DE P T HTM
u s e r s m a n u a l
c l s e l e c t r o s t a t i c
M LA R T I N O G A N
2 Contents
Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Installation in Brief . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Introduction and Assembly . . . . . . . . . . . . . . . . . . . . . .4
Introduction
Trim Removal and Installation
About the Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Connections and Control Settings . . . . . . . . . . . . . . . . .6
Before Connecting the Depth
2-Channel Mode
Multi-Channel Mode . . . . . . . . . . . . . . . . . . . . . . . . . . .7
2-Channel/Multi-Channel Mode . . . . . . . . . . . . . . . . . .8
2-Channel Using Speaker Level Inputs . . . . . . . . . . . . .9
2-Channel Mode With 2-Channel Output . . . . . . . . .10
Why the Filters Are Not Equal
Sub Out—Using Multiple Depths . . . . . . . . . . . . . . . .11
AC Power Connection . . . . . . . . . . . . . . . . . . . . . . . . .12
Replacing the Fuse
Break-In
Placement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Listening Position
Installing the Depth in a Cabinet
Ask Your Dealer
Enjoy Yourself
Room Acoustics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Your Room
Terminology
Solid Footing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Home Theater . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Depth Advantages . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
BalancedForce™ For Cleaner Bass
Servo-Controlled Dynamic Drivers
Low-Pass Filters Maximize Blending
25Hz Level Control
TriLinear™ Configuration
Frequently Asked Questions & Troubleshooting . . . .18
General Information . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Specifications
Warranty and Registration
Service
Glossary of Audio Terms . . . . . . . . . . . . . . . . . . . . . . . .20
Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
3Installation in Brief 3
We know that you are eager to hear your new Depth sub-
woofer, so this section is provided to allow fast and easy
set up. Once you have it operational, please take the time
to
read, in depth, the rest of the information in this manual.
It will give you perspective on how to attain the greatest
possible performance from this most exacting woofer system.
If you experience any difficulties in setup or operation of the
Depth, please refer to the Placement, Room Acoustics and
Connections and Control Settings sections of this manual.
Should you encounter a persistent problem that cannot be
resolved, please contact your authorized MartinLogan dealer.
They will provide you with the appropriate technical analysis
to alleviate the situation.
WARNING!
•Hazardous voltages exist inside—do not
remove cover.
•Refer servicing to a qualified technician.
•To prevent fire or shock hazard, do not
expose this module to moisture.
•Unplug subwoofer should any abnormal
conditions occur.
•Use only with a grounded outlet.
Step 1: Unpacking
Remove your new Depth subwoofer from its packing.
Step 2: Placement
Ideally, place the Depth in a corner near the front of the
room. This is a good place to start. Please see the Placement
section (page 13) of this manual for more details.
Step 3: Signal Connection
Use the best interconnect cables you can. High quality cables,
available from your specialty dealer, are recommended and
will give you superior performance.
Attach your preamplifier/processor outputs through cables
to the signal input area located on the Depths rear panel.
Please see the Connections and Control Settings section
(pages 6–12) of this manual for more details.
If you plan to connect your Depth using signal level (high
level) inputs, please refer to page 9 for instructions.
Step 4: Power Connection (AC) (see warning)
Make sure the level knob is set at 0. Plug the Depth subwoofer
into a wall outlet. Please see the Connections and Control
Settings section (page 12) of this manual for more details.
Step 5: Setting the Controls
Set the level knob to a medium volume position (12 o'clock).
Set the 25Hz Level to 0 (12 o'clock). Set the power switch
on the front of the Depth to ‘Auto’.
Step 6: Listen and Enjoy
Now, you may adjust your system and enjoy!
The lightning bolt flash with arrowhead symbol, within
an equilateral triangle, is intended to alert the user to the
presence of uninsulated dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude
to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
