Emptying condensation

Empty container each drying operation!after

1. Pull out condensate container keeping it horizontal.

2. Pour out condensation.

3. Always push container in fully until it clicks into place.

If flashes in the display panel .-(Container) aWhat to do if..., Page 10

Cleaning the fluff filter

Clean the fluff filter each drying operation.after

1. Open the door, remove fluff from door/door area.

2. Pull out and fold open the fluff filter.

3. Remove the fluff (by wiping the filter with your hand).

If the fluff filter is very dirty or blocked, rinse with warm water and dry

thoroughly.

4. Close and reinsert the fluff filter.

Switching off the dryer

Turn the programme selector to . (Off)

Do not leave laundry in the dryer.

Removing the laundry

The automatic anti-crease function causes the drum to move at specific intervals, the washing remains

loose and fluffy for an hour (two hours if the additional function is also selected- (Reduced Ironing)

depending on model).

... and adapt to individual requirements

Never start the dryer if it is damaged!

Inform your after-sales service. Inspecting the

dryer

Sorting and loading laundry

Remove all items from pockets.

Check for cigarette lighters.

The drum must be empty prior to loading.

See programme overview on page 7.

See also separate instructions for “Woollens basket”

(depending on model)

Your new dryer

Congratulations - You have chosen a modern, high-quality Neff

domestic appliance.

The condensation dryer is distinguished by its economical energy

consumption.

Every dryer which leaves our factory is carefully checked to ensure

that it functions correctly and is in perfect condition.

Should you have any questions, our after-sales service will be pleased

to help.

Environmentally-responsible disposal 

This appliance is labelled in accordance with European Directive 

2012/19/EU concerning used electrical and electronic appliances

(waste electrical and electronic equipment - WEEE). The guideline

determines the framework for the return and recycling of used

appliances as applicable throughout the EU.

For further information about our products, accessories, spare parts

and services, please visit: www.neff.de

Intended use Preparing for installation, see Page 8

Selecting and adjusting the programme

Drying

Condensate container

Control panel

ʋfor domestic use only,

ʋonly to be used for drying fabrics that have been

washed with water.

Keep children younger than 3 years old away from

the dryer.

Do not let children make the cleaning and

maintenance work on the dryer without supervision.

Do not leave children unsupervised near the dryer.

Keep pets away from the dryer.

The dryer can be operated by children 8 years old

and older, by persons with reduced physical,

sensory or mental abilities and by persons with

insufficient experience or knowledge if they are

supervised or have been instructed in its use by

a responsible adult.

Select the drying programme ...

Press the Start/Stop buttonu

Make sure your hands are dry.

Hold the plug only. Connecting the

mains plug

Drying

Information on laundry ...

Labelling of fabrics

Follow the manufacturer's care information.

(cDrying at normal temperature.

'cDrying at low temperature also select .a(Low Heat)

)cDo not machine dry.

Observe safety instructions without fail !aPage 11

Do not tumble-dry the following fabrics for example:

– Impermeable fabrics (e.g. rubber-coated fabrics).

– Delicate materials (silk or curtains made from synthetic material) they may creasea

– Laundry contaminated with oil.

Drying tips

– To ensure a consistent result, sort the laundry by fabric type and drying programme.

– Always dry very small items (e.g. baby socks) together with large items of laundry

(e.g. hand towel).

– Close zips, hooks and eyelets, and button up covers.

Tie fabric belts, apron strings, etc. together

– Do not over-dry easy-care laundry risk of creasing!a

Allow laundry to finish drying in the air.

– Do not dry woolens in the dryer, only use to freshen them up aPage 7, cWool finish

Programme (depending on model).

– Do not iron laundry immediately after drying, fold items up and leave for a while

a the remaining moisture will then be distributed evenly.

– The drying result depends on the type of water used during washing.

a a Fine adjustment of the drying result Page 5/6.

– Machine-knitted fabrics (e.g. T-shirts or jerseys) often shrink the first time they are dried

ado not use the programme.7(Cupboard Dry Plus)

– Starched laundry is not always suitable for dryers starch leaves behind a coating that a

adversely affects the drying operation.

– Use the correct dosage of fabric softener as per the manufacturer's instructions when

washing the laundry to be dried.

