Seite 1/6
STANDARD EQUIPMENT
PXPRSS-018
INSTRUCTION MANUAL
SPECIFICATIONS
Input: 18V
No Load Speed: 0-2600spm
Stroke Length: 20mm
Cutting Diameter:
80mm max. (with clamping jaw)
100mm max. (w/o clamping jaw)
Saw Blade Length: 150mm max.
Weight: 1.3kg
ozito.com.au
0822
Cordless Pruning Saw
150mm Wood Cutting Blade
CORDLESS
PRUNING SAW
IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY YOU
MUST RETURN THE PRODUCT TO YOUR NEAREST BUNNINGS
WAREHOUSE WITH YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY PLEASE TELEPHONE
OUR CUSTOMER SERVICE HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
WARRANTY
TO ENSURE A SPEEDY RESPONSE PLEASE HAVE THE MODEL
NUMBER AND DATE OF PURCHASE AVAILABLE. A CUSTOMER
SERVICE REPRESENTATIVE WILL TAKE YOUR CALL AND
ANSWER ANY QUESTIONS YOU MAY HAVE RELATING TO THE
WARRANTY POLICY OR PROCEDURE.
OZITO INDUSTRIES PTY. LTD. 25 Fox Drive, Dandenong South, Victoria, Australia 3175.
The benets provided under this warranty are in addition to other rights and
remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded at law. You are entitled to
a replacement or refund for a major failure and for compensation for any other
reasonably foreseeable loss or damage. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure
does not amount to a major failure.
Generally you will be responsible for all costs associated with a claim under this
warranty, however, where you have suffered any additional direct loss as a result of
a defective product you may be able to claim such expenses by contacting our
customer service helpline above.
WARNING
The following actions will result in the warranty being
void.
• If the tool has been operated on a supply voltage other than that specied
on the tool.
• If the tool shows signs of damage or defects caused by or resulting from
abuse, accidents or alterations.
• Failure to perform maintenance as set out within the instruction manual.
• If the tool is disassembled or tampered with in any way.
• Professional, industrial or high frequency use.
5 YEAR REPLACEMENT WARRANTY
Your Product is guaranteed for a period of 60 months from the original date of
purchase and is intended for DIY (Do It Yourself) use only. If a product is defective it
will be replaced in accordance with the terms of this warranty. Lithium Ion
batteries and chargers are covered by a 36 month
warranty and are excluded from the warranty extension. Warranty excludes
consumable parts.
ONLINE MANUAL
Scan this QR Code with your
mobile device to take you to
the online manual.
3
3
3.
Installing and Removing a Blade
The pruning saw can be fitted with standard
reciprocating saw blades, therefore can be used to cut
various materials. The included blade is for timber only.
1. Press both sides of the
protective cover and
open it.
2. Rotate and hold the
blade holder clockwise.
3. Insert the blade fully into
the blade holder then
release the blade holder.
Note: The blade holder will
snap back to lock the blade
in the holder.
4. Ensure the blade is secure by gently pulling on the
blade.
5. To remove the
blade, rotate and
hold the blade
holder clockwise,
then pull out the
blade.
6. Carefully close the
protective cover.
1. Blade Holder
2. Locking Sleeve
3. Blade
4. Clamping Jaw
5. Clamp Lock
6. Protective Cover
7. Safety Switch
8. Variable Speed Trigger
9. Sure Grip Handle
10. Belt Clip
11. Battery Seating
This tool is compatible with all batteries and
chargers from the Ozito PXC range.
CORDLESS PRUNING SAW
BATTERY & CHARGER
KNOW YOUR PRODUCT
1. SAW BLADE
SETUP & PREPARATION
1 2
3 4 5 6 7 8 9 10
WARNING! ENSURE THE PRUNING SAW IS SWITCHED
OFF AND THE BATTERY IS REMOVED BEFORE
PERFORMING ANY OF THE FOLLOWING TASKS.
WARNING! DO NOT HANDLE BLADES WITHOUT GLOVES
AS THEY ARE SHARP AND CAN BECOME HOT AFTER
USE, POTENTIALLY CAUSING PERSONAL INJURY.
WARNING! ALWAYS ENSURE THE BLADE IS REMOVED
WHEN NOT IN USE.
11
WARNING! A MAXIMUM LENGTH OF 150MM (6”)
BLADES SHOULD BE USED WITH THIS MACHINE.
Support
Installing and Removing the Battery
1. Align the ribs of the battery with the recess at the
back of the handle.
2. Slide the battery in so that it clicks into place.
3. To remove, press and hold the battery release tab
to release the battery, then slide the battery out.
Run Time
The operating time of the PXC battery (the number
of cuts that can be completed with a single battery
charge) is largely dependent on the material, battery
charge, blade condition and the rate of work.
Frequently turning the equipment on and off while
pruning will also reduce the amount of operating
time. If the operating time of the PXC battery is still
unsatisfactory in spite of the above measures, you can
remedy the problem by using PXC battery with a larger
capacity (Ah).
2. CLAMPING JAW 3. BATTERY
WARNING! ENSURE THE PRUNING SAW IS SWITCHED
OFF AND THE BATTERY IS REMOVED BEFORE
PERFORMING ANY OF THE FOLLOWING TASKS.
Installing and Removing the Clamping Jaw
The clamping jaw allows branches to be gripped up to
Ø80mm, providing cutting of unsupported branches
easier. When cutting wider branches or timber, the
clamping jaw can be removed and the pruning saw can
be used as a standard reciprocating saw.
Note: For convenience and ease of use the clamping
jaw can be removed and fitted with a blade fitted to the
pruning saw.
1. First, align then slide the
clamping jaw onto the
support.
2. Slide the clamping jaw
into place while pressing
the clamp lock on both
sides of the clamping
jaw. When in position
release the clamp lock
to hold it in place.
Note: The clamp lock is
spring loaded so will snap
back to lock the clamping jaw to the support when
released.
3. To remove the clamping jaw, press and hold the
clamp lock as you pull the clamping jaw out then up
away from the support.
WARNING! ALWAYS ENSURE THE BATTERY IS REMOVED
WHEN NOT IN USE.
