Q R or is turned. Rotate Right
Menu Item Function Default Setting Page
1
28
Introduction
*1 Available as a function in the control panel.
*2 The function appears in modes other than S mode.
*3 The function appears in S mode.
*4 The function appears only in O to Q modes.
A5
Memory
Sensitivity
Determines which settings to save when the power is turned
off.
On
p.105
EV Compensation On
Flash Mode On
Flash Exposure Comp.
On
Drive Mode On
White Balance On
Custom Image On
Clarity Off
Skin Tone Off
Digital Filter Off
HDR Capture Off
Pixel Shift Resolution
Off
Shooting Info Display
Off
Playback Info Display
On
Outdoor View Setting
Off
Night Vision LCD
Display Off
Save
USER
Mode
Save Settings You can save frequently used capture settings to O to Q
of the mode dial.
CLEAR TONE,
HDR LANDSCAPE,
ASTROPHOTO
p.103
Rename USER Mode Changes the names of the saved USER modes to display on
the monitor.
CLEAR TONE,
HDR LANDSCAPE,
ASTROPHOTO
Check Saved Settings
Displays the settings saved in USER modes.
Reset USER Mode Resets all the settings saved in USER modes to the defaults.
Menu Item Function Default Setting Page
1
29
Introduction
Movie Menus
Menu Item Function Default Setting Page
C1
Custom Image *1 Sets the image finishing tone such as color and contrast
before shooting an image. Bright p.75
AF with
Live View
AF Mode Selects the AF mode for movie recording. x
p.63
AF Active Area *1 Selects the area to adjust the focus for movie recording. Multiple AF
Points
Focus Peaking *1 Emphasizes the outline of the subject in focus and makes it
easier to check the focus. Off
AF Assist Light *1 Discharges the assist light when autofocusing in dark
locations. On p.62
AE Metering *1 Selects the part of the sensor to use for measuring brightness
and determining the exposure. Multi-segment p.58
Movie
Capture
Settings
Recorded Pixels *1 Sets the number of recorded pixels of the movie. u
p.49
Framerate *1 Sets the framerate of the movie. 30p
Recording Sound Level *1 Sets the sound level for recording. Auto p.55
C2
D-Range
Settings
Highlight
Correction *1
Expands the dynamic range and prevents overexposed
areas from occurring. Auto
p.78
Shadow
Correction *1
Expands the dynamic range and prevents underexposed
areas from occurring. Auto
Digital Filter *1 Applies a digital filter effect when recording a movie. No Filter p.77
Movie SR *1 Activates the Shake Reduction function. On
1
30
Introduction
*1 Available as a function in the control panel.
C2
Live View
Grid Display *1 Sets the type and color of the grid lines displayed during Live
View. Off, Black
p.13
Electronic Level *1 Displays the electronic level during Live View. On
Histogram Display Displays the histogram during Live View. Off
Highlight Alert Sets overexposed areas to blink red during Live View. Off
Flicker Reduction Cuts down on the Live View screen flicker by setting the
power frequency. 50Hz
Button
Customi-
zation
AF/AE-L Button Sets the function for when f is pressed. Enable AF1 p.98
E-Dial
Program-
ming
m
Sets the Q R M / / operation for each exposure mode.
–, –, –
p.101
n–, J G, LINE
pI
,
J
,
G
LINE
oI
,
J
,
G
LINE
Rotation
Direction Reverses the effect obtained when Q or R is turned. Rotate Right
Playback Menu
Menu Item Function Default Setting Page
B1
Slideshow
Display Duration Sets an image display interval. 3sec.
p.86
Screen Effect Sets a transition effect when the next image is displayed. Off
Repeat Playback Starts a slideshow again from the beginning after the last
image is displayed. Off
Auto Movie Playback Plays back movies during a slideshow. On
Protect All Images Protects all stored images at once. p.106
Delete All Images Deletes all stored images at once.
Quick Zoom Sets the initial magnification when magnifying images. Off p.48
Menu Item Function Default Setting Page
1
31
Introduction
B1
Playback Sound Volume Sets the sound volume during movie playback. 10 p.56
LCD
Display
Auto Image Rotation
Rotates images which were captured with the camera held
vertically or of which the rotation information has been changed.
On p.86
Grid Display Sets the type and color of grid lines. Off, Black p.48
Highlight Alert
Sets overexposed areas to blink red in Standard Information
Display, Histogram Display, and No Information Display of
the playback mode.
Off p.16
Set-up Menus
Menu Item Function Default Setting Page
D1
Language/WChanges the display language. English p.42
Date Adjustment Sets the date and time and the display format. 01/01/2022 p.43
World Time Switches between the date and time display of your
hometown city and that of a specified city. Hometown p.105
Text Size Magnifies the text size when selecting a menu item. Std. p.43
Sound
Effects
Volume Sets the sound volume of beep sounds. 3
In-focus
Sets whether to make a beep sound when the subject is focused.
On p.46
AE-L Sets whether to make a beep sound when the exposure
value is locked with f.On p.53
Self-timer Sets whether to make a beep sound during the countdown for
Self-timer shooting. On p.67
Remote Control Sets whether to make a beep sound during the countdown for
Remote Control shooting. On p.67
Mirror Up Sets whether to make a beep sound during Mirror Lock-up
Shooting. On p.69
Change AF Area
Sets whether to make a beep sound when the function of the
arrow keys (
ABCD
) is switched to the AF area change mode.
On p.63
Menu Item Function Default Setting Page
1
32
Introduction
D1Sound
Effects
One Push File
Format
Sets whether to make a beep sound when the One Push File
Format function is turned on with X or Y.On p.99
Wi-Fi Sets whether to make a beep sound when the Wi-Fi™
function is turned on or off with X or Y.On p.96
Night Vision LCD
Display
Sets whether to make a beep sound when the Night Vision
LCD Display is turned on or off with X or Y.On p.120
Electronic Level Sets whether to make a beep sound when the Electronic
Level display is turned on or off with X or Y.On p.19
D2
LCD Display Settings Sets the brightness, saturation, and color adjustment of the
monitor. 0p.102
Outdoor View Setting Adjusts the brightness of the monitor for outdoor shooting. Off p.102
Night Vision LCD Display *1 Changes the monitor display color to red for shooting in a
dark place such as night-time shooting. Off p.120
Indicator
Lamps
Other Indicator
Lamps
Sets the brightness of the main switch lamp when the camera
is turned on. High
p.102
Self-timer Sets whether to make the self-timer lamp blinking during the
countdown for the drive mode [Self-timer (12 sec.)]. On
Remote Control
Sets whether to make the remote control receiver lamp
blinking during the standby time for the drive mode [Remote
Control].
On
GPS LED Indicators Sets whether to light up the GPS unit lamps when the GPS
unit is attached. On
D3
Wi-Fi *1 Activates the Wi-Fi™ function. Off p.96
GPS/E-
Compass
GPS Time Sync Automatically adjusts the date and time settings. On
p.118
Calibration Performs a calibration of direction information.
USB Connection Sets the USB connection mode when connecting to a
computer with a commercially available USB cable. MSC p.94
Menu Item Function Default Setting Page
1
33
Introduction
*1 Available as a function in the control panel.
D3
HDMI Out Sets the output format when connecting to an AV device with
an HDMI input terminal. Auto p.87
External Input Devices *1 Sets the external input device connected to the microphone/
cable release terminal. Auto Select p.55
Auto Power Off Sets the time until the camera turns off automatically if no
operations are made for a certain period of time. 1min. p.42
D4
Create New Folder Creates a new folder on the memory card. p.107
Folder Name Sets the folder name in which images are stored. Date p.107
File Name Sets the file name assigned to an image. IMGP, _IMG p.108
File No.
Sequential
Numbering
Continues the sequential numbering for the file name when a
new folder is created. On
p.109
Reset File Number Resets the file number setting and returns to 0001 each time
a new folder is created.
Copyright Information Sets the photographer and copyright information embedded
in the Exif data. Off p.109
Format Formats a memory card. p.44
D5
Pixel Mapping Maps out and corrects defective pixels on the sensor. p.122
Dust Removal Cleans the sensor by applying high-frequency (ultrasonic)
vibrations. Off, Off p.121
Sensor Cleaning Locks the mirror in the up position for cleaning the sensor
with a blower. – p.122
Certification Marks Displays the certification marks of conformance to wireless
technical standards. – p.139
Firmware Info/Options Displays the camera’s firmware version. You can check the
current firmware version before running an update. – –
Reset
Resets the settings of the direct keys and for the items of the
A C B D menus, menus, menu, menus, control panel,
and playback mode palette.
– –
Menu Item Function Default Setting Page
1
34
Introduction
Custom Setting Menus
Menu Item Function Default Setting Page
E1
1 EV Steps Sets the adjustment steps for the exposure. 1/3 EV Steps p.52
2 Sensitivity Steps Sets the adjustment steps for the ISO sensitivity. 1 EV Step p.56
3 Meter Operating Time Sets the meter operating time. 10sec.
4 Auto EV Compensation Automatically compensates the exposure when the correct
exposure cannot be achieved with the current settings. Off –
5 Link AE and AF Point Sets whether to link the exposure value and the AF point in
the focusing area. Off p.58
6 AE-L with AF Locked Sets whether to lock the exposure value when the focus is
locked. Off –
7 Bulb (B) Mode Options Sets the camera operation when 0 is pressed in M
mode. Type1 p.53
E2
8 Release While Charging Sets whether to release the shutter while the built-in flash is
being charged. Off p.60
9 AF with Remote Control Sets whether to use autofocus when shooting with a remote
control unit. Off p.68
10 Bracketing Order Sets the order for Bracketing shooting. 0 - + p.69
11 One-Push Bracketing
Shoots all frames with one press of the release in Bracketing.
Off p.69
12 Interval Shooting Options
Sets whether to start counting the time of interval from when
exposure starts or when exposure ends for Interval
Shooting, Interval Composite, and Interval Movie Record.
Interval p.72
13 AF in Interval Shooting
Sets whether to lock the focus position used when the first
picture is taken or perform autofocus for each exposure for
Interval Shooting, Interval Composite, Interval Movie
Record, and Star Stream.
Locks focus at
1st exposure p.72
14 WB Adjustable Range
Sets whether to automatically fine-tune the white balance
when the light source is specified for the white balance
setting.
Fixed p.73
1
35
Introduction
E3
15 AWB in Tungsten Light Sets the tungsten light color tone when the white balance is
set to [Auto White Balance].
Strong
Correction p.73
16 WB When Using Flash Sets the white balance setting when using a flash. Auto White
Balance p.73
17 Color Temperature Steps Sets the adjustment steps for the Color Temperature option
of the white balance. Kelvin p.75
18 4-way Controller Settings
Selects the operation of the arrow keys (ABCD) when the
focusing area selection mode is set to one of some select-
type options.
Type1 p.63
19 Auto SR Off Automatically turns off the Shake Reduction function when
the drive mode is set to [Self-timer] or [Remote Control].
Enable Auto
SR Off p.66
20 Save Rotation Info Saves rotation information when shooting. On p.86
21 Save Menu Location Saves the last menu tab displayed on the monitor and
displays it again the next time F is pressed.
Reset Menu
Location p.23
E4
22 Catch-in Focus
Enables Catch-in Focus shooting when a manual focus lens
is attached. The shutter is released automatically when the
subject comes into focus.
Off p.116
23 AF Fine Adjustment Allows you to precisely fine-tune your lenses with the
camera’s autofocus system. Off p.65
24 Using Aperture Ring Enables the shutter to release when the lens aperture ring is
set to a position other than 9 (Auto). Disable p.115
Reset Custom Functions Resets the settings of the Custom Setting menus to the
defaults. – –
Menu Item Function Default Setting Page
2
Getting Started
36
1Pass the end of the strap
through the strap lug and
secure it on the inside of
the clasp.
2Attach the other end in the same manner.
1Make sure that the camera is turned off.
2
Remove the body mount
cover (
1
) and lens mount
cover (
2
).
After removing the cover, be sure
to put the lens down with the lens
mount side facing upward.
3Align the lens mount
indexes (red dots: 3) on
the camera and the lens,
and secure by turning the
lens clockwise until it
clicks.
Attaching the Strap Attaching a Lens
3
3
2
Getting Started
37
To remove the lens
Attach the lens cap, and then turn
the lens counterclockwise while
pressing the lens unlock button
(4).
u Caution
When attaching or removing the lens, choose an environment
that is relatively free of dirt and dust.
Keep the body mount cover attached to the camera when a
lens is not attached.
Be sure to attach the lens mount cover and lens cap to the
lens after removing it from the camera.
Do not insert your fingers inside the lens mount of the camera
or touch the mirror.
The camera body and lens mount incorporate lens
information contacts. Dirt, dust, or corrosion may damage the
electrical system. Please contact your nearest service center
for professional cleaning.
When a retractable lens is attached and is not extended, you
cannot take pictures or use some functions. If the lens is
retracted during shooting, the camera stops working. Refer to
“How to Use a Retractable Lens” (p.46) for details.
We assume no responsibility nor liability for accidents,
damages, and malfunctions resulting from the use of lenses
made by other manufacturers.
t Memo
Refer to “Functions Available with Various Lenses” (p.113) for
details on the functions of each lens.
Use the battery D-LI109 and battery charger D-BC186
exclusively developed for this camera.
Note: AC plug cord
UL Listed, Type SPT-2 or NISPT-2, 18/2 flexible cord, rated
125 V, 7 A, minimum 6 ft. (1.8 m)
1Insert the power plug to
the USB power adapter
until it clicks.
2Connect the USB cable to
the USB power adapter.
3Plug the USB power
adapter into the power
outlet.
4
Using the Battery and Charger
Charging the Battery
2
3
2
Getting Started
38
4Set the battery to the
battery charger while
aligning the + and -
terminals of each.
5Connect the USB cable to
the USB terminal.
The indicator lamp lights while
charging and turns off when the
battery is fully charged.
u Caution
Do not use the battery charger D-BC186 to charge batteries
other than the battery D-LI109. Charging other batteries may
cause damage or heating.
Replace the battery with a new one in the following cases:
If the indicator lamp blinks or does not light after the battery
is inserted correctly
If the battery starts to run down more quickly even after
being charged (the battery may have reached the end of its
service life)
t Memo
The maximum charging time is approximately 2 hours and
30 minutes (it depends on temperature and remaining battery
power). Charge the battery in a location where the
temperature is between 0°C and 40°C (32°F and 104°F).
u Caution
Insert the battery correctly. If the battery is inserted
incorrectly, it may not be removed.
Wipe the electrodes of the battery with a soft dry cloth before
inserting.
Do not open the battery cover or remove the battery while the
power is on.
Be careful as the camera or battery may become hot after the
camera has been used continuously for a long period of time.
Remove the battery when you do not use the camera for a
long time. The battery may leak and damage the camera if left
installed during prolonged periods of non-use. If the removed
battery is not used for six months or longer, charge the battery
for about 30 minutes before storing it. Be sure to recharge the
battery every six to twelve months.
Store the battery in a location where the temperature will
remain at or below room temperature. Avoid locations with
high temperatures.
The date and time may be reset if you leave the battery out of
the camera for long periods of time. If this happens, set the
current date and time again. (p.42)
1Open the battery cover.
Slide the battery cover unlock
lever (1) before opening the
cover.
4
5
Inserting/Removing the Battery
1
2
Getting Started
39
2Face the A mark on the
battery towards the
outside of the camera, and
insert the battery until it
locks into place.
To remove the battery, push the
battery lock lever in the direction
of 2.
3Close the battery cover.
t Memo
The battery level may not be displayed properly if the camera
is used at low temperatures or when performing Continuous
Shooting for a long time.
Battery performance temporarily decreases as the
temperature decreases. When using the camera in cold
climates, have extra batteries at hand and keep them warm in
your pocket. Battery performance will return to normal at
room temperature.
Have extra batteries ready when traveling overseas or taking
a lot of pictures.
We recommend the use of the optional AC adapter kit K-AC168
when using the monitor for a long time or when connecting the
camera to a computer or AV device.
1Make sure that the camera is turned off.
2Open the battery cover.
Remove the battery if it is inserted in the camera.
3Pull out the connection
cable cover on the right
side of the battery
chamber.
4Insert the DC coupler into
the battery chamber.
5Close the battery cover.
Make sure that the connection
cable comes out from the
connection cable opening.
2
Using the AC Adapter
2
Getting Started
40
6
Connect the DC coupler and the AC adapter.
7Connect the AC adapter to the AC plug cord, and
plug the cord into the power outlet.
u Caution
Make sure that the camera is turned off before connecting or
disconnecting the AC adapter.
Make sure that the connections are secure between the
terminals. The memory card or data may be corrupted if the
connection to the power supply is lost while the card is being
accessed.
After removing the DC coupler, return the connection cable
cover to its original position.
Be sure to read the manual of the AC adapter kit before using
the AC adapter.
The following memory cards can be used with this camera.
SD Memory Card
SDHC Memory Card
SDXC Memory Card
In this manual, these cards are referred to as memory cards.
1Make sure that the camera is turned off.
2Slide the memory card
cover in the direction of 1
and then rotate it to open
as shown by 2.
3Insert a card all the way
into the memory card slot
with the memory card label
facing toward the side with
the monitor.
Push the memory card in once
and release to remove.
Inserting a Memory Card
2
1
2
Getting Started
41
4Rotate the memory card
cover as shown by 3, and
slide it in the direction of
4.
u Caution
Do not remove the memory card while the card access lamp
(orange) is lit.
If the memory card cover is opened while the power is on, the
camera turns off. Do not open the cover while the camera is
in use.
Use this camera to format (initialize) a memory card that is
unused or has been previously used on other devices. (p.44)
Use a high-speed memory card when recording movies. If the
write speed cannot keep up with the recording speed, writing
may stop during recording.
The following procedure explains how to open the monitor with
the LCD screen facing inward.
1Open and rotate the
monitor 180° to the left
while holding the top and
bottom of it.
2Rotate the monitor 180°
backward.
The monitor can also be rotated
up to 90° forward.
3Close the monitor on the
camera so that the LCD
screen can be seen.
3
4
How to Open the Monitor
2
Getting Started
42
u Caution
When the monitor is closed with the LCD screen facing
inward, you cannot play back images and display the menus
unless the camera is connected to an AV device equipped
with an HDMI terminal.
Do not hold the camera by the monitor or rotate the monitor
beyond its movable range.
Do not carry the camera or put it in a bag with the monitor
open. You can carry the camera when the monitor is closed
regardless of the LCD screen direction.
t Memo
To close the monitor with the LCD screen facing inward,
rotate the monitor 180° forward in Step 2 and then 180° to the
right.
The items displayed on the monitor rotate according to the
direction and angle of the monitor.
Turn the camera on and make the initial settings.
1Turn the main switch to
[ON].
The lamp lights up in green.
The first time the camera is
turned on after purchase, the
[Language/W] screen
appears.
t Memo
The power automatically turns off when you do not perform
any operations within a set period of time. (Default setting:
1min.) You can change the setting in [Auto Power Off] of the
D3 menu. (p.33)
1Use ABCD to select the desired language and
press E.
The [Initial Setting] screen
appears in the selected
language.
Proceed to Step 6 if F
(Hometown) does not need to be
changed.
2Press to move the frame to BF and press D.
The [F Hometown] screen appears.
Initial Settings
Turning the Camera On
Setting the Display Language
Text Size
Std.
New York
English
Initial Setting
Settings complete
Cancel
2
Getting Started
43
3Use CD to select a city.
Use R to change the region.
Refer to “List of World Time
Cities” (p.131) for cities that can
be selected as a hometown.
4Press B to select [DST] (daylight saving time),
and use to select CD Y or Z.
5Press E.
The camera returns to the [Initial Setting] screen.
6Press B to select [Text Size] and press D.
7
Use
AB
to select [Std.] or
[Large], and press
E
.
Selecting [Large] increases the
text size of the selected menu
items.
8Press B to select [Settings
complete] and press E.
The [Date Adjustment] screen
appears.
1Press D, and use AB to
select the date format.
2Press D, and use AB to select [24h] or [12h].
3Press E.
The frame returns to [Date Format].
4Press B, and then press D.
The frame moves to the month if the date format is set to
[mm/dd/yy].
5Use AB to set the month.
Set the day, year, and time in the
same manner.
6Press B to select [Settings
complete] and press E.
The [LCD Display] screen
appears.
