Seite 1/8
SPECIFICATIONS
Voltage: 18V
No Load Speed: 15,500/min
Max. Air Speed: 78km/hr
Charge Time: 30mins (1.5Ah)
Weight: 1.0kg
CORDLESS
BLOWER /
INFLATOR
INSTRUCTION MANUAL
ozito.com.au
IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY YOU
MUST RETURN THE PRODUCT TO YOUR NEAREST BUNNINGS
WAREHOUSE WITH YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY PLEASE TELEPHONE
OUR CUSTOMER SERVICE HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
WARRANTY
TO ENSURE A SPEEDY RESPONSE PLEASE HAVE THE MODEL
NUMBER AND DATE OF PURCHASE AVAILABLE. A CUSTOMER
SERVICE REPRESENTATIVE WILL TAKE YOUR CALL AND
ANSWER ANY QUESTIONS YOU MAY HAVE RELATING TO THE
WARRANTY POLICY OR PROCEDURE.
OZITO Australia/New Zealand (Head Ofîce) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.
The beneîts provided under this warranty are in addition to other rights and
remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded at law. You are entitled to
a replacement or refund for a major failure and for compensation for any other
reasonably foreseeable loss or damage. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure
does not amount to a major failure.
Generally you will be responsible for all costs associated with a claim under this
warranty, however, where you have suffered any additional direct loss as a result of
a defective product you may be able to claim such expenses by contacting our
customer service helpline above.
0517
WARNING
The following actions will result in the warranty being
void.
⢠If the tool has been operated on a supply voltage other than that speciîed
on the tool.
⢠If the tool shows signs of damage or defects caused by or resulting from
abuse, accidents or alterations.
⢠Failure to perform maintenance as set out within the instruction manual.
⢠If the tool is disassembled or tampered with in any way.
5 YEAR REPLACEMENT WARRANTY
Your Product is guaranteed for a period of 60 months from the original date of
purchase and is intended for DIY (Do It Yourself) use only. If a product is defective it
will be replaced in accordance with the terms of this warranty. Lithium Ion
batteries and chargers are covered by a 36 month
warranty and are excluded from the warranty extension. Warranty excludes
consumable parts, for example: blower tube.
WHATâS IN THE BOX
PX2DB-215
Cordless Drill Driver
Cordless Blower / Inîator
Inîation Adapters & Extension
Nozzle
2 x 1.5Ah Batteries
Fast Charger
The purchased battery will be shipped in a low charge condition, and requires charging
prior to use. Allow several cycles of charging and discharging (through use of the tool)
for the battery to reach its optimum performance / runtime.
1 Connect the charger into a mains power outlet.
4 The charger LED will illuminate
red signifying that the battery is
charging.
3 With the charger sitting on a îat
surface, align the raised ribs on
the battery with the recess in the
charger and slide onto the charger
ensuring a îrm connection.
2 The charger LED will îash green
showing power is being supplied
to the charger.
5 The charger LED will illuminate
green once the battery is fully
charged.
Charging your lithium ion battery - Fast Charger
Charger LED Indicator
LED Indicator Situation
GREEN (Flashing) Stand By (no battery pack is inserted)
RED (Flashing) Battery is charging (low charge)
RED (Illuminated) Battery is charging (mid charge)
GREEN (Illuminated) Battery is fully charged
BOTH(Illuminated) Battery pack is too hot or too cold (charging will begin
automatically when battery reaches correct charging
temperature).
BOTH (Flashing) Defective battery. Never charge a defective battery
pack!
Remove battery pack from charger.
1. BATTERY & CHARGING
KNOW YOUR PRODUCT SETUP & PREPARATION
CORDLESS BLOWER / INFLATOR
(PXWBS-200)
1 2 3 4 5
6
1 Blower Nozzle
2 Blower Housing
3 On/Off Switch
4 Sure Grip Handle
5 Battery Seating
6 Inîation Adaptors x 3
7 Extension Nozzle
CAUTION: THE CHARGER FOR THIS PRODUCT
SHOULD BE PROTECTED BY A RESIDUAL CURRENT
DEVICE (RATED AT 30mA OR LESS).
ONLINE MANUAL
Scan this QR Code with your
mobile device to take you to the
online manual.
8 1.5Ah Battery x 2 9 Fast Charger
BATTERY & CHARGER
8 9
7
2. FITTING THE BATTERY
Battery Charge Indicator
The purchased battery is equipped with a
battery charge indicator to show the state of
the battery charge.
Press the charge indicator button and look to
see which LED lights.
Battery requires
immediate charging
Low state of charge, requires charging soon.
Mid state of charge
Full state of charge.
Note: The battery needs to be removed from the tool to check the state of charge.
1 Connect the charger into a mains power outlet.
4 The charger LED will illuminate red signifying that the battery is charging.
3 With the battery sitting on a îat
surface, align the raised ribs on the
battery with the recess in the charger
and slide onto the battery ensuring a
îrm connection.
2 The charger LED will îash green
showing power is being supplied
to the charger.
5 When removing the charger from the
battery, îrst press the battery release
tab, then slide the charger from its
position.
Charging your lithium ion battery - Eco Charger
Charger LED Indicator
LED Indicator Situation
GREEN (Flashing) Stand By (no battery pack is inserted)
RED (Illuminated) Battery is charging (low charge)
GREEN (Illuminated) Battery is fully charged
RED (Flashing) Battery or Charger fault
RED & GREEN (Flashing) Battery pack is too hot or too cold (remove battery from
charger and store at room temperature 20ÂşC. Insert
battery again when at correct charging temperature). If
this happens again, the battery is defective and needs
to be replaced.
Inserting & Removing the Battery
1 Align the ribs of the battery with the recess at the rear of the blower and
push in until it clicks into place.
2 To remove, press and hold the battery release tab and pull the battery
away from the blower.
a
b
Battery protection system
The tool is equipped with the battery protection system, which helps to ensure a long service
life.
The output power automatically cuts off during operation when the tool and/or battery are
placed under the following situations:
⢠When the tool is overloaded:
If this occurs, release the trigger switch and remove causes of overload, then pull the
switch trigger again to restart.
⢠When the remaining battery capacity becomes low:
Recharge the battery pack.
Note: The battery protection system does not in any way damage the tool.
Note: The indicated capacity may be lower than the actual level during use or immediately
after using the tool.
