LaCie 500 Series LCD Monitor
User Manual page 1
Table of Contents
Table of Contents
Safety Precautions and Maintenance 3
Health and Ergonomic Precautions 4
Environmental Regulations 5
Manufacturerās Recycling and Energy Information 6
Monitor Speciļ¬cations 7
1. Introduction to Your LaCie 500 Series LCD Monitor 8
1.1. 500 Series LCD Monitor Features 8
1.2. Box Content 9
2. Installing Your LaCie 500 Series LCD Monitor 10
3. Using Your LaCie 500 Series LCD Monitor 13
3.1. Physical Adjustments 13
3.1.1. Raise and lower monitor screen 13
3.1.2. Screen tilt 13
3.1.3. Screen rotation 14
3.1.4. Swivel 14
3.1.5. Remove monitor stand for mounting 15
3.1.6. Flexible arm installation 16
4. OSD (On-Screen Display) Control Button Functions 17
4.1. Brightness/Contrast Controls 18
4.2. Auto Adjust (Analog input only) 18
4.3. Image Controls 18
4.4. Color Control Systems 20
4.5. Tools 1 21
4.6. Menu Tools 24
4.7. Information 25
4.8. OSD Warnings 26
4.9. Advanced Menu Functions 26
4.10. Using the Auto Brightness Function 39
5. Troubleshooting 41
6. Contacting Customer Support 43
6.1. LaCie Technical Support Contacts 44
7. Warranty Information 45
LaCie 500 Series LCD Monitor
User Manual page 2
Copyrights
Copyright Ā© 2007 LaCie. All rights
reserved. No part of this publication
may be reproduced, stored in a retrieval
system, or transmitted in any form or by
any means, electronic, mechanical, pho-
tocopying, recording or otherwise, with-
out the prior written consent of LaCie.
Changes
īe material in this document is for
information only and subject to change
without notice. While reasonable ef-
forts have been made in the preparation
of this document to assure its accuracy,
LaCie assumes no liability resulting
from errors or omissions in this docu-
ment, or from the use of the informa-
tion contained herein. LaCie reserves
the right to make changes or revisions
in the product design or the product
manual without reservation and without
obligation to notify any person of such
revisions and changes.
FCC Declaration of Conformity:
Tested To Comply
With FCC standards
For Home of Oļ¬ce Use
LaCie 500 Series
LCD Monitor
NOTE: īis equipment has been
tested and found to comply with the
limits for a Class B digital device, pur-
suant to Part 15 of the FCC Rules.
īese limits are designed to provide
reasonable protection against harm-
ful interference in a residential instal-
lation. īis equipment generates, uses
and can radiate radio frequency energy
and, if not installed and used in accor-
dance with the instructions, may cause
harmful interference to radio commu-
nications. However, there is no guaran-
tee that interference will not occur in a
particular installation. If this equipment
does cause harmful interference to radio
or television reception, which can be de-
termined by turning the equipment oļ¬
and on, the user is encouraged to try and
correct the interference by one or more
of the following measures:
Reorient or relocate the receiving an-
tenna.
Increase the separation between the
equipment and receiver.
Connect the equipment into an out-
let on a circuit diļ¬erent from that to
which the receiver is connected.
Consult the dealer or an experienced
radio/TV technician for help.
Use only shielded cables to connect
I/O devices to this equipment.
Use the attached speciļ¬ed cables
with the LaCie 500 Series color moni-
tor so as not to interfere with radio and
television reception.
1. īe power supply cord you use must
have been approved by and comply
with the safety standards of U.S.A.
and meet the following condition.
Power supply
chord
Non shield type,
3-conductor
Length 2.0 m
Plug shape
(USA)
2. Please use the supplied shielded video
ā
ā
ā
ā
ā
signal cable, 15-pin mini D-SUB to
DVI-A cable or DVI-D to DVI-D
cable. Use of other cables and adapt-
ers may cause interference with radio
and television reception.
U.S. Responsible Party: LaCie, LTD
Address: 22985 NW Evergreen Pkwy
Hillsboro, OR 97124
Tel. No.: (503) 844-4503
Manufacturerās Declaration for
CE Certiļ¬cation
We, LaCie, solemnly declare that this
product conforms to the following Eu-
ropean standards:
EN60950-1, EN61000-3-2
EN61000-3-3, EN55024
With reference to the following condi-
tions:
73/23/EEC Low Voltage Directive
89/336/EEC EMC Directive
LaCie S.A.