– Use the timer programme for small loads this improves the drying result.a

Environmental protection / Energy-saving tips

– Before drying, spin the laundry thoroughly in the washing machine the higher the spin a

speed the shorter the drying time will be (consumes less energy), also spin easy-care

laundry.

– Put in, but do not exceed, the maximum recommended quantity of laundry

a a programme overview Page 7.

– Make sure the room is well ventilated during drying.

– Do not obstruct or seal up the air inlet.

– Keep the air cooler clean .aPage 6 “Care and cleaning”

Fine adjustment of the drying result

Adjustment of the levels of dryness

1 x to the right Press and hold (Low Heat)

and turn 5 x to the right

Press (Low Heat) until

the required level is reached

Turn to

(Off)

Turn to

(Off)

Drum

All buttons are sensitive and only

need to be touched lightly.

Only operate the dryer with

the fluff filter inserted! Air inlet

Fluff filter

Drum interior light

(depending on model)

Maintenance

flap Programme end once lights up in the display.

Interrupt programme removing or adding laundry.

The drying cycle can be interrupted for a brief period so that laundry may be added or removed.

The programme selected must then be resumed and completed.

Never switch the dryer off before the drying process has ended.

Drum and door may be hot!

1. Open door, the drying process is interrupted.

2. Load or remove laundry and close door.

3. If required, select a new programme and additional functions.

4. Press the /Stop button.uStart

Additional

functions

Programme selectorDisplay panel

Select On/Off for a acoustic signal at end of programme. ˎ3(Buzzer)

Reduced temperature for delicate fabrics that require a longer'

drying time; e.g. for polyacrylics, polyamide, elastane or acetate.

ˎ (Low Heat)

Reduces creasing and extends the anti-creasing phase once the

program has ended.

ˎ (Reduced

Ironing)

Read these instructions and the separate

Energy-saving mode instructions before

operating the dryer.

Observe the safety instructions on page 11.

Contents Page

ʋPreparation . . . . . . . . . . . . . . . . . . . . . . 2

ʋSetting the programmes . . . . . . . . . . . . . 2

ʋDrying . . . . . . . . . . . . . . . . . . . . . . . . 3/4

ʋInformation on laundry . . . . . . . . . . . . . . 5

ʋFine adjustment of the drying result . . 5/6

ʋCare and cleaning . . . . . . . . . . . . . . . . . 6

ʋProgramme overview . . . . . . . . . . . . . . . . 7

ʋInstallation . . . . . . . . . . . . . . . . . . . . . . . . 8

ʋFrost protection / Transport. . . . . . . . . . . 8

ʋTechnical data . . . . . . . . . . . . . . . . . . . . 9

ʋOptional accessories . . . . . . . . . . . . . . . . 9

ʋWhat to do if... / After-sales service . . . . 10

ʋSafety instructions . . . . . . . . . . . . . . . . 11

ˎh:min 

(Finished in)

End of programme in 1*-24 hours (Press button several times if required)

(*depending on the selected programme, e.g. duration 1:54h 2h. a

Can always be selected to the next full hour.)

Fine adjustment

of the drying

result

The drying result (e.g. Cupboard Dry) can be adjusted over three levels (1 - max. 3)

for the , and programmes presetting = 0.Cottons I Synthetics  Super 40 a

After one of these programmes has been finely adjusted, the setting is retained for the others.

Further information .aPage 5/6

0, 1, 2, 3

Time

remaining

Fine adjustment of the drying result

Care and cleaning

Dryer housing, control panel, air cooler, moisture sensors

– Wipe with a soft, damp cloth.

– Do not use harsh cleaning agents and solvents.

– Remove detergent and cleaning agent residue immediately.

– During drying, water may collect between the door and seal.

This does not affect your dryer's functions in any way.

Clean the protective filter 5 - 6 times a year

or if v÷(Filter) flashes after cleaning the fluff filter.

Air cooler / Protective filter

When cleaning, only remove the protective filter. Clean the air cooler behind

the protective filter once a year.

– Allow the dryer to cool.

– Residual water may leak out, so place an absorbent towel underneath

the maintenance door.

1. Unlock the maintenance door.

2. Open the maintenance door fully.

3. Turn both locking levers towards each another.

4. Pull out the protective filter/air cooler.

Do not damage the protective filter or air cooler.