Hometown
Hometown
Hometown
HometownHometown
New Y
New Y
New Y
New York
ork
ork
orkNew York
DST
DST
DST
DSTDST
Cancel
Cancel
Cancel
CancelCancel OK
OK
OK
OKOK
T
T
T
Text Size
ext Size
ext Size
ext Size
Text Size
Std.
Std.
Std.
Std.
Std.
Large
Large
Large
Large
Large
New Y
New Y
New Y
New York
ork
ork
ork
New York
Initial Setting
Initial Setting
Initial Setting
Initial Setting
Initial Setting
Settings complete
Settings complete
Settings complete
Settings complete
Settings complete
Cancel
Cancel
Cancel
Cancel
Cancel
OK
OK
OK
OK
OK
T
T
T
Text Size
ext Size
ext Size
ext Size
Text Size
Std.
Std.
Std.
Std.
Std.
New Y
New Y
New Y
New York
ork
ork
ork
New York
English
English
English
English
English
Initial Setting
Initial Setting
Initial Setting
Initial Setting
Initial Setting
Settings complete
Settings complete
Settings complete
Settings complete
Settings complete
Cancel
Cancel
Cancel
Cancel
Cancel
OK
OK
OK
OK
OK
Setting the Date and Time
Time
Date
Date Format
00:00
mm/dd/yy
01/01/2022
Date Adjustment
Settings complete
Cancel
OK
10:00
Time
Date
Date Format
mm/dd/yy
07/07/2022
Date Adjustment
Settings complete
Cancel
OK
2
Getting Started
44
1Use CD to select a color.
Select the display color of the
status screen, control panel, and
menu cursor from colors 1 to 12.
2Press E.
The camera switches to capture mode and is ready to take
a picture.
t Memo
You can change the language, text size, and date and time
settings from the D1 menu, and the display color from [Other
Display Settings] of the A5 menu. (p.27, p.31)
1Press F.
The A1 menu appears.
2Use Q or R to display D4 menu.
3Use AB to select [Format] and press D.
The [Format] screen appears.
4Press A to select [Format]
and press E.
Formatting starts. When
formatting is completed, the D4
menu reappears.
5Press F.
u Caution
Do not remove the memory card while formatting, or the card
may be damaged.
Formatting deletes all data, both protected and unprotected.
t Memo
When a memory card is formatted, the volume label “KF” is
assigned to the card. When the camera is connected to a
computer, the memory card is recognized as a removable
disk with the name “KF”.
Setting the LCD Display
1
1
1
1/
/
/
/1 /
1
1
1
12
2
2
25
5
5
5125
1
1
1
11
Display Color
Display Color
Display Color
Display ColorDisplay Color
LCD Display
LCD Display
LCD Display
LCD DisplayLCD Display
Cancel
Cancel
Cancel
CancelCancel OK
OK
OK
OKOK
Formatting a Memory Card D4
2
Getting Started
45
Take pictures in the Auto Picture (R) mode in which the
camera automatically selects the optimal capture mode.
1Remove the front lens cap
by pushing the top and
bottom portions as
indicated in the
illustration.
When a retractable lens is
attached, extend the lens before
turning the camera on.
yHow to Use a Retractable Lens (p.46)
2Turn the camera on.
3Set the focus mode switch
to v.
4Turn the mode dial and
align the dial indicator to
R.
The selected capture mode is
displayed on the monitor (Guide
Display).
yGuide Display settings
(p.27)
5Look through the
viewfinder to view the
subject.
When using a zoom lens, turn the
zoom ring to the right or left to
change the angle of view.
Basic Shooting Operation
Shooting with the Viewfinder
Dial indicator
1/
250
F
5.6
1 6 0 0
Auto Picture
2
Getting Started
46
6Position the subject inside
the AF frame and press
0 halfway.
The focus indicator (P) appears
and you will hear a beep when
the subject comes into focus.
7Press 0 fully.
The captured image is displayed on the monitor (Instant
Review).
Available operations during Instant Review
t Memo
You can use f to focus on the subject. (p.61)
You can select whether to make a beep sound and change
the sound volume in [Sound Effects] of the D1 menu. (p.31)
You can set the operation and display settings for Instant
Review in [Instant Review] of the A5 menu. (p.27) When
[Display Time] is set to [Hold], Instant Review is displayed
until the next operation.
LDeletes the image.
R to the right Magnifies the image.
J
Saves the RAW data (only when a
JPEG image was taken and the
data remains in the buffer).
Focus indicator
How to Use a Retractable Lens
If the camera is turned on when a
retractable lens, such as smc
PENTAX-DA L 18-50mm F4-5.6
DC WR RE, is attached and is not
extended, an error message is
displayed on the monitor. Turn the
zoom ring in the direction of 2
while pressing the button on the ring (1) to extend the lens.
When retracting the lens, turn the zoom ring in the opposite
direction to 2 while pressing the button on the ring and align
the white dot to the position 3.
1
2
3
2
Getting Started
47
1Press K in Step 5 of
“Shooting with the
Viewfinder” (p.45).
The Live View image is displayed
on the monitor.
2Position the subject inside
the AF frame on the
monitor and press 0
halfway.
The AF frame turns green and
you will hear a beep when the
subject comes into focus.
Available operations
Subsequent steps are the same as shooting with the
viewfinder.
Review the captured image on the monitor.
1Press 3.
The camera enters playback
mode and the most recently
captured image is displayed
(single image display).
Shooting while Viewing the Live View Image
EMagnifies the image.
Use R to change the magnification (up to
16×).
Use ABCD to change the area to display.
Press M to return the display area to the
center.
Press E to return to 1× image display.
KExits shooting with Live View.
1/
1/
1/
1/
20
20
20
200
0
0
00
0
0
0
1/
2000
F2
F2
F2
F2.
.
.
.8
8
8
8
F2.8
16
16
16
160
0
0
00
0
0
0
1600
999
999
999
9999
9
9
9
9999
AF frame
Reviewing Images
1/
2000
F2.8
200
0.0
100-0001
2
Getting Started
48
2Review the captured image.
Available operations
t Memo
When R is turned to the right to magnify the image, the
magnification is displayed at the bottom right of the screen.
You can set the initial magnification when magnifying images
in [Quick Zoom] of the B1 menu. (p.30)
When Jv is displayed on the monitor, the JPEG image
that was just taken can also be saved in RAW format (Save
RAW Data).
You can display grid lines in single image display. Set in [Grid
Display] of [LCD Display] in the B1 menu. (p.31)
C Q/ to the left Displays the previous
image.
D Q/ to the right Displays the next image.
L Deletes the image.
R to the right Magnifies the image (up to
16×).
Use ABCD to change
the area to display.
Press M to return the
display area to the center.
Press E to return to the
entire image display.
R to the left Switches to the thumbnail
display (p.84).
J Saves the RAW data (only
when a JPEG image was
taken and the data remains
in the buffer).
GChanges the type of
information displayed
(p.16).
BDisplays the playback
mode palette (p.83).
3
Shooting
49
Set the file format for still pictures in [Image Capture Settings] of
the 2 menu.A
t Memo
When [File Format] is set to [RAW+], a JPEG image and a
RAW image with the same file number are saved at the same
time.
You can change the setting so that you can take pictures in
another file format when X or Y is pressed. (p.99)
[PEF] of [RAW File Format] is a PENTAX original RAW file
format.
Set the file format for movies in [Movie Capture Settings] of the
C1 menu.
Configuring the Capture Settings
Image Capture Settings A2
File Format JPEG, RAW, RAW+
JPEG Recorded
Pixels q p o r, , ,
JPEG Quality m l k, ,
RAW File Format PEF, DNG
Color Space sRGB, AdobeRGB
Movie Capture Settings C1
Recorded Pixels Framerate
u 60i, 50i, 30p, 25p, 24p
t 60p, 50p
3
Shooting
50
Select the capture mode that suits the subject and shooting
conditions.
The following capture modes are available on this camera.
t Memo
The functions that can be set vary depending on the capture
mode. Refer to “Restrictions on Each Capture Mode” (p.110)
for details.
You can save frequently used exposure modes and capture
settings as USER modes to O Q to and replace the preset
settings with them. (p.103)
1Set the mode dial to S.
The scene mode selection screen appears.
2Select a scene mode.
Taking Still Pictures
Capture Mode Function Page
R
(Auto Picture
modes)
Automatically selects the optimal
capture mode from
a
(Standard),
b
(Portrait),
c
(Landscape),
d
(Macro),
e
(Moving Object),
f
(Night Scene Portrait),
g
(Sunset),
h
(Blue Sky), or
i
(Forest).
p.45
S
(Scene modes)
Offers you various scene modes
to choose from. p.50
G, H, I J, ,
K L M, ,
(Exposure modes)
Allows you to change the shutter
speed, aperture value, and
sensitivity.
p.51
O
(CLEAR TONE)
Creates a clear and bright
atmosphere in pictures.
P
(HDR LANDSCAPE)
Gives a bold and dramatic look to
landscape shots.
Q
(ASTROPHOTO)
Adjusts the background black
level and reproduces the colors
of stars faithfully.
Scene Modes
bPortrait For capturing portraits. Reproduces a
healthy and bright skin tone.
cLandscape For capturing landscape views.
Reproduces the vivid green of trees.
dMacro
For capturing tiny objects at close
focus range like flowers, coins,
jewelry, and more.
eMoving
Object
For capturing images of fast moving
subjects.
f
Night
Scene
Portrait
For capturing images of people in low
light conditions, such as dusk or at
night.
gSunset For capturing sunrises or sunsets in
beautiful, vivid color.
hBlue Sky
For capturing images of blue sky.
Produces a more impressive deep blue.
iForest
Enhances colors of trees and
sunbeams through foliage and
produces a vivid color image.
Portrait
For capturing portraits.
Reproduces a healthy
and bright skin tone
Cancel
OK
3
Shooting
51
3Press E.
The camera is in standby mode.
Turn R to change the scene mode.
t Memo
You can change the scene mode also from the A1 menu.
x: Available #: Restricted ×: Not available
*1 You can set the value to change in [E-Dial Programming] of [Button
Customization] in the A5 menu. (p.101)
*2 [ISO AUTO] is not available.
*3 Fixed to [ISO AUTO].
*4 When the timed exposure is enabled, shutter speeds ranging from 10
seconds to 20 minutes can be set.
j
Night
Scene Used for shooting at night.
kNight
Scene HDR
Takes three consecutive images at
three different exposure levels (-1, ±0,
+1) to create a single composite image
from them.
lNight Snap For taking snapshots in poorly lit
places.
mFood
For capturing images of food.
Saturation will be rather high to make
food look appetizing.
oPet For capturing moving pets.
pKids
For capturing moving kids.
Reproduces healthy and bright skin
tone.
qSurf &
Snow
For capturing images of dazzling
backgrounds, such as snowy
mountains.
sBacklight
Silhouette
Produces a silhouette image of the
subject in backlight conditions.
tCandlelight For capturing scenes in candlelight.
uStage
Lighting
For capturing moving subjects in
poorly lit places.
vMuseum For capturing images in places where
a flash is prohibited.
Exposure Modes
Mode
Change
Shutter
Speed
Change
Aperture
Value
Change
Sensitivity
EV
Compen-
sation
G
Program Automatic
Exposure
# *1 # *1 x x
H
Sensitivity Priority
Automatic Exposure
× × x *2 x
I
Shutter Priority
Automatic Exposure
x×x x
J
Aperture Priority
Automatic Exposure
×xxx
K
Shutter & Aperture
Priority Automatic
Exposure
x x × *3 x
L
Manual Exposure x x x *2 x
M
Bulb Exposure × *4 x x *2 ×
3
Shooting
52
1Set the mode dial to the desired exposure mode.
Q R or appears on the
status screen for the value that
can be changed.
The value that can be changed is
underlined in the viewfinder.
During Live View, D appears for
the value that can be changed.
2Turn R.
The aperture value is changed in
J K L, , , or M mode.
The sensitivity is changed in H
mode.
3Turn Q.
The shutter speed is changed in
I K L, , or mode.
t Memo
The settings for the exposure can be specified in increments
of 1/3 EV steps. In [1 EV Steps] of the E1 menu, you can
change the adjustment steps to 1/2 EV steps.
In L mode, the difference from the correct exposure is
displayed on the EV bar scale while the exposure is adjusted.
For each exposure mode (excluding M mode), you can set
the camera operation for when Q or R is turned or M
is pressed. Set in [E-Dial Programming] of [Button
Customization] in the A 5 menu. (p.101)
u Caution
The correct exposure may not be obtained with the selected
shutter speed and aperture value when the sensitivity is fixed
at a certain sensitivity.
1
1
1
1/
/
/
/1/
3
3
3
30
0
0
03 0
F
F
F
FF
4
4
4
4.
.
.
.5
5
5
54.5
9
9
9
99
9
9
99
9
9
99
9
9
99
9
9
999999
1
1
1
10
0
0
00
0
0
0100
1/
1/
1/
1/
30
30
30
30
1/
30
F4
F4
F4
F4.
.
.
.5
5
5
5
F4.5
10
10
10
100
0
0
0
100
999
999
999
9999
9
9
9
9999
Noise Reduction when Shooting with a Slow Shutter
Speed
When shooting with a slow shutter speed, you can reduce
image noise in [Slow Shutter Speed NR] of [Noise
Reduction] in the A2 menu.
Auto
Applies Noise Reduction according to the shutter
speed, sensitivity, and internal temperature of the
camera.
On Applies Noise Reduction when the shutter speed
is slower than 1 second.
Off Does not apply Noise Reduction at any shutter
speed.
3
Shooting
53
1Set the mode dial to M.
2Use R to set the
aperture value.
3To enable the timed exposure, press M, and
then use Q to set the exposure time.
You can set the exposure time within the range from 10" to
20'00".
4Press 0.
While 0 is pressed, exposure continues.
If the timed exposure is enabled in Step 3, the exposure
ends when the set exposure time elapses after 0 is
fully pressed.
t Memo
You can start and end exposure also by pressing 0. Set
in [7 Bulb (B) Mode Options] of the E1 menu.
When performing the bulb exposure, use a tripod and mount
the camera on it securely. The use of the optional remote
control unit or cable release is recommended. (p.55, p.67)
u Caution
The drive mode cannot be set to [Continuous Shooting],
[Bracketing], or [Interval Shooting].
Checking the Depth of Field (Preview)
When [Preview] is assigned to X or Y in [Button
Customization] of the A5 menu, you can check the depth of
field before taking pictures. (p.98)
Locking the Exposure
To lock the exposure before shooting, use the AE Lock
function. This function can be used by assigning [AE Lock]
to the f button in [Button Customization] of the A5 and
C2 menus. (p.98)
Bulb Exposure
3
Shooting
54
1Turn the main switch to
C.
The indicator lamp lights red and
the Live View image is displayed.
2Set the mode dial to the desired capture mode.
The following settings are available depending on the
capture mode.
3Focus on the subject.
In v mode, press 0 halfway.
4Press 0 fully.
Movie recording starts.
In the upper left area of the monitor, “REC” blinks and the
size of the recorded movie file is displayed.
5Press 0 fully again.
Movie recording stops.
6Return the main switch to the [ON] position to
exit C mode.
The camera returns to shooting with the viewfinder in A
mode.
u Caution
When recording a movie with sound, camera operation
sounds are also recorded.
When recording a movie with an image processing function
such as Digital Filter applied, the movie file may be saved with
some frames omitted.
If the internal temperature of the camera becomes high
during recording, recording may be terminated.
When a retractable lens is attached, recording stops if the
lens is retracted during recording and an error message is
displayed.
In C mode, the Wi-Fi™ function is disabled.
Recording Movies
G J K L, , ,
The camera operates in the selected
exposure mode. (The aperture value
can be changed only before shooting.
When set to L mode, the sensitivity
can also be changed.)
O Q to The camera operates according to the
saved exposure mode.
Other modes The camera operates in G mode.
99
99
99
99'
'
'
'9
9
9
99
9
9
9"
"
"
"
99'99"
Sound
Recordable Time
Focus Motor Noise during Movie Recording
When [AF Mode] of [AF with Live View] in the C1 menu is
set to y, focus motor drive noise is recorded.
Adjusting the sound level in [Recording Sound Level] of the
C1 menu, or using an external microphone can reduce the
motor noise to be recorded.
3
Shooting
55
t Memo
You can change the movie settings in the C menus. (p.29)
By default, autofocus is not performed when 0 is
pressed halfway during movie recording. If a compatible lens
is attached to the camera, you can select y in [AF Mode]
of [AF with Live View] in the C1 menu and continuously
autofocus even during movie recording. (p.63) When [AF
Mode] is set to , the y f button operation varies as
follows depending on the setting assigned to f in [Button
Customization] of the C2 menu. (p.98)
The sound volume for recording a movie can be set in
[Recording Sound Level] of the C1 menu. When [Manual] is
selected, the sound volume can be set from 0 to 20.
You can record a movie continuously up to 4 GB or 25
minutes. When the memory card is full, recording stops.
u Caution
Do not connect a microphone or other device outside the
recommended specifications to the microphone/cable release
terminal. Doing so may cause the camera to malfunction.
[Button Customization]
setting
Autofocus operation when
f is pressed
Enable AF1, Enable AF2
Pressing f performs
autofocus based on the [AF
Mode] setting.
Cancel AF
Pressing f stops autofocus
and pressing f again
restarts autofocus.
Using a Microphone or Cable Release
You can connect a commercially
available stereo microphone to
the microphone/cable release
terminal on the camera. Using an
external microphone can also help
to reduce the possibility of
recording camera operation
sounds.
The following specifications are
recommended for external
microphones. (A monaural microphone cannot be used with
this camera.)
You can also connect the optional Cable Switch CS-310 to
the microphone/cable release terminal on the camera. When
the cable release is connected, sounds are recorded with the
built-in microphone.
You can set the device to connect
in [External Input Devices] of the
D3 menu. Normally, you do not
need to change the default setting
([Auto Select]).
Microphone/cable
release terminal
Plug Stereo mini plug (ø3.5 mm)
Format Stereo electret condenser
Power Plug-in Power Method (operating voltage of
2.0 V or lower)
Impedance 2.2 kΩ
Automatically detects input
Automatically detects input
Automatically detects input
Automatically detects inputAutomatically detects input
device and switches between
device and switches between
device and switches between
device and switches betweendevice and switches between
cable release and microphone
cable release and microphone
cable release and microphone
cable release and microphoneable release and microphone
External Input Devices
External Input Devices
External Input Devices
External Input DevicesExternal Input Devices
External Input Devices
External Input Devices
External Input Devices
External Input DevicesExternal Input Devices
Cancel
Cancel
Cancel
CancelCancel OK
OK
OK
OKOK
3
Shooting
56
1Display the movie to play
back in single image
display of the playback
mode.
Available operations
t Memo
The sound volume at the start of movie playback can be set
in [Playback Sound Volume] of the B1 menu. (p.31)
In [Movie Edit] of the playback mode palette, a movie file can
be divided into multiple segments or selected frames can be
deleted. (p.91)
1Press A in standby mode.
2Use AB to select an item.
3Use Q or R to change the value.
4Press E.
The camera returns to standby mode.
t Memo
The adjustment steps for ISO sensitivity is 1 EV step. To
adjust the sensitivity in accordance with the EV step setting
for the exposure, set from [2 Sensitivity Steps] of the E1
menu.
When the sensitivity is set to ISO 102400, ISO value is
displayed in the viewfinder by a combination of the letter “H”
and the three-digit number “102” (H102).
Playing Back Movies
A Plays back/pauses a movie.
D
Forwards a frame (when paused).
Press and hold D Fast-forwards playback.
C
Reverses a frame (when paused).
Press and hold C Fast-reverses playback.
BStops playback.
RAdjusts the sound volume (21
levels).
J Saves the displayed frame as a
JPEG file (when paused).
G Switches between [Standard
Information Display] and [No
Information Display].
10
10
10
10'
'
'
'3
3
3
30"
0"
0"
0"10'30"
10
10
10
100
0
0
0-
-
-
-00
00
00
000
0
0
01
1
1
1100-0001
Setting the Exposure
Sensitivity
ISO
AUTO
Sets the range to be
adjusted
automatically.
Both the upper limit
and lower limit can be
changed.
ISO
Sets a fixed value from
ISO 100 to ISO
102400.
32 0 0
100
100
-
1/
250
F5.6
0.0
Cancel
OK
3
Shooting
57
You can set the Noise Reduction setting when shooting with a
high ISO sensitivity.
1Select [Noise Reduction] in A2 menu and press
D.
The [Noise Reduction] screen appears.
2Select [High-ISO NR] and press D.
