Chateau 5G
Chateau 5G
Chateau 5G
Chateau 5GChateau 5G
Chateau 5G ( ).
D53G-5HacD2HnD-TC&RG502Q-EA
Safety Warnings
Before you work on any equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard practices for preventing
accidents.
Ultimate disposal of this product should be handled according to all national laws and regulations.
The Installation of the equipment must comply with local and national electrical codes.
This unit is intended to be installed in the rackmount. Please read the mounting instructions carefully before beginning installation. Failure to use the
correct hardware or to follow the correct procedures could result in a hazardous situation to people and damage to the system.
This product is intended to be installed indoors. Keep this product away from water, fire, humidity or hot environments.
Use only the power supply and accessories approved by the manufacturer, and which can be found in the original packaging of this product.
Read the installation instructions before connecting the system to the power source.
We cannot guarantee that no accidents or damage will occur due to the improper use of the device. Please use this product with care and operate at your
own risk!
In the case of device failure, please disconnect it from power. The fastest way to do so is by unplugging the power plug from the power outlet.
It is the customer's responsibility to follow local country regulations, including operation within legal frequency channels, output power, cabling
requirements, and Dynamic Frequency Selection (DFS) requirements. All Mikrotik radio devices must be professionally installed.
Exposure to Radio Frequency Radiation:
Exposure to Radio Frequency Radiation:
Exposure to Radio Frequency Radiation:
Exposure to Radio Frequency Radiation:Exposure to Radio Frequency Radiation:This MikroTik equipment complies with the FCC, IC, and European Union radiation exposure limits set forth for an
uncontrolled environment.This MikroTik device should be installed and operated no closer than 20 centimeters from your body, occupational user, or the
general public.
Quickstart
Please follow these quick steps to set up your device:
Connect an external antennas to the SMA connector (The antennas are provided in the package, see " ");Antenna usage
Insert micro SIM card into the slot located under the device;
Connect your computer to one of the Ethernet ports;
Connect the power adapter to the DC jack;
Once the device is powered on and PC connected to the device, open in your https://192.168.88.1
web browser to start the configuration (or, for some models, check user and wireless passwords on
;the sticker)
User name: a and there is no password by default you will be logged in automatically to the
dmin
Quick Set screen;
We recommend clicking the "Check for updates" button on the right side and updating your
RouterOS software to the latest version to ensure the best performance and stability, Must have a
valid SIM card inserted;
To manually update the device, please go to https://mikrotik.com/download
Choose ARM packages for this device and download them to your PC.
Upload downloaded packages to the WebFig "Files" menu and reboot the device.
Updating your RouterOS software to the latest version will ensure the best performance, stability,
and security updates.
To personalize your wireless network, SSID can be changed in the fields "Network Name";
Choose your country on the left side of the screen in the field "Country", to apply country regulation
settings;
Set up your wireless network password in the field "WiFi Password" the password must be at least
eight symbols;
Set up your router password in the bottom field "Password" to the right and repeat it in the field "Confirm Password", it will be used to log in next
time;
Click on the "Apply Configuration" to save changes.
Connecting with a mobile app
Use your smartphone to access your router through WiFi.
Insert the SIM card and power on the device.
Scan QR code with your smartphone and choose your preferred OS.
Connect to the wireless network. SSID starts with MikroTik and has the last digits of the device's MAC address.
Open application.
By default, the IP address and user name will be already entered.
Click Connect to establish a connection to your device through a wireless network.
Choose Quick setup and the application will guide you through all basic configuration settings in a couple of easy steps.
An advanced menu is available to fully configure all necessary settings.
Expansion slots and ports
1.
2.
3.
4.
5.
6.
7.
8.
Reset button.
Powering DC jack 2.0 mm.
Five Gigabit ports, supporting automatic cross/straight cable correction (Auto MDI/X). Either straight or crossover cable can be used for
connecting to other network devices.
USB type-A.
SIM slot for Micro sim card.
Mode button.
Cover for external is not provided for models with antennas.SMA antenna connector
WPS Sync button.
Integrated Wireless module operating at 2.4 GHz, 802.11b/g/n protocol. Antenna gain 3 (dBi).
Integrated Wireless module operating at 5 GHz, 802.11a/n/ac protocol. Antenna gain 5.5 (dBi).
Mounting
The device is designed to be used indoors, by placing it on the desktop.
Powering
The device accepts power from an adapter:
Direct-input power jack (5.5 mm outside and 2 mm inside, female, pin positive plug) 12-28 V DC.
The power consumption under maximum load can reach 17 W, with attachments of 23 W.
Configuration
We recommend using Cat5 shielded cable. When using and installing this device please pay attention to the Maximum Permissible Exposure
(MPE) safety distance with a minimum of 20 cm between the radiator and your body.
