TECHNICAL MANUAL GS 4x.10 KNX – ENGLISH

Technical manual GS 4x.10 knx

Application description air quality sensor & control–

General Information

The device fits for the particular use of the following tasks: monitoring of the air quality in building systems technology ( offices, hotels, conference venue etc.), data schools,

transfer and regulation via bus system. The device is intended for use in accordance with the defined technical data. Operate the device exclusively in a dry room! The device is

not qualified for security relevant tasks such as emergency doors, fire protection equipment, fermenting cellars etc.

The air quality sensor GS 4x.10 knx can provide the following data and control for the KNX bus:

Please consider that handling and installation of the device is explained in the instruction manual enclosed to the product!

Please take into account the resolution of the 2 Bytes data type (see KNX Specification)!

CO2: Value output

Control (step and PI control)

Relative humidity: Value output

Control (step and PI control)

Temperature: Value output

- Control heating / cooling (2 point and PI control)

Alarms

Dew point: Value output

Alarm

Air pressure: Value output

GS 40.10 knx

GS 41 .10 knx

TECHNICAL MANUAL GS 4x.10 KNX – ENGLISH

Table of contents

General Information ................................................................................................................................................................................................................................................................................................................................... 1

Application program ................................................................................................................................................................................................................................................................................................................................... 3

Technische Daten ...................................................................................................................................................................................................................................................................................................................................... 3

Overview parameters ................................................................................................................................................................................................................................................................................................................................. 4

Communication objects.............................................................................................................................................................................................................................................................................................................................. 5

Communication flags ............................................................................................................................................................................................................................................................................................................................... 18

1. Global Settings ............................................................................................................................................................................................................................................................................................................................. 19

2. CO 2 Sensor .................................................................................................................................................................................................................................................................................................................................. 20

3. CO 2 Control .................................................................................................................................................................................................................................................................................................................................. 21

3.1 Switching commands / priority CO 2 – Thresholds 1 / 2 / 3 ........................................................................................................................................................................................................................................................... 22

3.2 -control for CO PI 2 ......................................................................................................................................................................................................................................................................................................................... 23

4. Relative humidity sensor .............................................................................................................................................................................................................................................................................................................. 24

5. Relative humidity control .............................................................................................................................................................................................................................................................................................................. 25

5.1 Switching commands and priority relative humidity control – Threshold 1 / 2 / 3 ........................................................................................................................................................................................................................ 26

5.2 PI control for relative humidity ...................................................................................................................................................................................................................................................................................................... 27

6. Temperature Sensor .................................................................................................................................................................................................................................................................................................................... 28

7. Temperature Alarme .................................................................................................................................................................................................................................................................................................................... 29

8. Temperature control ..................................................................................................................................................................................................................................................................................................................... 30

8.1 mperature control – heating and cooling ................................................................................................................................................................................................................................................................................. 30 Te

8.2 Temperature control – General .................................................................................................................................................................................................................................................................................................... 31

8.3 Temperature control – Set points ................................................................................................................................................................................................................................................................................................. 32

8.4 Temperature control – Main level and extra level heating / cooling ............................................................................................................................................................................................................................................. 33

9. Dew point Temperature ............................................................................................................................................................................................................................................................................................................... 34

10. Dew point Alarm ........................................................................................................................................................................................................................................................................................................................... 35

11. Air pressure sensor ...................................................................................................................................................................................................................................................................................................................... 36

12. VAV control .................................................................................................................................................................................................................................................................................................................................. 37

13. Inputs ........................................................................................................................................................................................................................................................................................................................................... 38

13.1 General ................................................................................................................................................................................................................................................................................................................................... 38

13.2 E1 – E5 General ..................................................................................................................................................................................................................................................................................................................... 39

13.2.1 E1 – E5 as binary inputs ......................................................................................................................................................................................................................................................................................................... 40

13.2.1.1 .................................................................................................................................................................................................................................................................................................... 40 Switching/Alarm function

13.2.1.2 Dimming ............................................................................................................................................................................................................................................................................................................................. 42

13.2.1.3 Blind sensor ....................................................................................................................................................................................................................................................................................................................... 43

13.2.1.4 Value / forced operation ..................................................................................................................................................................................................................................................................................................... 44

13.2.1.5 Scene ................................................................................................................................................................................................................................................................................................................................. 46

13.2.1.6 Switching sequences ......................................................................................................................................................................................................................................................................................................... 47

13.2.1.7 Multiple operation ............................................................................................................................................................................................................................................................................................................... 48

13.2.1.8 Pulse counter ..................................................................................................................................................................................................................................................................................................................... 49

13.2.1.8.1. Intermediate counter (with function pulse counter) ....................................................................................................................................................................................................................................................... 50

13.2.2 Function analogue input (Only available at input E1) ............................................................................................................................................................................................................................................................. 51

13.2.2.1 E1 Voltage ......................................................................................................................................................................................................................................................................................................................... 51

13.2.2.2 E1 Output ........................................................................................................................................................................................................................................................................................................................... 52

13.2.2.3 E1 Threshold value ............................................................................................................................................................................................................................................................................................................ 53

13.2.2.4 E1 Output threshold value ................................................................................................................................................................................................................................................................................................. 54

13.2.3 Function external Temperature sensor (input E4/5 only) ........................................................................................................................................................................................................................................................ 55

13.2.3.1 E4 General ......................................................................................................................................................................................................................................................................................................................... 55

13.2.3.2 E4/5 External temperature sensor / floor heating thermal ....................................................................................................................................................................................................................................... 56 limiter

13.2.3.3 E4/5 Output ........................................................................................................................................................................................................................................................................................................................ 57

13.2.3.4 E4/5 Threshold value 1 / 2 (only if E4 General temperature function = Temperature) .................................................................................................................................................................................................. 58 

13.2.3.5 E4/5 Output threshold value 1 / 2 (only if E4 general temperature function = Temperature) ........................................................................................................................................................................................ 59 

13.2.3.6 E4/5 Threshold values (only if E4 general temperature function = Floor heating thermal limiter) ................................................................................................................................................................................. 59 