3Select the Noise Reduction
level and press E.
Proceed to Step 7 when other than [Custom] is selected.
4Select [Setting] and press D.
5Select the Noise Reduction
level for each ISO setting.
Available operations
6Press F.
The screen of Step 3 reappears.
7Press F twice.
Noise Reduction when Shooting with a
High ISO Sensitivity A2
Auto Applies Noise Reduction at optimally
calculated levels throughout ISO range.
Low,
Medium,
High
Applies Noise Reduction at constant chosen
level throughout ISO range.
Custom Applies Noise Reduction at user-defined
levels for each ISO setting.
Off Does not apply Noise Reduction at any ISO
setting.
Noise Reduction
Noise Reduction
Noise Reduction
Noise ReductionNoise Reduction
High-ISO NR
High-ISO NR
High-ISO NR
High-ISO NRHigh-ISO NR
Slow Shutter Speed NR
Slow Shutter Speed NR
Slow Shutter Speed NR
Slow Shutter Speed NRSlow Shutter Speed NR
Cancel
Cancel
Cancel
CancelCancel OK
OK
OK
OKOK
R Shows the next/previous page.
M Resets the Noise Reduction level to the
default setting.
3
Shooting
58
The compensation value can be set between -5 and +5 EV (-2
and +2 EV in C mode).
1Press J, and then turn
R.
e and the compensation value
are displayed on the status
screen, Live View screen, and in
the viewfinder during adjustment.
Available operations
t Memo
Bracketing shooting enables you to take pictures while
automatically changing exposure. (p.68)
Choose the part of the sensor to use for measuring brightness
and determining the exposure in [AE Metering] of the A1 and
C1 menus.
t Memo
In [5 Link AE and AF Point] of the 1 menu, the metering E
point and the AF point can be linked.
EV Compensation
JStarts/ends adjusting the compensation value.
M
Resets the adjustment value to the default setting.
9
9
9
99
9
9
99
9
9
99
9
9
99
9
9
999999
1
1
1
1/
/
/
/1/
2
2
2
25
5
5
50
0
0
0250
F
F
F
FF
5
5
5
5.
.
.
.6
6
6
65.6
1
1
1
16
6
6
60
0
0
00
0
0
0160 0
AE Metering A C1/ 1
AMulti-
segment
Meters the brightness in multiple different
zones of the sensor.
In backlit conditions, this mode automatically
adjusts the exposure.
BCenter-
weighted
Meters the brightness with an emphasis on the
center of the sensor.
The sensitivity increases at the center and no
automatic adjustment is performed even in
backlit conditions.
C Spot
Meters the brightness only within a limited
area at the center of the sensor.
Useful when the subject is small.
3
Shooting
59
1Press C in standby mode.
2Select a flash mode.
Available operations
3Press E.
The camera returns to standby mode.
4Press 1.
The built-in flash is popped up.
Using the Built-in Flash
AAuto Flash
Discharge
Automatically measures the ambient
light and determines whether to use
the flash.
BAuto Flash +
Red-eye
Discharges a pre-flash for red-eye
reduction before an automatic flash.
C Flash On Discharges a flash for each picture.
DFlash On +
Red-eye
Discharges a pre-flash for red-eye
reduction before the main flash for
each picture.
ESlow-speed
Sync
Sets to a slow shutter speed and
discharges a flash for each picture.
Use this, for example, when shooting
a portrait with the sunset in the
background.
FSlow Sync +
Red-eye
Discharges a pre-flash for red-eye
reduction before the main flash is
discharged with Slow-speed Sync.
0.0
0.0
0.0
0.0EV
EV
EV
EV
0.0EV
±0
±0
±0
±0EV
EV
EV
EV
±0EV
Auto Flash Discharge
Auto Flash Discharge
Auto Flash Discharge
Auto Flash Discharge
Auto Flash Discharge
Cancel
Cancel
Cancel
Cancel
Cancel
OK
OK
OK
OK
OK
H
G
Trailing
Curtain Sync
Discharges a flash immediately
before closing the shutter.
Sets to a slow shutter speed.
Captures moving objects as if they
are leaving a light trail behind them.
K
Manual
Flash
Discharge
Sets the amount of flash discharge
between FULL and 1/128 power.
R Compensates the flash exposure.
Selects the amount of flash discharge (when
[Manual Flash Discharge] is selected).
M Resets the compensation value to the
default setting.
3
Shooting
60
t Memo
The flash modes that can be selected vary depending on the
capture mode.
*1 The built-in flash cannot be used for some scene modes. (p.110)
You cannot take pictures while the built-in flash is being
charged. If you want to take pictures while charging the flash,
set [8 Release While Charging] in the 2 menu.E
Depending on the lens being used, the use of the built-in flash
may be limited. (p.114)
When the built-in flash is used in J mode, the shutter speed
automatically changes over a range from 1/180 seconds to a
slow shutter speed depending on the lens being used. The
shutter speed is locked at 1/180 seconds when a lens other
than a DA, DA L, D FA, FA J, FA, or F lens is used.
When the built-in flash is used in I , K, or L mode, any
desired shutter speed of 1/180 seconds or slower can be set.
The built-in flash is optimum for a subject at a distance from
approx. 0.7 m to 5 m. Vignetting may occur when used at a
distance closer than 0.7 m (this distance varies slightly
depending on the lens being used and the sensitivity setting).
For details on the use of external flashes, refer to “Functions
when Using an External Flash” (p.117).
Capture Mode Selectable Flash Mode
R S, *1 A B C D, , ,
G H J, , C D E F H K, , , , ,
I K L M, , , C D G K, , ,
Guide Number
Sensitivity Guide
Number Sensitivity Guide
Number
ISO 100 Approx. 12 ISO 6400 Approx. 96
ISO 200 Approx. 17 ISO 12800 Approx. 136
ISO 400 Approx. 24 ISO 25600 Approx. 192
ISO 800 Approx. 34 ISO 51200 Approx. 272
ISO 1600 Approx. 48 ISO 102400 Approx. 384
ISO 3200 Approx. 68
3
Shooting
61
Set the focus mode switch to v or
w.
The autofocus method for shooting with the viewfinder differs
from that for shooting with Live View.
The autofocus operation when
shooting with the viewfinder can be
set in [AF with Viewfinder] of the A1
menu.
In [Hold AF Status], you can set whether to immediately
reactivate autofocus or to maintain the focus for a certain
amount of time before reactivating autofocus when the subject
happens to move out of the selected focusing area after being
focused.
Setting the Focus Method
Shooting with
the viewfinder
TTL phase-matching AF:
Select from x, y, or z mode
which enables automatically switching
between x y and .
Faster autofocus performance than the
contrast detection AF is possible. (p.61)
Shooting with
Live View
Image plane phase-matching AF + contrast
detection AF:
Face Detection and Tracking are available.
(p.63)
Focusing on the Subject Using the f Button
You can use f to focus on the
subject. The f button
operation can be set in [Button
Customization] of the A5 and
C2 menus. (p.98)
Setting the Autofocus when Shooting
with the Viewfinder A1
AF Mode z x, , y
AF Active Area 6 7 9 8 D, , , ,
AF.S Setting Focus-priority, Release-priority
1st Frame Action in AF.C Auto, Focus-priority, Release-
priority
Action in AF.C Cont. Auto, Focus-priority, FPS-priority
Hold AF Status Off, Low, Medium, High
AF Mode
AF.S Setting
1st Frame Action in AF.C
Action in AF.C Cont.
Hold AF Status
AF with Viewfinder
AF Active Area
3
Shooting
62
1Select an autofocus mode in [AF Mode] on the
[AF with Viewfinder] screen.
2Press E.
3Press F twice.
The camera returns to standby mode.
t Memo
In S mode, the autofocus mode is fixed to x y or
depending on the selected scene mode. (p.110)
In R mode, the autofocus mode is fixed to z.
1Select a focusing area selection mode in [AF
Active Area] on the [AF with Viewfinder] screen.
2Press E.
3Press F twice.
The camera returns to standby mode.
If you selected 9 or 8 in Step 1, proceed to Step 4.
AF Mode
z
(Auto-select
mode)
Switches automatically between x
and y modes according to the
subject.
x
(Single mode)
When 0 is pressed halfway and the
subject comes into focus, the focus is
locked at that position.
The AF assist light turns on as necessary.
y
(Continuous
mode)
The subject is kept in focus by continuous
adjustment while 0 is pressed
halfway.
The shutter can be released even if the
subject is not in focus.
AF Active Area (AF Point)
6Auto
(11 AF Points)
Out of the 11 AF points, the camera
automatically selects the optimum
focusing area.
7Auto
(5 AF Points)
Out of the 5 AF points, the camera
automatically selects the optimum
focusing area.
9Select Sets the focusing area to the user
selected point from 11 points.
8Expanded
Area AF
Sets the focusing area to the user
selected point from 11 points. When
the subject happens to move out of
the selected focusing area after
being focused, 8 peripheral points
are used as back-up points.
Not available in x mode.
DSpot Sets the focusing area to the center
of the 11 points.
3
Shooting
63
4Select the desired AF
point.
Available operations
t Memo
You can also set the camera so that switching to the AF point
change mode by pressing and holding E can be operated
with X or Y. (p.98)
You can select the button operation when changing the
focusing area in [18 4-way Controller Settings] of the E3
menu.
The autofocus operation when
shooting with Live View can be set in
[AF with Live View] of the A1 and
C1 menus.
When [Focus Peaking] is set to [On], the outline of the subject
in focus is emphasized, and this makes it easier to check the
focus. This function works in both v and w modes.
The menu item [AF Mode] in [AF with Live View] of the C1 can
be changed to y only when a compatible lens is attached
to the camera.
1Select an autofocus mode in [AF Mode] on the
[AF with Live View] screen.
Select from x or y.
2Press E.
ABCD Changes the AF point.
EReturns the AF point to the
center.
Press and hold E Switches the function of the
arrow keys (ABCD) to the
AF point change mode or the
direct key operation mode.
Type1
Switches the operation of the arrow keys
(ABCD) to the AF point change mode or the
direct key operation mode.
Type2 Prioritizes the AF point change mode in standby
mode.
9
9
9
99
9
9
99
9
9
99
9
9
99
9
9
999999
AUT
AUT
AUT
AUTO
O
O
OAUTO
Setting the Autofocus when
Shooting with Live View A C1/ 1
AF Active Area e f 0 h i, , , ,
Focus Peaking On, Off
AF.S Setting Focus-priority, Release-priority
AF Mode C1
AF Active Area
Focus Peaking
AF.S Setting
AF with Live View
3
Shooting
64
1Select a focusing area selection mode in [AF
Active Area] on the [AF with Live View] screen.
Select from 0, h, or i in C mode.
2Press E.
3Press F twice.
The camera returns to standby mode.
If you selected 0 or h in Step 1, proceed to Step 4.
4Press and hold E.
5Select the AF area.
Use the frame that appears on
the monitor to change the
position and size of the AF area.
Available operations
6Press E.
The AF area is set.
u Caution
When f is selected, the focus lock operation (composition
adjustment with the half press of 0) does not work.
t Memo
You can also set the camera so that switching to the AF area
change mode by pressing and holding E can be operated
with X or . (p.98)Y
[AF Active Area] is fixed to e in R mode and b, , f
and p of S mode.
AF Active Area
eFace
Detection
Detects and tracks faces of people.
The main face detection frame for AF
and AE is displayed in yellow.
f Tracking
Tracks the subject in focus.
The shutter can be released even if the
subject is not in focus.
0Multiple AF
Points
Sets the focusing area to the desired
area.
The sensor is divided into 35 areas (7
horizontal by 5 vertical), and you can
select a wider or narrower focusing
area by using 1, 9, 15, or 25 of those 35
available areas.
hSelect Sets the focusing area by the pixel.
iSpot Sets the focusing area to a limited area
at the center.
ABCD Changes the position of the AF area.
RIncreases/reduces the size of the AF
area (when 0 is selected).
MReturns the AF area to the center.
3
Shooting
65
You can precisely fine-tune your lenses with the camera’s
autofocus system.
1Select [23 AF Fine Adjustment] in E4 menu and
press D.
The [23 AF Fine Adjustment] screen appears.
2Select [Apply All] or [Apply One] and press E.
3Select [Setting] and adjust
the value.
Available operations
4Press E.
The adjustment value is saved.
5Press F twice.
The camera returns to standby mode.
1Press D in standby mode.
The Drive Mode screen appears.
2Select a drive mode.
AF Fine Adjustment E4
Apply All
Applies the same adjustment value to all lenses.
Apply One
Saves an adjustment value for the lens being
used. (Up to 20 values)
D R/ to the right Adjusts the focus to a closer
position.
C R/ to the left Adjusts the focus to a farther
position.
MResets the adjustment value to
the default setting.
±0
±0
±0
±0±0
±0
±0
±0
±0±0
3
3
3
33
23
23
23
2323 AF Fine Adjustment
AF Fine Adjustment
AF Fine Adjustment
AF Fine AdjustmentAF Fine Adjustment
Apply One
Apply One
Apply One
Apply OneApply One
Setting
Setting
Setting
SettingSetting
Reset Individual Settings
Reset Individual Settings
Reset Individual Settings
Reset Individual SettingsReset Individual Settings
Save
Save
Save
SaveSave
Cancel
Cancel
Cancel
CancelCancel
Setting the Drive Mode
Single Frame Shooting
( )L Normal capture mode
Continuous Shooting
( )Z, b
Continuously takes pictures while
0 is kept pressed. (p.66)
Self-timer
(O, P, Y)
Releases the shutter about 12
seconds or 2 seconds after
0 is pressed. (p.67)
Remote Control
( )Q, R, S
Enables shooting with remote
control. (p.67)
Bracketing
( )T, 1, U
Takes consecutive pictures at
different exposure levels. (p.68)
Mirror Lock-up
Shooting
( )c, d
Takes pictures with the mirror
raised. (p.69)
Multi-exposure
(V, z, W X, )
Creates a composite image by
taking multiple pictures and
merging them into a single image.
(p.70)
Interval Shooting
( )q, U, V, w
Automatically takes pictures at set
intervals. (p.71)
Single Frame Shooting
Cancel
OK
3
Shooting
66
u Caution
There are restrictions on some drive modes when used in
some capture modes or in combination with some other
functions. (p.110)
t Memo
In C mode, you can select only [Remote Control Off] or
[Remote Control].
The Drive Mode setting is saved even after the power is
turned off. If [Drive Mode] is set to Y (Off) in [Memory] of the
A5 menu, the setting returns to [Single Frame Shooting]
when the power is turned off. (p.105)
The [Shake Reduction] of the A4 menu is automatically set
to [Off] when the drive mode is set to [Self-timer] or [Remote
Control]. If you do not want to turn off the Shake Reduction
function, set in [19 Auto SR Off] of the E3 menu.
1Select Z on the Drive
Mode screen and press B.
2Use CD to select Z or b, and press E.
The camera returns to standby mode.
t Memo
When [AF Mode] in [AF with Viewfinder] of the A1 menu is
set to x, the focus position is locked in the first frame.
(p.62)
If Light Enters through the Viewfinder
When the drive mode that employs the self-timer or remote
control is selected, exposure may be affected by the light
entering through the viewfinder. In such a case, use the AE
Lock function. (p.53)
Continuous Shooting
Z Continuous Shooting (at high speed)
b Continuous Shooting (at low speed)
3
Shooting
67
1Select O on the Drive
Mode screen and press B.
2Use CD to select O, P, or Y.
Proceed to Step 6 when O or P is selected.
3Press G.
4Set [Shooting Speed] and
[Number of Shots].
5Press E.
The screen of Step 1 reappears.
6Press E.
The camera returns to standby mode.
7Press 0 halfway, and then fully.
The shutter is released after about 12 seconds or 2
seconds.
1Select Q on the Drive Mode
screen and press B.
2Use CD to select Q, R, or S.
Proceed to Step 6 when Q or R is selected.
3Press G.
4Set [Shooting Speed].
5Press E.
The screen of Step 1 reappears.
6Press E.
The camera returns to standby mode.
7Press 0 halfway.
Self-timer
O
Self-timer (shutter release after about 12 seconds)
P Self-timer (shutter release after about 2 seconds)
Y Self-timer + Continuous Shooting
Self-timer (12 sec.)
Self-timer (12 sec.)
Self-timer (12 sec.)
Self-timer (12 sec.)Self-timer (12 sec.)
Cancel
Cancel
Cancel
CancelCancel OK
OK
OK
OKOK
3
3
3
3
3
Self-timer + Continuous
Self-timer + Continuous
Self-timer + Continuous
Self-timer + Continuous
Self-timer + Continuous
Shooting Speed
Shooting Speed
Shooting Speed
Shooting Speed
Shooting Speed
Number of Shots
Number of Shots
Number of Shots
Number of Shots
Number of Shots
times
times
times
times
times
Cancel
Cancel
Cancel
Cancel
Cancel
OK
OK
OK
OK
OK
Remote Control
Q Remote Control
RRemote Control (shutter release after about 3
seconds)
S Remote Control + Continuous Shooting
Remote Continuous Shooting
Shooting Speed
Cancel
OK
3
Shooting
68
8Point the remote control unit towards the remote
control receiver on the front of the camera, and
press the shutter release button on the remote
control unit.
t Memo
The maximum operating distance of the remote control unit is
approximately 4 m from the front of the camera.
To adjust focus with remote control, set in [9 AF with Remote
Control] of the E2 menu.
When using the Remote Control Waterproof O-RC1, the
autofocus system can be operated with the q button on the
remote control unit. The r button cannot be used.
1Select T on the Drive
Mode screen and press B.
2Use CD to select T, , or 1 U.
Proceed to Step 6 when T is selected.
3Press G.
4Select the operation mode.
Bracketing
T Bracketing
1 Bracketing + Self-timer
U Bracketing + Remote Control
Bracketing
Self-timer
Cancel
OK
Bracketing
Remote Control
Cancel
OK
3
Shooting
69
5Press E.
The screen of Step 1 reappears.
6Set the number of shots and bracket value.
Available operations
7Press E.
The camera returns to standby mode.
8Shoot.
After pictures are taken, the camera returns to standby
mode.
t Memo
The bracket value can be set in increments of 1/3 EV steps or
1/2 EV steps according to the [1 EV Steps] setting of the E1
menu.
The following settings for Bracketing can be set in the E2
menu.
1Select c on the Drive
Mode screen and press B.
2Use CD to select c or d.
3Press E.
The camera returns to standby mode.
4Press 0 halfway, and then fully.
The mirror pops up and the AE Lock function is activated.
5Press 0 fully again.
The picture is taken and then the mirror returns to its
original position.
t Memo
The mirror automatically returns to its original position if 1
minute elapses after the mirror pops up.
u Caution
While this function is used, [Shake Reduction] of the A4
menu is fixed to [Off].
QSets the number of shots.
RChanges the bracket value.
JR Adjusts the exposure
compensation value.
MResets the adjustment value to the
default setting.
10 Bracketing Order Changes the shooting order of
pictures.
11 One-Push Bracketing Takes all pictures with one
release of the shutter.
Mirror Lock-up Shooting
c Mirror Lock-up Shooting
d Mirror Lock-up Shooting + Remote Control
3
Shooting
70
1Select V on the Drive
Mode screen and press B.
2Use CD to select V, , or z, W X.
Proceed to Step 6 if you do not need to change the shooting
conditions.
3Press G.
4Set the shooting
conditions.
5Press E.
The screen of Step 1 reappears.
6Press E.
The camera returns to standby mode.
7Shoot.
Instant Review is displayed.
Available operations during Instant Review
After the specified number of shots are taken, the camera
returns to standby mode.
t Memo
Composite images are created as follows in each Composite
Mode.
Multi-exposure
V Multi-exposure
z Multi-exposure + Continuous Shooting
W Multi-exposure + Self-timer
X Multi-exposure + Remote Control
Composite Mode Select from [Average], [Additive], or
[Bright].
Number of Shots Select from 2 to 2000 times.
Shooting Speed/
Self-timer/
Remote Control
Specify the operation mode for the
selected shooting mode.
0002
0002
0002
00020002
Multi-exposure
Multi-exposure
Multi-exposure
Multi-exposureMulti-exposure
Cancel
Cancel
Cancel
CancelCancel
Parameter Adj.
Parameter Adj.
Parameter Adj.
Parameter Adj.Parameter Adj.
