SXTSA-series

SXTSA-seriesSXTSA-series

SXT series: SXT SA5, SXT SA5 ac

SXT series: SXT SA5, SXT SA5 acSXT series: SXT SA5, SXT SA5 ac

SXT is an outdoor wireless router that can be used as a CPE in a PtM setup, or for point to point links. Please ensure the device is correctly mounted, with

the cable pointing straight down.

Safety Warnings

Before you work on any equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard practices for preventing

accidents.

Ultimate disposal of this product should be handled according to all national laws and regulations.

All installation methods for mounting an access point on any wall surface is subject to the acceptance of local jurisdiction.

The Installation of the equipment must comply with local and national electrical codes.

This product is intended to be mounted outdoors on a pole. Please read the mounting instructions carefully before beginning installation. Failure to use the

correct hardware and configuration or to follow the correct procedures could result in a hazardous situation for people and damage to the system.

Use only the power supply and accessories approved by the manufacturer, and which can be found in the original packaging of this product.

Read the installation instructions before connecting the system to the power source.

We cannot guarantee that no accidents or damage will occur due to the improper use of the device. Please use this product with care and operate at your

own risk!

In the case of device failure, please disconnect it from power. The fastest way to do so is by unplugging the power plug from the power outlet.

It is the customer's responsibility to follow local country regulations, including operation within legal frequency channels, output power, cabling

requirements, and Dynamic Frequency Selection (DFS) requirements. All Mikrotik radio devices must be professionally installed.

This is a class A device. In a domestic environment, this product might cause radio interference in which case the user might be required to take adequate

measures.

Assembly and mounting

With the clip pointed forward, slide the mounting bracket into the rail on the bottom of the case, until the clip clicks into place. The SXT comes bundled with

a hose clamp, guide the clamp through the opening in the bracket and around the pole where it will be mounted. Tighten the hose clamp screw when

alignment is complete. Two screw holes are provided as additional security against accidental bracket movement.

The SXT device has a sliding door, behind which the Ethernet port and the reset jumpers are located. This door can be also secured shut with a screw in

the provided screw hole.

Connecting

Open the ethernet door to connect an ethernet cable to the ethernet port, connect the other end of the ethernet cable to the included PoE injector.

Plug the PoE injector into your network switch or computer.

Plug the included power supply into the PoE injector to start up the device.

Set LAN computer IP configuration to (DHCP).

automatic

The default IP address of the unit is 192.168.88.1, open this address in your web browser to start the configuration. The username is admin and

there is no password . (or, for some models, check user and wireless passwords on the sticker)

Please select your country in the screen that loads, to ensure your device meets local regulations. Set a wireless password, a management

password, and upgrade the device to the latest software with the "check for updates" button.

The device is preconfigured as a wireless client (CPE), and all you need to do is select the AP to connect to and set a device password. You can do this in

the quickSET tab that is loaded by default. In case IP connection is not available, Winbox can be used to connect to the MAC address of the device.

In case you wish to boot the device from the network, for example, to use MikroTik Netinstall, hold the RESET button of the device when starting it, until

the LED light turns off, then the device will start to look for Netinstall servers.

We recommend clicking the "Check for updates" button and updating your RouterOS software to the latest version to ensure the best performance and

stability. More information about using RouterOS and connecting to this device

in our documentation: *+https://mt.lv/help+*

Powering

The device only accepts 8-32 V power from Passive PoE injectors (one power supply and PoE injector are included).

Extension Slots and Ports

One Ethernet (10/100 Mbit or Gigabit, depends on model), supporting automatic cross/straight cable correction (Auto MDI/X), so you can use

either straight or cross-over cables for connecting to other network devices.

One Integrated Wireless with a built-in directional antenna, max gain 16 dBi.

Buttons and Jumpers

The routerBOOT reset button has the following functions. Press the button and apply the power, then:

Release the button when green LED starts flashing, to reset RouterOS configuration to defaults.

Release the button when the LED turns solid green to clear all configuration and defaults.

Release the button after LED is no longer lit (~20 seconds) to cause a device to look for Netinstall servers (required for reinstalling RouterOS over

the network).

Regardless of the above option used, the system will load the backup RouterBOOT loader if the button is pressed before power is applied to the device.

Useful for RouterBOOT debugging and recovery.

The device includes a grounding connection behind the ethernet port door (a screw or a metal loop, depending on the model), which you should connect to

the grounding installation of the tower or building where the device will be used. This is to substantially reduce the risk of ESD and lightning damage.

