I-00319 Rev N
Please read this manual before removing the UPS from the shipping carton and before making any
connections to and operating your UPS.
THANK YOU
IMPORTANT
Thank you for purchasing the 1000R or 2200R Series Rackmounted UPS. The UPS provides battery
backup during power outages, automatic voltage regulation during periods of inconsistent utility power
and surge protection.
• UPS-1000R
• UPS-1000R-IP
• UPS-1000R-8IP
• UPS-2200R
• UPS-2200R-IP
• UPS-2200R-8IP
MODEL NUMBERS
Page 2
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 - 4
Middle Atlantic Products Green Power UPS Technology . . . . . . . . . . . . . . . . . . . . . 5
FCC Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 6
Circuit Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Unpacking and Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Installation and Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 8
Front Panel Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Rear Panel Descriptions (Bank Outlets) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 - 10
Rear Panel Descriptions (Individual Outlets) . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 - 12
Setup Of (NIC) UPS-IPCARD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 - 15
LCD Display Definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Battery Charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Self Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
EPO (Emergency Power Off) Port Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
General Status Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Functions Setup Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 - 20
Battery Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 - 24
Optional External Battery Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 - 26
Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27 - 28
Estimated Runtime . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28 - 29
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Warranty Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS
The lightning flash with the arrowhead symbol, within an equilateral triangle, is intended to alert the user
to the presence of uninsulated dangerous voltage within the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions in the literature accompanying the product.
Page 3
CAUTION: Use only the specified type of battery. See your dealer for replacement batteries.
CAUTION: For PLUGGABLE EQUIPMENT, the socket-outlet shall be installed near the equipment
CAUTION: To reduce the risk of fire, connect only to a circuit provided with 20 Amperes maximum branch
overcurrent protection in accordance with the National Electrical Code, ANDI/NFPA 70.
CAUTION: Risk of energy hazard, 12V, 9AH battery. Before replacing batteries, remove conductive jewelry
such as chains, wrist watches, and rings. High energy through conductive materials could cause severe
burns.
WARNING: The battery may present the risk of electrical shock. Do not dispose of batteries in a fire, as
they may explode. Follow all local ordinances regarding proper disposal of batteries.
WARNING: A battery can present a high risk of short circuit current or electrical shock.
WARNING:
To avoid electric shock, turn off the unit and unplug it from the AC power before
servicing the battery or installing a component
.
WARNING:
Do not use for medical or life support equipment. Do not use in any circumstance that would
affect operation or safety of any life support equipment, with any medical applications, or patient care
.
WARNING: Risk of battery explosion, if battery is replaced by an incorrect type or rating.
WARNING: Do not open or mutilate the batteries. Electrolyte is harmful to the skin and eyes and may be
toxic.
WARNING:
The UPS must be connected to a grounded AC power outlet with fuse or circuit breaker
protection. DO NOT plug the UPS into an outlet that is not grounded. If you need to de-energize this
equipment, turn off and unplug the UPS.
WARNING:
The internal battery in this UPS is always charged. The battery can energize hazardous live
parts inside the unit, even when the AC input power is disconnected.
WARNING:
To prevent the risk of fire or electric shock, install in a temperature and humidity controlled
indoor area, free of conductive contaminants. (Please see specifications for acceptable temperature and
humidity range).
WARNING:
To reduce the risk of electric shock, do not remove the cover, except to service the battery.
There are no serviceable parts inside, except for the battery.
This manual contains important instructions that should
be followed during installation and maintenance of the
UPS and batteries.