Clean with warm water only. Do not use any hard or sharp-edged objects.

5. Clean the air cooler thoroughly,protective filter/

Allow to drip dry.

6. Clean the seals.

7. Re-insert the protective filter/air cooler,

with the handle facing down.

8. Turn back both locking levers.

9. Close the maintenance door until the lock clicks into place.

Moisture sensors

The dryer is fitted with stainless steel moisture sensors. The sensors

measure the level of moisture in the laundry. After a long period of operation,

a fine layer of limescale may form on the sensors.

1. Open the door and clean the moisture sensors with a damp sponge

which has a rough surface.

Do not use steel wool or abrasive materials.

L:00, L:01, L:02, L:03 are shown in sequence

Short signal when changing from L:03 to L:00, otherwise long

signal.

Only when switched off!

dccccc+ccc!/b drying, iron dry, cupboard dry, fluff/finished

-(Container) Empty the condensate container.

v (Filter) Clean the fluff filter and/or air cooler under running water. aPage 4/6.

Programme overview also see Page 5

Sort the laundry according to type of textile and fabric. Fabrics must be suitable for tumble drying.

After drying... c @c ciron laundry lightly iron laundrydo not iron laundry mangle laundry

PROGRAMMES TEXTILE TYPE AND INFORMATION

** Cottonsmax. 7 kg Hard-wearing fabrics, boil-resistant fabrics made of cotton or linen.

** SyntheticsI max. 3.5 kg Non-iron laundry made of synthetic fibres and blended fabric, easy-care cotton.

c c @c (Iron Dry) ÷ Fabrics suitable for ironing (iron fabrics in order to avoid creasing).

+ @ (Cupboard Dry) Single-layer fabrics.

* (Cupboard Dry Plus) / 7

9c(Very Dry) @Fabrics made of thick, multilayered items of clothing.

 Wool finish max. 3 kg Woollen fabrics suitable for washing machines. Fabrics become fluffier but not dry.

Remove fabrics once the programme has ended and allow to dry.

WOutdoor max. 1.5 kg Fabrics with membrane coating, water-repellent fabrics, functional clothing, fleece fabrics (dry jackets/trousers

with removable internal lining separately).

u Dessous max. 1 kg Lingerie made of synthetic fibres, cotton or blended fabric.

A Super 40 max. 2 kg

Laundry made of synthetic fibres, cotton or blended fabrics (for example) that needs to be dried quickly. The values may

differ from the those specified depending on the type of fabric, mixture of laundry to be dried, residual moisture in the

fabric and loading capacity.

 Timed programme 20 min. max. 3 kg Pre-dried, multi-layered, sensitive fabrics made of acrylic fibres, or separate small items of laundry.

Also for subsequent drying.

*for and programmes only Cottons ISynthetics

**Dryness levels can be selected individually (Cupboard Dry Plus) / (Very Dry), (Cupboard Dry) and (Iron Dry) .a7 9c + c (depending on the model)

Degree of dryness can be finely adjusted; multi-layered textiles require a longer drying time than single-layered items of clothing. Recommendation: Dry separately.

9409/ 9000964457

*964457* R7380X1EU

Installation

– Delivery specification: dryer, instructions for installation and use, woollens basket

(depending on model).

– Check dryer for transport damage.

– The dryer is very heavy. Do not attempt to lift it on your own.

– Be careful to avoid sharp edges.

– Do not lift the dryer by any of the protruding parts (e.g. the door) as they may break off.

– Do not set up in a room that is susceptible to frost.

Freezing water may cause damage.

– If in doubt, have the appliance connected by an expert.

Setting up the dryer

– The appliance plug must always be accessible.

– Ensure that the appliance is installed on a clean, level

and solid surface.

– Keep the cooling grille at the front of the dryer

unobstructed.

– Keep the area around the dryer clean.

– Make the dryer level using the threaded feet

and a spirit level.

Do not remove the threaded feet under any

circumstances.

Mains connection see safety instructions Page 11.a

– Connect to an AC earthed socket. If in doubt have the socket checked by an expert.

– The mains voltage and the voltage shown on the rating plate (aPage 9) must correspond.