Composite Mode
Composite Mode
Composite Mode
Composite ModeComposite Mode
Number of Shots
Number of Shots
Number of Shots
Number of ShotsNumber of Shots
Aver
Aver
Aver
Average
age
age
ageAverage
OK
OK
OK
OKOK
times
times
times
timestimes
0002
0002
0002
0002
0002
Multi-exposure
Multi-exposure
Multi-exposure
Multi-exposure
Multi-exposure
Composite Mode
Composite Mode
Composite Mode
Composite Mode
Composite Mode
Aver
Aver
Aver
Average
age
age
age
Average
Shooting Speed
Shooting Speed
Shooting Speed
Shooting Speed
Shooting Speed
Number of Shots
Number of Shots
Number of Shots
Number of Shots
Number of Shots
times
times
times
times
times
Cancel
Cancel
Cancel
Cancel
Cancel
OK
OK
OK
OK
OK
LDiscards pictures taken up to that point and
takes pictures again from the first picture.
FSaves pictures taken up to that point and
displays the A menu.
Average Creates a composite image with the average
exposure.
Additive Creates a composite image with the cumulatively
added exposure.
Bright
Creates a composite image replacing only the
portions that are brighter compared with the first
image.
3
Shooting
71
1Select q on the Drive
Mode screen and press B.
2Use CD to select q, , U V, or w.
Proceed to Step 6 if you do not need to change the shooting
conditions.
3Press G.
4Set the shooting
conditions.
5Press E.
The screen of Step 1 reappears.
6Press E.
The camera returns to standby mode.
7Press 0.
When [Start Interval] is set to [Now], the first picture is
taken. When set to [Set Time], shooting starts at the set
time.
To cancel shooting, turn the main switch to [OFF].
After the specified number of shots are taken, the camera
returns to standby mode.
Interval Shooting
qInterval Shooting
Takes pictures at set intervals and saves them.
U
Interval Composite
Takes pictures at set intervals and merges them
into a single image.
V
Interval Movie Record
Takes still pictures at set intervals and saves
them as a single movie file (Motion JPEG, file
extension: .AVI).
w
Star Stream
Takes still pictures at set intervals and merges
them into a single movie file (Motion JPEG, file
extension: .AVI) using Interval Composite.
0002
0002
0002
00020002
00
00
00
00
:
:
:
:
00´02˝
00´02˝
00´02˝
00´02˝00
:
00´02˝
Interval Shooting
Interval Shooting
Interval Shooting
Interval ShootingInterval Shooting
Cancel
Cancel
Cancel
CancelCancel
Parameter Adj.
Parameter Adj.
Parameter Adj.
Parameter Adj.Parameter Adj.
Interval
Interval
Interval
IntervalInterval
Number of Shots
Number of Shots
Number of Shots
Number of ShotsNumber of Shots
OK
OK
OK
OKOK
times
times
times
timestimes
Start Interval
Start Interval
Start Interval
Start IntervalStart Interval
00
00
00
00
:
:
:
:
00´02˝
00´02˝
00´02˝
00´02˝
00
:
00´02˝
0002
0002
0002
0002
0002
-
-
-
--
-
-
-:
:
:
:-
-
-
--
-
-
-
- - :- -
Interval Shooting
Interval Shooting
Interval Shooting
Interval Shooting
Interval Shooting
Interval
Interval
Interval
Interval
Interval
Start Interval
Start Interval
Start Interval
Start Interval
Start Interval
Number of Shots
Number of Shots
Number of Shots
Number of Shots
Number of Shots
times
times
times
times
times
Cancel
Cancel
Cancel
Cancel
Cancel
OK
OK
OK
OK
OK
Start Time
Start Time
Start Time
Start Time
Start Time
Recorded Pixels
Select from z, u, or t (only for
V w and ).
Interval Select from 2 seconds to 24 hours.
Standby Interval Select from the minimum time or 1
second to 24 hours.
Number of Shots Select from 2 to 2000 times.
Start Interval
Select when and how to take the first
picture from [Now], [Self-timer],
[Remote Control], or [Set Time].
Start Time Set the shooting start time when [Start
Interval] is set to [Set Time].
Composite Mode Select from [Average], [Additive], or
[Bright] (only for U).
Save Process Select Z to save images in the
middle of processing (only for U).
Fade-out Select the fade-out effect level of light
trails (only for w).
3
Shooting
72
t Memo
For q U and , a new folder is created and the captured
images are saved there.
The shortest time that can be set for [Interval] is 5 seconds
when [Digital Filter], [Clarity], or [Skin Tone] is set, and 10
seconds when [HDR Capture] is set.
The second and later exposures start at the intervals set in
[Interval]. If the exposure time is longer than the time set in
[Interval], some of the pictures that are supposed to be taken
at the set intervals are not actually taken. For example, if the
time set in [Interval] is 2 seconds and the exposure time is 3
seconds, the first exposure does not end at the time the
second exposure is supposed to start (2 seconds after the
start of shooting), and so the second picture is not taken. As
a result, Interval Shooting ends before the specified number
of shots are taken. In such cases, you can set [Standby
Interval] in [12 Interval Shooting Options] of the E2 menu so
that pictures are taken at the set intervals after each exposure
ends. The screen displayed in Step 4 varies depending on the
[12 Interval Shooting Options] setting.
For
q
and
U
, the focus position used when the first picture
is taken is locked. In order to perform autofocus for each
exposure, set [13 AF in Interval Shooting] to [Adjusts focus for
each shot] in the
E
2 menu.
For
U
and
w
, set the camera on a fixed support such as
tripods during shooting.
For
w
, [Shake Reduction] of the
A
4 menu is fixed to [Off].
1Press B in standby mode.
The White Balance setting screen appears.
Press X to use Digital Preview when shooting with the
viewfinder.
2Select the desired white
balance setting.
For k, o, and p, turn R to
select the type of white balance.
Setting the White Balance
gAuto White Balance
uMulti Auto White Balance
hDaylight
iShade
jCloudy
k
q Fluorescent - Daylight Color
r Fluorescent - Daylight White
s Fluorescent - Cool White
t Fluorescent - Warm White
lTungsten
nColor Temperature Enhancement
oManual White Balance 1 to 3
pColor Temperature 1 to 3
WB
±
Auto White Balance
Cancel
Check
OK
3
Shooting
73
Available operations when shooting with the
viewfinder
Proceed to Step 5 if you do not need to fine-tune the white
balance.
3Press G.
The fine-tuning screen appears.
Available operations
4Press E.
The screen of Step 2 reappears.
5Press E.
The camera returns to standby mode.
u Caution
The Digital Preview operation in Step 1 is disabled when the
drive mode is set to [Mirror Lock-up Shooting], [Multi-
exposure], or [Interval Shooting].
t Memo
When u is set, even if various light sources are present at
the shooting location, the camera automatically adjusts the
white balance according to the light source of each area. (u
is not available in C mode.)
The following settings for the white balance can be set in the
E2-3 menus.
J
Saves the preview image (only
when the image can be saved).
AB Adjust: Green-Magenta
CD Adjust: Blue-Amber
MResets the adjustment value to the default
setting.
G
G
G
G3
3
3
3
G 3
A
A
A
A2
2
2
2
A2
±0
±0
±0
±0
±0
Cancel
Cancel
Cancel
Cancel
Cancel
OK
OK
OK
OK
OK
Auto White Balance
Auto White Balance
Auto White Balance
Auto White Balance
Auto White Balance
14 WB Adjustable Range
Fixed, Auto Adjustment
15 AWB in Tungsten Light Strong Correction, Subtle
Correction
16 WB When Using Flash
Auto White Balance, Multi
Auto White Balance,
Unchanged
17 Color Temperature Steps Kelvin, Mired
3
Shooting
74
You can measure the white balance at a selected location.
1Select o in Step 2 of “Setting the White
Balance” (p.72).
2Use R to select 1 to 3.
1 to 3 are the locations where you
can store three different manual
white balance settings.
3Under the light you wish to measure the white
balance of, select a white area as the subject,
and press 0 fully.
The captured image is displayed.
4Use ABCD to specify
the measuring area.
Press M to return the measuring
area to the center.
5Press E.
The White Balance setting screen reappears.
[The operation could not be completed correctly] appears
when measuring is unsuccessful. Press E to remeasure
the white balance.
t Memo
You can copy the white balance settings of a captured image
and save them as o1 to o3 in [Save as Manual WB] of the
playback mode palette. (p.83)
Adjusting the White Balance Manually
WB
WB
WB
WB
±
±
±
±
WB
±
Manual White Balance
Manual White Balance
Manual White Balance
Manual White Balance
Manual White Balance
Cancel
Cancel
Cancel
Cancel
Cancel
Check
Check
Check
Check
Check
Adjust
Adjust
Adjust
Adjust
Adjust
OK
OK
OK
OK
OK
Cancel
Cancel
Cancel
Cancel
Cancel
OK
OK
OK
OK
OK
3
Shooting
75
Specify the white balance with the color temperature.
1Select p in Step 2 of “Setting the White
Balance” (p.72).
2Use R to select 1 to 3.
3Press G.
4Adjust the color
temperature.
Set the color temperature value
within the range from 2,500K to
10,000K.
Available operations
5Press E.
The White Balance setting screen reappears.
t Memo
Select [Mired] in [17 Color Temperature Steps] of the E3
menu to set the color temperature in mired units. The color
temperature can be changed in 20 mired units with Q, and
100 mired units with R. However, figures are converted to
and displayed in Kelvin.
When you want to take pictures with a slightly different style,
you can set the desired picture style before shooting.
Try out the various settings, and find your best picture style.
1Select [Custom Image] in A1 or C1 menu and
press D.
The Custom Image setting screen appears.
2Select an image finishing
tone.
*1 Selectable only when a compatible lens is attached
Adjusting the White Balance with Color
Temperature
QChanges the color temperature in
increments of 100 Kelvin.
RChanges the color temperature in
increments of 1,000 Kelvin.
ABCD Fine-tunes the color temperature.
±0
±0
±0
±0± 0 ± 0
±0
±0
±0± 0
±0
±0
±0
±0± 0
Cancel
Cancel
Cancel
CancelCancel OK
OK
OK
OKOK
Color T
Color T
Color T
Color Temperature
emperature
emperature
emperatureColor Temperature
Controlling the Image Finishing
Tone
Custom Image A C1/ 1
Auto Select
Bright
Natural
Portrait
Landscape
Vibrant
SATOBI
Radiant
Muted
Flat
Bleach Bypass
Reversal Film
Monochrome
Cross Processing
KATEN *1
KYUSHU *1
3
Shooting
76
Available operations when shooting with the viewfinder
Proceed to Step 6 if you do not need to change the
parameters.
3Press G.
The parameter setting screen appears.
4Set the parameters.
Available operations
5Press F.
The screen of Step 2 reappears.
The adjustment values for parameters are displayed.
6Press F twice.
The camera returns to standby mode.
u Caution
In R mode, the image finishing tone is fixed to [Auto
Select].
The Digital Preview operation in Step 2 is disabled when the
drive mode is set to [Mirror Lock-up Shooting], [Multi-
exposure], or [Interval Shooting].
When [Cross Processing] is set to [Random], the outcome
varies each time a picture is taken. If you take a cross
processed image that you like, you can save the Cross
Processing settings used in the image so that you can
repeatedly use the same settings.
1Press B in single image display of playback
mode.
The playback mode palette appears.
2Select j and press E.
The camera searches for cross processed images starting
from the most recent image taken.
[No cross processed image] appears if there are no cross
processed images.
X
Uses Digital Preview to preview the background
image with the selected setting applied.
J
Saves the preview image (only when the image
can be saved).
AB Selects a parameter.
CD Adjusts the value.
QSwitches between [Contrast], [Highlight
Adjustment], and [Shadow Adjustment].
RSwitches between [Sharpness], [Fine
Sharpness], and [Extra Sharpness]. (Not
available in C mode.)
MResets the adjustment value to the default
setting.
Saturation
Saturation
Saturation
Saturation
Saturation
Cancel
Cancel
Cancel
Cancel
Cancel
OK
OK
OK
OK
OK
Reset
Reset
Reset
Reset
Reset
Saving the Cross Processing Settings of a
Captured Image
3
Shooting
77
3Use Q to select a cross
processed image.
4Select the “Favorite” number 1, 2, or 3 to save
the settings, and press E.
The settings of the selected image are saved as your
“Favorite” settings.
t Memo
The saved Cross Processing settings can be loaded by
selecting [Cross Processing] in Step 2 of “Custom Image”
(p.75), and selecting one of the Favorite settings 1 to 3 for the
parameter.
1Select [Digital Filter] in A3 or C2 menu and
press D.
The Digital Filter setting screen appears.
2Select a filter.
Select [No Filter] to not shoot with
a digital filter.
Available operations when shooting with the
viewfinder
Proceed to Step 6 if you do not need to change the
parameters.
3Press G.
The parameter setting screen appears.
10
10
10
100
0
0
0-
-
-
-0
0
0
00
0
0
00
0
0
01
1
1
1
100-0001
Saves this image's Cross
Saves this image's Cross
Saves this image's Cross
Saves this image's Cross
Saves this image's Cross
Processing settings
Processing settings
Processing settings
Processing settings
Processing settings
Save as Fav
Save as Fav
Save as Fav
Save as Favorite 1
orite 1
orite 1
orite 1
Save as Favorite 1
Save as Fav
Save as Fav
Save as Fav
Save as Favorite 2
orite 2
orite 2
orite 2
Save as Favorite 2
Save as Fav
Save as Fav
Save as Fav
Save as Favorite 3
orite 3
orite 3
orite 3
Save as Favorite 3
Cancel
Cancel
Cancel
Cancel
Cancel
OK
OK
OK
OK
OK
Digital Filter A C3/ 2
Extract Color
Replace Color
Toy Camera
Retro
High Contrast
Shading
Invert Color
Unicolor Bold
Bold Monochrome
XUses Digital Preview to preview the
background image with the selected setting
applied.
J
Saves the preview image (only when the
image can be saved).
Extract Color
Cancel
Parameter Adj.
Check
OK
3
Shooting
78
4Set the parameters.
Available operations
5Press E.
The screen of Step 2 reappears.
6Press E.
7Press F.
The camera returns to standby mode.
u Caution
This function cannot be used in some capture modes or in
combination with some other functions. (p.110)
The Digital Preview operation in Step 2 is disabled when the
drive mode is set to [Mirror Lock-up Shooting], [Multi-
exposure], or [Interval Shooting].
Depending on the filter used, it may take longer to save
images.
t Memo
Still images can also be processed with digital filters in
playback mode. (p.89)
Expands the dynamic range and
enables a wider range of tones to be
recorded by the CMOS sensor and
reduces the occurrence of
overexposed/underexposed areas.
Set the correction functions from [D-
Range Settings] of the A2 or C2
menu.
u Caution
When the sensitivity is set to less than ISO 200, [Highlight
Correction] cannot be set to [On].
t Memo
[Highlight Correction] in C mode can be set to [Auto] or [Off].
AB Selects a parameter.
CD Adjusts the value.
Extracted Color 1
Extracted Color 1
Extracted Color 1
Extracted Color 1Extracted Color 1
Cancel
Cancel
Cancel
CancelCancel OK
OK
OK
OKOK
Check
Check
Check
CheckCheck
Correcting Images
Brightness Adjustment
Highlight Correction
Shadow Correction A C2/ 2
3
Shooting
79
Takes three consecutive images at three different exposure
levels to create a single composite image with them.
1Select [HDR Capture] in 3 menu and press AD.
The [HDR Capture] screen appears.
2Select the capture type and
press E.
3Set the range in which to change the exposure in
[Bracket Value].
Select from [±1EV], [±2EV], or [±3EV].
4Set whether to use Auto Align or not.
5Press F twice.
The camera returns to standby mode.
u Caution
This function cannot be used in some capture modes or in
combination with some other functions. (p.110)
When k of S mode is selected, [HDR Capture] is fixed
to [HDR AUTO].
When the drive mode is set to [Interval Shooting] or [Interval
Movie Record], [Auto Align] is fixed to Y (Off).
When [Auto Align] is set to Y (Off), [Shake Reduction] of the
A4 menu is fixed to [Off].
For HDR Capture, multiple images are combined together to
create a single image, so it may take time to save the image.
HDR Capture A3
ZUses Auto Align.
YDoes not use Auto Align.
99999
99999
99999
9999999999
Bracket
Bracket
Bracket
Bracket Value
Value
Value
ValueBracket Value
Auto Align
Auto Align
Auto Align
Auto AlignAuto Align
HDR Capture
HDR Capture
HDR Capture
HDR CaptureHDR Capture
Cancel
Cancel
Cancel
CancelCancel OK
OK
OK
OKOK
6
Settings
98
You can set the functions for when X, Y, or f is pressed.
In C mode, you can set only the function for when f is
pressed.
1Select [Button Customization] in A5 or 2 C
menu and press D.
The [Button Customization] screen appears.
2Select the desired item and
press D.
The screen to set the function for
the selected item is displayed.
3Press D and use AB to select the function to
assign to each part.
The following functions can be assigned to each part.
Camera Settings
Customizing the Button/E-dial
Functions A C5/ 2
Setting the Button Operation
Button Customization
Button Customization
Button Customization
Button CustomizationButton Customization
Fx2 Button
Fx2 Button
Fx2 Button
Fx2 ButtonFx2 Button
AF/AE-L Button
AF/AE-L Button
AF/AE-L Button
AF/AE-L ButtonAF/AE-L Button
E-Dial Programming
E-Dial Programming
E-Dial Programming
E-Dial ProgrammingE-Dial Programming
Fx1 Button
Fx1 Button
Fx1 Button
Fx1 ButtonFx1 Button
Setting PageFunction
Fx1 Button
Fx2 Button
One Push
File Format
Temporarily changes
the file format. p.99
Wi-Fi Turns the Wi-Fi™
function on or off. p.96
Outdoor
View Setting
Adjusts the brightness
of the monitor for
outdoor shooting.
p.102
Night Vision
LCD Display
Turns the Night Vision
LCD Display on or off. p.120
Preview
Displays the preview
image to check the
composition,
exposure, and focus
before shooting.
p.100
Electronic
Level
Turns the Electronic
Level display for the
viewfinder and Live
View on or off.
p.19
Change AF
Area
Switches the function
of the arrow keys to
the AF area change
mode or the direct key
operation mode.
p.63,
p.64
6
Settings
99
4Press E.
5Press F.
The screen of Step 2 reappears.
Repeat Steps 2 to 5.
6Press F twice.
t Memo
You can check the functions assigned to the buttons while the
Guide Display (p.45) is shown.
You can assign the same function to both X and Y.
When [AE Lock], [One Push File Format], [Wi-Fi], [Night
Vision LCD Display], or [Electronic Level] is assigned to a
button, pressing the button makes a beep sound. To disable
the beep sound, change the sound setting for each function
in [Sound Effects] of the D1 menu. (p.31)
You can temporarily change the file format by pressing X or
Y during shooting. By default, [One Push File Format] is
assigned to X.
Select the file format to change to when X or Y is pressed
for each [File Format] setting.
1Set [Fx1 Button] or [Fx2 Button] to [One Push
File Format] in Step 3 of “Setting the Button
Operation” (p.98).
2Select Z or Y for [Cancel after 1 shot].
3Select the file format when
X Y or is pressed.
The left side is the [File Format]
setting and the right side is the
changed file format when X or
Y is pressed.
4Press F three times.
The camera returns to standby mode.
AF/AE-L
Button
Enable AF1
Autofocus is
performed when
f is pressed.
p.61Enable AF2
Autofocus is
performed when
f is pressed. Half
press of 0 is
disabled.
Cancel AF
While f is
pressed, half press of
0 is disabled.
AE Lock Locks the exposure
setting. p.53
Setting Function Page
Setting the One Push File Format
Z
The recording format returns to the [File Format]
setting of [Image Capture Settings] in the A2 menu
after a picture is taken.
Y
The setting is retained until any of the following
operations is performed:
When X or Y is pressed again
When 3 F G, , or is pressed, or when the
mode dial or main switch is turned
Fx1 Button
Cancel after 1 shot
One Push File Format
Cancel
OK
6
Settings
100
You can display the preview image by pressing X or Y
before shooting.
1Set [Fx1 Button] or [Fx2 Button] to [Preview] in
Step 3 of “Setting the Button Operation” (p.98).
2Select a preview method in
[Preview Selection] and
press E.
Proceed to Step 4 when U is selected.
3Press and select BY or
Z for each display item.
4Press F three times.
The camera returns to standby mode.
t Memo
Optical Preview is always used in the following situations
regardless of the setting.
