N0
5105
TURNTABLE OWNER’S MANUAL
N0
5105 MC
N0 5105 / N0 5105 MC TURNTABLE / OWNER’S MANUAL
2
Thank you for your investment in a N05105 turntable. For nearly 50 years, discerning individuals have chosen Mark Levinson products for
their luxurious quality and revealing sound. Robust materials, lavish finishes, bold geometry, and outstanding performance are celebrated
attributes of the Mark Levinson brand. The N05105 Turntable is made with the finest materials, technology, and craftsmanship in the world
and will deliver outstanding performance for many years to come.
For optimum performance, please read this guide and follow the unpacking and set up instructions carefully.
PACKING
PARTS
1 – Chassis with mounted tonearm
2 – Record weight
3 – Platter
4 – Alignment template
IMPORTANT:
READ BEFORE PROCEEDING!
• Read and follow th instructionse
• Keep all instructions for your reference.
• Save all packing materials. The N05105
should only be moved or shipped in its
original packaging to reduce the risk of
damage in transit.
IMPORTANT SAFETY
INSTRUCTIONS
PLEASE SEE ADDITIONAL
SAFETY INSTRUCTIONS
INCLUDED IN THE PACKAGE
FOLLOW THE INSTRUCTIONS
BELOW TO REDUCE RISK OF
ELECTRICAL HAZARD OR INJURY.
1. To avoid electrical shock, do not open
the motor housing.
2. To avoid electrical shock, always plug
the N05105 into a grounded outlet.
3. If the power cord provided with the
N05105 does not reach an outlet, use a
heavy-duty, grounded extension cord.
4. Use the N05105 in a controlled
temperature environment.
5. Install in accordance with the
manufacturer’s instructions.
6. Refer to the operating instructions
for power requirements. Be advised
that different operating voltages may
require the use of different line cord
and/or attachment plug.
7. Never attach audio power amplifier
outputs directly to any of the unit’s
connectors.
In case of any damage or question please
contact your authorized Mark Levinson
dealer.
1
2
3
4
N0 5105 / N0 5105 MC TURNTABLE / OWNER’S MANUAL 3
SETUP
PREPARATION
To avoid transport damage your
N05105
comes in carefully designed packaging and is partially
preassembled. Make sure you have plenty of clear flat space to unpack and set up the N05105.
We recommend at least 2ft x 2ft flat surface to set up.
UNPACKING THE BOX
It is important that you save the packing materials and box to use for shipping or moving
the N05105. Remove the chassis and place it on the designated surface. The N05105 must
be placed on a flat, level surface capable of supporting its considerable weight (75 lbs).
This will make setup easy and put less strain on the main bearing. The stronger and better
isolated the shelf or stand is, the better the N05105 will sound.
• Remove and set aside these items:
Alignment template
Record weight
Power cords
Anti-skating weight
Bearing oil
Belt
12" LP jacket containing the manual and platter mat
LEVELLING
After placing the chassis, you can now level the turntable by turning the 3 feet in the chassis.
Turn the feet right for lowering the chassis and left to lift it. Use the integrated bubble level for
adjustment.
MOUNTING THE PLATTER
Take away the cover strip over the bearing hole.
Insert the platter carefully into the bearing. Take care that it slides in slowly and easily. Do not
let the platter drop into the bearing hole, as this may damage the bearing.
Turn the platter by hand to make sure it spins easily. Let the platter settle for about 15 minutes
before turning on the motor.
Note: The bearing is factory lubricated, and is generally maintenance free. The bearing oil
is included as a courtesy in case service is needed in the future.
MOUNTING THE BELT
Place the provided belt around the platter (1) and then around the pulley (2). Turn platter by
hand to align belt on tread. Do not use sharp tools or pointed tweezers. This may damage
belt, platter and pulley.
TONEARM
Set up with standard cartridge
If you purchased a
N05105
MC, it will have the cartridge mounted and its tonearm adjusted.
The only thing you must do is to set the anti-skating (as detailed on the next page).
