for Canon EOS / Nikon digital SLR cameras
for Sony digital SLR cameras
INSTRUCTION MANUAL
Nissin Japan Ltd., Tokyo
http://www.nissin-japan.com
Nissin Marketing Ltd., Hong Kong
http://www.nissindigital.com
Nissin Di622 Mark II is designed for digital SLR cameras with hotshoe
and the latest TTL flash control technology.
Note: No film camera can be used with Di622 Mark II.
Attach Di622 Mark II to your camera, and then almost all jobs are
controlled by the camera for the most proper exposure.
Read this instruction manual and refer your canera owner’s manual to
enjoy flash photography.
The compatibility list of Di622 Mark II, please check at our official
website: www.nissindigital.com
WARNING
The flash unit contains high voltage electric parts. Do not try
to open or repair the flash unit. Return it back to the repair
service station or the store you bought it.
Do not touch the inside parts from the opening when the unit
was dropped and broken.
Do not fire the flash direct to the eye at short distance. It may
damage the eye. When taking flash picture especially
toward a baby, it is recommended to keep the flash unit at
least 1 meter (3.3feet) away from the subject.
Or use diffuser or bounce the light to the ceiling or to the wall
to soften its intensity.
Do not use the flash unit in the flammable gas, chemicals or
such liquids. It may cause fire or electric shock.
CAUTIONS
Do not leave or store the flash unit in the temperature over
40°C, such like in the automobile.
The flash unit is not water resistant. Keep the unit away from
rain, snow and humidity.
Do not use benzene, thinner or other alcoholic agents to
clean the unit.
Do not use this flash with the cameras which is not listed in
the compatibility list at our official website, otherwise it may
damage the camera’s circuitry.
Remove the batteries when not in use for a longer period of
time.
This sign refers the danger or serious damage.
This sign refers the damage or defect.
622II.Rev.0211.1.0
Design and Specifications are subject to change without prior notice.
D
F
Ch 1 G roup A
P
i
l
o
t
S
y
n
c
Names of the Components
Flash stand
Light diffusing panel / Fill-in reflector
Flash head
AF-assist light / wireless flash sensor
Lock ring
Mounting foot
Hotshoe contacts
X - Terminal
Pilot lamp (Test flash button)
Battery compartment door
Power switch (Press button)
Mode select button / indicator
(TTL Manual SD SF Wireless) → → → →
Flash power leveel indication lamp (6 LEDs)
Flash power level select button
Accessories: Flash stand, Pouch
Basic Operation
Inserting batteries
Open the battery compartment door and
insert 4 x size AA batteries as shown by
the picture.
Make sure the + and - battery contacts are
correctly inserted at the battery compart-
ment.
Close the battery compartment door and
slide it back in place.
NOTE
Wrong insertion or using different size batteries may result damage on the
flash unit.
It is recommended to use all 4 batteries in same brand and type, and
replace them all att p2-he same time.
Ch 1 Group A
F/
P
ilo
t
On/O ff
Ch 1 Grou p A
F/
P
i
l
o
t
On/Off
Ch 1 Group A
F/
P
ilo
t
On/O ff
Mounting Di622 Mark II on the camera
Slide the mounting foot of Di622 Mark
II into the hotshoe of camera.
Twist the lock ring clockwise to tighten
it.
Twist the lock ring anti-clockwise to
loosen it as shown in the picture.
Removing Di622 Mark II from the camera
Loosen the lock ring and slide the mounting foot of Di622 Mark II off
the hotshoe of camera.
Before mounting or removing Di622 Mark II into or from the camera,
make sure to turn off the power switch of both Di622 Mark II and the
camera.
NOTE
Push the lever of the locking ring (in the
direction of the arrow) of Di622 Mark II
to loosen it as shown in the picture.
Slide the mounting foot of Di622 Mark
II into the hotshoe of the camera while
holding down the lock ring .
Release the lock ring of Di622 Mark II
when the mounting foot is fully slide into
the hotshoe of the camera.
Lock pin comes out to hook the foot at
the hotshoe for sure contact.
*For Nikon and Canon type digital SLR cameras
Mounting Di622 Mark II on the camera
*For Sony type digital SLR cameras
S
*Sony type hotshoe / Flash stand
Removing Di622 Mark II from the camera
Push down the lock ring and slide the mounting foot of Di866 Mark II
off the hotshoe of the camera. Make sure to slide off the mounting foot
and completely clear the lock pin off the hooking slot on the hotshoe.
Before mounting or removing Di622 Mark II into or from the camera,
make sure to turn off the power switch of both Di622 Mark II and the
camera.
