Seite 1/60
English 2
French (N. America) 11
Spanish (N. America) 21
French 31
Spanish 41
German 51
O W N E R ’ S M A N U A L
We’re here to help.
We want you to have an exceptional project building experience.
If you have questions or need support, please get in touch.
1-800-447-8638 technicalsupport@kregtool.com |
Tell us about your experience.
Your opinion counts. And we’re always looking for ways to improve.
Share your feedback so we can keep growing and innovating for you.
www.kregtool.com/feedback
WARNING Every user must read and follow instructions and safety precautions in this manual.
Failure to do so could result in serious injury. Save manual for future reference.
Crosscut Station
Manual applies to Item # KMA4100 and KMA4100-INT
2
Safety Precautions
WARNING Before using a power tool with this product, read, and follow the tool manufacturer’s instructions
and safety precautions in addition to the safety precautions below to reduce risk of serious injury from hazards
such as re, electric shock, or rotating saw blade.
■Follow your saw manufacturer’s instructions and safety precautions.
â– Always wear personal protective equipment required by the saw manufacturer.
â– Do not allow familiarity gained from frequent use of your tools to replace safe work practices. A moment of
carelessness is sufcient to cause serious injury.
â– Avoid awkward hand positions where a sudden slip could cause contact with the rotating blade.
â– This product is only intended for use with circular saws. Not intended for use with other power tools such as
routers or jig saws.
â– Always secure the cutting station to prevent movement while cutting.
â– Do not attempt bevel cuts with this product.
â– Inspect your workpiece before cutting. If the workpiece is bowed or warped, ensure there is no gap between
the workpiece and fence along the cut line.
■Always secure the workpiece with a rm grip ensuring your hand stays
outside of the cutting area as designated by the symbol.
WARNING Do not operate this tool or any machinery while under the inuence of drugs, alcohol, or
medications.
WARNING This product can expose you to chemicals including Acrylonitrile, which is known to the State of
California to cause cancer. For more information go to www.P65Warnings.ca.gov.
WARNING Drilling, sawing, sanding or machining wood products can expose you to wood dust, a substance
known to the State of California to cause cancer. Avoid inhaling wood dust or use a dust mask or other
safeguards for personal protection. For more information go to www.P65Warnings.ca.gov/wood.
Pre-Assembly
WARNING Avoid cutting irregular-shaped workpieces that can twist, rock, or slip while being cut.
Review this section before you begin. Ensure you have all tools/materials that were in the package on hand and
compare them with the items listed in the Hardware Included and Product Description sections. If any item is
missing, do not use this product. Contact customer service or return product to place of purchase.
Table of Contents
Safety Precautions . . . . . . . . . . . . . . . . 2
Pre-Assembly 2 . . . . . . . . . . . . . . . . . . .
Recommended Tools (Not Included) 3. . . . . . .
Hardware Included 3. . . . . . . . . . . . . . . .
Product Description 3 . . . . . . . . . . . . . . .
Assembly . . . . . . . . . . . . . . . . . . . . . 4
Operation . . . . . . . . . . . . . . . . . . . . . 6
Make your Kerf Line Cut 6. . . . . . . . . . . . .
Make a 90° Cut . . . . . . . . . . . . . . . . . 7
Cut Different Angles 8 . . . . . . . . . . . . . . .
Cut Long Workpieces 8 . . . . . . . . . . . . . .
Care and Cleaning . . . . . . . . . . . . . . . . 9
Troubleshooting 9. . . . . . . . . . . . . . . . . .
3
Recommended Tools (Not Included)
Phillips Screwdriver
Hardware Included
CC - Large Screw – 4AA - Small Screw – 12 BB - Rail Bracket with
Top Screw – 2
Product Description
A
B
C
D
D
E
F
H
G
I
Part Description Part Description
A Cutting base F Material hold-down clamps
B Fixed saw guide rail G Adjustable fence
C Adjustable saw guide rail H Front blade guard actuator board
D Material support wings with detachable blocks I Angle indicators
E Sure-Cutâ„¢ back board
