Adjustable Shelf
for A/V Components
A versatile solution that not only looks great, but let’s you easily incorporate A/Vcomponents
into virtually any environment. This exible and space-saving shelf gets components organized
and out of the way. It offers a low-prole solutionthat mounts to two studs allowing you to center
the shelf and components underthe screen, completing the picture-perfect installation.
Levelling made easy with the use of
adjustment knobs
Max load: 100lb (45kg)
PS200
Double-stud installation
allows A/V equipment
to be centered directly
underneath at panel
screen
Adjustable width up to 18"
and depth range of 15" to
23" accommodate even
largest receivers, multi-disk
DVD players
Decorative snap-on covers
conceal all mounting
hardware
Adjustment knobs allows
for easy leveling of
components
Embossed arms with screw
holes secure components
to shelf
100lb (45kg) load capacity
allows stacking of multiple
components, ideal for A/V
closets
CLICK: CALL: FAX: www.peerlessmounts.com 800.865.2112 708.865.2941
FeAtureS
SLeeK AeSthetIC
Decorative snap-on covers
conceal all mounting
hardware
unIverSAL
CompAtIbILIty
Adjustable arms to
match the footprint of
any component
A R C H I T E C T S S P E C I F I C A T I O N S
The A/V Component Shelf shall be a Peerless model PS200 and shall be located where indicated on the plans. It shall be constructed of heavy gauge steel.
The nish shall be scratch resistant gloss black fused epoxy. Assembly and installation shall be done according to instructions provided by the manufacturer.
Visit peerlessmounts.com to see the full line of Peerless LCD/plasma, projector and TV/monitor mounts. © 2010 Peerless Industries, Inc. All rights reserved.
Peerless Industries, Inc. 2300 White Oak Circle Aurora, IL 60502 (800) 865-2112 (708) 865-8870 Fax: (708) 865-2941 www.peerlessmounts.com   
LIT-0590
PACKAGE SIZE (W x H x D) PACKAGE SHIP WEIGHT PACKAGE UPC CODE PACKAGE CONTENTS UNITS IN PACKAGE
PS200 9.5" x 4.25" x 22.25"
(241 x 208 x 565mm) 10.7lb (5kg) 735029253402
Wall plate, adjustable
arms, covers, assembly
and attachment
hardware
1
Package Specifications
Accessories
DImENSIONS (W x H x D) PRODUCT WEIGHT LOAD CAPACITy FINISH AVAILABLE COLORS
PS200 15.96"-18.44" x 4.25" x 14.86"-23"
(405-468 x 108 x 377-584mm) 8.8lb (4kg) 100lb (45kg)
Scratch
resistant fused
epoxy, plastic
Gloss black
Product Specifications
Model Numbers WARRANTY: Limited 5-year
ACC215: 2-pack Metal Stud Fastener Kit
All dimensions = (mm)inch
PS200 Adjustable Shelf for A/V Components
17.22"
(438mm)
14.86"
(377mm)
9.32"
(237mm)
11.32"
(288mm)
15.96"
(405mm)
18.44"
(468mm)
20.24"
(514mm)
4.25"
(108mm)
1.91"
(49mm)
2.63"
(67mm)
0.74"
(19mm)
25.36"
(644mm)
23.00"
(584mm)
19.46"
(494mm)
17.46"
(443mm)
3.14"
(80mm)
5.64"
(143mm)
1.47
"
(37mm)
2.48"
(63mm)
ISOMETRIC VIEW
FRONT VIEW
SIDE VIEW
TOP VIEW
MAXIMUM EXTENDED WIDTH
MINIMUM RETRACTED LENGTH
TOP VIEW
MINIMUM RETRACTED WIDTH
MAXIMUM EXTENDED LENGTH
