Seite 1/7
ARISTOCRAT
Sound Floor Lectern
ASSEMBLY MANUAL
MODEL #6010
INTRODUCTION
Aristocrat Sound Lectern — Model 6010
Perfect for the smallest to largest venues. Executive style podium include 50 Watt
Multimedia amplifier with two built in 8” speakers surrounded by gold appointments.
Includes Microphones, Holders, Digital Timepiece & rolls on four casters. For audiences
up to 2,500 people. Assembly required.
Colors: Walnut, Light Oak, Medium Oak, Mahogany/Black Edging
Dimensions: 251⁄4”W x 46” H x 201⁄4” D.
ASSEMBLY TIPS
• Do not use a sharp instrument such as a knife or a screwdriver to open the packag-
ing, as this may scratch or possibley damage the unit.
• All assembly should be done on a clean protected surface such as carpet or similar.
• Mak sure e that you have all the required parts. A list of all the parts are listed.
• Read instructions carefully and follo diagrams to ensur easy & correct assembly.w e
CARE OF YOUR CABINET
• All exterior and interior exposed surfaces are melamine covered as well as edges in
matching patterned melamine material. To refresh the appearance, wipe the sur-
face with a cloth soaked lightly in furniture oil. Avoid speaker grill area. Your cabinet
will look as good as new.
TECHNICAL SPECIFICATIONS
O S CKLAHOMA OUND ORPORATION
2
Manufacturers Warranty
Our Lecterns undergo the most rigid and exacting tests for superior quality and performance before leaving the
factory. Oklahoma Sound Corporation warrants this product to be free from defective material and workman -
ship on the electronic product speakers and microphones for two years from the date of resale by an authorized
Oklahoma Sound distributor. Oklahoma Sound will replace defective parts and repair malfunctioning products
under this warranty when the defect occurs under normal installation and use, provided the unit is returned to
our factory via prepaid transportation after direct authorization and approval by Oklahoma Sound. This war-
ranty provides that examination of the returned product must disclose in our judgement, a manufacturing
defect. This warranty does not extend to any product which has been subject to misuse, neglect, accident,
improper installation, or where the serial number has been removed or defected and is given in lieu of any
other warranty implied or expressed and will not cover any consequential damages.
Power Output ..50W RMS at 10% THD
Mic ....................Electret Condenser Mic (2)
Aux....................150 mV>220K
Frequency........100HZ-25KHZ
Response.......... + 3dB
Power Supply ..110-120V ohms DC 10.8 12V
Fuse ..................2A Normal
Output ............8 ohms
Accessories ......Handheld mic; clip-on
mic; gooseneck;
Shockmount mic holder;
digital clock
Aristocrat Sound Floor Lectern • Model 6010
3
Tool Required
• #2 Phillips Head
Screwdriver
• Hammer
(1) Amplifier
Series 700
(1) Gooseneck
Left Side Panel Right Side Panel Front Panel
BottomTop
(Reading Surface)
Shelf
ASSEMBLY PARTS
Cam-Lock Assembly
(3) Corner Braces
(2) Non
Locking
Casters
(14) Cams
(14) Cam Bolts
(36) #8
1/2” Phillips
Screw
(2) Locking Casters
(1) Tie-Clip
Mic
(1) Hand-held
Condenser Mic