When the drive mode is set to [Mirror Lock-up Shooting],
[Multi-exposure], or [Interval Shooting]
When using the ASTROTRACER function
In C mode
u Caution
The effects of some functions cannot be checked during
Digital Preview or are not applied to the saved preview image.
Setting the Preview
U
Optical Preview
Activates the Optical Preview function to
check the depth of field with the
viewfinder.
f
Digital Preview
Activates the Digital Preview function to
check the composition, exposure, and
focus on the monitor.
You can magnify or save the preview
image.
Fx1 Button
Fx1 Button
Fx1 Button
Fx1 Button
Fx1 Button
Preview
Preview
Preview
Preview
Preview
Preview Selection
Preview Selection
Preview Selection
Preview Selection
Preview Selection
For checking depth of
For checking depth of
For checking depth of
For checking depth of
For checking depth of
field with viewfinder
field with viewfinder
field with viewfinder
field with viewfinder
field with viewfinder
Cancel
Cancel
Cancel
Cancel
Cancel
OK
OK
OK
OK
OK
Fx1 Button
Fx1 Button
Fx1 Button
Fx1 Button
Fx1 Button
Preview
Preview
Preview
Preview
Preview
Zoom Review
Zoom Review
Zoom Review
Zoom Review
Zoom Review
Save Preview Image
Save Preview Image
Save Preview Image
Save Preview Image
Save Preview Image
Histogram Display
Histogram Display
Histogram Display
Histogram Display
Histogram Display
Highlight Alert
Highlight Alert
Highlight Alert
Highlight Alert
Highlight Alert
Preview Selection
Preview Selection
Preview Selection
Preview Selection
Preview Selection
6
Settings
101
For each exposure mode, you can set the functions for when
Q R M and are turned and is pressed.
The function can be set for exposure modes other than M
mode.
1Select [E-Dial Programming] of [Button
Customization] in A5 or 2 menu and press C
D.
The [E-Dial Programming] screen appears.
2Select an exposure mode and press D.
The screen for the selected exposure mode appears.
3Press D and use AB to
select the combination of
functions for when Q
and R are turned and M
is pressed.
4Press E.
5Press F.
The [E-Dial Programming] screen reappears.
Repeat Steps 2 to 5.
6Press F twice.
t Memo
If you select [Rotation Direction] in Step 2, you can reverse
the effect obtained by turning Q or R.
You can check the functions assigned to Q, R, and M
while the Guide Display (p.45) is shown.
Setting the E-dial Operation
IChange Shutter Speed
JChange Aperture Value
ISO Change Sensitivity
eEV Compensation
XGReturn to G Mode
GSHIFT Program Shift
GLINE Program Line
-- Not available
Exposure Mode
Exposure Mode
Exposure Mode
Exposure ModeExposure Mode
Cancel
Cancel
Cancel
CancelCancel OK
OK
OK
OKOK
6
Settings
102
You can adjust the brightness, saturation, and color of the
monitor.
1Select [LCD Display Settings] in D2 menu and
press D.
The [LCD Display Settings] screen appears.
2Adjust the brightness,
saturation, and color.
Available operations
3Press E.
The D2 menu reappears.
If the monitor display is difficult to see
when you take pictures outdoors or in
other situations, adjust the brightness
of the monitor in [Outdoor View
Setting] of the D2 menu.
t Memo
When [Outdoor View Setting] is assigned to X or Y in
[Button Customization] of the A5 menu, you can adjust the
brightness of the monitor by a simple button operation. (p.98)
You can set whether to light up each
indicator lamp in [Indicator Lamps] of
the D2 menu.
Setting the Monitor and Indicator
Lamps D2
LCD Display Settings
AB Selects a parameter.
CD Adjusts the value.
MResets the adjustment value to the default
setting.
±0
±0
±0
±0± 0
LCD Display Settings
LCD Display Settings
LCD Display Settings
LCD Display SettingsLCD Display Settings
Brightness Level
Brightness Level
Brightness Level
Brightness LevelBrightness Level
OK
OK
OK
OKOK
Cancel
Cancel
Cancel
CancelCancel
Outdoor View Setting
Indicator Lamps
Other Indicator Lamps High, Low, Off
Self-timer On, Off
Remote Control On, Off
GPS LED Indicators On, Off
2
Outdoor View Setting
Night Vision LCD Display
Indicator Lamps
LCD Display Settings
Exit
Indicator Lamps
Self-timer
Remote Control
GPS LED Indicators
Other Indicator Lamps
6
Settings
103
Three factory preset settings—CLEAR TONE, HDR
LANDSCAPE, and ASTROPHOTO—are assigned to O Q to
of the mode dial. You can save your favorite camera settings to
O Q to and replace the preset settings with them.
The following settings can be saved.
1Set the exposure mode and all the necessary
settings to save.
2Select [Save USER Mode] in A5 menu and
press D.
The [Save USER Mode] screen appears.
3Select [Save Settings] and
press D.
The [Save Settings] screen
appears.
4Select a USER mode from [USER1] to [USER3],
and press D.
5Select [Save] and press E.
The screen of Step 3 reappears.
u Caution
[Save USER Mode] cannot be selected when the mode dial
is set to R or S.
t Memo
The settings saved as the USER mode can be displayed on
the monitor when you select [Check Saved Settings] in Step
3.
To reset the saved settings to their default values, select
[Reset USER Mode] in Step 3.
You can change the name of the USER mode in which you
saved settings.
1Select [Rename USER Mode] in Step 3 of
“Saving the Settings” (p.103) and press D.
The [Rename USER Mode] screen appears.
2Select a USER mode from [USER1] to [USER3],
and press D.
The text-entry screen appears.
Saving Frequently Used Settings A5
Exposure Mode (G, H,
I J K L M, , , , )
Sensitivity
EV Compensation
AF Active Area
Flash Mode
Drive Mode
White Balance
Custom Image
A menu settings (with
exceptions)
E menu settings
Saving the Settings
Save USER Mode
Save USER Mode
Save USER Mode
Save USER Mode
Save USER Mode
Rename USER Mode
Rename USER Mode
Rename USER Mode
Rename USER Mode
Rename USER Mode
Check Saved Settings
Check Saved Settings
Check Saved Settings
Check Saved Settings
Check Saved Settings
Reset USER Mode
Reset USER Mode
Reset USER Mode
Reset USER Mode
Reset USER Mode
Save Settings
Save Settings
Save Settings
Save Settings
Save Settings
Editing a Setting Name
6
Settings
104
3Change the text.
Up to 18 single-byte
alphanumeric characters and
symbols can be entered.
Available operations
4After entering the text, move the text selection
cursor to [Finish], and press E.
The [Rename USER Mode] screen reappears.
1Set the mode dial to O to Q.
The USER mode name is
displayed.
Use AB to check the saved
settings.
2Change the settings as necessary.
The exposure mode can be
changed in [Exposure Mode] of
the 1 menu.A
t Memo
The settings changed in Step 2 are not saved as the USER
mode settings. When the camera is turned off, the camera
returns to the saved USER settings. To change the saved
settings, save the USER mode settings again.
ABCD Moves the text selection cursor.
RMoves the text input cursor.
JSwitches between upper and lower case
letters.
EEnters a character selected with the text
selection cursor at the position of the text
input cursor.
LDeletes a character at the position of the
text input cursor.
A
A
A
A
A
B
B
B
B
B
C
C
C
C
C
D
D
D
D
D
E
E
E
E
E
F
F
F
F
F
G
G
G
G
G
H
H
H
H
H
I
I
I
I
I
J
J
J
J
J
K
K
K
K
K
L
L
L
L
L
M
M
M
M
M
N
N
N
N
N
O
O
O
O
O
P
P
P
P
P
Q
Q
Q
Q
Q
R
R
R
R
R
S
S
S
S
S
T
T
T
T
T
U
U
U
U
U
V
V
V
V
V
W
W
W
W
W
X
X
X
X
X
Y
Y
Y
Y
Y
Z
Z
Z
Z
Z
0
0
0
0
0
1
1
1
1
1
2
2
2
2
2
3
3
3
3
3
4
4
4
4
4
5
5
5
5
5
6
6
6
6
6
7
7
7
7
7
8
8
8
8
8
9
9
9
9
9
A
A
A
A
A
B
B
B
B
B
C
C
C
C
C
Rename USER Mode
Rename USER Mode
Rename USER Mode
Rename USER Mode
Rename USER Mode
Cancel
Cancel
Cancel
Cancel
Cancel
Delete One Character
Delete One Character
Delete One Character
Delete One Character
Delete One Character
Enter
Enter
Enter
Enter
Enter
Finish
Finish
Finish
Finish
Finish
Text selection cursor
Text input cursor
Using the Saved USER Mode
1
Exposure Mode
AF with Viewfinder
Custom Image
AF with Live View
AF Assist Light
AE Metering
Cancel
OK
6
Settings
105
The date and time set at the time of initial setting (“Initial Settings”
(p.42)) serve as the date and time of your present location and
are reflected in the shooting date and time for images.
Setting the destination to a location other than your present
location enables you to display the local date and time on the
monitor when traveling abroad and also save images time-
stamped with the local date and time.
1Select [World Time] in D1 menu.
The [World Time] screen appears.
2Select the time you wish to
display in [Time Setting].
F G (Hometown) or
(Destination) can be selected.
3Select [G Destination] and press D.
The [G Destination] screen appears.
4Use CD to select a city.
Use R to change the region.
5Select [DST] (daylight saving time), and use CD
to select Y or Z.
6Press E.
The screen of Step 2 reappears.
7Press F twice.
t Memo
Refer to “List of World Time Cities” (p.131) for cities that can
be selected as a hometown or destination.
Select [F Hometown] in Step 3 to change the city and DST
settings for the hometown.
G and the local date and time appear in the control panel
when [Time Setting] is set to G.
The setting values for most functions of this camera are saved
even if the camera is turned off. For the following function
settings, you can select whether to save the settings (Z) or to
return the settings to their default values (Y) when the camera
is turned off.
Set in [Memory] of the A5 menu.
t Memo
When [Reset] of the D5 menu is performed, all Memory
settings return to the default values.
Displaying the Local Date and Time of
the Specified City D1
World Time
World Time
World Time
World TimeWorld Time
Time Setting
Time Setting
Time Setting
Time SettingTime Setting
Destination
Destination
Destination
DestinationDestination
London
London
London
LondonLondon
Hometown
Hometown
Hometown
HometownHometown
New Y
New Y
New Y
New York
ork
ork
orkNew York
16:00
16:00
16:00
16:0016:00
10:00
10:00
10:00
10:0010:00
Destination
Destination
Destination
Destination
Destination
London
London
London
London
London
DST
DST
DST
DST
DST
+6:00
+6:00
+6:00
+6:00
+6:00
16:00
16:00
16:00
16:00
16:00
Cancel
Cancel
Cancel
Cancel
Cancel
OK
OK
OK
OK
OK
Selecting Settings to Save in the
Camera A5
Sensitivity
EV Compensation
Flash Mode
Flash Exposure Compensation
Drive Mode
White Balance
Custom Image
Clarity
Skin Tone
Digital Filter
HDR Capture
Pixel Shift Resolution
Shooting Info Display
Playback Info Display
Outdoor View Setting
Night Vision LCD Display
6
Settings
106
You can protect images from being accidentally deleted.
u Caution
Even protected images are deleted if the inserted memory
card is formatted.
1Select f in the playback mode palette.
The screen for selecting the processing type appears.
2Select [Select image(s)] or
[Select a folder] and press
E.
3Select the image(s) or folder to protect.
Refer to Step 2 of “Deleting Selected Images” (p.84) for how
to select image(s).
Proceed to Step 5 if [Select a folder] is selected.
4Press G.
The confirmation screen appears.
5Select [Protect] and press E.
t Memo
To protect all images stored on the memory card, select
[Protect All Images] of the B1 menu.
File Management Settings
Protecting Images from Deletion (Protect)
Select image(s)
Select image(s)
Select image(s)
Select image(s)
Select image(s)
Select a folder
Select a folder
Select a folder
Select a folder
Select a folder
OK
OK
OK
OK
OK
6
Settings
107
When [Create New Folder] is selected in the D4 menu, a folder
is created with a new number when the next image is saved.
u Caution
You cannot successively create multiple folders.
t Memo
A new folder is automatically created in the following cases.
When the drive mode is set to [Interval Shooting] (p.71)
When [Select multiple images] or [Select a folder] is
selected for [RAW Development] of the playback mode
palette (p.92)
When images are captured with this camera, a folder is
automatically created and the captured images are stored in it.
Each folder name consists of a sequential number from 100 to
999 and a string of 5 characters.
The character string in the folder name can be changed.
1Select [Folder Name] in D4 menu and press D.
The [Folder Name] screen appears.
2Press D and select [Date]
or [Optional].
Proceed to Step 6 if you select [Date] or do not need to
change the character string.
3Press B, and then press D.
The text-entry screen appears.
4Change the text.
Enter five single-byte
alphanumeric characters.
Selecting the Folder/File Settings
D4
Create New Folder
Folder Name
Date
The four digits of the month and day of the
shooting date are assigned after the folder
number.
The month and day appear according to the
date format set in [Date Adjustment].
Example) 101_0125: for images taken on
January 25th
Optional
A freely defined string of five characters is
assigned after the folder number.
(Default setting: PENTX)
Example) 101PENTX
P
E
N
T
X
A B C D E F G H I J K L M
N O P Q R S T U V W X Y Z
0123456789 _
Folder Name
Cancel
Reset
Enter
Finish
Text selection cursor
Text input cursor
6
Settings
108
Available operations
5After entering the text, move the text selection
cursor to [Finish], and press E.
6Press F twice.
t Memo
A folder with a new number is created when the folder name
is changed.
A maximum of 500 images can be stored in a single folder.
When the number of captured images exceeds 500, a new
folder is created with the number following the number of the
folder currently being used. When the drive mode is set to
[Bracketing], images are stored in the same folder until
shooting is completed.
u Caution
The maximum folder number is 999. After the folder number
reaches 999, you cannot capture new images if you attempt
to change the folder name or create a new folder, or when the
file name number reaches 9999.
One of the following string of characters is used as the file name
prefix depending on the [Color Space] setting of [Image Capture
Settings] in the A2 menu.
The first four characters can be changed to a character string of
your choice.
1Select [File Name] in D4 menu and press D.
The [File Name] screen appears.
2Select A or C, and press
D.
The text-entry screen appears.
3Change the text.
Up to four single-byte alphanumeric characters can be
entered as an alternative for the first part of the file name,
while the asterisks stand for figures that increase
automatically shot by shot.
Refer to Steps 4 and 5 of “Folder Name” (p.107) for how to
enter text.
4Press F twice.
ABCD Moves the text selection cursor.
RMoves the text input cursor.
EEnters a character selected with the text
selection cursor at the position of the text
input cursor.
MResets the entered text to “PENTX”.
File Name
Color Space File Name
sRGB IMGP

.JPG
AdobeRGB _IMG

.JPG
6
Settings
109
t Memo
When [Color Space] is set to [AdobeRGB], the file name
prefix is “_” and first three characters of the entered character
string becomes the file name.
For movies, regardless of the [Color Space] setting, the file
name is “IMGP

.MOV” or the one with the entered string
of characters.
Each file name consists of a string of
four characters and a sequential
number from 0001 to 9999. You can
set whether to continue the
sequential numbering for the file
name even if a new folder is created
in [Sequential Numbering] of [File
No.] in the D4 menu.
Select [Reset File Number] to reset the file number to its default
value.
t Memo
When the file number reaches 9999, a new folder is created
and the file number is reset.
Sets the photographer and copyright information embedded in
the Exif data.
1Select [Copyright Information] in D4 menu and
press D.
The [Copyright Information] screen appears.
2Use CD to set [Embed
Copyright Data].
3Select [Photographer] or [Copyright Holder],
and press D.
The text-entry screen appears.
4Change the text.
Up to 32 single-byte alphanumeric characters and symbols
can be entered.
Refer to Steps 3 and 4 of “Editing a Setting Name” (p.103)
for how to enter text.
5Press F twice.
t Memo
The Exif information can be checked in Detailed Information
Display of the playback mode (p.17) or using the provided
software “Digital Camera Utility 5”.
File No.
ZContinues the sequential numbering for the file name
even if a new folder is created.
YReturns the file number of the first image saved to a
folder to 0001 each time a new folder is created.
File No.
File No.
File No.
File No.File No.
Sequential Numbering
Sequential Numbering
Sequential Numbering
Sequential NumberingSequential Numbering
Reset File Number
Reset File Number
Reset File Number
Reset File NumberReset File Number
Uses sequential file number
Uses sequential file number
Uses sequential file number
Uses sequential file numberUses sequential file number
in new folder based on last
in new folder based on last
in new folder based on last
in new folder based on lastin new folder based on last
number in previous folder
number in previous folder
number in previous folder
number in previous foldernumber in previous folder
Setting the Copyright Information D4
YDoes not embed copyright information in the Exif
data.
ZEmbeds copyright information in the Exif data.
Copyright Information
Embed Copyright Data
Photographer
Copyright Holder
7
110
Appendix
#: Restricted ×: Not available
Restrictions on Each Capture Mode
Capture Mode
Function
R
S
MC
b
cd
im
q
eo f
gh
js
tv
k l p u
Sensitivity × × × *1
Flash × × × ×
Drive Mode
Continuous
Shooting Z*2 ×Z*2 × ×
Self-timer × × ×
Remote Control × × Q*3
Bracketing × × × × ×
Multi-exposure × × × ×
Interval Shooting × × × ×
Interval
Composite × × × × ×
Interval Movie
Record × × × ×
Star Stream × × × × ×
AF with Viewfinder z *2 x*2 x*2 y*2 x*2 x*2 x*2 y*2 y*2 y*2
7
111
Appendix
*1 [ISO AUTO] is not available.
*2 Fixed to; the setting cannot be changed.
*3 Limited to; available settings are limited.
*4 Fixed to; specific settings to the selected mode are used.
*5 Fixed to [HDR AUTO].
*6 [Bracketing] is not available.
File Format
RAW/RAW+ ×
White Balance g *2 g*2 g*2 g*2 g*2 g*2 g*2 g*2 g*2 g*2
Custom Image ×*4 ×*4 ×*4 ×*4 ×*4 ×*4 ×*4 ×*4 ×*4 ×*4
Clarity/Skin Tone ×
Digital Filter ×
HDR Capture × ×*5 × × ×
Pixel Shift Resolution × × × × ×
AA Filter Simulator # *6 ×#*6 #*6 ×
Shake Reduction On *2 ×
Save RAW Data × × ×
Capture Mode
Function
R
S
MC
b
cd
im
q
eo f
gh
js
tv
k l p u
7
112
Appendix
#: Restricted ×: Not available
*1 There is a restriction on the minimum value for [Interval].
*2 [Bracketing] is not available.
*3 Only the final frame can be saved.
Restrictions on the Combinations of Special Functions
Clarity/
Skin Tone/
Digital Filter
HDR
Capture
Pixel Shift
Resolution
ASTRO-
TRACER
AA Filter
Simulator
Distortion
Correction/
Diffraction
Correction
Save RAW
Data
Flash × ×
Drive Mode
Continuous
Shooting ×××#*2 ×
Bracketing ×××#*2
Mirror Lock-up
Shooting ×#*2
Multi-exposure × × × × #*2 ×
Interval Shooting # *1 #*1 × × #*2 #*3
Interval Composite × × × × #*2 ×#*3
Interval Movie
Record #*1 #*1 × × #*2 ×
Star Stream × × × × #*2 × ×
HDR Capture × × × ×
Pixel Shift Resolution × × × ×
AA Filter Simulator × × #*2
7
Appendix
113
All capture modes are available when a DA, DA L, D FA, FA J,
or FA lens is used, or when a lens with an
9
position is used with
the aperture ring set to the
9
position.
Depending on the lens to use, the following restrictions apply.
x: Available #: Restricted ×: Not available
*1 Lenses with a maximum aperture of F2.8 or faster. Only available at
the 9 position.
*2 Lenses with a maximum aperture of F5.6 or faster.
*3 Available when using the built-in flash, AF540FGZ, AF540FGZ II,
AF360FGZ, AF360FGZ II, AF201FG, AF200FG, or AF160FC.
*4 Only available with compatible lenses.
*5 Distortion Correction and Peripheral Illumination Correction are
disabled when a DA FISH-EYE 10-17mm lens is used.
