Job Number:_____________________________________________ Location: ____________________________________________________________________ ____
www.micromatic.com • 1 (866) 327-4159
DRIP TRAY
Designed specifically for Metropolis H draft towers
Add European style while creating dispense excitement
Condition the glass before pouring - invert glass, push down on sprayer
for cold water rinsing
Robust 18 gauge stainless steel construction
NSF Certified
(Rinser Only)
SURFACE MOUNT SERIES DRIP TRAY
SURFACE MOUNT SERIES WITH CUTOUT 8 1/2" X 40"
DP-MET-H-40GR-Z
Stainless Steel
DP-MET-H-PVD-40GR-Z
PVD Brass / Stainless Steel
Specifications
Central
10726 North Second St.
Machesney Park, IL 61115
Tel. (815) 968-7557
Fax. (815) 968-0363
Northeast
4601 Saucon Creek Rd.
Center Valley, PA 18034
Tel. (610) 625-4464
Fax. (610) 625-4466
West
19791 Bahama St.
Northridge, CA 91324
Tel. (818) 701-9765
Fax. (818) 701-9844
Toll-Free: 1-866-327-4159
www.micromatic.com
©2016 Micro Matic USA, Inc. All Rights Reserved.
Dimensions
Rinser Water Inlet Installation
Micro Matic reserves the right to change specifications without notice.
• Always check local plumbing codes first
• Install in-line water regulator set at 15 PSI from the street water supply (no greater, perfect operating pressure)
• Install in-line one way check valve from the street water supply (prevents pressure drop which can cause leaking)
• Install in-line shut off for the rinser system from the street water supply (this must be turned off nightly)
• If teed into soda system make sure system can handle the increased water demand. Have plumber install a
45° 1/2" O.D. barb for the drains if line is not hard plumbed into the system.
• Install a shut off for the rinser water supply if line is not hard plumbed into the system
Southeast
2386 Simon Ct.
Brooksville, FL 34604
Tel. (352) 799-6331
Fax. (352) 796-2429
000011S-D0117
203.2 [8.00]
R77.79 [R3.062]
TOWER PEDESTAL CENTER
508.0 [20.00]
139.7 [5.50]
1016.0 [40.00]
19.05 [0.75]
Drain: Threaded Brass
5/8" -18 UNF X 3 1/2" LONG
0.53" OD.
7/8" -14 UNF
1/2" BSP
215.9 [8.50]
63.5 [2.50]
101.6 [4.0]
Part No. Dimensions Finish Shipping Weight
DP-MET-H-40GR-Z 8 1/2"W x 40"L x 3/4"H Stainless Steel TBD
TBD
DP-MET-H-PVD-40GR-Z 8 1/2"W x 40"L x 3/4"H PVD Brass / Stainless Steel TBD
TBD
