LHG-series

LHG-seriesLHG-series

This manual covers LHG models:

This manual covers LHG models:This manual covers LHG models:

LHG 2 (RBLHG-2nD)

LHG 5 (RBLHG-5nD)

LHG HP5 (RBLHG-5HPnD)

LHG 5 ac (RBLHGG-5acD)

Safety Warnings

Before you work on any equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard practices for preventing

accidents.

Ultimate disposal of this product should be handled according to all national laws and regulations.

All installation methods for mounting an access point on any wall surface is subject to the acceptance of local jurisdiction.

The Installation of the equipment must comply with local and national electrical codes.

This product is intended to be mounted outdoors on a pole. Please read the mounting instructions carefully before beginning installation. Failure to use the

correct hardware and configuration or to follow the correct procedures could result in a hazardous situation for people and damage to the system.

Use only the power supply and accessories approved by the manufacturer, and which can be found in the original packaging of this product.

Read the installation instructions before connecting the system to the power source.

We cannot guarantee that no accidents or damage will occur due to the improper use of the device. Please use this product with care and operate at your

own risk!

In the case of device failure, please disconnect it from power. The fastest way to do so is by unplugging the power plug from the power outlet.

It is the customer's responsibility to follow local country regulations, including operation within legal frequency channels, output power, cabling

requirements, and Dynamic Frequency Selection (DFS) requirements. All Mikrotik radio devices must be professionally installed.

The LHG is an outdoor wireless router with a built-in directional antenna. It can be used as a CPE or for point-to-point links (use RouterOS wireless mode

"bridge" to work as a single-client AP for point-to-point scenarios).

Exposure to Radio Frequency Radiation:

Exposure to Radio Frequency Radiation:Exposure to Radio Frequency Radiation:This MikroTik equipment complies with the FCC, IC, and European Union radiation exposure limits set forth for an

uncontrolled environment.This MikroTik device should be installed and operated no closer than 20 centimeters from your body, occupational user, or the

general public.

Connecting

Open the Ethernet door to connect an Ethernet cable to the Ethernet port, connect the other end of the Ethernet cable to the included PoE injector.

Plug the PoE injector into your network switch or computer.

Plug the included power supply into the PoE injector to start up the device.

Download WinBox configuration tool ;https://mt.lv/winbox

Default IP: 192.168.88.1, user name: and there is no password (or, for some models, check user and wireless passwords on the sticker),

admin

or useNeighborstab and connect through MAC address;

Once connected configure the device, so it has an active Internet connection ;https://mt.lv/configuration

Upgrade the RouterOS software to the latest version ;https://mt.lv/upgrade

Connect again and in the QuickSet menu choose your country, to apply country regulation settings;

Set up your router password in the bottom field to the right and repeat it, it will be used to log in next time.

The device is preconfigured as a wireless client and all you need to do is select the AP to connect to and set a device password. You can do this in the

QuickSet tab that is opened by default.

In case the IP connection is not available, Winbox can be used to connect to the MAC address of the device. In case you wish to boot the device from the

network, for example, to use MikroTik Netinstall, hold the RESET button of the device when starting it, until the LED light turns off, then the device will start

to look for Netinstall servers. More information about using RouterOS and connecting to this device in our documentation: https://mt.lv/help

Assembly and Mounting

Attach the two legs to the LHG case.

Snap the assembled LHG unit to the grid in the appropriate locations.

Fix the legs in place with two self-thread screws (Use Phillips screwdriver PH2).

The device is designed to be mounted on the pole using zip ties or steel clamps as shown in the picture. The clamping diameter with provided steel clamps

is 35 – 70 mm.

Guide provided steel clamps through the unit.

Attach the device to the pole.

Align and tighten the clamps to secure the device.

Optional: If required, before mounting the unit, you can insert the included 5-degree adjustment adapter into the top or bottom slot where the

mounting ring is inserted. This will create an additional upward or downward angle when the unit is tightened to a vertical pole.

The device includes a grounding connection (marked ) which you should connect to the grounding installation of the tower or building where the device will

be used. This is to substantially reduce the risk of ESD and lightning damage.
