METRA. The World’s best kits.™metraonline.com © COPYRIGHT 2004-2015 METRA ELECTRONICS CORPORATION
REV. 9/11/2015 INST99-9100
Installation instructions for part 99-9100
CAUTION!
Metra recommends disconnecting the negative bat
-
tery terminal before beginning any installation, unless the vehicle
manufacturer recommends against so. Please check with your local
Dealership for more information. All accessories, switches, climate
controls panels, and especially air bag indicator lights must be con
-
nected before reconnecting the battery or cycling the ignition. Also,
do not remove the factory radio with the key in the on position, or the
vehicle running. It would be best to remove the key from the ignition
and then wait a few seconds before removing the factory radio.
• DIN radio provision
• A) Trim plate (a) • B) Trim plate (b) • C) (2) Screw caps
KIT FEATURES
KIT COMPONENTS
WIRING & ANTENNA CONNECTIONS (sold separately)
Wiring Harness: • Please visit metraonline.com for more information
Antenna Adapter: • Please visit metraonline.com for more information
• 86-9001 radio removal keys • Pry tool
TOOLS REQUIRED
Dash Disassembly ................................................. 2
Kit Assembly
– A4/A6/A8 1996-1999 3 ...........................................
– TT 2000-2006...................................................... 3
Table of Contents
BA C
99-9100
1. Insert Metra’s 86-9001 into the
slots in the factory radio and pull
the radio out. (Figure A)
2. Disconnect the wiring.
3. For TT models only: Remove (2)
Phillips screws from inside the
radio opening. (Figure B)
Continue to kit assembly
Dash Disassembly
(Figure A)
99-9100
Kit Assembly
AUDI A4/A6/A8 1996-1999
1. Remove the metal DIN sleeve and trim ring from
the aftermarket radio.
Note: Disregard the trim ring, it will not be used in
this application.
2. Slide the sleeve into the radio opening in the dash
and secure by bending the metal locking tabs
down.
3. Locate the factory wiring harness and antenna
connector in the dash, and complete all necessary
connections to the radio. Metra recommends using
the proper mating adapter from Metra and/or
AXXESS. Re-connect the negative battery terminal
and test the radio for proper operation.
4. Slide the radio back into the sleeve until it clicks in.
5. Snap Trim Plate (a) onto the front of the radio.
Audi TT 2000-2006
1. Remove the metal DIN sleeve and trim ring from
the aftermarket radio.
Note: Disregard the trim ring, it will not be used in
this application.
2. Slide the sleeve into the radio opening in the dash
and secure by bending the metal locking tabs
down.
3. Locate the factory wiring harness and antenna
connector in the dash, and complete all necessary
connections to the radio. Metra recommends using
the proper mating adapter from Metra and/or
AXXESS. Re-connect the negative battery terminal
and test the radio for proper operation.
4. Slide the radio back into the sleeve until it clicks in.
5. Secure Trim Plate (b) to the front of the radio
opening using the screws removed during
disassembly.
6. Place the screw caps into the screw openings in
the trim plate.
