If the lighting appliance has faults other than those mentioned
above, please contact us or the local representative of our
company immediately. We will provide solutions as soon as
possible.
HL-1000-EX
BW7101B
LED Portable
Explosion-proof
Searchlight
Instruction manual
www.tormin-lighting.com
ADD: No. 35, Qingjiang Road, High-tech District, Wenzhou, Zhejiang, China.
P. C: 325011
Tel: +86 577 56 96636 6 +86 577 569663 68
Fax: +86 577 56966 166
Http://www.tormin-lighting.com E-mail: sales@tormin.com
ZHEJIANG TORMIN ELECTRICAL CO.,LTD.
50
Reference standards:
EN 60079-0: 2018; EN 60079-1: 2014;
EN 60079-11: 2012; EN 60079-31: 2014
MANUFACTURER: ZHEJIANG TORMIN ELECTRICAL CO., LTD.
Add: Thungenfeld 8, 58256 Ennepetal, Germany
Tel: +49 (0)2333 -98 247 40
Fax: +49 (0)2333 -98 247 49
..
Main Specification
This product is widely used in high-voltage line inspection, search and rescue,
equipment inspection, maintenance and various flammable and explosive places
as mobile lighting.
Zone 1 and Zone 2 for hazardous gases; Zone 21 and Zone 22 for hazardous dust.
Instructions:
Characteristics Of Performance
â–  Three levels of strong light, weak light, and flashing warning can be switched at
will;
â–  Dual modes can be switched freely.
(below using BW7101B as example)
â–  Digital battery display, real-time understanding of lighting time;
â–  Using ultra-high brightness LED, suitable for field patrol operations and search
targets;
â–  The patented structure for heat dissipation can quickly reduce the temperature of
the light source and effectively ensure the reliability and service life of the light
source;
â–  The shell is made of CNC precision processing, and the surface of the shell is
treated with the hardest oxidation treatment, making the whole elegant atmosphere;
â–  It can be equipped with a rubber protective cover to increase the resistance to fall
and wear and prolong the service life of the product;
â–  Built-in 6pcs 18650 lithium batteries, with strong endurance, can be selected
according to the use situation.
When the light is on, press and hold the
switch for 5 seconds to switch the mode.
Mode 1: High light illumination for 8 hours, low light illumination for 16 hours;
Mode 2: High light illumination for 11 hours, low light illumination for 16 hours;
1. When in use, lightly press the handle switch to start the High light illumination
for the first time, press the second time to turn into Low light, press the third time
to turn off, and cycle in turn.
2. When the light is off, press and hold the switch for 2 seconds, the light will
flash, and then press the switch again to turn off the light.
3. When the light is on, press and hold the switch for 5 seconds to switch the
mode:
Mode 1: High light illumination for 8 hours, low light illumination for 16 hours;
Mode 2: High light illumination for 11 hours, low light illumination for 16 hours;
4. When the light is turned on, the battery power will be detected. The battery
power is displayed as a percentage value in the window at the end of the lamp.
When the power is 10%, the lamp needs to be charged.
5. After the first few times of use, the charging time is 8~10 hours. In the future,
it can be recharged in time according to the normal charging time to ensure that
the battery is always fully charged; after a full charge, it can be used at any time
within 90 days; if it is long-term Leave it unused and charge it for about 8 hours
before use.
6. During use, if the power is about to run out, the brightness of the light will be
significantly dimmed and enter the stroboscopic state. The power will be
automatically cut off after about 10 minutes. At this time, stop using and charge
in time.
7. The charger has a built-in charging protection device. Open the charging
rubber plug on the back cover of the lamp, and insert the charger's output plug
into the charging socket. The red light is on to indicate that it is charging, and the
red to green indicates that it is fully charged.
Ex marking: II 2 G Ex db ib IIC T6 Gb
II 2 D Ex ib tb IIIC T80℃ Db IP68
(below using BW7101B as example)
Precautions:
1. Frequently check and ensure that the handle and the back cover, the lamp tube
and the back cover are tightly integrated to enhance the waterproof, explosion-
proof, and impact resistance capabilities.
2. When charging in a place with a high ambient temperature or continuously
discharging with strong light for a long time, the surface of the flashlight will rise
slightly in temperature, which is a normal phenomenon.
3. It is strictly forbidden to place the transparent part of the lamp facing down
after turning on the lamp; do not illuminate the human eye directly (because the
strong light may hurt the human eye).
4. Do not disassemble the structural parts of the lamp at will, especially the sealed
structural parts.
5. Wipe the surface after use in a corrosive environment or seawater.
The box includes lamps, lanyard, charger, manual.
Lighting
time
Luminous
Service life of battery
Rated voltage V
Item
Rated capacity Ah
Unit Model 1
Model 2
BW7101B
mm
h
h
Rated wattage
High
High
Low
Low
Time of charging
Dimension
Net weight
Recycle
lm
lm
g
h
2.6
22.2 (6 batteries series)
3 3×
≥890
≥515
≥8
≥16
≥670
≥515
≥11
≥16
8
≈1000
φ67 140×
830
Note: When BW7101B is on, press and hold for 5 seconds to switch between
mode 1 and mode 2; When switching to mode 1, the display shows P1;
when switching to mode 2, the display shows P2.
W