Operating System Support

The device only supports RouterOS software with the version number at or above what is indicated in the RouterOS menu /system resource. Other

operating systems have not been tested.

Federal Communication Commission Interference Statement

Model

ModelModel IC

ICIC

RBSXTG-5HPnD-SAr2 TV7SXTG-5HPND

RBSXTG-5HPacD-SAr2 TV7SXTG-5HACD

Model RBSXTG-5HPnD-SAr2 (SXT SA5):

Model RBSXTG-5HPnD-SAr2 (SXT SA5):Model RBSXTG-5HPnD-SAr2 (SXT SA5):

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to correct the interference by one of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

75 cm minimum distance has to be maintained between the antenna and user. Under such

MPORTANT: Exposure to Radio Frequency Radiation.

MPORTANT: Exposure to Radio Frequency Radiation.MPORTANT: Exposure to Radio Frequency Radiation.

configuration, the FCC radiation exposure limits set forth for an population/uncontrolled environment can be satisfied.

To avoid pollution of the environment, please separate the device from household waste and dispose of it in a safe manner, such as in

designated waste disposal sites. Familiarize yourself with the procedures for the proper transportation of the equipment to the designated

disposal sites in your area.

Model RBSXTG-5HPacD-SAr2 (SXT SA5 ac):

Model RBSXTG-5HPacD-SAr2 (SXT SA5 ac):Model RBSXTG-5HPacD-SAr2 (SXT SA5 ac):

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a commercial installation.

This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may

cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case

the user will be required to correct the interference at his own expense.

20 cm minimum distance has to be maintained between the antenna and user. Under such

MPORTANT: Exposure to Radio Frequency Radiation.

MPORTANT: Exposure to Radio Frequency Radiation.MPORTANT: Exposure to Radio Frequency Radiation.

configuration, the FCC radiation exposure limits set forth for an population/uncontrolled environment can be satisfied.

Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this

FCC Caution:

FCC Caution:FCC Caution:

equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful

interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.This device and its

antenna must not be co-located or operation in conjunction with any other antenna or transmitter.

It is installer's responsibility to ensure that when using the authorized antennas in the United States (or where FCC rules

Antenna Installation. WARNING:

Antenna Installation. WARNING:Antenna Installation. WARNING:

apply); only those antennas certified with the product are used. The use of any antenna other than those certified with the product is expressly forbidden in

accordance to FCC rules CFR47 part 15.204. The installer should configure the output power level of antennas, according to country regulations and per

antenna type. Professional installation is required of equipment with connectors to ensure compliance with health and safety issues.

Innovation, Science and Economic Development Canada

Model

ModelModel IC

ICIC

RBSXTG-5HPnD-SAr2 7442A-SXTG5HPND

RBSXTG-5HPacD-SAr2 7442A-SXTG5HACD

This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not

cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.

Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux

conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi,

même si le brouillage est susceptible d'en compromettre le fonctionnement.

Model RBSXTG-5HPnD-SAr2 (SXT SA5):

Model RBSXTG-5HPnD-SAr2 (SXT SA5):Model RBSXTG-5HPnD-SAr2 (SXT SA5):

This ClassBdigital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.

CAN ICES-003 (B) / NMB-003 (B)

. 33 cm minimum distance has to be maintained between the antenna and user. Under such

MPORTANT: Exposure to Radio Frequency Radiation

MPORTANT: Exposure to Radio Frequency RadiationMPORTANT: Exposure to Radio Frequency Radiation

configuration, the FCC radiation exposure limits set forth for an population/uncontrolled environment can be satisfied.

Model RBSXTG-5HPacD-SAr2 (SXT SA5 ac):

Model RBSXTG-5HPacD-SAr2 (SXT SA5 ac):Model RBSXTG-5HPacD-SAr2 (SXT SA5 ac):

This Class A digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [A] est conforme à la norme NMB-003 du Canada.

CAN ICES-003 (A) / NMB-003 (A)

IMPORTANT: Exposure to Radio Frequency Radiation.

IMPORTANT: Exposure to Radio Frequency Radiation. IMPORTANT: Exposure to Radio Frequency Radiation. cm minimum distance has to be maintained between the antenna and user. Under such 22

configuration, the FCC radiation exposure limits set forth for an population/uncontrolled environment can be satisfied.