– The connected load and necessary fuse protection are specified on the rating plate.

Converting the installed load Note the fuse protection of the socket.

10/16 Amps

Frost protection / Transport

Preparation

1. Empty the condensate container .apage 4

2. Select any programme using the programme selector.

3. Press the uStart/Stop button condensation is pumped into the container.a

4. Wait 5 min., and then empty the condensate container again.

5. Turn the programme selector to  (Off).

1. Take all accessory parts

out of the drum.

The drum must be empty.

Make sure that the air

inlet remains unobstructed

Clean and level

turn to

(Off)

Press and hold selection

then turn 3 x to the right turn to

(Off)

Set

amperage

1 x to the

right

Feedback (depending on model): off

flashes

10 A

16 A

Do not operate the dryer if

there is a danger of frost.

Do not set up the dryer behind a door or sliding

door as this may obstruct or prevent the dryer door

from opening. This will prevent a potentially fatal

danger to children from locking themselves in.

Technical data

ʠDimensions (DxWxH) 60 x 60 x 85 cm (height adjustable)

Weight approximately 45 kg

Max. capacity 7 kg

condensate container 4.2 l

Connection voltage

Connected load

Fuse protection see appliance rating plate

Ambient temperature

Product number/

Production number

You can find the rating plate on the back of the dryer.

Power consumption when switched off 0.10 W

Power consumption when ready for use (left-on mode) 1.00 W

ʠDrum interior light (bulb E14, 25 W)(depending on model)

The drum lights up after the door is opened or closed, and after the programme starts, and switches off automati-

cally. Changing the bulb .apage 10

Consumption values table (The value on the label is achieved at the maximum heat setting.)

Programme

Spin speed which

is used for spinning

the laundry

Duration** Energy consumption**

cCottons 7 kg 3.5 kg 7 kg 3.5 kg

10 A 16 A 10 A 16 A 10 A 16 A 10 A 16 A

+c(Cupboard Dry)* 1400 rpm 112 min 98 min 93 min 63 min 3.54 kWh 3.54 kWh 1.95 kWh 1.95 kWh

1000 rpm 131 min 115 min 100 min 70 min 4.13 kWh 4.13 kWh 2.27 kWh 2.27 kWh

800 rpm 150 min 133 min 116 min 86 min 4.72 kWh 4.72 kWh 2.79 kWh 2.79 kWh

 (Iron Dry)* 1400 rpm 93 min 69 min 78 min 48 min 2.55 kWh 2.55 kWh 1.78 kWh 1.78 kWh

1000 rpm 111 min 82 min 87 min 57 min 3.22 kWh 3.22 kWh 2.23 kwh 2.23 kwh

800 rpm 130 min 94 min 98 min 68 min 3.90 kWh 3.90 kWh 2.81 kwh 2.81 kwh

cSynthetics 3.5 kg 3.5 kg

+(Cupboard Dry)* 800 rpm 48 min 42 min 1.35 kWh 1.35 kWh

600 rpm 60 min 51 min 1.65 kWh 1.65 kWh

*Programme setting for testing in accordance with the applicable EN61121 standard.

** The values may differ from those specified, depending on the type of fabric, composition of laundry to be dried, residual moisture in the fabric and the

amount of laundry being loaded.

Optional accessories (from after-sales service using order number, depending on model)

Washer-dryer stack connection set

The dryer can be placed on top of a suitable washing machine with the same width and depth to save space. The

dryer fastened to the washing machine using this connection set. With pull-out worktop: WZ 20300must be

Connection fittings for condensation outlet

The condensation is conveyed directly via a hose.

Installation underneath the worktop

Instead of the appliance covering plate, you have a metal cover fitted by a specialist.must

20310

20160

20290

Most efficient programme for cotton fabrics

The following "standard cottons programme" (identified with ) is suitable for drying normal, wet cotton laundry and is most efficient in terms of its 

combined energy consumption for drying wet cotton laundry.

Standard programme for cottons in accordance with current EU regulation 932/2012

Programme Load Energy consumption Programme duration

Cottons

Cupboard Dry 7 kg/3.5 kg

10 A 16 A 10 A 16 A

4.13 kWh/2.27 kWh 4.13 kWh/2.27 kWh 131 min/100 min 115 min/70 min

Programme setting for testing and energy labelling in accordance with Directive 2010/30/EU.

