Seite 1/12
Mounting MG8000 on the Camera
Quick Manual for Nikon
or wai sect 8 .
hol secd 2 .
POWER ON
Function
Pilo Lamt p
Confir presm s
On/Off
Selec functio prest n s
or wait 8 .sec
Pres on/os ff
Set
FUNCTIO SEN T
Nomenclature
Press the on/off switch. Screen A appears, and the mode A is set.
The pilot lamp blinks red showing the unit is charging.
In a few seconds, the pilot lamp turns green.
The display screen automatically turns off in about 30 seconds after the
setting job is terminated.
For a test-flash, press the pilot lamp.
To turn off the flash unit manually, press the on/off switch and hold it for 2
seconds.
Turn off the power switch of both MG8000
and the camera.
Turn the lock ring of MG8000 to loosen it
all the way as shown in the picture.
Slide the mounting foot of MG8000 into
the hotshoe of the camera.
Turn the lock ring to opposite direction
and tighten it.
1.
2.
3.
4.
Lock pin comes out to hook the foot at the
hotshoe for sure contact.
5.
Loosen the lock ring and slide the mounting foot of MG8000 off the hotshoe
of the camera. Make sure to turn the lock ring all the way to completely
clear the lock pin off the hooking slot on the hotshoe.
Turn on the flash unit
Removing MG8000 from the Camera
3.6
MG0512N REV.1.3
Flash head/
Wireless transmitter
Sub-Flash
AF-assist light
External auto exposure sensor
Rotating
display screen
Set button
Pilot lamp (Test flash button) On/Off switch (System lock button)
Select button
Select button
Battery magazine
Lock ring
X-terminal
USB service port
Power Pack socket
Hotshoe contacts
Foot lock pin
External service
box
Mounting foot
Multifunction button
Remote/ Slave sensor
Distributed in Canada by Gentec International
Markham, Ontario L3R 9X6 • www.gentec-intl.com
INSTRUCTION MANUAL
DIGITAL TTL POWER ZOOM FLASH
Please refer Nissin’s compatibility chart shown in its home page for details and
recent updates: http://www.nissin-japan.com or http://www.nissindigital.com
SIMPLE OPERATION
When attaching MG8000 to the camera, the basic flash exposure operation is
fully controlled by the camera. It is the same idea as when you use the built-in
camera flash but placed on the hotshoe.
SPECIAL FEATURES
MG8000 is featuring exetreme high heat resistance to obtain more than 1000
times continuum emitting with full power without overheating problems.
Assorting with Nissin Power Pack PS300 is suggested, enables blazing fast
and maximizes the extreme performance.
In additon, MG8000 provides many advanced flash functions, such as Wireless
TTL off camera flash technology, high speed shutter synchronization, frequent
repeat-flash system, External Av priority setting, etc. are supported.
1 2
Compatible cameras
Thank you for purchasing a Nissin product
UNIQUE FUNCTION
Before using this flash unit, please read this instruction manual and refer
your camera owner’s manual carefully to get a better understanding of
proper operation to enjoy flash photography.
The color display automatically rotates
to allow for easy operation in both the
horizontal and vertical positions.
Nissin MG8000 Extreme type Nikon is designed for Nikon digital SLR, with the
latest TTL flash control system, and features Nissin’s original rotating color
display, easily guiding its operations.
It works automatically with Nikon i-TTL auto-flash systems.
Please note that MG8000 Extreme type N is not usable with other branded
cameras for TTL operation.
Nissin Japan Ltd., Tokyo
http://www.nissin-japan.com
Nissin Marketing Ltd., Hong Kong
http://www.nissindigital.com
Distributed in Canada by Gentec International
Markham, Ontario L3R 9X6
www.gentec-intl.com
MG0412N REV. 1.1
For Nikon
Design and Specifications are subject to change without prior notice.
MG8000 Flash Mode and Functions - to be set on the flash unit.
These safety instructions refer to important information on how to use this
product safely and properly. Please read the following instructions before using
the product.
MENU SCREEN FOR MAIN MODES
5 6
3 4
Flash light is fully controlled by the camera for the most proper exposure.
SAFETY INSTRUCTIONS Nomenclature
WARNING
The flash unit contains high voltage electric parts. Do not try to open or repair the flash unit. Return it back to the
repair service station or the store you bought it from.
