INPUT – Connect the source audio to the DS 50 via XLR cable. The connector will accept line-level or microphone signals. To disconnect the XLR cable, press the tab while

pulling the connector out.

THRU – When used with line-level signals, the DS 50 can split the audio up to 5 times without a ecting the signal quality. If used to split a microphone signal, only 2 of the THRU jacks

should be used.

Speci cations

Inputs

Connector XLR, balanced

Outputs

Connectors 5 x XLR, balanced

System

Frequency response 20 Hz to 22 kHz (± 0.05 dB)

THD + N (distortion) < 0.01% @ 1 kHz,+4 dBu

Signal-to-noise ratio 121 dB

CMRR 98 dB typical

Insertion loss 0.05 dB @ 100 kΩ, 0.7 dB @ 600 Ω

Power requirement Passive

System

Dimensions (W x D x H) 118 x 112 x 64 mm (4.6 x 4.4 x 2.5")

Weight 0.43 kg (0.9 lbs)

PRO SPLITTER 5 DS 50

Passive 1-In / 5-Out Signal Splitter with Extended Dynamic Range

LEGAL DISCLAIMER

MUSIC Group accepts no liability for any loss which may be su ered by any person who relies either wholly or in part upon any description, photograph, or statement contained herein.

Technical speci cations, appearances and other information are subject to change without notice. All trademarks are the property of their respective owners. MIDAS, KLARK TEKNIK,

LAB GRUPPEN, LAKE, TANNOY, TURBOSOUND, TC ELECTRONIC, TC HELICON, BEHRINGER, and BUGERA are trademarks or registered trademarks of MUSIC Group IP Ltd.

LIMITED WARRANTY

For the applicable warranty terms and conditions and additional information regarding MUSIC Group’s Limited Warranty, please see complete details online at

music-group.com/warranty.