*6 To use an FA SOFT 28mm F2.8 lens, FA SOFT 85mm F2.8 lens, or
F SOFT 85mm F2.8 lens, set [24 Using Aperture Ring] to [Enable] in
the E4 menu. Pictures can be taken with the aperture you set, but
only within a manually adjustable aperture range.
*7 The Lens Correction features are available with the following FA
lenses (Only Distortion Correction and Lateral Chromatic Aberration
Adjustment can be used when the aperture ring is set to a position
other than 9.): FA k24mm F2 AL [IF], FA 28mm F2.8 AL, FA 31mm
F1.8 Limited, FA 35mm F2 AL, FA 43mm F1.9 Limited, FA 50mm
F1.4, FA 77mm F1.8 Limited, FA k85mm F1.4 [IF], FA k200mm F2.8
ED [IF], FAkMACRO 200mm F4 ED, FA k300mm F2.8 ED [IF],
FAk300mm F4.5 ED [IF], FA k400mm F5.6 ED [IF], FA k600mm F4
ED [IF], FAk28-70mm F2.8 ED [IF], FA k80-200mm F2.8 ED [IF],
and FA k250-600mm F5.6 ED [IF].
*8 Fixed to [Spot].
*9 J with the aperture set to wide open. (The aperture ring has no
effect on the actual aperture value.)
u Caution
When the aperture ring is set to a position other than 9 or a
lens without an 9 position or accessories such as an
extension tube are used, the camera does not operate unless
[24 Using Aperture Ring] is set to [Enable] in the E4 menu.
Refer to “Using the Aperture Ring” (p.115) for details.
When a retractable lens is attached and is not extended, you
cannot take pictures or use some functions. If the lens is
retracted during shooting, the camera stops working.
Functions Available with Various
Lenses
Lens
[Mount type]
Function
DA
DA L
D FA
FA J
FA *6 F *6 AM
P
[KAF]
[KAF2]
[KAF3]
[KAF4]
[KAF]
[KAF2]
[KAF] [KA] [K]
Autofocus
(Lens only)
(With AF adapter 1.7×) *1
x
x
x
#
#
Manual focus
(With focus indicator) *2
(With matte field)
xxxxx
Quick-shift focus # *4 ××××
AF Active Area [Auto] x x x # *8 ×
AE Metering [Multi-segment] x x x x ×
G H I J K/ / / / mode x x x x # *9
L mode x x x x #
P-TTL auto flash *3 xxxx ×
Automatic obtaining of the
lens focal length information xxx × ×
Lens Correction x *5 # *7 ×××
7
Appendix
114
Depending on the lens being used, the use of the built-in flash
may be limited.
(As of June 2022)
About Mount Names
DA and D FA lenses with a motor and FA zoom lenses with
a power zoom use the KAF2 mount. (Of these lenses, the
lenses without an AF coupler use the KAF3 mount.)
The KAF3 mount equipped with an electromagnetic
diaphragm mechanism instead of an aperture control lever is
referred to as the KAF4 mount.
FA single focal length lenses (non-zoom lenses), DA and DA
L lenses without a motor, and D FA, FA J, and F lenses use
the KAF mount. (The power zoom function is not compatible
with this camera.)
Refer to respective lens manuals for details.
Compatibility with the Built-in Flash
Lens Restrictions when using
the built-in flash
DA FISH-EYE 10-17mm
F3.5-4.5 ED [IF]/
DA
k
11-18mm F2.8 ED DC AW/
DA 12-24mm F4 ED AL/
DA 14mm F2.8 ED [IF]/
DA 15mm F4 ED AL/
D FA 15-30mm F2.8 ED SDM WR/
D FA 21mm F2.4 ED
Limited DC WR/
FAk300mm F2.8 ED [IF]/
DAk560mm F5.6 ED AW/
FAk600mm F4 ED [IF]/
FA
k
250-600mm F5.6 ED [IF]
The built-in flash is not
available due to vignetting.
F FISH-EYE 17-28mm
F3.5-4.5
Vignetting may occur if the
focal length is less than 20 mm.
DA 16-45mm F4 ED AL
When the focal length is less
than 28 mm, or when the focal
length is 28 mm and the
shooting distance is 1 m or less,
vignetting may occur.
DAk16-50mm F2.8 ED AL
[IF] SDM
When the focal length is 20 mm
or less, or when the focal length
is 35 mm and the shooting
distance is less than 1.5 m,
vignetting may occur.
7
Appendix
115
The shutter can be released even if the aperture ring of the D
FA, FA, F, or A lens is not set to the 9 position or a lens without
an 9 position is attached.
Select [Enable] in [24 Using Aperture
Ring] of the E4 menu.
The following restrictions apply depending on the lens being
used.
*1 When the mode dial is set to L or M, the aperture can be stopped
down to the selected value.
DA 16-85mm F3.5-5.6 ED
DC WR
When the focal length is 24 mm
or less and the shooting
distance is 0.8 m or less,
vignetting may occur.
DA 17-70mm F4 AL [IF]
SDM
When the focal length is less
than 24 mm, or when the focal
length is 35 mm and the
shooting distance is 1 m or less,
vignetting may occur.
DA 18-250mm F3.5-6.3 ED
AL [IF]
Vignetting may occur if the
focal length is less than 35 mm.
DA 18-270mm F3.5-6.3 ED
SDM
Vignetting may occur if the
focal length is less than 24 mm.
D FA 24-70mm F2.8 ED
SDM WR
Vignetting may occur if the
focal length is less than 36 mm.
FA k28-70mm F2.8 AL
Vignetting may occur if the
focal length is 28 mm and the
shooting distance is less than
1 m.
FA SOFT 28mm F2.8/
FA SOFT 85mm F2.8
The built-in flash always
discharges fully.
Lens Restrictions when using
the built-in flash
Using the Aperture Ring E4
Lens Restriction
D FA, FA, F, A, M (lens
only or with automatic
diaphragm accessories
such as auto extension
tube K)
The aperture remains open *1.
The shutter speed changes in
relation to the open aperture but
an exposure deviation may occur.
D FA, FA, F, A, M, S (with
diaphragm accessories
such as extension tube K) Pictures can be taken with the set
aperture value but an exposure
deviation may occur.
Manual diaphragm lens
such as reflex lens (lens
only)
FA SOFT 28mm/
FA SOFT 85mm/
F SOFT 85mm
(lens only)
Pictures can be taken with the set
aperture value within a manually
adjustable aperture range *1.
7
Appendix
116
t Memo
If the aperture ring is set to a position other than 9, the
camera operates in J mode regardless of the mode dial
setting except when set to L or M mode.
[F--] appears for the aperture indicator in the status screen,
Live View screen, and viewfinder.
You can perform Catch-in Focus shooting using a manual focus
lens. The shutter is released automatically when the subject
comes into focus.
1Attach a manual focus lens to this camera.
2Set [22 Catch-in Focus] to [On] in the E4 menu.
3Set the focus method to v and set [AF Mode]
to x.
4Place the camera on a fixed support such as
tripods.
5Adjust the focus to the position where the
subject may pass and press 0 fully.
When the subject comes into focus at the specified position,
the shutter is released automatically.
How to Achieve the Correct Exposure with the Aperture
Ring Not Set to 9
The correct exposure can be achieved by the following
procedures when the aperture ring is not set to 9.
1 Set the mode dial to L.
2 Set the aperture ring to the desired aperture.
3 Press M.
The correct shutter speed will be set.
4 If the correct exposure cannot be achieved, adjust the
ISO sensitivity.
Performing Catch-in Focus Shooting
E4
7
Appendix
117
The Shake Reduction function operates by obtaining the lens
information such as focal length. Set the focal length when
using a lens that the focal length information cannot be
automatically obtained.
1Set [24 Using Aperture Ring] to [Enable] in the
E4 menu.
2Turn the camera off.
3Attach a lens to the camera and turn the camera
on.
The [Input Focal Length] screen appears.
4Use AB to set the focal
length.
Press C to select a value from
the list.
When using a zoom lens, select
the actual focal length which the
zoom is set to.
5Press E.
The camera returns to standby mode.
t Memo
The focal length setting can be changed in [Input Focal
Length] of the A4 menu.
Use of the following external flashes (optional) enables a variety
of flash modes, such as P-TTL auto flash mode.
x: Available #: Restricted ×: Not available
Setting the Focal Length A4
3
3
3
35
5
5
5
35
mm
mm
mm
mm
mm
OK
OK
OK
OK
OK
Input Foc
Input Foc
Input Foc
Input Focal Length
al Length
al Length
al Length
Input Focal Length
Functions when Using an
External Flash
Compatible Flash
Camera Function
Built-in
Flash
AF540FGZ
AF540FGZ II
AF360FGZ
AF360FGZ II
AF201FG
AF200FG
AF160FC
Red-eye reduction flash x x x
Auto Flash Discharge x x x
Automatic switch to the flash
sync speed xxx
Automatic setting of the
aperture value in G or I
mode
xxx
P-TTL auto flash x *1 x *1 x *1
Slow-speed Sync flash x x x
Flash Exposure
Compensation xxx
AF assist light of the external
flash × x *2 ×
Trailing Curtain Sync flash *3 x x # *4
Contrast Control Sync flash # *5 x # *6
Slave flash ×x×
High-speed Sync flash ×x×
7
Appendix
118
*1 Available only when using a DA, DA L, D FA, FA J, FA, F, or A lens.
(When using a lens with an aperture ring, set the aperture ring to the
9 position.)
*2 AF assist light is not available with the AF540FGZ or AF360FGZ.
*3 Shutter speed of 1/90 seconds or slower.
*4 Available with the AF201FG.
*5 When combined with the AF540FGZ, AF540FGZ II, AF360FGZ, or
AF360FGZ II, 1/3 of the flash discharge can be output by the built-in
flash and 2/3 can be output by the external flash.
*6 Available only when combined with the AF540FGZ, AF540FGZ II,
AF360FGZ, or AF360FGZ II.
u Caution
Never press 1 on the camera when any external flash unit
is attached to the camera. The built-in flash will hit the
external flash. If you want to use both at once, connect them
using an extension cord.
Flashes with the reversed polarity (the center contact on the
hot shoe is minus) cannot be used due to the risk of damaging
the camera and flash.
Do not combine with accessories that have a different
number of contacts, such as Hot Shoe Grip, as a malfunction
may occur.
Combining with flashes from other manufacturers may cause
equipment breakdown.
t Memo
With the AF540FGZ, AF540FGZ II, AF360FGZ, or
AF360FGZ II, you can use the high-speed sync flash to
discharge a flash and take a picture at a shutter speed faster
than 1/180 seconds. Set the capture mode to I, K, or L.
In addition to GPS information being saved in the shooting
information of the image, the following functions are available when
the optional GPS unit O-GPS1/O-GPS2 is attached to this camera.
t Memo
Refer to the manual of the GPS unit for details on how to
attach the unit and information on the unit’s functions.
To display [Electronic Compass], refer to “Shooting Info
Display” (p.15).
u Caution
“Simple Navigation” cannot be used with this camera.
Using the GPS Unit
Electronic
Compass
Displays the
current latitude,
longitude,
altitude, direction,
Coordinated
Universal Time
(UTC), capture mode, and exposure value.
ASTROTRACER
Tracks and captures celestial bodies.
By matching the movement of the camera’s
built-in Shake Reduction unit with the
movement of celestial bodies, celestial
bodies can be captured as individual points
even when shooting with a long exposure
setting. (p.119)
GPS Time Sync
Automatically adjusts the camera’s date
and time settings using information
obtained from GPS satellites.
Set in [GPS/E-Compass] of the D3 menu.
7
Appendix
119
1Attach the GPS unit to the camera and turn the
camera on.
2Select [ASTROTRACER] in A3 menu and press
D.
The [ASTROTRACER] screen appears.
3Select [ASTROTRACER] and press D.
4Select [On] and press E.
5Select [Precise Calibration] and press D.
The [Precise Calibration] screen appears.
6Rotate the camera
according to the
instruction displayed on
the monitor.
The result of calibration appears.
7Press E.
The screen of Step 4 reappears.
If [The operation could not be completed correctly] appears,
change the camera direction and perform a calibration
again.
8Press F twice.
The camera returns to standby mode.
u Caution
When performing a calibration, be careful not to drop the
camera. Wrap the strap around your wrist or take other
preventive measures.
If the battery is removed, perform a calibration again after the
battery is put back in.
As the magnetic field environment varies depending on the
shooting location, a precise calibration must be performed at
each location when shooting images of celestial bodies with
ASTROTRACER.
Changing the lens or the angle of the monitor after performing
a calibration may have some effect on the magnetic field
environment. In this case, perform a calibration again.
Shooting Celestial Bodies
(ASTROTRACER)
Setting the ASTROTRACER A3
Enables ASTROTRACER function
Enables ASTROTRACER function
Enables ASTROTRACER function
Enables ASTROTRACER functionEnables ASTROTRACER function
in Bulb mode to eliminate star
in Bulb mode to eliminate star
in Bulb mode to eliminate star
in Bulb mode to eliminate star in Bulb mode to eliminate star
trails during timed exposures
trails during timed exposures
trails during timed exposures
trails during timed exposuresrails during timed exposures
ASTROTRACER
ASTROTRACER
ASTROTRACER
ASTROTRACERASTROTRACER
ASTROTRACER
ASTROTRACER
ASTROTRACER
ASTROTRACERASTROTRACER
Precise Calibration
Precise Calibration
Precise Calibration
Precise CalibrationPrecise Calibration
Cancel
Cancel
Cancel
CancelCancel OK
OK
OK
OKOK
Rotate camera in each of thr
Rotate camera in each of thr
Rotate camera in each of thr
Rotate camera in each of three
ee
ee
ee
Rotate camera in each of three
directions ensuring that each
directions ensuring that each
directions ensuring that each
directions ensuring that each
directions ensuring that each
rotation exceeds 180 degrees
rotation exceeds 180 degrees
rotation exceeds 180 degrees
rotation exceeds 180 degrees
rotation exceeds 180 degrees
Precise Calibration
Precise Calibration
Precise Calibration
Precise Calibration
Precise Calibration
Stop
Stop
Stop
Stop
Stop
7
Appendix
120
1Set the mode dial to M and set the focus method
to w.
2Set the shooting
conditions.
Available operations
3Adjust the focus and press 0 fully.
Shooting starts.
4Press 0 fully again.
Shooting stops.
When the timed exposure is enabled, shooting stops
automatically after the set time has elapsed.
u Caution
This function cannot be used in some capture modes or in
combination with some other functions. (p.110)
Shooting with the ASTROTRACER
M Enables/Disables the timed exposure.
Q Changes the exposure time within the range
from 10" to 5'00" when the timed exposure is
enabled.
R Changes the aperture value.
J Performs a precise calibration.
9
9
9
99
9
9
99
9
9
99
9
9
99
9
9
9
99999
F
F
F
F
F
8
8
8
8.
.
.
.0
0
0
0
8.0
1
1
1
16
6
6
60
0
0
00
0
0
0
160 0
When the Monitor is too Bright
For shooing in a dark place for a long period of time, you can
change the monitor display color to red by setting [Night
Vision LCD Display] to [On] in the D2 menu. When [Night
Vision LCD Display] is assigned to X or Y in [Button
Customization] of the A5 menu, you can turn the Night
Vision LCD Display on or off by a simple button operation.
(p.98)
7
Appendix
121
t Memo
In rare cases, the camera may not operate correctly due to
causes such as static electricity, etc. This can be remedied by
taking the battery out and putting it back in again. If the
camera operates correctly, it does not require any repairs.
Troubleshooting
Problem Cause Remedy
The camera does
not turn on.
The battery is not
installed properly.
Check the orientation of the
battery.
The battery power
is low. Charge the battery.
The shutter cannot
be released.
The built-in flash is
being charged. Wait until charging is finished.
There is no
available space on
the memory card.
Insert a memory card with
available space or delete
unwanted images.
Data is being
processed.
Wait until processing is
finished.
The lens aperture
ring is set to a
position other than
9.
Set the lens aperture ring to the
9 position or select [Enable] in
[24 Using Aperture Ring] of the
E4 menu. (p.115)
The autofocus
mode is set to
x and the
subject is not in
focus.
Set the focus method to w
and adjust focus manually.
Autofocus does
not work.
The subject is
difficult to focus
on.
v cannot work well for low-
contrast objects (the sky, white
walls, etc.), dark colors,
intricate designs, rapidly-
moving objects, or scenery shot
through a window or a net-like
pattern.
Lock the focus on another
object located at the same
distance as your subject, then
aim at the target and take a
picture. Alternatively, use w.
The subject is too
close.
Move away from the subject
and take a picture.
The focus cannot
be locked.
f is set for [AF
Active Area] of
Live View.
Set [AF Active Area] to e, 0,
h i, or . (p.63)
The built-in flash
does not
discharge.
The flash mode is
set to A or B.
When the flash mode is set to
A B or , the flash does not
discharge if the subject is
bright.
Change the flash mode. (p.59)
The camera is not
recognized when it
is connected to a
computer.
The USB
connection mode
is set to [PTP].
Set [USB Connection] to [MSC]
in the D3 menu.
Dust or dirt
particles appear in
images.
The CMOS sensor
is dirty or dusty.
Activate [Dust Removal] from
the 5 menu. The Dust D
Removal function can be
activated every time the camera
is turned on and off.
Refer to “Sensor Cleaning”
(p.122) if the problem persists.
Problem Cause Remedy
7
Appendix
122
Raise the mirror up and open the shutter when cleaning the
CMOS sensor with a blower.
1Turn the camera off and remove the lens.
2Turn the camera on.
3Select [Sensor Cleaning] in D5 menu and press
D.
The [Sensor Cleaning] screen appears.
4Select [Mirror Up] and press E.
The mirror rises up.
5Clean the CMOS sensor with a blower.
6Turn the camera off.
The mirror automatically returns to its original position.
Pixel defects such
as bright spots
and dark spots
appear in the
image.
There are
defective pixels in
the CMOS sensor.
Activate [Pixel Mapping] from
the D5 menu.
It takes about 30 seconds to
correct the defective pixels, so
be sure to install a fully charged
battery.
Problem Cause Remedy
Sensor Cleaning D5
7
Appendix
123
u Caution
Never use a spray blower or a blower with a brush. The
CMOS sensor may be damaged. Do not wipe the CMOS
sensor with a cloth.
Do not put the tip of the blower inside the lens mount area. If
the power is turned off during cleaning, it may cause damage
to the shutter, the CMOS sensor, and the mirror. Hold the
camera with the lens mount down while cleaning the sensor
so dust will fall away from the sensor when the blower is used.
When the battery level is low, the message [Not enough
battery power remaining to clean sensor] is displayed on the
monitor. Install a fully charged battery. If the battery capacity
becomes low during cleaning, a warning beep will sound. In
this case, stop cleaning immediately.
t Memo
Please contact your nearest service center for professional
cleaning as the CMOS sensor is a precision part.
You can use the optional Image Sensor Cleaning Kit O-ICK1
when cleaning the CMOS sensor.
Error Messages
Error Messages Description
Memory card full
The memory card is full and no more
images can be saved. Insert a new
memory card or delete unwanted files.
No image There are no images that can be played
back on the memory card.
This image cannot
be displayed
You are trying to play back an image in a
format not supported by this camera. You
may be able to play it back on a computer.
No card in the camera There is no memory card inserted in the
camera.
Memory card error
The memory card has a problem, and
image capture and playback are
impossible. You may be able to play back
or recover the images on a computer.
Card is not formatted
The memory card you have inserted is
unformatted or has been previously used
on another device and is not compatible
with this camera. Use the card after
formatting it with this camera.
Card is locked The write-protect switch on the memory
card you have inserted is locked. (p.139)
Cannot use this card A memory card not compatible with this
camera is inserted.
Wi-Fi connection disabled
The capture mode is changed to C
mode while the wireless LAN function is
enabled.
This image cannot
be magnified
You are trying to magnify an image that
cannot be magnified.
This image is protected
You are trying to delete an image that is
protected. Remove the protection from
the image. (p.106)
7
Appendix
124
Not enough battery
power remaining to
activate Pixel Mapping These messages appear when you try to
perform Pixel Mapping or Sensor
Cleaning, or to update the firmware if the
battery level is insufficient. Install a fully
charged battery.
Not enough battery
power remaining to
clean sensor
Not enough battery
power remaining to
update the firmware
Unable to update firmware.
There is a problem with the
firmware update file
The firmware cannot be updated. The
update file is damaged. Try downloading
the update file again.
Image folder cannot
be created
The maximum folder number (999) is
being used, and no more images can be
saved. Insert a new memory card or
format the card.
