INSTRUCTION MANUAL
ANALOGUE INSULATION EARTH TESTER
MODEL 6018
KYORITSU ELECTRICAL INSTRUMENTS
WORKS, LTD
1. Safety Warnings ---------------------------------------------------------------------------- 1
2. Features ---------------------------------------------------------------------------------------- 3
3. Specifications --------------------------------------------------------------------------------- 4
4. Instrument Layout --------------------------------------------------------------------------- 8
5. Preparation for Measurement
5-1 Installing Batteries ---------------------------------------------------------------------- 9
5-2 Mechanical Zero Adjustment ------------------------------------------------------- 10
5-3 Connecting Test Leads -------------------------------------------------------------- 10
5-4 Battery Voltage Check ---------------------------------------------------------------- 11
5-5 "Power-on"Indication LED ----------------------------------------------------------- 11
5-6 Scale Illumination Function ---------------------------------------------------------- 12
5-7 Attaching Neck Strap ----------------------------------------------------------------- 12
5-8 Fitting Case Lid Under Case -------------------------------------------------------- 13
6. Measurement
6-1 AC Voltage Measurement
(Mains Disconnection Check)
---------------------- 14
6-2 Insulation Resistance Measurement ---------------------------------------------- 16
6-3 Continuous Insulation Resistance Measurement ----------------------------- 18
6-4 Output Voltage Characteristics ----------------------------------------------------- 18
6-5 Earth Resistance Measurement --------------------------------------------------- 19
6-6 Precision Measurement -------------------------------------------------------------- 19
6-7 Simplified Measurement ------------------------------------------------------------- 21
7. Test Prods for Line Probe and Replacement ---------------------------------------- 24
8. Adapters for Earth Lead and Replacement ------------------------------------------ 25
9. Optional Accessories
9-1 How to Use Test Leads and Cord Reels ----------------------------------------- 26
10. Cleaning Meter Cover --------------------------------------------------------------------- 27
11. Before Sending for Repair ---------------------------------------------------------------- 28
Table of contents
1
1. Safety Warnings
This instruction manual contains warnings and safety rules which must be
observed by the user to ensure safe operation of the instrument and to retain it in
safe condition. Therefore, read through these operating instructions before using
the instrument. This instrument has been designed and tested according to the
following standards.
IEC 61557-2: Insulation Tester
IEC 61557-5: Earth Resistance Tester
IEC 61010-1 measurement category CAT 600V, pollution degree 2Ⅲ
Symbol # indicated on the instrument means that the user must refer to related
parts in the manual for safe operation of the instrument. Be sure to carefully read
the instructions following each # symbol in this manual.
# DANGER is reserved for conditions and actions that are likely to cause
serious or fatal injury.
# WARNING is reserved for conditions and actions that can cause serious or
fatal injury.
# CAUTION is reserved for conditions and actions that can cause injury or
instrument damage.
# WARNING
◦Read through and understand instructions contained in this manual before
using the instrument.
◦ Save and keep the manual handy to enable quick reference whenever
necessary.
◦ The instrument is to be used only in its intended applications.
　Understand and follow all the safety instructions contained in the manual.
　Failure to follow the instructions may cause injury, instrument damage and/
or damage to equipment under test. Kyoritsu is by no means liable for any
damage resulting from the instrument in contradiction to this cautionary
note.
# DANGER
◦ Never make measurement on a circuit above 600VAC or DC.
◦Do not attempt to make measurement in the presence of flammable
gasses. Otherwise, the use of the instrument may cause sparking, which
can lead to an explosion.
◦
When testing a circuit that can carry high current, including a power line, be
sure to make voltage measurement at the secondary side of a circuit breaker
in order to avoid possible hazard to the user. Exercise extreme caution not to
short live conductors together with the metal tips of test probes.
