Seite 1/2
75 OpenHarp
76 Rich Rez
Delay Eects
77 Delay 1
78 Slap It
79 LongChrs
80 LongDlay
81 Delay280
82 Delay450
83 AntrChor
84 Chor Too
85 ChorDubl
86 SlapChor
87 ChorDlay
88 ThruRngr
89 ThikChor
90 SwngDlay
91 LongEkos
92 6VoxChor
93 VoclChor
94 *MAT Chor
95 ChorSlap
96 KickSlap
97 *LongChor
98 *SlapChrs
99 *SheenChr
100 *BootBass
101 Delay 2
102 Image
103 SideSlap
104 MultiEko
Auto Tempo
Effects
105 1/4 Multi
106 1/8 Multi
107 1/16 Mult
108 1/8 TMult
109 1/4 Chor
110 1/8 Chor
111 1/16 Chor
112 1/8TChor
113 Preset 1
• •
128 Preset 16
1 Preset 1
• •
16 Preset 16
Reverbs
17 SmalHall
18 BritHall
19 DarkHall
20 BigHall
21 MidVerb
22 LongVerb
23 HugeVerb
24 Tight
25 SmalRoom
26 SmallRm1
27 SmallRm2
28 MedRm1
29 MedRm2
30 LrgeRm1
31 LrgeRm2
32 SmalPlat
33 Plate
34 Plate15
35 GuitPlat
36 DrmPlat
37 GoldPlat
38 GudPlat
39 VocPlat
40 RustPlat
41 DrkPlat
42 BritPlat
43 Church1
44 LongPlat
45 DifPlate
46 BigPlate
47 BotmPlat
48 *SoloPlat
49 EchoPlat
50 DeepEnd
Gates
51 SmalGate
52 ShrtGate
53 MedGate
54 MediGate
55 LarjGate
56 Gate1
57 GateSlap
58 BritGate
59 SlapGate
60 SprngChs
61 MegaGate
62 Snar+Tom
63 MetlGate
64 *ElvsGate
Inverse Eects
65 Inverse1
66 Deverse
67 RevRpeat
68 SkiSlope
Chorus, Flange
and Resonator
Effects
69 TalkFlng
70 FullChor
71 SlapFlng
72 SislEkos
73 Rez 2
74 Edge 1
* These eects have one parameter patched to MIDI controller 7, Volume.
© Lexicon, Inc. 1994 Lexicon Part No. 070-10776
Reflex is shipped
with its 128 regis-
ters lled with the
eects listed here.
These registers are
volatile. When you
save an eect, the
current contents of
the register will be
overwritten. Once
you've overwritten
a register, it cannot
be restored, even
by reinitializing the
unit.
Load
Pressing the REGISTER/PRESET button determines whether
one of 16 presets (LARGE HALL ... RESONATOR), or one of 128
registers will be selected by the front panel knob. (The LED lights
when registers are selected.) Selected programs are automatically
loaded.
Edit
Press PARAMETER/LEARN to choose one of the 3 parameters:
DECAY, DELAY or FX LVL. A lighted LED indicates your selection.
Turn VALUE to adjust the parameter.
Store
To store the currently running eect, briey press STORE/CLEAR
until a plus sign (+) is displayed. Press and hold STORE/CLEAR.
The display will show the last selected register number. Release
STORE/CLEAR to store to this location, or select another register
before releasing STORE/CLEAR.
Registers
For more about Reex,
including MIDI opera-
tion, read the Reflex
User Guide.
Lexicon, Inc. • 3 Oak Park • Bedford, MA 01730
Tel: (781) 280-0300 Fax: (781) 280-0490
Reex Basic Operation
Algorithm ID A8
Chorus
(Presets 13-14)
1 Feedback
2 Delay 1
3 FX Lvl
4 Hi Cut
5 Delay 2
6 Delay 3
7 – –
8 Diffusion
9 Rate
10 Eko Rthm
A7
Gate
(Preset 8)
1 Gate
2 Predelay
3 FX Lvl
4 – –
5 Hi Cut
6 Slope
7 Pdly Fbk
8 Diffusion
9 – –
10 – –
A6
Inverse
(Preset 7)
1 Size
2 Predelay
3 FX Lvl
4 – –
5 Hi Cut
6 Slope
7 Pdly Fbk
8 Diffusion
9 – –
10 – –
A5
Resonator
(Preset 16)
1 Res Fbk
2 Tuning
3 FX Lvl
4 Predelay
5 Lo Cut
6 Shimmer
7 – –
8 Richness
9 Slope
10 – –
A4
Multi-Taps
(Preset 15)
1 Feedback
2 Group Dly
3 FX Lvl
4 – –
5 L Delay
6 R Delay
7 – –
8 Hi Cut
9 Diffusion
10 Eko Rthm
A3
Flanger
(Preset 12)
1 Neg Fbk
2 Depth
3 FX Lvl
4 R Dly Fbk
5 R Delay
6 Shape
7 L Dly Fbk
8 L Dly
9 Rate
10 – –
A2
Plate
(Presets 9-11)
1 Decay
2 Predelay
3 FX Lvl
4 Bass Mult
5 Hi Cut
6 Size
7 Pdly Fbk
8 Diffusion
9 – –
10 – –
A1
Hall
(Presets 1-6)
1 Decay
2 Predelay
3 FX Lvl
4 Bass Mult
5 Hi Cut
6 Size
7 Pdly Fbk
8 Diffusion
9 Rx Lvl
10 Rflx Dly
Algorithm ID
Advanced Programming Mode
Simultaneously press PARAMETER/LEARN and REGISTER/PRESET to enter the
Advanced Programming Mode for the currently running eect.
REGISTER/PRESET knob positions 1-10 select parameters adjustable with VALUE.
Positions 11-15 provide Utility functions. Position 16 displays Algorithm ID.
Press REGISTER/PRESET to return to front panel operation.
Reex Advanced Programming
APM
Parameters
Shaded parameters corre-
spond to the 3 front panel
controls: DECAY, DELAY
and FX LVL.
* These functions are memorized, and remain in
eect until deliberately altered.
Utility
Functions
11 Pc* MIDI Program Change (Press STORE) + = enable; – = disable
12 Ch* Channel for incoming MIDI (Turn VALUE) 0 = OMNI, or 1-16
13 dA Dump all registers (Press STORE)
14 dC Dump current effect (Press STORE)
15 F* Footswitch type (Turn VALUE) 0 = latching; 1 = momentary
16 A1-8 Display Algorithm ID