Unable to store image The image could not be saved because of
a memory card error.
The operation could not be
completed correctly
The operation failed. Try the operation
again.
No more images
can be selected
You are trying to select more than the
maximum number of images for the
following functions.
Select & Delete
RAW Development
• Protect
No image can be processed
There are no images that can be
processed using the Digital Filter or RAW
Development function.
This image cannot
be processed
This message appears when you try to
perform Resize, Cropping, Digital Filter,
Movie Edit, RAW Development, or Save
as Manual WB for images captured with
other cameras, or when you try to perform
Resize or Cropping for minimum file size
images.
Error Messages Description
This function is not available
in the current mode
You are trying to set a function that is not
available with the currently selected
capture mode.
The camera will turn off
to prevent damage from
overheating
The camera will turn off because its
internal temperature is too high. Leave
the camera turned off until it has had time
to cool down before turning on the
camera again.
Shutter release is disabled.
Ensure the zooming index on
the lens is set to a position
that permits shutter release
Pictures cannot be taken when a
retractable lens is attached and is not
extended. (p.46)
Error Messages Description
7
Appendix
125
Model Description
Image Capture Unit
File Formats
Viewfinder
Live View
LCD Monitor
Main Specifications
Type TTL autofocus, auto-exposure SLR digital camera
with a built-in retractable P-TTL flash
Lens Mount PENTAX KAF2 bayonet mount (AF coupler, lens
information contacts, K-mount with power contacts)
Usable Lenses KAF4, KAF3, KAF2 (power zoom not compatible),
KAF, KA mount lenses
Image Sensor
CMOS with a primary color filter, Size: 23.5 × 15.6 (mm)
Effective Pixels Approx. 24.24 megapixels
Total Pixels Approx. 24.78 megapixels
Dust Removal Image sensor movement combined with SP coating
Sensitivity
(Standard Output)
ISO AUTO, Manual ISO range: 100 to 102400
EV steps can be set to 1 EV, 1/2 EV, or 1/3 EV
Image Stabilizer Sensor-shift Shake Reduction (SR)
AA Filter
Simulator
Moiré reduction using SR unit: Off, Type1, Type2,
Bracketing (3 images)
Recording
Formats
RAW (PEF/DNG), JPEG (Exif 2.3 compliant), DCF
2.0 compliant
Recorded Pixels
JPEG: q (24M: 6000×4000), p (14M:
4608×3072), o (6M: 3072×2048), r (2M:
1920×1280)
RAW: 24M, 6000×4000
Quality Level
RAW (14bit): PEF, DNG
JPEG: m (Best), l (Better), k (Good)
RAW + JPEG simultaneously recordable
Color Space sRGB, AdobeRGB
Storage Media SD/SDHC*/SDXC* memory card
* UHS-I compatible
Storage Folder Folder Name: Date (100_1018, 101_1019...) or
user-assigned name (default: PENTX)
Storage File
File Name: user-assigned name (default:
IMGP

)
File No.: Sequential Numbering, Reset
Type Pentaprism Finder
Coverage (FOV) Approx. 100%
Magnification Approx. 0.95× (50mm F1.4 at infinity)
Eye-Relief Length Approx. 20.5 mm (from the view window)
Approx. 22.3 mm (from the center of lens)
Diopter
Adjustment Approx. -2.5 to +1.5 m -1
Focusing Screen Interchangeable Natural-Bright-Matte III focusing
screen
Type TTL method using the CMOS image sensor
Autofocusing
System
Hybrid AF of image plane phase-matching and
contrast detection
AF Active Area: Face Detection, Tracking, Multiple
AF Points, Select, Spot
Focus Peaking: On, Off
Display
Field of view: approx. 100%, Magnified view (up to
16×), Grid Display (4×4 Grid, Golden Section, Scale,
Square 1, Square 2, Grid Color: Black, White),
Histogram, Highlight Alert
Type Vari-angle TFT color LCD monitor featuring an air-
gapless structure with a tempered-glass front panel
Size 3.0 inches (aspect ratio 3:2)
Dots Approx. 1037K dots
Adjustment Brightness, saturation and colors adjustable
7
Appendix
126
White Balance
Focus System
Exposure Control
Shutter
Drive Modes
Outdoor View
Setting ±2 steps
Night Vision LCD
Display On, Off
Type TTL method using the CMOS image sensor
Preset Modes
Auto White Balance, Multi Auto White Balance,
Daylight, Shade, Cloudy, Fluorescent Light
(D: Daylight Color, N: Daylight White, W: Cool
White, L: Warm White), Tungsten Light, n,
Manual White Balance (up to 3 settings), Color
Temperature (up to 3 settings), Copying the white
balance settings of a captured image
Fine Adjustment Adjustable ±7 steps on A-B axis and G-M axis
Type TTL phase-matching autofocus system
Focus Sensor
SAFOX X, 11 points (9 cross type focus points in the
center)
Brightness Range EV -3 to 18 (ISO100, at normal temperature)
AF Modes Single AF (x), Continuous AF (y), Auto
select AF (z)
Focusing Area
Selection Modes
Auto (11 AF Points), Auto (5 AF Points), Select,
Expanded Area AF, Spot
AF Assist Light Dedicated LED AF assist light
Type
TTL open-aperture 77 segment metering
Metering modes: Multi-segment, Center-weighted,
Spot
Metering Range EV 0 to 22 (ISO100 at 50mm F1.4)
Capture Modes
Auto Picture (R) modes: Standard, Portrait,
Landscape, Macro, Moving Object, Night Scene
Portrait, Sunset, Blue Sky, Forest
Scene (S) modes: Portrait, Landscape, Macro,
Moving Object, Night Scene Portrait, Sunset, Blue
Sky, Forest, Night Scene, Night Scene HDR, Night
Snap, Food, Pet, Kids, Surf & Snow, Backlight
Silhouette, Candlelight, Stage Lighting, Museum
Exposure modes: Program, Sensitivity Priority,
Shutter Priority, Aperture Priority, Shutter & Aperture
Priority, Manual, Bulb
EV Compensation ±5 EV (1/3 EV steps or 1/2 EV steps can be selected)
AE Lock Can be assigned to f in [Button Customization].
Type
Electronically controlled vertical-run focal plane
shutter
Electronic shutter is used for Pixel Shift Resolution
Shutter Speed
Auto: 1/6000 to 30 seconds, Manual: 1/6000 to 30
seconds (1/3 EV steps or 1/2 EV steps), Bulb (timed
exposure setting possible from 10 seconds to 20
minutes)
Mode Selection
[Still picture]
Single frame, Continuous (H, L), Self-timer (12 sec.,
2 sec., continuous), Remote Control (immediately,
3 sec., continuous), Bracketing *1 (2, 3, or 5 frames),
Mirror Lock-up Shooting *2, Multi-exposure *3, Interval
Shooting *1, Interval Composite *1, Interval Movie
Record *1, Star Stream *1
[Movie]
Remote Control
*1 Available with Self-timer or Remote Control
*2 Available with Remote Control
*3 Available with Continuous Shooting, Self-timer,
or Remote Control
7
Appendix
128
Movie
Playback Functions
Customization
Recording Format MPEG-4 AVC/H.264 (MOV)
Recorded Pixels u (1920×1080, 60i/50i/30p/25p/24p)
t (1280×720, 60p/50p)
Autofocusing
System
Hybrid AF of image plane phase-matching and
contrast detection
AF Mode: Single AF (x), Continuous AF
(y)*
* Continuous AF (y) is available only when a
compatible lens is attached to the camera.
AF Active Area: Multiple AF Points, Select, Spot
Focus Peaking: On, Off
Sound
Built-in stereo microphone, external microphone
(stereo recording compatible)
Recording Sound Level: adjustable
Recording Time
Up to 4 GB or 25 minutes; automatically stops
recording if the internal temperature of the camera
becomes high.
Custom Image
Auto Select, Bright, Natural, Portrait, Landscape,
Vibrant, Radiant, Muted, Flat, Bleach Bypass,
Reversal Film, Monochrome, Cross Processing
Cross Processing Random, Preset 1-3, Favorite 1-3
Digital Filter
Extract Color, Replace Color, Toy Camera, Retro,
High Contrast, Shading, Invert Color, Unicolor Bold,
Bold Monochrome
Playback View
Single image, Multi-image display (6, 12, 20, 35, and
80 thumbnails), Image magnification (Up to 16× and
quick zoom), Grid Display (4×4 Grid, Golden Section,
Scale, Square 1, Square 2, Grid Color: Black, White),
Rotated image display, Histogram (Y histogram, RGB
histogram), Highlight Alert, Auto Image Rotation,
Detailed Information Display, Copyright Information
(Photographer, Copyright Holder), GPS information
(Latitude, Longitude, Altitude, Coordinated Universal
Time (UTC)), Direction, Folder Display, Calendar
Filmstrip Display, Slideshow
Delete Single image, all images, select & delete, folder,
Instant Review image
Digital Filter
Base Parameter Adj, Extract Color, Replace Color,
Toy Camera, Retro, High Contrast, Shading, Invert
Color, Unicolor Bold, Bold Monochrome, Tone
Expansion, Sketch, Water Color, Pastel,
Posterization, Miniature, Soft, Starburst, Fish-eye,
Slim, Monochrome
RAW
Development
Development options: Select single image, Select
multiple images, Select a folder
Development parameters: White Balance, Custom
Image, Sensitivity, Clarity, Skin Tone, Digital Filter,
HDR Capture, Pixel Shift Resolution, Shadow
Correction, High-ISO NR, Distortion Correction,
Peripheral Illumination Correction, Lateral Chromatic
Aberration Adjustment, Diffraction Correction, Color
Fringe Correction, Aspect Ratio, JPEG Recorded
Pixels, JPEG Quality, Color Space
Editing Features
Image Rotation, Color Moiré Correction, Resize,
Cropping (aspect ratio can be changed and tilt
correction is available), Movie Edit (dividing a movie
file and deleting unwanted segments), Capturing a
JPEG still picture from a movie, Save RAW Data
USER Modes Up to 3 settings can be saved.
Custom Functions 24 items
Mode Memory 16 items
Button
Customization
X Y/ button: One Push File Format, Wi-Fi,
Outdoor View Setting, Night Vision LCD Display,
Preview, Electronic Level, Change AF Area
f button: Enable AF1, Enable AF2, Cancel AF,
AE Lock
E-dials (front/rear): customizable to each exposure
mode
7
Appendix
130
USB Power Adapter AC-U2
Rechargeable Lithium-ion Battery D-LI109
Battery Charger D-BC186
Optional Accessories
Power Supply 100 to 240 VAC (50/60 Hz), 0.2 A
Output 5.0 VDC, 1.0 A, 5.0 W
Average Active
Efficiency 76%
No-Load Power
Consumption 70 mW
Operating
Temperature
0 to 40°C (32 to 104°F)
This depends on the operating temperature of the
battery charger.
Storage
Temperature -20 to 60°C (-4 to 140°F)
Dimensions 42.5 mm (W) × 22 mm (H) × 66.5 mm (D) (1.7 in. (W)
× 0.9 in. (H) × 2.6 in. (D)) (excluding the power plug)
Weight Approx. 40 g (1.4 oz) (excluding the power plug)
Nominnal Voltage 7.4 V
Rated Capacity 1050 mAh, 7.8 Wh
Operating
Temperature
-10 to 60°C (14 to 140°F)
This depends on the operating temperature of the
camera and battery charger.
Storage
Temperature -20 to 50°C (-4 to 122°F)
Dimensions Approx. 36.1 mm (W) × 56.6 mm (H) × 14.4 mm (D)
(1.4 in. (W) × 2.2 in. (H) × 0.6 in. (D))
Weight Approx. 57 g (2 oz.)
Rated Input 5 VDC, 3 A; 9 VDC, 3 A; 12 VDC, 3 A
Rated Output 8.4 VDC, 1.2 A
Dimensions Approx. 83 mm × 62 mm × 24 mm (3.3 in. × 2.4 in. ×
0.9 in.)
Weight Approx. 55 g (1.9 oz)
GPS Unit
O-GPS1/O-GPS2: GPS information (Latitude,
Longitude, Altitude, Coordinated Universal Time
(UTC)), Direction, Electronic Compass,
ASTROTRACER
Cable Release Cable Switch CS-310
7
Appendix
131
(When using the fully charged battery)
Tested in compliance with CIPA standard using a fully charged lithium-
ion battery at a temperature of 23°C. Actual results may vary depending
on the shooting conditions/circumstances.
(When using an 8 GB memory card)
The number of storable images may vary depending on the subject,
shooting conditions, selected capture mode, and memory card, etc.
The following cities can be set as Hometown and Destination.
Approximate Image Storage Capacity and
Playback Time
Battery Tempe-
rature
Normal
Shooting
Flash Photography Playback
Time
50%
Use
100%
Use
D-LI109 23°C 460 400 350 250
minutes
Approximate Image Storage Capacity by Size
Recorded
Pixels
JPEG Quality PEF
m l k
q 24M 528 1192 2339 151
p 14M 889 1996 3837
o6M 1964 4309 7923
r 2M 4723 9824 16374
List of World Time Cities
Region City
North
America
Honolulu, Anchorage, Vancouver, San
Francisco, Los Angeles, Calgary, Denver,
Chicago, Miami, Toronto, New York, Halifax
Central
and South
America
Mexico City, Lima, Santiago, Caracas, Buenos
Aires, Sao Paulo, Rio de Janeiro
Europe
Lisbon, Madrid, London, Paris, Amsterdam,
Milan, Rome, Copenhagen, Berlin, Prague,
Stockholm, Budapest, Warsaw, Athens, Helsinki,
Moscow
Africa/
West Asia
Dakar, Algiers, Johannesburg, Istanbul, Cairo,
Jerusalem, Nairobi, Jeddah, Tehran, Dubai,
Karachi, Kabul, Male, Delhi, Colombo,
Kathmandu, Dacca
East Asia
Yangon, Bangkok, Kuala Lumpur, Vientiane,
Singapore, Phnom Penh, Ho chi Minh, Jakarta,
Hong Kong, Beijing, Shanghai, Manila, Taipei,
Seoul, Tokyo, Guam
Oceania Perth, Adelaide, Sydney, Noumea, Wellington,
Auckland, Pago Pago
7
Appendix
132
With the provided software “Digital Camera Utility 5”, you can
develop RAW images, make color adjustments, or check
shooting information on a computer. Install the software from
the provided CD-ROM (S-SW186).
We recommend the following system requirements to connect
the camera to a computer with a commercially available USB
cable and to use the software.
t Memo
Application software that supports both MOV (MPEG-4AVC/
H.264) and AVI (Motion JPEG) formats is required to play
back movie files transferred to a computer.
Operating Environment for USB Connection
and Provided Software
Windows®
OS Windows®11 or Windows® 10
CPU Intel® Core™ i5 or higher
RAM 8 GB or more
HDD
For installing and starting up the program:
Approx.100 MB or more of available space
For saving image files: Approx. 10 MB/file (JPEG),
Approx. 30 MB/file (RAW)
Monitor 1280×1024 dots, 24-bit full color or higher
Mac
OS macOS 12 Monterey, macOS 11 Big Sur, macOS
10.15 Catalina
CPU Intel® Core™ i5 or higher
RAM 8 GB or more
HDD
For installing and starting up the program:
Approx.100 MB or more of available space
For saving image files: Approx. 10 MB/file (JPEG),
Approx. 30 MB/file (RAW)
Monitor 1280×1024 dots, 24-bit full color or higher
7
Appendix
133
Symbols
A menus ........................ 24
C menus ........................ 29
B menu.......................... 30
D menus......................... 31
E menus ......................... 34
C mode.......................... 54
b Portrait ....................... 50
c Landscape................. 50
d Macro ........................ 50
e Moving Object ........... 50
f Night Scene Portrait .. 50
g Sunset ....................... 50
h Blue Sky .................... 50
i Forest ........................ 50
j Night Scene............... 51
k Night Scene HDR...... 51
l Night Snap................. 51
m Food .......................... 51
o Pet............................. 51
p Kids ........................... 51
q Surf & Snow .............. 51
s Backlight Silhouette... 51
t Candlelight ................ 51
u Stage Lighting ........... 51
v Museum..................... 51
Numerics
1st Frame Action in AF.C
........................................ 61
4-way Controller Settings
........................................ 63
A
AA Filter Simulator .......... 81
AC adapter ...................... 39
Action in AF.C Continuous
........................................ 61
AdobeRGB ...................... 49
AE Lock ........................... 53
AE Metering..................... 58
AE-L with AF Locked....... 34
AF Active Area .......... 62, 64
AF Assist Light ............ 9, 62
AF coupler ......................... 9
AF Fine Adjustment......... 65
AF frame.................... 46, 47
AF in Interval Shooting .... 72
AF Mode.................... 62, 63
AF point ........................... 62
AF with Remote Control .. 68
z.............................. 62
y............................... 62
x............................... 62
AF.S Setting .............. 61, 63
AF/AE-L Button ............... 99
Anti-aliasing filter ............. 81
Aperture Priority Automatic
Exposure ......................... 51
Aperture value ................. 51
Aspect Ratio .............. 88, 93
ASTROPHOTO ............... 50
ASTROTRACER ........... 119
Auto (AF Active Area)...... 62
Auto EV Compensation ... 34
Auto Flash + Red-eye...... 59
Auto Flash Discharge ...... 59
Auto Image Rotation........ 86
R mode.................... 45
Auto Picture mode........... 45
Auto Power Off ................ 42
Auto Select (Custom Image)
........................................ 75
Auto SR Off ..................... 66
Auto White Balance (White
Balance) .......................... 72
Autofocus ........................ 61
AV device ........................ 87
J mode......................... 51
AWB in Tungsten Light.... 73
B
M mode........................... 51
Backlight Silhouette (S)
........................................ 51
Base Parameter Adjustment
(Digital Filter) ................... 89
Battery ............................. 37
Bleach Bypass (Custom
Image) ............................. 75
Blue Sky (S)............... 50
Bold Monochrome (Digital
Filter) ......................... 77, 89
Bracketing........................ 68
Bracketing Order ............. 69
Bright (Custom Image) .... 75
Brightness adjustment..... 78
Brightness histogram....... 18
Built-in flash..................... 59
Bulb (B) Mode Options .... 53
Bulb Exposure ........... 51, 53
Button .............................. 10
Button Customization ...... 98
C
Cable release .................. 55
Cable release terminal..... 55
Calendar Filmstrip Display
........................................ 85
Calibration ..................... 119
Candlelight (S)........... 51
Capture mode.................. 50
Card................................. 40
Card access lamp.............. 9
Catch-in Focus .............. 116
Center-weighted metering
........................................ 58
Certification Marks......... 139
Changing the image size
........................................ 88
Charging the battery ........ 37
City names............... 42, 131
Index
7
Appendix
134
Clarity .............................. 80
Cleaning ........................ 122
CLEAR TONE ................. 50
Cloudy (White Balance)... 72
Color Fringe Correction ... 93
Color Moiré Correction .... 89
Color Space..................... 49
Color Temperature (White
Balance) .......................... 75
Color Temperature Steps
........................................ 75
Communication device .... 97
Communication Info ........ 96
Computer......................... 94
Connection cable cover... 39
Continuous mode (AF Mode)
......................................... 62
Continuous playback ....... 86
Continuous Shooting ....... 66
Contrast (Custom Image)
........................................ 76
Contrast detection AF...... 61
Control panel ............. 14, 20
Copyright Holder ........... 109
Copyright Information .... 109
Correcting images ........... 78
Create New Folder ........ 107
Cropping.......................... 88
Cross Processing (Custom
Image) ............................. 75
n................................ 72
Custom Image ................. 75
Custom Setting menus .... 34
Customization............ 21, 98
D
Date Adjustment .............. 43
Date Format .................... 43
Daylight (White Balance)
........................................ 72
DC coupler ...................... 39
Delete .............................. 48
Delete All Images ............ 30
Deleting selected images
........................................ 84
Depth of field ................... 53
Destination .................... 105
Detailed Information Display
........................................ 17
Developing RAW images
........................................ 92
Dial .................................. 10
Dial indicator.................... 45
Diffraction Correction....... 80
Digital Camera Utility 5
................................ 93, 132
Digital Filter ............... 77, 89
Digital Preview............... 100
Diopter adjustment lever
........................................ 19
Direct keys....................... 20
Display Color ................... 44
Distortion Correction........ 80
DNG ................................ 49
D-Range Settings ............ 78
Drive Mode ...................... 65
DST (daylight saving time)
................................ 43, 105
Dust Removal ................ 121
Dynamic range ................ 78
E
E-dial ............................. 101
Editing images ................. 88
Electronic Compass
................................ 15, 118
Electronic Level ......... 15, 19
Error Messages ............. 123
EV Compensation ........... 58
EV Steps ......................... 52
Exif data ........................ 109
Expanded Area AF (AF
Active Area) ..................... 62
Exposure modes ..... 51, 104
External flash................. 117
External Input Devices .... 55
Extract Color (Digital Filter)
.................................. 77, 89
F
Face Detection (AF Active
Area)................................ 64
File Format ...................... 49
File Name ...................... 108
File No. .......................... 109
Filter .......................... 77, 89
Firmware Info/Options ..... 33
Fish-eye (Digital Filter) .... 89
Flash........................ 59, 117
Flash compensation ........ 59
Flash On .......................... 59
Flash On + Red-eye ........ 59
Flat (Custom Image)........ 75
Flicker Reduction....... 26, 30
Fluorescent - Cool White
(White Balance)............... 72
Fluorescent - Daylight Color
(White Balance)............... 72
Fluorescent - Daylight White
(White Balance)............... 72
Fluorescent - Warm White
(White Balance)............... 72
Focus indicator ................ 46
Focus Method.................. 61
Focus mode switch.... 45, 61
Focus Peaking................. 63
Folder display .................. 85
Folder Name.................. 107
Food (S)..................... 51
Forest (S)................... 50
Format ............................. 44
Four-way controller.... 11, 20
Framerate ........................ 49
Function restrictions ...... 110
Fx1 button........................ 98
Fx2 button........................ 98
G
GPS LED Indicators ...... 102
GPS Time Sync ............. 118
GPS unit ........................ 118
Grid Display ............... 26, 48
Guide Display .................. 45
Guide number.................. 60
H
HDMI Out......................... 87
HDR Capture................... 79
HDR LANDSCAPE .......... 50
7
Appendix
137
Switch.............................. 10
T
K mode........................ 51
Text input............... 104, 107
Text Size ......................... 43
Texture adjustment.......... 80
Thumbnail display ..... 48, 84
Time Setting .................. 105
Timed exposure............... 53
Tone Expansion (Digital
Filter) ............................... 89
Toy Camera (Digital Filter)
.................................. 77, 89
Tracking (AF Active Area)
........................................ 64
Trailing Curtain Sync ....... 59
TTL phase-matching AF
........................................ 61
Tungsten (White Balance)
........................................ 72
I mode......................... 51
U
Unicolor Bold (Digital Filter)
.................................. 77, 89
USB Connection...... 94, 132
USB terminal ................... 94
User registration ................ 8
Using Aperture Ring ...... 115
V
Vibrant (Custom Image) .. 75
Viewfinder........................ 18
Viewfinder Overlay .......... 26
Volume ...................... 31, 55
Volume label.................... 44
W
WARRANTY POLICY.... 143
Water Color (Digital Filter)
........................................ 89
WB Adjustable Range ..... 73
WB When Using Flash .... 73
White Balance ................. 72
Wi-Fi™ ............................ 95
Windows®...................... 132
Wireless LAN................... 95
World Time .................... 105
Z
Zoom Review .................. 48
7
Appendix
138
When the camera has not been used for a long time, confirm that it is still
working properly, particularly prior to taking important pictures (such as
at a wedding or when traveling). Contents of the recording cannot be
guaranteed if recording, playback or transferring your data to a
computer, etc. is not possible due to a malfunction of your camera or
recording media (memory cards), etc.
