SC R I P T TM i

u s e r ’ s m a n u a l

c l s e l e c t r o s t a t i c

M LA R T I N O G A N ®

2 Contents & Introduction

Contents & Introduction . . . . . . . . . . . . . . . . . . . . . . . . .2

Contents

Introduction

Installation in Brief . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Low Voltage Power Connection

Signal Connection

Using Only One Power Supply . . . . . . . . . . . . . . . . . . .5

Break-In

Mounting the Script i On A Wall . . . . . . . . . . . . . . . . . .6

Changing the Direction of Rotation . . . . . . . . . . . . . .10

Room Acoustics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Your Room

Terminology

Rules of Thumb

Dipolar Speakers and Your Room

Dispersion Interactions . . . . . . . . . . . . . . . . . . . . . . . . .12

Controlled Horizontal Dispersion

Controlled Vertical Dispersion

Three Major Types of Dispersion

Home Theater . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Electrostatic Advantages . . . . . . . . . . . . . . . . . . . . . . . .15

Full Range Operation . . . . . . . . . . . . . . . . . . . . . . . . .16

MartinLogan Exclusives . . . . . . . . . . . . . . . . . . . . . . . . .17

Curvilinear Line Source

MicroPerf Stator

Plasma Deposited Diaphragm

Transducer Integrity

Low Voltage Power

Electrostatic Loudspeaker History . . . . . . . . . . . . . . . .18

Frequently Asked Questions . . . . . . . . . . . . . . . . . . . . .20

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

General Information . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Specifications

Warranty and Registration

Service

Serial Numbers

Glossary of Audio Terms . . . . . . . . . . . . . . . . . . . . . . . .24

Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

Congratulations! You have invested in one of the world’s

premier loudspeaker systems.

The MartinLogan Script i represents the culmination of an

intensive, dedicated group research program directed

toward establishing a world class reference monitor

utilizing leading-edge technology, without compromising

durability, reliability, craftsmanship or aesthetic design.

The result of cumulative technology gleaned from previous

research and development projects, the Script i represents

the latest developments in electrostatic and hybrid loud-

speaker technology.

Combining our proprietary curvilinear electrostatic transduc-

er with a compact, but powerful woofer, we have designed

a product, in one package, that reproduces music with

uncomprimised electrostatic clarity.

The materials in your new Script i speakers are of the high-

est

quality and will provide years of enduring enjoyment

and

deepening respect. The cabinetry is constructed from

the highest quality composite material for acoustical integrity

and is finished with our attractive custom matte finish.

Through rigorous testing, the curvilinear electrostatic panel

has proven itself to be one of the most durable and reliable

transducers available today. Fabricated from a custom tool

punched high-grade steel, the patented panel is then coated

with a special polymer that is applied via a proprietary plasma

bonding process. This panel assembly houses a membrane

just 0.0005 of an inch thick. Ruggedly constructed and

insulated, as much as 150 watts of continuous power has

driven the Script i’s energized diaphragm into massive

excursions with no deleterious effects.

The other sections of your User’s Manual will explain in

detail the operation of your Script i’s and the philosophy

applied to their design. A clear understanding of your

speakers will insure that you obtain maximum perfor-

mance and pleasure from this most exacting transducer. It

has been designed and constructed to give you years of

trouble-free listening enjoyment.

Installation in Brief 3

We know you are eager to hear your Script i loudspeakers,

so this section is provided to allow fast and easy set up.

Once you have them operational, please take the time to

read, in depth, the rest of the information in this manual.

It will give you perspective on how to attain the greatest

possible performance from this most exacting transducer.

If you should experience any difficulties in the setup or

operation of your Script i’s, please refer to the Installation

or Operation sections of this manual.

Should you encounter a persistent problem that cannot be

resolved, please contact your authorized MartinLogan

dealer. They will provide you with the appropriate technical

analysis to alleviate the situation.

WARNING!

•Hazardous voltages exist inside—do not

remove cover

•Refer servicing to a qualified technician

•To prevent fire or shock hazard, do not

expose this module to moisture

•Turn amplifier off and unplug speaker

should any abnormal conditions occur

•Do not operate if there is any visual

damage to the electrostatic panel element

•Do not over drive speaker beyond its rated power

Step 1: Unpacking

Remove your new Script i speakers from their packing.

Step 2: Mounting

Mount each Script i at its desired location on your front,

side, or back wall(s). Please see the Mounting the Script i

section (pages 6–10) of this manual for details on installation

and determining the proper mounting height.

Step 3: Power Connection (see warning)

The Script i requires power to energize its electrostatic

panel. Plug the provided power supply first into the Power

In power receptacle on the rear panel of the speaker

making sure that you have made a firm

connection, and

then to a convenient wall outlet. Please see the Operations

section (pages 4–5) of this manual for more details.

Step 4: Signal Connection

Use the best speaker cables you can. Higher quality cables,

available from your specialty dealer, are recommended

and will give you superior performance. Spade connectors

are suggested for optimum contact and ease of installation.

Attach your speaker cables to the Signal Input section on

the rear panel. Be consistent when connecting speaker

leads to the terminals on the back of the Script i: take

great care to assign the same color to the (+) terminal on

both the left and right channels. If bass is nonexistent and

you cannot discern a tight, coherent image, you may need

to reverse the (+) and (-) leads on one side to bring the

system into proper polarity.

Please see the Operations section (pages 5) of this manual

for more details.

Step 5: Listen and Enjoy

Now, you may turn on your system and enjoy!

The lightning bolt flash with arrowhead symbol, within

an equilateral triangle, is intended to alert the user to

the presence of uninsulated “dangerous voltage” within the

product’s enclosure that may be of sufficient magnitude

to constitute a risk of electric shock.

The exclamation point within an equilateral triangle is

intended to alert the user to the presence of important

operating and maintenance (servicing) instructions in

the literature accompanying the appliance.
