2012-12-11 #: 180-9043-2 (2013-07-11)
* Transmitter not included.
1
2300 White Oak Circle Aurora, Il 60502 • (800) 865-2112 • Fax: (800) 359-6500 • www.peerless-av.com
Installation and Assembly:
HDS200 Security Bracket
Model: HDS-ASE
2012-12-11 #: 180-9043-2 (2013-07-11)
3
NOTE: Read entire instruction sheet before you start installation and assembly.
Table of Contents
Parts List................................................................................................................................................ 3
Installation to Single Stud Wall ..............................................................................................................4
Installation to Solid Concrete or Cinder Block........................................................................................5
Desk or Solid Surface ............................................................................................................................6
Tools Needed for Assembly
stud nder ("edge to edge" stud nder is recommended)
phillips screwdriver
drill
5/16" bit for solid concrete surface
1/8" bit for desk or solid surface
5/32" bit for wood stud
level
hammer
Pencil
Tape Measure
• Do not begin to install your Peerless-AV® product until you have read and understood the
instructions and warnings contained in this Installation Sheet. If you have any questions regarding
any of the instructions or warnings, for US customers please call Peerless-AV
® customer care at
1-800-865-2112, for all international customers, please contact your local distributor.
• This product should only be installed by someone of good mechanical aptitude, has experience
with basic building construction, and fully understands these instructions.
• Make sure that the supporting surface will safely support the combined load of the equipment and
all attached hardware and components.
• If mounting to wood joists, make sure that mounting screws are anchored into the center of the
studs. Use of an "edge to edge" stud nder is highly recommended.
• Tighten screws rmly, but do not overtighten. Overtightening can damage the items, greatly
reducing their holding power.
• This product is intended for indoor use only. Use of this product outdoors could lead to product
failure and personal injury.
WARNING