33 Bld du GƩnƩral Martial Valin
75015 Paris
France
ā
ā
ā
ā
Forward
CAUTION: Modiļ¬cations not au-
thorized by the manufacturer may void
the userās authority to operate this de-
vice. Modiļ¬cations not authorized by
the manufacturer may void the userās
authority to operate this device.
CAUTION: A shielded-type
power cord is required in order to meet
FCC emission limits and also to pre-
vent interference to the nearby radio
and television reception. It is essential
that only the supplied power cord be
used.
LaCie 500 Series LCD Monitor
User Manual page 3
Safety Precautions and Maintenance
Safety Precautions and Maintenance
DO NOT OPEN THE MONI-
TOR. īere are no user serviceable
parts inside and opening or removing
covers may expose you to dangerous
shock hazards or other risks. Refer all
servicing to qualiļ¬ed service person-
nel.
Do not spill any liquids into the cabi-
net or use your monitor near water.
Do not insert objects of any kind into
the cabinet slots, as they may touch
dangerous voltage points, which can
be harmful or fatal or may cause elec-
tric shock, ļ¬re or equipment failure.
Do not place any heavy objects on
the power cord. Damage to the cord
may cause shock or ļ¬re.
Do not place this product on a slop-
ing or unstable surface, as the moni-
tor may fall, causing serious damage.
Do not place any objects onto the
monitor and do not use the monitor
outdoors.
īe inside of the ļ¬uorescent tube
located within the LCD monitor
contains mercury. Please follow the
bylaws or rules of
your municipality to dispose of the
tube properly.
Do not bend power cord.
Do not use monitor in high tempera-
tured, humid, dusty, or oily areas.
Do not cover vent on monitor.
Immediately unplug your monitor
from the outlet and refer servicing to
ā
ā
ā
ā
ā
ā
ā
ā
ā
ā
qualiļ¬ed personnel under the following
conditions:
When the power supply cord or plug
is damaged.
If liquid has been spilled, or objects
have fallen into the monitor.
If the monitor has been exposed to
rain or water.
If the monitor has been dropped or
the cabinet damaged.
If the monitor does not operate nor-
mally by following operating instruc-
tions.
If glass is broken, handle with care.
If monitor or glass is broken, do not
come in contact with the liquid crys-
tal and handle with care.
Allow adequate ventilation around
the monitor so that heat can properly
dissipate. Do not block ventilated
openings or place the monitor near
a radiator or other heat sources. Do
not put anything on top of monitor.
īe power cable connector is the pri-
mary means of detaching the system
from the power supply. īe monitor
should be installed close to a power
outlet which is easily accessible.
Handle with care when transporting.
Save packaging for transporting.
Image Persistence: Please be aware
that LCD Technology may experi-
ence a phenomenon known as Image
Persistence.
ā
ā
ā
ā
ā
ā
ā
ā
ā
ā
ā
Image Persistence occurs when a re-
sidual or āghostā image of a previous
image remains visible on the screen.
Unlike CRT monitors, LCD moni-
torsā image persistence is not per-
manent, but constant images being
displayed for a long period of time
should be avoided. To alleviate im-
age persistence, turn oļ¬ the monitor
for as long as the previous image was
displayed. For example, if an image
was on the monitor for one hour, the
monitor should be turned oļ¬ for one
hour to erase the image.
When operating the LaCie 500 Se-
ries LCD Monitor with a 220-240V
AC power source in Europe, use the
power cord provided with the moni-
tor.
In the UK, a BS approved power cord
with a moulded plug has a Black (ļ¬ve
Amps) fuse installed for use with this
equipment.
If a power cord is not supplied with
this equipment please contact your
supplier.
When operating the LaCie 500 Se-
ries LCD Monitor with a 220-240V
AC power source in Australia, use the
power cord provided with the moni-
tor. If a power cord is not supplied
with this equipment please contact
your supplier.
For all other cases, use a power cord
that matches the AC voltage of the
power outlet and has been approved
by and complies with the safety stan-
dard of your particular country.
ā
ā
ā
ā
ā
ā