To keep the battery in optimum condition, avoid storing it in a fully
charged state or in high temperatures.
If the battery is left inserted and the camera is not used for a long time,
the battery will over-discharge and shorten the battery’s life.
Charging the battery a day before use or on the day of use is
recommended.
Do not subject the camera to high temperatures or high humidity. Do not
leave the camera in a vehicle, as the temperature can get very high.
Do not subject the camera to strong vibrations, shocks, or pressure. Use
a cushion to protect the camera from vibrations of motorcycles,
automobiles, or ships.
The temperature range for camera use is -10°C to 40°C (14°F to 104°F).
The monitor may appear black at high temperatures, but will return to
normal at normal temperatures.
The monitor may respond more slowly at low temperatures. This is due
to liquid crystal properties, and is not a malfunction.
Sudden temperature changes will cause condensation on the inside and
outside of the camera. Place the camera in your bag or a plastic bag,
and remove it after temperatures of the camera and surroundings are
equalized.
Avoid contact with garbage, mud, sand, dust, water, toxic gases, or salt.
These could cause the camera to breakdown. Wipe the camera to dry
off any rain or water drops immediately.
Do not attach or remove a lens when there are any rain or water drops
on the camera. If water enters the camera or the lens, a malfunction may
occur.
Do not press on the monitor with excessive force. This could cause it to
break or malfunction.
Be careful not to overtighten the screw in the tripod socket when using
a tripod.
Do not clean the camera with organic solvents such as thinner, alcohol,
and benzine.
Use a lens brush to remove dust accumulated on a lens. Never use a
spray blower for cleaning as it may damage the lens.
Please contact your nearest service center for professional cleaning of
the CMOS sensor. (This will involve a fee.)
Periodic inspections are recommended every one to two years to
maintain high performance.
Do not store the camera with preservatives or chemicals. Storage in high
temperatures and high humidity can cause mold to grow on the camera.
Remove the camera from its case and store it in a dry and well-ventilated
place.
Avoid using or storing the camera where it may be exposed to static
electricity or electrical interference.
Avoid using or storing the camera in direct sunlight or in locations where
it may be exposed to rapid changes in temperature or to condensation.
Care to be Taken During Handling
Before Using Your Camera
About the Battery and Charger
Precautions on Carrying and Using Your Camera
Cleaning Your Camera
Storing Your Camera
7
Appendix
139
The SD Memory Card is
equipped with a write-protect
switch. Setting the switch to
LOCK prevents new data from
being recorded on the card, the
stored data from being deleted,
and the card from being
formatted by the camera or
computer.
The SD Memory Card may be
hot when removing the card immediately after using the camera.
Do not remove the SD Memory Card or turn off the power while the card
is being accessed. This may cause the data to be lost or the card to be
damaged.
Do not bend the SD Memory Card or subject it to violent impact. Keep it
away from water and store away from high temperatures.
Do not remove the SD Memory Card while formatting. The card may be
damaged and become unusable.
Data on the SD Memory Card may be deleted in the following
circumstances. We do not accept any liability for data that is deleted if
1. the SD Memory Card is mishandled by the user.
2. the SD Memory Card is exposed to static electricity or electrical
interference.
3. the SD Memory Card has not been used for a long time.
4. the SD Memory Card or the battery is removed while the card is being
accessed.
If the SD Memory Card is not used for a long time, the data on the card
may become unreadable. Be sure to regularly make a backup of
important data on a computer.
Format new SD Memory Cards. Also format SD Memory Cards
previously used with other cameras.
Please note that deleting data stored on an SD Memory Card, or
formatting an SD Memory Card does not completely erase the original
data. Deleted data can sometimes be recovered using commercially
available software. If you are going to discard, give away or sell your SD
Memory Card, you should ensure that the data on the card is completely
deleted or the card itself is destroyed if it contains any personal or
sensitive information.
The data on your SD Memory Card should be managed at your own risk.
Do not use the camera in a place where electrical products, AV/OA
devices, and so on generate magnetic fields and electromagnetic
waves.
If the camera is affected by magnetic fields and electromagnetic waves,
it may not be able to communicate.
If the camera is used near a TV or a radio, poor reception or TV screen
glitch may occur.
If there are multiple wireless LAN access points near the camera and the
same channel is used, search operation may not be executed correctly.
The security of your data stored, sent or received is your own responsibility.
This camera conforms to the technical standards under the Radio Law and
Telecommunications Business Law and the certification of conformance to
technical standards can be displayed on the monitor.
About SD Memory Cards
Write-protect
switch
About the Wireless LAN Function
In the frequency band used by the camera, along with industrial,
scientific, and medical devices such as microwave ovens, premises
radio stations (wireless stations requiring license) and specified low
power radio stations (wireless stations not requiring license) for
mobile object identification used in factory production lines, etc., and
amateur radio stations (wireless stations requiring license) are
operated.
1. Before using the camera, confirm that premises radio stations and
specified low power radio stations for mobile object identification
and amateur radio stations are not operated in the vicinity.
2. In the event that the camera causes harmful radio wave
interference to premises radio stations for mobile object
identification, immediately change the frequency being used to
avoid interference.
3. If you have other troubles such that the camera causes harmful
radio wave interference to specified low power radio stations for
mobile object identification or to amateur radio stations, contact
your nearest service center.
Display the Certification Marks
1Press F to display the menu screen.
2Use ABCD to display the D5 menu.
3Use ABCD to select [Certification Marks], and press E.
7
Appendix
140
N'utilisez pas l'appareil photo dans un endroit où des produits
électriques, des dispositifs AV/OA, etc. génèrent des champs
magnétiques et des ondes électromagnétiques.
Si l'appareil photo est affecté par des champs magnétiques et des
ondes électromagnétiques, il se peut qu'il ne puisse pas communiquer.
Si l'appareil photo est utilisé à proximité d'un téléviseur ou d'une radio,
une mauvaise ception ou un scintillement de l'écran du téléviseur peut
se produire.
S'il y a plusieurs point d'accès au réseau local sans fil à proximité de
l'appareil photo et que le même canal est utilisé, l'opération de
recherche peut ne pas être exécutée correctement.
La sécurité des données stockées, envoyées ou reçues relève de votre
propre responsabilité.
Cet appareil photo est conforme aux normes techniques en vertu de la loi
sur la radio et de la loi sur les télécommunications et la certification de
conformité aux normes techniques peut être affichée sur l'écran.
À propos de la fonction de réseau local sans fil
Dans la bande de fréquences utilisée par l'appareil photo, ainsi que
les dispositifs industriels, scientifiques et médicaux tels que les fours
à micro-ondes, les stations de radio locales (stations sans fil
nécessitant une licence) et les stations de radio de faible puissance
spécifiées (stations sans fil ne nécessitant pas de licence) pour
l'identification d'objets mobiles utilisés dans les chaînes de production
d'usine, etc., et les stations de radioamateur (stations sans fil
nécessitant une licence) sont exploitées.
1. Avant d'utiliser l'appareil photo, vérifiez que les stations de radio
locales et les stations de radio de faible puissance spécifiées
pour l'identification d'objets mobiles et les stations de
radioamateur ne sont pas exploitées à proximité.
2. Dans le cas où l'appareil photo provoque des interférences
d'ondes radio nuisibles aux stations radio locales pour
l'identification d'objets mobiles, changez immédiatement la
fréquence utilisée pour éviter les interférences.
3. Si vous rencontrez d'autres problèmes tels que des interférences
d'ondes radio provoquées par l'appareil photo, nuisibles aux
stations radio de faible puissance spécifiées pour l'identification
d'objets mobiles ou aux stations de radioamateur, contactez votre
centre de service le plus proche.
Afficher les marques de certification
1Appuyez sur F pour afficher l'écran du menu.
2Utilisez ABCD pour afficher le menu 5.D
3Utilisez ABCD pour sélectionner [Marques de certification],
puis appuyez sur E.
7
Appendix
141
Microsoft and Windows are registered trademarks of Microsoft
Corporation in the United States of America and other countries.
Mac, macOS, and App Store are trademarks of Apple Inc., registered in
the U.S. and other countries.
IOS is a trademark or registered trademark of Cisco in the U.S. and
other countries and is used under license.
Intel and Intel Core are trademarks of Intel Corporation in the U.S. and/
or other countries.
SDXC Logo is a trademark of SD-3C, LLC.
Google, Google Play, and Android are trademarks or registered
trademarks of Google Inc.
Wi-Fi is a registered trademark of Wi-Fi Alliance.
This product includes DNG technology under license by Adobe Systems
Incorporated.
The DNG logo is either a registered trademark or trademark of Adobe
Systems Incorporated in the United States and/or other countries.
HDMI, the HDMI logo and High-Definition Multimedia Interface are
trademarks or registered trademarks of HDMI Licensing, LLC in the
United States and/or other countries.
All other trademarks are the property of their respective owners.
This product uses the RICOH RT font designed by Ricoh Company Ltd.
This product supports PRINT Image Matching III. PRINT Image
Matching enabled digital still cameras, printers and software help
photographers to produce images more faithful to their intentions. Some
functions are not available on printers that are not PRINT Image
Matching III compliant.
Copyright 2001 Seiko Epson Corporation. All Rights Reserved. PRINT
Image Matching is a trademark of Seiko Epson Corporation. The PRINT
Image Matching logo is a trademark of Seiko Epson Corporation.
This product is licensed under the AVC Patent Portfolio License for the
personal use of a consumer or other uses in which it does not receive
remuneration to (i) encode video in compliance with the AVC standard
(“AVC video”) and/or (ii) decode AVC video that was encoded by a
consumer engaged in a personal activity and/or was obtained from a video
provider licensed to provide AVC video. No license is granted or shall be
implied for any other use.
Additional information may be obtained from MPEG LA, L.L.C.
See http://www.mpegla.com.
Trademarks
AVC Patent Portfolio License
7
Appendix
142
This product includes software licensed under the BSD License. BSD
license is a form of license which permits the redistribution of the software
provided that it is clearly stated that use is unwarranted, and a copyright
notice and a list of licensing conditions are provided. The following
contents are displayed based on the abovementioned licensing conditions
and are not for the purpose of restricting your use of the product, etc.
Tera Term
Copyright (C) 1994-1998 T. Teranishi
(C) 2004-2016 TeraTerm Project
All rights reserved.
Redistribution and use in source and binary forms, with or without
modification, are permitted provided that the following conditions are met:
1. Redistributions of source code must retain the above copyright notice,
this list of conditions and the following disclaimer.
2. Redistributions in binary form must reproduce the above copyright
notice, this list of conditions and the following disclaimer in the
documentation and/or other materials provided with the distribution.
3. The name of the author may not be used to endorse or promote
products derived from this software without specific prior written
permission.
THIS SOFTWARE IS PROVIDED BY THE AUTHOR “AS IS” AND ANY
EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT
LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN
NO EVENT SHALL THE AUTHOR BE LIABLE FOR ANY DIRECT,
INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR
CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO,
PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF
USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION)
HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER
IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING
NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE
USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY
OF SUCH DAMAGE.
Announcement on the Use of BSD-Licensed Software
7
Appendix
143
All our cameras purchased through authorized bona fide
photographic distribution channels are guaranteed against
defects of material or workmanship for a period of twelve
months from the date of your purchase. Service will be
rendered, and defective parts will be replaced without cost to
you within that period, provided the camera does not show
evidence of impact, sand or liquid damage, mishandling,
tampering, battery or chemical corrosion, operation contrary to
operating instructions, or modification by an unauthorized repair
shop. The manufacturer or its authorized representatives shall
not be liable for any repair or alterations except those made with
its written consent and shall not be liable for damages from
delay or loss of use or from other indirect or consequential
damages of any kind, whether caused by defective material or
workmanship or otherwise; and it is expressly agreed that the
liability of the manufacturer or its representatives under all
guarantees or warranties, whether expressed or implied, is
strictly limited to the replacement of parts as hereinbefore
provided. No refunds will be made on repairs by non-authorized
service facilities.
Procedure During 12-month Warranty Period
Any camera which proves defective during the 12-month
warranty period should be returned to the dealer from whom you
purchased the camera or to the manufacturer. If there are no
representatives of the manufacturer in your country, send the
camera to the manufacturer, with postage prepaid. In this case,
it will take a considerable length of time before the camera can
be returned to you owing to the complicated customs
procedures required. If the camera is covered by warranty,
repairs will be made and parts replaced free of charge, and the
camera will be returned to you upon completion of servicing. If
the camera is not covered by warranty, regular charges of the
manufacturer or of its representatives will apply. Shipping
charges are to be borne by the owner. If your camera was
purchased outside of the country where you wish to have it
serviced during the warranty period, regular handling and
servicing fees may be charged by the manufacturer’s
representatives in that country. Notwithstanding this, your
camera returned to the manufacturer will be serviced free of
charge according to this procedure and warranty policy. In any
case, however, shipping charges and customs clearance fees
to be borne by the sender. To prove the date of your purchase
when required, please keep the receipt or bills covering the
purchase of your camera for at least a year. Before sending
your camera for servicing, please make sure that you are
sending it to the manufacturer’s authorized representatives or
their approved repair shops, unless you are sending it directly
to the manufacturer. Always obtain a quotation for the service
charge, and only after you accept the quoted service charge,
instruct the service station to proceed with the servicing.
This warranty policy does not affect the customer’s
statutory rights.
The local warranty policies available from our
distributors in some countries can supersede this
warranty policy. Therefore, we recommend that you
review the warranty card supplied with your product at
the time of purchase, or contact our distributor in your
country for more information and to receive a copy of
the warranty policy.
WARRANTY POLICY
7
Appendix
146
avoir des effets sur la santé (en chauffant les tissus),
l’exposition à de faibles RF qui ne produisent pas de chaleur n’a
pas de mauvais effets connus sur la santé. De nombreuses
études ont été menées sur les expositions aux RF faibles et
n’ont découvert aucun effet biologique. Certaines études ont
suggéré qu’il pouvait y avoir certains effets biologiques, mais
ces résultats n’ont pas été confirmés par des recherches
supplémentaires. Le R06010 a été testé et jugé conforme aux
limites d’exposition aux rayonnements ISDE énoncées pour un
environnement non contrôlé et respecte les règles d’exposition
aux fréquences radioélectriques (RF) CNR-102 de l’ISDE.
For Customers in Europe
Information for Users on Collection and Disposal of Old
Equipment and Used Batteries
1. In the European Union
These symbols on the products, packaging and/
or accompanying documents mean that used
electrical and electronic equipment and batteries
should not be mixed with general household
waste.
Used electrical/electronic equipment and
batteries must be treated separately and in
accordance with legislation that requires proper
treatment, recovery and recycling of these
products.
By disposing of these products correctly you will
help ensure that the waste undergoes the
necessary treatment, recovery and recycling
and thus prevent potential negative effects on
the environment and human health which could
otherwise arise due to inappropriate waste
handling.
If a chemical symbol is added beneath the symbol shown
above, in accordance with the Battery Directive, this indicates
that a heavy metal (Hg = Mercury, Cd = Cadmium, Pb = Lead)
is present in the battery at a concentration above an applicable
threshold specified in the Battery Directive.
For more information about collection and recycling of used
products, please contact your local authorities, your waste
disposal service or the point of sale where you purchased the
products.
7
Appendix
147
2. In other countries outside the EU
These symbols are only valid in the European Union. If you wish
to discard used products, please contact your local authorities
or dealer and ask for the correct method of disposal.
For Switzerland: Used electrical/electronic equipment can be
returned free of charge to the dealer, even when you don’t
purchase a new product. Further collection facilities are listed
on the home page of www.swico.ch or www.sens.ch.
Notice to Users in CE Marking
This product complies with the essential requirements and
provisions of RE Directive 2014/53/EU.
The EU Declaration of Conformity is available by accessing the
URL:
https://www.ricoh-imaging.co.jp/english/support/
declaration_of_conformity.html
and selecting the product applicable.
Operating frequency band: 2400 MHz - 2483.5 MHz
Maximum radio-frequency power: 8.16 dBm EIRP
Importer (CE marking): RICOH IMAGING EUROPE S.A.S.
Parc Tertiaire SILIC 7-9, avenue Robert Schuman - B.P. 70102,
94513 Rungis Cedex, FRANCE
Manufacturer: RICOH IMAGING COMPANY, LTD.
1-3-6, Nakamagome, Ohta-ku, Tokyo 143-8555, JAPAN
Notice to Users in UKCA Marking
This product complies with the essential requirements and
provisions of Radio Equipment Regulations 2017.
The UK Declaration of Conformity is available by accessing the
URL:
https://www.ricoh-imaging.co.jp/english/support/
declaration_of_conformity.html
and selecting the product applicable.
Operating frequency band: 2400 MHz - 2483.5 MHz
Maximum radio-frequency power: 8.16 dBm EIRP
Manufacturer: RICOH IMAGING COMPANY, LTD.
1-3-6, Nakamagome, Ohta-ku, Tokyo 143-8555, JAPAN
The CE Mark is a Directive conformity mark of the
European Union.
The UKCA Mark is a Regulation conformity mark
of the United Kingdom.
