SC R I P T TM

u s e r ’ s m a n u a l

c l s e l e c t r o s t a t i c

M LA R T I N O G A N

2 Contents

CONTENTS

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Installation in Brief . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

AC Power Connection

Signal Connection

Break-In

Mounting the Script . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

The Wall Mount Bracket

Preparing for Installation

Mounting the Script On A Wall

Room Acoustics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Your Room

Terminology

Rules of Thumb

Dipolar Speakers and Your Room

Dispersion Interactions . . . . . . . . . . . . . . . . . . . . . . . . .12

Controlled Horizontal Dispersion

Controlled Vertical Dispersion

Three Major Types of Dispersion

Home Theater . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Electrostatic Advantages . . . . . . . . . . . . . . . . . . . . . . . .15

Full Range Operation

MartinLogan Exclusives . . . . . . . . . . . . . . . . . . . . . . . . .17

Curvilinear Line Source

Vapor Deposited Film

Transducer Integrity

Electrostatic Loudspeaker History . . . . . . . . . . . . . . . .18

Frequently Asked Questions . . . . . . . . . . . . . . . . . . . . .20

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

General Information . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Specifications

Warranty and Registration

Service

Glossary of Audio Terms . . . . . . . . . . . . . . . . . . . . . . . .24

Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

3Installation in Brief 3

INSTALLATION IN RIEFB

We know you are eager to hear your Script loudspeakers,

so this section is provided to allow fast and easy set up.

Once you have them operational, please take the time to

read, in depth, the rest of the information in this manual.

It will give you perspective on how to attain the greatest

possible performance from this most exacting transducer.

If you should experience any difficulties in the setup or

operation of your Scripts, please refer to the Installation or

Operation sections of this manual.

Should you encounter a persistent problem that cannot be

resolved, please contact your authorized MartinLogan

dealer. They will provide you with the appropriate technical

analysis to alleviate the situation.

WARNING!

•Hazardous voltages exist inside—do not

remove cover

•Refer servicing to a qualified technician

•To prevent fire or shock hazard, do not

expose this module to moisture

•Turn amplifier off and unplug speaker

should any abnormal conditions occur

•Do not operate if there is any visual

damage to the electrostatic panel element

•Do not over drive speaker beyond its rated power

Step 1: Unpacking

Remove your new Script speakers from their packing.

Step 2: Mounting

Mount each Script at its desired location on your front, side,

or back wall(s). Please see the Mounting the Script section

(pages 6–9) of this manual for details on installation and

determining the proper mounting height.

Step 3: Power Connection (AC) (see warning)

MartinLogan speakers require AC power to energize their

electrostatic cells. Using the AC power cords provided,

plug them in

first to the AC power receptacle on the rear

panel of the speaker

, making sure that you have made a

firm

connection, and then to the wall outlet. Please see the

Operations section (pages 5) of this manual for more details.

Step 4: Signal Connection

Use the best speaker cables you can. Higher quality cables,

available from your specialty dealer, are recommended

and will give you superior performance. Spade connectors

are suggested for optimum contact and ease of installation.

Attach your speaker cables to the Signal Input section on

the rear panel. Be consistent when connecting speaker

leads to the terminals on the back of the Script: take great

care to assign the same color to the (+) terminal on both

the left and right channels. If bass is nonexistent and you

cannot discern a tight, coherent image, you may need

to reverse the (+) and (-) leads on one side to bring the

system into proper polarity.

Please see the Operations section (pages 5) of this manual

for more details.

Step 5: Listen and Enjoy

Now, you may turn on your system and enjoy!

The lightning bolt flash with arrowhead symbol, within

an equilateral triangle, is intended to alert the user to

the presence of uninsulated “dangerous voltage” within the

product’s enclosure that may be of sufficient magnitude

to constitute a risk of electric shock.

The exclamation point within an equilateral triangle is

intended to alert the user to the presence of important

operating and maintenance (servicing) instructions in

the literature accompanying the appliance.
