PV-CG20
1080p Car Charger DVR
(With Night Vision)
5. Format memory card
(1) Press and power on the DVR, the yellow LED will blink and
shut itself off .
(2) When the LED turns off, the format is completed.
4
V1.0
○
6
6. Download the video to PC
(5) : When you Charging the baery plug the DVR to the car
cigaree lighter socket and start the car, the internal baery
will be charged automacally (internal baery is only
used for saving the video clips when the engine is off).
(1)
Use memory card reader to retrieve video files.
(2) With the device powered on and memory card inserted,
plug the USB cable into , and plug the other end
into the PC.The device will be recognized by PC as an external
drive for user to retrieve the files.
* There are two ways to read the retrieve video files.
* Do not remove serial number stickers! Warranty is invalid
if the sticker is tampered!
3.3 Long Press and the device will be turned off
when the yellow LED is off.
○
7
* Battery-Powered,Car Engine is Off (Last Around 20 Minutes)
Short Press and the device will be turned on when the
yellow LED is on.
(1)
7
(2) : o start When youRecording Switch t the le to the Rec.
see the yellow/red LED is on, you know the Rec is on.
To turn off the Rec, switch to the right and the device
will enter the standby mode. Aer 3 minutes of inacvity
in standby mode, the device will be turned off automacally.
8
8
Long Press and the device will be turned off when the
yellow LED is off.
(3)
7
4
(1) : o start When youRecording Switch t the le to the Rec.
see the yellow/red LED is on, you know the Rec is on.
To turn off the Rec, switch to the right and the device
will enter the standby mode. Aer 3 minutes of inacvity
in standby mode, the device will be turned off automacally.
○
8
○
8
* Power On the DVR Via Car Cigarette Lighter Socket
(3) Power :off
3.1 If you turn off the engine, the DVR will also be turned
off automacally
3.2 Unplug the DVR from the car cigaree lighter socket, the
DVR will also be turned off automacally
* There are three ways to turn the power off:
(The video clip will also be saved simultaneously when the
power is turned off)
start the car.
(2) Plug the DVR directly to your car cigaree lighter socket and
5
LawMate, innovation never stops
®
2 1
1. Name and Parts 9
5
6
8
7
(6) Format Key
2. Package content
1 Car Charger DVR 2
User's manual
User manual 3
4GB
Lock
Adapter
Memory card
3
3. Date & Time setting (for Windows system)
4
(1) Power/Rec LED
(2) Camera lens
(3) Power Out:5V 1A
(4) USB Port
(5) Memory Card Slot
(7) Power On/Off Key
(8) IR On/Off Switch
(Le Off/Right On)
(9) IR LED
(1) From the desk top right-click to open Notepad, create a
text (.txt) file named seme
(2) On the first line of the file, enter date and me informaon as
year.month.day hours.minutes.seconds. For example, suppose
the me is October 16th, 2018 15:00. Then, please enter
2018.10.16 15:00:00
Note: There should be a space le between date and hour;
me format should be the 24-hour format.
(3) Save the file to the root directory of the memory card.
Note: If the seng is completed, the seme.txt file will not be
visible when you connect the device to the computer
again.
On
Off
4. Operation
(1) The power keys/USB port and memory card slot are
designed on the side of the DVR that can be covered up by a
hard shell.
(2) You can decide whether to show or to hide the and
by rotang the hard shell(as above picture shows).
(3) You can adjust the camera lens direcon by panning, lng and
rotang the base of the DVR.
45 6
8
3
( :4) IR LED When you switch to on, the recording video color
will turn black and white.
To turn off the IR LED, just slid the LED switch to off.
7. Specification
Built-in image sensor Progressive 1/2.9 inch SONY CMOS
Sensor resolution 2000 x 1121
Sensor sensitivity 0.1 Lux @ F2.0 50IRE
Lens F/No. F2.0
Focal Length 4.6mm
Angle of View 78.2°
Algorithm H.264, JPEG
File Format MOV
Video recording mode Manual
Recoreding Capability 1920x1080
Frame rate Up to 30 fps
Memory type Micro SD Card ( Support SDHC max=32GB)
Data interface Mini USB 2.0
Date/Time Table YYYY/MM/DD, HH:MM:SS
Power Input DC 12-24V
Power Consuption 260-300mA IR OFF)(IR O（N+330mA)
Battery Input DC 3.7V / 130 mA polymers battery(XK032030)
Power Output 1.1A
Dimension 9.5x4x4 (cm)
Weight 57G
Misc.
Powe r
Physical
Video Spec.
Storage & I/O
8