What to do if ...

If you cannot rectify a fault yourself (e.g. switching off/on), please contact our after-sales service. We will

always find an appropriate solution and will avoid unnecessary visits by engineers. Trust the expertise of

the manufacturer and rest assured that the repair will be carried out by trained service technicians using

original spare parts. The contact details of your local after-sales service can be found in the enclosed

after-sales service directory, or by calling one of these numbers:

– 0344 892 8989 (Calls charged at local or mobile rate.)GB

– 01450 2655 (0.03 € per minute at peak. Off peak 0.0088 € per minute.)IE

When contacting the after-sales service, please quote the appliance's product number (E no.) and

production number (FD) (see the inside of the door).

Set the programme selector to  (Off) and remove the appliance plug from the socket.

ʠThe /Stop indicator lamp uStart

does not light up.

Mains plug plugged in?

Programme selected?

Check the socket fuse.

ʠThe display panel light and

indicator lights (depending on

model) go out and the

uStart/Stop indicator light

flashes.

Energy-saving mode is activated a see the separate Energy-saving

mode instructions.

ʠThe and -(Container)

uStart/Stop indicator lights are

flashing.

Empty the condensate container.

If featured, check hose for condensation outlet.

ʠThe and /Stopv÷(Filter) uStart

indicator lights are flashing.

Clean the fluff filter and/or air cooler under running water aPage 4/6.

ʠDryer does not start. /Stop button selected?uStart

Door closed? Programme set?

Ambient temperature greater than 5°C?

ʠWater is running out. Align dryer horizontally.

Clean air cooler seal.

ʠThe door opens by itself. Push the door closed until you hear it engage.

ʠCreasing. Laundry load exceeded?

Remove articles of clothing immediately after the end of the

programme, hang up and pull into shape.

Unsuitable programme selected a Page 7.

ʠLaundry is not dried correctly or is

still too damp.

After the end of the programme, warm laundry feels damper than it

actually is. Spread the laundry out and allow the heat to disperse.

Finely adjust the dryness level – this extends the drying time but does

not increase the temperature. Your laundry will become drier.

Select a programme with a longer drying time or increase the drying

level. This does not increase the temperature.

Select a time programme for extended drying of laundry that is still

damp.

If you have exceeded the maximum load for the programme, the

laundry may not be dried correctly.

Clean the moisture sensor in the drum. A fine layer of limescale may

adversely affect the performance of the sensors and your washing will

not dry properly.

Drying has been interrupted as a result of a power cut, because the

condensate container is full or because the maximum drying time has

been exceeded.

ʠDrying time too long. Rinse the fluff filters under running water a Page 4.

Insufficient supply of air a ensure that air can circulate.

Air inlet possibly blocked a a Clear inlet Page 8.

Ambient temperature higher than 35°C a ventilate the room.

ʠThe humidity in the room

increases significantly.

Make sure the room is sufficiently ventilated.

ʠPower failure. Remove laundry from the dryer immediately and spread out. This

allows the heat to dissipate. Be careful as the door, the drum and the

laundry may be hot.

ʠOne or more indicator lights for

programme status are flashing.

Clean filter and air cooler aPage 4/6.

Check installation conditions aPage 8.

Switch off, leave to cool down, switch on again, restart programme.

ʠThe interior light is not working

(depending on model).

Pull out the appliance plug, remove the cover cap in the interior above

the door (use Torx 20 screw driver) and replace the bulb.

Close the cover cap.

Never operate the dryer without a cover cap.

Safety instructions

Emergency

– Pull the appliance plug out of the socket immediately or disconnect the fuse.

ONLY use the

dryer...

– in rooms inside the house.

– to dry fabrics.

The dryer must

NEVER...

– be used for other purposes than those described above.

– be modified in terms of its technology or attributes.

Dangers

– The dryer must not be used by children or persons who have not been

instructed in its use.

– Do not leave children unsupervised near the dryer.

– Keep pets away from the dryer.

– Remove all objects from pockets. Make especially sure that cigarette lighters

are removed as they constitute an a explosion hazard.

– Do not lean or sit on the door a risk of tipping.

