Seite 1/20
12019-08-26 #:090-9217-5 (2021-03-01)
60 lb
(27 kg)
MAX
For Samsung Super Ultra Wide Curved Monitor
43": LC43J890DKNXZA
49": C49J890DKN
49": LC49HG90DMNXZA/C49HG90DMN
49": LC49RG90SSNXZA/C49RG90SSN
ENG
B-MIS38426
22019-08-26 #:090-9217-5 (2021-03-01)
Tools Needed for Assembly.ENG
3/8"
(10mm)
ENG To properly tighten screws: Tighten until screw
head makes contact, then tighten another 1/2
turn. Do not overtighten screws.
1
2
+1/2
4
3
ENG - Before installing make sure the supporting surface will support the combined load of the equipment and
hardware. Screws must be tightly secured. Do not overtighten screws or damage can occur and product may fail.
Never exceed the Maximum Load Capacity. Always use an assistant or mechanical lifting equipment to safely lift
and position equipment. This product is intended for indoor use only. Use of this product outdoors could lead to
product failure or personal injury. Be careful not to pinch îš¿ngers when operating the mount. For support please
call customer care at 1-800-865-2112.
WARNING
17/64" 5/8", 7/16"
3/32" 2"-3"
SymbolsENG
WARNING
ENG
#
Skip to step.
ENG
x3
Screws must get at least three
full turns and îš¿t snug.
ENG
Do not overtighten screws.
ENG
Listen
ENG
32019-08-26 #:090-9217-5 (2021-03-01)
A (1)
desktop swivel base
Parts (Before beginning, make sure you have all parts shown below).
ENG
Parts List
Part #Description Qty
Adesktop swivel base 1 090-1821
Badaptor bracket 2 091-1211
Cright adaptor bracket 2 091-1243
Dleft adaptor bracket 2 091-1244
Esupport tube 1 091-1221
FM6 x 6mm hex set screw 2 510-9150
GM4 x 8mm phillips screw 8 520-1237
Hslope nut 3 530-0035
I1/4-20 x 3/4" washer head screw 4 520-1321
J1/4" x 1/2" x .068 split washer 4 540-9402
K48" foam strip 1 570-1170
L1/4-20 lock nut 4 530-1021
Mfender washer 4 540-1008
N1/4-20 x 3" threaded rod 4 520-2585
Obase plate 1 090-1544
Pthrust washer 1 590-1287
Q1/4-20 x 1.5" threaded rod 4 520-2250
R3mm allen wrench 1 560-0194
S10-32 x 1/2" set screw 2 520-1614
D (2)
C (2)
B (2)
adaptor bracket
right adaptor bracket
left adaptor bracket
J (4)
1/4" x 1/2" x .068 split washer
I (4)
1/4-20 x 3/4"
G (8)
M4 x 8mm
F (2)
M6 x 6mm hex set screw
H (3)
slope nut
L (4)
1/4-20 lock nut
K (1)
foam strip
E (1)
support tube
R (1)
3mm allen wrench
