AXDSPL-HN3
I N S T A L L A T I O N I N S T R U C T I O N S
AxxessInterfaces.com Ā© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION REV. 11/3/20 INSTAXDSPL-HN3
Google Play Store Apple App Store
iOS 12.1 or higher
INTERFACE FEATURES
INTERFACE COMPONENTS
TOOLS & INSTALLATION ACCESSORIES REQUIRED
ā€¢ Crimping tool and connectors, or solder gun,
solder, and heat shrink ā€¢ Tape ā€¢ Wire cutter
ā€¢ Zip ties ā€¢ Multimeter
TABLE OF CONTENTS
Connections ............................................................2
Installation .............................................................3
AXDSPL-BT Installation...........................................4
AXDSPL-SP Installation...........................................5
Mobile App ........................................................6-14
Speciļ¬cations ........................................................15
Honda DSP Interface With Amp Bypass Harness
2016-Up
ā€¢ Includes a DSP (Digital Signal Processor)
ā€¢ 15 Band graphic EQ
ā€¢ 4 inputs and 6 individually assignable outputs
ā€¢ Independent equalization for front, rear, and sub
ā€¢ Selectable low pass, band pass, and high pass ļ¬lters
ā€¢ Selectable crossover slopes; 12db, 24db, 36db, 48db
ā€¢ Each channel can be delayed independently up to 10ms
ā€¢ Clipping detection and limiting circuits
ā€¢ Designed for ampliļ¬ed models
ā€¢ Includes an amp bypass harness
ā€¢ Internal header port for adding interface modules
ā€¢ Retains level control of subwoofer through the factory radio
ā€¢ Settings adjusted via BluetoothĀ® in a smart device application (tablet
or mobile phone), compatible with both Android and Apple devices
ā€¢ Read, write, and store conļ¬gurations for future recall
ā€¢ Password protect feature available in the mobile app
ā€¢ Micro-B USB updatable
ā€¢ AXDSPL-HN3 interface
ā€¢ AXDSPL-HN3 interface harness
ā€¢ AXDSPL-HN3 amp bypass harness
APPLICATIONS
Visit axxessinterfaces.com for current application list
2
4
3
2
1
5
5
TBA
Blue/White - Amp Turn-On Wire
Any remaining wires
tape off and disregard
RCA Jacks
(sold separately)
Any remaining wires
tape off and disregard
White / Front Left Woofer +
White/Black / Front Left Woofer -
Gray / Front Right ofer +Wo
Gr /Blackay Front Right ofer -Wo
Green / Rear Left Woofer +
Green/Black / Rear Left Woofer -
Purple / Rear Right Woofer +
Purple/Black / Rear Right Woofer -
Br eown/Whit / Center +
Blue/Pink / Center -
Green/White / Su oofer +bw
White/Red / Su oofer -bw
TBA
An SPDT rela Metra part numbery,
E-123, is required if the amp turn-on
current of all amps exceeds 1-amp.
Yello Bluew/ / Front Left eeter +Tw
Yello Blackw/ / Front Left eeter -Tw
Yello dw/Re / Front Right +Tweeter
Yello Orangew/ Front Right -Tweeter
Green range/O / Rear Left Tweeter +
Green/Red / Rear Left Tweeter -
Black/Yellow / Rear Right eeter +Tw
Black/Green / Rear Right Tweeter -
Factory Amp
Passenger Side Kick Panel
(Remo Amp)ve
Interface
SPDIF interface
Amp Bypass Harness
CONNECTIONS
3
REV. 11/3/2020 INSTAXDSPL-HN3
INSTALLATION
1. Locate the factory amp in the passenger side kick panel. Unplug and remove the amp.
2. Install the AXDSPL-HN3 amp bypass harness to the vehicle and make all necessary
connections, but leave the amp turn-on wire disconnected.
3. AXDSPL-HN3 amp bypass harness AXDSPL-HN3 interface Connect the to the .
4. Connect the AXDSPL-HN3 interface harness AXDSPL-HN3 interfaces to the .
5. Download and install the AX-DSP-XL app Google Play Store Apple App Store from the or .
6. Cycle the ignition on.
7. Open the app then select the Bluetooth Connection tab. Follow the instructions to pair the
mobile device to the interface. Refer to page 7 for more information. (Figure A)
8. Conļ¬guration Scroll to the tab then select the vehicle type. Press the Lock Down ā€” button to
save the conļ¬guration. Refer to page 8 for more information. (Figure B)
9. Connect the amp turn-on wire.
10. Identify Click the button to conļ¬rm the interface is connected properly. A chime will be heard
from the front left speaker. Test all functions of the installation for proper operation.
Note: The outputs may need to be conļ¬gured within the tab.Outputs
11. Adjust the settings in the app as desired. Press the ā€” button to save any new Lock Down
conļ¬gurations.
ā€” Anytime the interface is locked down the key must be cycled off then back on
Note: The interface provides a 12-volt 1-amp output to turn on aftermarket amp(s). If installing
multiple amps, an SPDT automotive relay will be required if the amp turn-on current of all
amps combined exceeds 1-amp. Use Metra part number E-123 (sold separately) for best results.
(Figure A)
(Figure B)