Do not touch the inside parts from the opening when the unit was dropped or broken.
Do not shoot the flash directly to the eyes at short distance. It may damage the eyes.
When taking a flash picture, especially toward a baby, it is recommended to keep the flash unit at least 1 meter
(3.3feet) away from the subject. Or use diffuser or bounce the light to the ceiling or wall to soften its intensity.
Do not place the flash unit near any flammable gas, chemical or such liquids. It may cause fire or electric shock.
Do not touch the flash unit with wet hands or use in the water. The flash unit carries high voltage inside and it
may cause an electric shock.
Do not shoot the flash unit directly at the driver of automobiles or such vehicles.
Do not set the flash window close to the human body and shoot, which may get scalded.
Place the batteries correctly in position. Placing the batteries in wrong polarity may cause leakage, exothermic
heat or explosion.
Do not touch the metal parts after long time flashing, which may get scalded.
CAUTIONS
Do not leave or store the flash unit in the temperature over 40ºC, such as in the automobile.
The flash unit is not water resistance. Keep the unit away from rain, snow and humidity.
Do not use benzene, thinner or other alcoholic agents to clean the unit.
Do not use this flash unit with the cameras which are not recommended in compatibility list at official
website, otherwise it may damage the camera’s circuitry.
Remove the batteries when not in use for a longer period of time.
Do not have a heavy impact to the flash unit, nor throw it onto a hard surface floor.
When using the external power pack, read the safety instructions carefully and follow the operation manual.
This sign refers the danger or serious damage.
This sign refers the damage or defect.
Full Automatic Mode
TTL Program Mode
Manual Setting Mode
Multi- flash Mode
Wireless Remote Flash Mode
Custom Setting Mode
Full Automatic Mode
…
…
…
…
…
…
page 10
Flash light is automatically controlled by the camera but the flash exposure
TTL Program Mode page 12
Manual Mode -Selecting the desired manual power on the flash unit,
Manual Setting Mode page 16
Multiple lighting exposes the playback photos in one frame of picture.
Multi-flash Mode page 22
Placing multiple numbers of flashes (slave flash) off camera and controlling the
Wireless Remote Flash Mode page 24
Variety of custom settings is available for own default value.
Custom Setting Mode page 29
value can be compensated.
Av poriority Mode- Selecting the desired f-stop on the flash unit.
creative TTL lighting.
Flash stand
Extra
battery magazine (optional)
Soft Case
Diffuser
Advanced functions are provided in some operation modes –
to be set on the flash unit
Functions by Camera setting – The flash is automatically
controlled by the camera
ADVANCED FUNCTIONS
Flash synchronizes to the faster shutter speed than regular synchronization speed.
High speed shutter synchronization page 31
The flash fires just before the rear curtain closes. A moving subject will appear
Rear curtain synchronization page 31
Flash exposure level is automatically compensated on the sequence of frames
Auto Flash Bracketing page 31
Blinks of flash released before actual effective flash eliminate
Red-eye reduction page 32
The flash is controlled at slow shutter speeds considering the dim condition of the
Slow Shutter Synchronization page 32
Flash exposure can be locked at the main subject while moving the framing.
Fv. Lock page 32
Fv.
Lock
Advanced
Functions
Operation Modes
Sub-Flash
Manual Zoom
Slave Mode
F.Stop Setting
ISO setting
TTL Program Mode
TTL Program Mode
Manual Setting Mode
Manual Setting Mode*1
Manual Setting Mode*2
Manual Setting Mode
Manual Setting Mode
*1 Effective on at Universal Slave function in Manual Power operation and when using MG8000 with film
type camera or with non dedicted camera.
*2 Effective on Universal Slave function, and when using MG8000 with film type camera or with non
dedicated camera.
such moving marks behind.
pre-set in the camera.
background.
the red eye problem.
Flash head/
Wireless transmitter
Sub-Flash
AF-assist light
External auto exposure sensor
Rotating
display screen
Set button
Pilot lamp (Test flash button) On/Off switch (System lock button)
Select button
Select button
Battery magazine
Lock ring
X-terminal
USB service port
Power Pack socket
Hotshoe contacts
Foot lock pin
External service
box
Mounting foot
Multifunction button
Remote/ Slave sensor
