PCI Express to 2 PCI & 2 PCIe Expansion Enclosure System - Full Length
StarTech ID: PEX2PCIE4L
The PEX2PCIE4L PCI/PCI Express Expansion Chassis provides a quick and simple I/O expansion solution to
almost any PCI Express (PCIe) enabled system. Adding PCI/PCIe cards to a server or workstation, or providing a
platform to swap cards between a mobile and desktop setup is a cost-effective and time-saving solution for
maximizing the I/O capabilities of your system.
The external expansion chassis adds two full-length (38cm) PCI slots (32-bit/33MHz), as well as two PCIe x1 (single-
lane) slots to a host computer through a single PCI Express connection. Providing total bandwidth up to 250MBps
from the PCIe x1 host controller card allows the computer to function as though the expansion chassis cards were
connected directly to the motherboard.
For mobile applications, the Expansion Chassis can be connected to an ExpressCard- enabled laptop using the
StarTech.com ExpressCard connection cable (EC2PCI), eliminating the added expense of purchasing different
card adapters for the laptop.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
Applications
Ideal for system testers, and engineers who regularly swap out PCI or PCIe I/O cards
Expand an existing systems PCI and PCI Express I/O capabilities
Expand a laptops PCI and PCI Express I/O capabilities by purchasing the optional EC2PCI adapter cable
Add full-length or full-height cards to a small form factor system
Provide PCI support to systems with only PCIe slots
www.startech.com
1 800 265 1844
Features
Expansion bay providing 2 PCI ports (32-bit/33 MHz), and 2 PCIe single-lane ports (250MBps)
Self-powered PCI/PCIe expansion system with an on/off button
Rugged steel construction satisfies demands of industrial and server environments
Support for both 5V and 3.3V add-in full-length cards
Complies with PCI 2.3 and PCIe 1.1 specifications
Supports advance error reporting including ECRC support
Support add-in cards with extended length (38cm)
www.startech.com
1 800 265 1844
Technical Specifications
Warranty 2 Years
Interface PCI / PCI-X (5 / 3.3V)
Bus Type PCI Express
Card Type Standard Profile (LP bracket incl.)
Port Style Integrated on Card
Chipset ID Texas Instruments - XIO200A + XIO3130
Connector
Type(s)
1 - PCI Express x1 Male
External Ports 2 - PCI / PCI-X (Universal 3.3 & 5V; 32-bit) Slot Female
External Ports 2 - PCI Express x1 Slot Female
Maximum Data
Transfer Rate
250 Mbps
OS
Compatibility
OS Independent; No additional drivers or software required
Note The Maximum power consumption of the adapter cards used in this expansion box is 36W. Cards
might not function if their total power exceeds the maximum power consumption
Note This product has a compatibility issue with Silicon Image SATA Controllers on an AMD platform
Color Black
Enclosure Type Steel
Product Length 15 in [382 mm]
Product Width 5.4 in [137 mm]
Product Height 5.6 in [143 mm]
Product Weight 4.4 lb [2 kg]
Power Adapter
Included
Yes
Input Voltage 115 ~ 230 AC
Output Voltage 12 DC
Output Current 3A
Center Tip
Polarity
Positive
Plug Type M
Operating
Temperature
0°C to 55°C (32°F to 131°F)
Storage
Temperature
-40°C to 75°C (-40° to 167°F)
Humidity 5 to 95% RH
www.startech.com
1 800 265 1844