NOTE
Turn on the flash unit
D F
Ch1 Group A
For a test flash, press the Pilot lamp. When using
the test flash as an open flash, please note that the
reference guide number in this case is G.No.10 (ISO
100).
To turn off the flash unit manually, press the On/Off
switch for 2 seconds.
Press the On/Off switch and Pilot
lamp turns red showing the unit is
turned on.
In a few seconds, the Pilot lamp
turns green. Di622 Mark II is
ready to shoot.
Di622 Mark II has energy saving double power off function
To save battery energy, the power is automatically turned off
(switch to stand-by mode), both in TTL mode & Manual Power
mode, in about 2 minutes of idle use.
While Di622 Mark II is in the stand-by mode a Pilot lamp blinks
every 2 seconds showing the flash unit is in stand-by mode.
To turn on Di622 Mark II again, press the camera’s shutter button
halfway or press any button of the flash unit.
In case Di622 Mark II is not in use over 30 minutes, the unit is
completely turned off and shut out the current leakage from the
batteries.
To turn on Di622 Mark II again, take the first step of turning the
flash unit on.
In case of using Di622 Mark II in slave or remote mode, Di622
Mark II will not go into the stand-by mode. It will however
automatically turn off when not used over 60 minutes.
Shooting Di622 Mark II automatically
Canon cameras
Nikon cameras
(Program), (Full Auto), (Aperture priority),
(Shutter priority) or (Manual); and / or
(Program), (Full Auto), (Aperture priority),
(Shutter priority) or (Manual);
Set the camera’s shooting mode, select focal length and take pictures with
Di622 Mark II on your camera.
Di622 Mark II is a supplement to help you taking a creative and live
picture. Almost all jobs are automatically done by the camera and you just
control the camera only.
Set Di622 Mark II to the camera’s hotshoe and turn on the power switch.
Di622 Mark II is automatically set for the camera’s TTL mode when
ready lamp lights up.
Press the shutter button of your camera halfway to focus the subject.
Take the picture. Di622 Mark II is fired and the result is immediately shown
on the camera’s LCD display.
When you change the focal length, The power zoom flash head of
Di622 Mark II responds without delay and immediately sets its position to
match the lens focal length you selected.
The flash illumination coverage of Di622 Mark II responds to the lens
focal length of 24mm to 105mm (35mm film camera standard).
In all camera's shooting mode listed above, Di622 Mark II will fully work
in TTL (ETTL, ETTL-II for Canon, i-TTL for Nikon and ADI, P-TTL for Sony )
automatic-flash system.
Shutter speed, aperture and flash mark ( ) are indicated in camera’s view
finder.
Mode
Canon Nikon Sony
Shutter
Speed
Aperture
Setting
Control on
the camera
Automatic Automatic Automatic
Automatic Automatic Automatic
Manual Automatic
Automatic Manual
Manual Manual
Any available shutter
speed can be set
Any available f-stop
can be set
Any available shutter
speed / f-stop can be set
Synchro Terminal
Di622 Mark II equipped a Synchro terminal (X terminal) to connect the
off-camera cable, allows photography with flash units seperate from
the camera. This feature can be applied in Manual mode only.
Joy of Flash Photography
TTL flash power compensation is provided in 7 steps by half Ev
increment for -1.5, -1.0, -0.5, 0, +0.5, +1.0, and +1.5 Ev.
Set the Flash power level select button to the power level you desire.
When Di622 Mark II shows no level indication LED is turned on, the
flash power compensation level is at even (0 Ev) level as default
value.
Take a picture and the aimed subject is shown with required lighting
effect by keeping the background exposure level as originally
expected.
Press the flash power select button, by each press of + marked knob,
it sets the power of +0.5 +1.0 +1.5 Ev. and the - marked knob → →
sets it to -0.5 -1.0 -1.5 Ev. The power level indication lamp → →
shows the power level you set.
On some cameras, the TTL flash power compensation setting is
provided in its menu mode.
When setting the TTL flash power compensation on your camera, the
same of Di622 Mark II is, in this case, to be counted in addition to
the compensation you selected in the camera’s menu mode.
With the latest TTL flash control system, the
flash power level is always automatically
controlled by the camera for the most
appropriate exposure. You wish if you can
soften or weaken the flash light, or give more
light to the subject without changing the
environmental or background exposure effect
Di622 Mark II can make it possible quickly
for each shot at respective occasion of flash
picture.
TTL flash power compensation
DF
Ch1 Group A
Sony cameras
(Program), (Full Auto), (Aperture priority),
(Shutter priority) or (Manual);
