cAP XL ac

cAP XL accAP XL ac

cAP XL ac (RBcAPGi-5acD2nD-XL)

Safety Warnings

Before you work on any equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard practices for preventing

accidents.

Ultimate disposal of this product should be handled according to all national laws and regulations.

The Installation of the equipment must comply with local and national electrical codes.

This unit is intended to be installed in the rackmount. Please read the mounting instructions carefully before beginning installation. Failure to use the

correct hardware or to follow the correct procedures could result in a hazardous situation to people and damage to the system.

This product is intended to be installed indoors. Keep this product away from water, fire, humidity or hot environments.

Use only the power supply and accessories approved by the manufacturer, and which can be found in the original packaging of this product.

Read the installation instructions before connecting the system to the power source.

We cannot guarantee that no accidents or damage will occur due to the improper use of the device. Please use this product with care and operate at your

own risk!

In the case of device failure, please disconnect it from power. The fastest way to do so is by unplugging the power plug from the power outlet.

It is the customer's responsibility to follow local country regulations, including operation within legal frequency channels, output power, cabling

requirements, and Dynamic Frequency Selection (DFS) requirements. All Mikrotik radio devices must be professionally installed.

Exposure to Radio Frequency Radiation:

Exposure to Radio Frequency Radiation:Exposure to Radio Frequency Radiation:This MikroTik equipment complies with the FCC, IC, and European Union radiation exposure limits set forth for an

uncontrolled environment.This MikroTik device should be installed and operated no closer than 20 centimeters from your body, occupational user, or the

general public.

Connecting

Connect POE to Ethernet port 1, please see the section for instructions on how to connect POE.Powering

Set your computer IP configuration to (DHCP).

automatic

The device wireless access point mode is enabled by default.

The device will boot up and a Wireless network will be available for connecting.

Open network connections on your PC, mobile phone, or other device and search for MikroTik wireless network and connect to it.

Once connected to the wireless network, open in your web browser to start configuration, user name: admin, since there is https://192.168.88.1

no password by default, you will be logged in automatically .(or, for some models, check user and wireless passwords on the sticker)

We recommend clicking the "Check for updates" button and updating your RouterOS software to the latest version to ensure the best

performance and stability.

Choose your country, apply country regulation settings, and set up your password on the screen that loads.

Powering

The device accepts power from the Ethernet port, so you must either use the included passive PoE injector or make sure your switch supports passive or

802.3af/at PoE output.

Ethernet port accepts 12-57 V DC (802.3af/at).

The power consumption under maximum load can reach 24 W.

Connecting to a POE Adapter:

Connect the Ethernet cable from the device to the POE port of the POE adapter.

Connect an Ethernet cable from your LAN to the LAN port of the POE adapter, please mind arrows for data and power flow.

Connect the power cord to the adapter, and then plug the power cord into a power outlet.

Mounting

It is possible to attach the device to a wall or ceiling, using the provided mounting bracket on the back of the unit:



Configuration

By default, the device is configured as a wireless access point, with the first ethernet port (Eth1) configured as a DHCP client, and the second interface

bridged together with the wireless interface. A DHCP server is configured on the bridge interface.

Once logged in, we recommend clicking the "Check for updates" button in the QuickSet menu, as updating your RouterOS software to the latest version

ensures the best performance and stability. For wireless models, please make sure you have selected the country where the device will be used, to

conform with local regulations.

RouterOS includes many configuration options in addition to what is described in this document. We suggest starting here to get yourself accustomed to

the possibilities: . In case an IP connection is not available, the Winbox tool ( ) can be used to connect to the MAC https://mt.lv/help https://mt.lv/winbox

address of the device from the LAN side (all access is blocked from the Internet port by default).

For recovery purposes, it is possible to boot the device from the network, see a section .cAP ac#Reset button

Expansion slots and ports

Product code RBcAPGi-5acD2nD-XL

CPU Quad-core IPQ-4018 710 MHz

Size of RAM 128 MB

RAM type DDR3L

Storage 16 MB, Flash

Number of 1G Ethernet ports 2

Wireless 2.4 GHz 5 GHz

Supported protocol 802.11b/g/n 802.11a/n/ac

Antenna gain 6 dBi 5,5 dBi

The mounting and configuration of this device should be done by a qualified person.

Warning! This equipment should be installed and operated with a minimum distance of 20 cm between the device and your body. The operation

of this equipment in the residential environment could cause radio interference.

Operating humidity can be from 5% to 95% non-condensing.

Number of chains 2

Operating system RouterOS (License level 4)

Switch chip model IPQ-4018

Dimensions 191 x 42 mm

Operating temperature -40°C to +70°C

Buttons and jumpers

Reset button

The reset button has three functions:

Hold this button during boot time until LED light starts flashing, release the button to reset RouterOS configuration (total 5 seconds).

Keep holding for 5 more seconds, LED turns solid, release now to turn on CAP mode. The device will now look for a CAPsMAN server (total 10

seconds).

Or Keep holding the button for 5 more seconds until LED turns off, then release it to make the RouterBOARD look for Netinstall servers (total 15

seconds).

Regardless of the above option used, the system will load the backup RouterBOOT loader if the button is pressed before power is applied to the device.

Useful for RouterBOOT debugging and recovery.

Mode button

There are two mode buttons on this unit, but they both are performing the same action. The action of the mode buttons can be configured from RouterOS

software to execute any user-supplied RouterOS script. You can also disable this button. By default, the buttons will enable "dark mode", which disables

beeps and LED lights. The mode button can be configured in the RouterOS menu /system routerboard mode-button.

LED indicators

There are seven LED lights on the unit, which can be controlled in RouterOS software, or disabled

altogether.

User – user-configurable led for any desired script.

5G – 5GHz interface activity.

2G – 2.4 GHz interface activity.

E2 – Ethernet 2 connected.

E1 – Ethernet 1 connected.

PoE LED indicates that the ETH2 port is currently powering another device with PoE.

The power LED indicates that the unit is receiving power in the ETH1 port.

Accessories

The package includes the following accessories that come with the device:

ADAPT1_ EU/US Switching Power Supply 24V, 1.2A.

POE1_ Gigabit POE injector.

BRAC1_ CAPGB-Mounting Bracket.

Screw set 2 screws and dowels for mounting.

Operating system support

The device supports RouterOS software version 6.48.4. The specific factory-installed version number is indicated in the RouterOS menu /system resource.

Other operating systems have not been tested.

MikroTik mobile app
