Seite 1/18
SPECIFICATIONS
Input: 18V
Bar Length: 200mm
Cutting Length Max.: 170mm
Chain Speed: 3.76m/s
Oil Tank Capacity: 125ml
Length: 1.83 - 2.77m
Weight: 3.9kg
STANDARD EQUIPMENT
Pole
CORDLESS
POLE PRUNER
INSTRUCTION MANUAL
ozito.com.au
Guide Bar Cover
Pruner Head
Chain
Guide Bar
Rear Handle
Shoulder Strap
Auxiliary Handle
PXCPPS-018
IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY YOU
MUST RETURN THE PRODUCT TO YOUR NEAREST BUNNINGS
WAREHOUSE WITH YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY PLEASE TELEPHONE
OUR CUSTOMER SERVICE HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
WARRANTY
TO ENSURE A SPEEDY RESPONSE PLEASE HAVE THE MODEL
NUMBER AND DATE OF PURCHASE AVAILABLE. A CUSTOMER
SERVICE REPRESENTATIVE WILL TAKE YOUR CALL AND
ANSWER ANY QUESTIONS YOU MAY HAVE RELATING TO THE
WARRANTY POLICY OR PROCEDURE.
OZITO Australia/New Zealand (Head Ofîce) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.
The beneîts provided under this warranty are in addition to other rights and
remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded at law. You are entitled to
a replacement or refund for a major failure and for compensation for any other
reasonably foreseeable loss or damage. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure
does not amount to a major failure.
Generally you will be responsible for all costs associated with a claim under this
warranty, however, where you have suffered any additional direct loss as a result of
a defective product you may be able to claim such expenses by contacting our
customer service helpline above.
0219
WARNING
The following actions will result in the warranty being
void.
⢠If the tool has been operated on a supply voltage other
than that speciîed on the tool.
⢠If the tool shows signs of damage or defects caused
by or resulting from abuse, accidents or alterations.
⢠Failure to perform maintenance as set out within the instruction manual.
⢠If the tool is disassembled or tampered with in any way.
5 YEAR REPLACEMENT WARRANTY
Your Product is guaranteed for a period of 60 months from the original date of
purchase and is intended for DIY (Do It Yourself) use only. If a product is defective it
will be replaced in accordance with the terms of this warranty. Lithium Ion
batteries and chargers are covered by a 36 month
warranty Warranty excludes consumable parts, for example: guide bar, chain
and included accessories.
KNOW YOUR PRODUCT SETUP & PREPARATION
1. ASSEMBLY
1. Chain
2. Guide Bar
3. Oil Cap
4. Side Cover
5. Pivoting Pruner Head Release
6. Telescopic Tube Lock
7. Main Tube
8. Auxiliary Handle
9. Shoulder Strap Holder
10. Assembly Nut
11. Pivoting Handle Release
12. Rear Handle
13. Chain Cover Lock
14. Chain Tension Adjustment Dial
15. Switch Lock
16. Auxiliary Handle Lever
17. Trigger Switch
18. Battery Seating
19. Mounting Attachment Lever
CORDLESS POLE PRUNER
1
2
3
4
5
6
7
8
ONLINE MANUAL
Scan this QR Code with your
mobile device to take you to the
online manual.
15
16
10
11
12
13 14 9
17 18 19
BATTERY & CHARGER
This tool is compatible with all battery and
chargers from the Ozito Power X Change Range.
CAUTION: ENSURE THE TOOL IS OFF & THE BATTERY
REMOVED BEFORE PERFORMING ANY OF THE FOLLOWING
OPERATIONS.
Fitting Rear Handle
1. Push the rear handle fully
onto tube aligning the
internal prongs.
2. Screw tight with
the assembly nut.
Fitting Auxiliary Handle
1. Place the Auxiliary Handle onto
the mounting attachment.
2. Pass the bolt through the auxiliary handle and screw the lever to the end
of the bolt.
3. Select the most comfortable
position and close the lever
to lock the auxiliary handle in
position.
2. TENSIONING THE CHAIN
Note: The Lock Button will âCLICKâ back to the left (original position) when
the pruner head is correctly secured in place.
3 - 4mm gap is
the ideal tension
Fitting Pruner Head
1. Align the pruner head and
the motor head so the
arrows on both coincide.
2. (a) Press the pruner head
against the motor head.
This will cause the lock
button to be pushed to the
right.
(b) Turn the pruner head
clockwise. The pruner head
will lock onto the motor
head and is then secured
in place.
Lock Button
a
b
Note: Only tighten the chain cover locking knob securely once the chain
tension has been adjusted (see: Tensioning the chain.)
CAUTION: THE CHAIN HAS SHARP EDGES. FOR YOUR
OWN SAFETY, PLEASE WEAR WORK GLOVES.
IMPORTANT: IF THE CHAIN IS INSTALLED BACKWARDS
(CHAIN CUTTERS ARE FACING IN THE OPPOSITE
DIRECTION OF ROTATION) THE POLE PRUNER WILL
VIBRATE EXCESSIVELY AND NOT CUT.
Fitting Guide Bar & Chain
1. Loosen the
chain cover
lock and
remove the
side cover.
2. Place the chain in the groove
of the guide bar as shown.
Refer to the image printed on
the guide bar that indicates
the direction that the chain
should face.
Sprocket
3. Place onto the mount,
ensuring that the chain sits
around the chain sprocket.
4 Re-mount and înger-tighten
the side cover with the chain
cover lock.
1. Loosen the chain
cover lock. Do not
remove the side
cover.
CAUTION: IF YOU TRY TO ROTATE THE CHAIN TENSIONING
ADJUSTMENT DIAL WHILST THE CHAIN COVER LOCK IS
TIGHT, IT WILL RESULT IN THE CHAIN NOT LOOSENING
AND POSSIBLE DAMAGE TO THE MECHANISM.
2. Adjust the chain tension with
the chain tensioning adjustment
dial. Turning the dial CLOCKWISE
increases the chain tension,
turning it COUNTER-CLOCKWISE
decreases the chain tension.
For the correct chain tension, îrmly
pull up on the chain at the middle
of the top of the exposed guide bar.
When the chain is pulled up to its
highest point, the bottom tip of the
links should only just stay in the track
[middle of the guide bar]
CAUTION: THE CHAIN HAS SHARP EDGES. FOR YOUR
OWN SAFETY, PLEASE WEAR WORK GLOVES.
3. After the chain has been
accurately tensioned, lock the
guide bar in place with the
chain cover locking knob.
Note: Proper tension of the chain is extremely important and must be
checked before starting, as well as during any cutting operation.
Taking the time to make adjustments to the chain will result in
improved cutting performance and prolonged chain life.