Installation

– Secure loose cables a tripping hazard.

– Do not operate the dryer if there is a risk of frost.

Mains

connection

– Connect the dryer according to specifications to an AC earthed socket, as

otherwise it cannot be guaranteed that the appliance is completely safe.

– The cable cross-section must be sufficient.

– Only use earth-leakage circuit breakers with the following symbol:

– The appliance plug and socket must be compatible.

– Do not use multiple plugs/couplings and/or extension cables.

– Do not hold the appliance plug with wet hands a risk of electric shock.

– Never pull the appliance plug out of the socket by its cable.

– Do not damage the mains lead a risk of electric shock.

Operation

– Only load the drum with laundry. Check the contents before you

switch the dryer on.

– Do not use the dryer if the laundry has been in contact with solvents, oil, wax,

grease or paint (e.g. hair setting spray, nail polish remover, stain remover,

cleaning solvent, etc.) a fire/explosion hazard.

– The tumble dryer is not to be used if industrial chemicals have been used for

cleaning.

– Dust (e.g. coal dust, flour) poses a danger: do not use the dryer

aexplosion hazard.

– Do not turn off the dryer until the drying process ends, unless the laundry will

be removed quickly and spread out, so that the heat can dissipate.

– Do not put laundry containing foamed material/rubber in the dryer a elastic

material may be destroyed and the dryer may be damaged due to possible

deformation of the foamed material.

– Light things, such as long hair, may be sucked into the air inlet of the dryer

aRisk of injury.

– Final part of a tumble dryer cycle occurs without heat (cool down cycle), to

ensure that the items are left at a temperature that ensures that the items will

not be damaged.

– Switch off the dryer once the programme has ended.

– Condensation is not drinking water and may be contaminated with fluff.

Defect

– Do not use the dryer if it is defective or if you suspect it is.

Repairs must only be carried out by the after-sales service.

– Do not use the dryer if the mains cable is defective. To avoid danger, only

have the defective mains cable replaced by the after-sales service.

– Always pull the mains plug out of the socket before changing the bulb for the

interior light a risk of electric shock.

Spare parts

– Only use genuine spare parts and accessories for safety reasons.

Disposal

– Dryer: pull out the appliance plug, cut off the mains cable from the then

appliance. Dispose of at municipal waste disposal facility.

– Packaging: do not leave children alone with packing parts a risk of

suffocation.

– All materials are environmentally sound and can be reused.

Dispose of in an environmentally-responsible manner.

INSTRUCTIONS FOR INSTALLATION AND USE

TUMBLE DRYER

Produktspezifikationen

Marke:	Neff
Kategorie:	Trockner
Modell:	R7380X1EU
Breite:	598 mm
Tiefe:	625 mm
Gewicht:	45000 g
Produktfarbe:	Weiß
Steuerung:	Rotary, Touch
Höhe:	842 mm
AC Eingangsspannung:	220-240 V
AC Eingangsfrequenz:	50 Hz
Eingebautes Display:	Ja
Verpackungsbreite:	630 mm
Verpackungstiefe:	680 mm
Verpackungshöhe:	870 mm
Paketgewicht:	46000 g
Zertifizierung:	VDE, CE
Geräteplatzierung:	Freistehend
Energieeffizienzklasse:	B
Kabellänge:	1.45 m
Trockenprogramme:	Wool, Sport, Lingerie
Maximale Schleuderdrehzahl:	1400 RPM
Startzeitvorwahl:	Ja
Ladetyp:	Frontlader
Anschlusswert:	2800 W
Jährlicher Energieverbrauch:	497 kWh
Nennstrom:	10 A
Energieverbrauch:	3.92 kWh
Zykluszeit:	150 min
Nennkapazität:	7 kg
Geräuschpegel:	64 dB
Trommelmaterial:	Edelstahl
Türanschlag:	Rechts
Trocknungssystem:	Kondensation
Einschalteverzögerung (max.):	24 h
Stromverbrauch (aus):	0.1 W
Türöffnungswinkel:	160 °
Trommelvolumen:	112 l
Trommelinnenbeleuchtung:	Ja
Anzahl Trocknungsprogramme:	11
LED Programm-Kontrollleuchte:	Ja
