Optical smoke alarm device
Model no.: 2106
The smoke alarm is designed for private homes.
PLEASE READ THE USER GUIDE CAREFUL-
LY BEFORE INSTALLATION AND RETAIN
FOR FUTURE USE.
SAFETY INSTRUCTIONS:
The device comes with a 3V lithium battery.
Batteries are to be handled with care and battery
powered devices should be kept out of reach of
children. Do not try to recharge or burn the bat-
teries.
1. TEST FUNCTION:
After installation, and at least once per quarter, test
all of your alarms to ensure they are operating cor-
rectly and are within range of each other.
It is recommended to check visually every week
ifthe LED ashes correctly (every 48sec.)
Press the test button on any alarm for at least
10 seconds. This will send out a test signal
from the alarm; all other connected
alarms should receive the signal within a short
time. The alarms will emit a short beep and the
LED will ash every 8 seconds for 2 minutes.
NOTE: Test function also allows to send a deplet-
ed RF signal to ensure an optimal operation in
normal conditions.
When the test signal is sent out, the alarms will
respond in two ways:
1. A single beep every 8 seconds indicates that the
alarms are connected and functioning.
2. Three short beeps every 8 seconds indicates a
smoke sensor fault. The alarm should be cleaned
by running the vacuum (on a low setting) around
the smoke alarm chamber and tested again.
If required this indication can be stopped early on
each alarm by a short press of the test button.
TIP: It is safe to cover the sound output hole with
your nger during the testing to minimize the
sound level emitted.
If the problem continues, please visit www.cavius.
com for any trouble shooting.
2. NORMAL MODE:
In normal mode the LED will ash every 48 seconds
to show correct operation.
3. ALARM MODE:
When a concentration of smoke is detected, the
smoke alarm will go into ‘Alarm Mode’. It will sound
the alarm signal and the LED will ash.
The smoke alarm will also transmit the alarm sig-
nal to the other connected alarms, which will also
sound the alarm signal after a short delay.
The CAVIUS Wireless Family have two different
alarm signals:
Alarm signal 1 (--- --- ---) is life threatening alarms.
Alarm signal 2 (- - -) is a non life threatening
alarm.
Smoke alarm signal: --- --- ---
Heat alarm signal: --- --- ---
Please note that only the originating alarm’s LED
will ash, so it can be identied.
4. PAUSE/HUSH FUNCTION:
If the smoke alarms are to set into a false alarm by
cooking, replace, etc. they can be paused for 10
minutes by pressing the test button on the origi-
nating smoke alarm only (indicated by the ashing
LED).
The reason of this is that it is necessary to locate
the source of the alarm before using the hush
function. This is to make sure that it is not a life
threatening situation.
5. LOW BATTERY SIGNAL:
Your product has a 10Y battery life.
When the battery is starting its end of life, a short
beep will sound out every 48 seconds for 30 days.
The alarm affected by the low battery will only
beep, no other connected alarms will sound.
It is recommended to replace the smoke alarm af-
ter 10 years, or if the alarm has suffered any dam-
age. The alarm is not active unless it is inserted in
the mounting base.
Always check the alarm after inserting in the
mounting base (allow a few seconds before test-
ing).
6. MAINTENANCE & TROUBLE SHOOTING:
• The smoke alarm should be vacuum cleaned
once per quarter, to remove dust particles, and
it can be wiped with a damp cloth. (Do not open
the alarm).
• High humidity condensing which can be
resolved by drying the smoke alarm.
If the smoke alarm does not work when the test
button is pushed, the probable cause is a faulty
battery. Check if the battery is depleted by pushing
the test button
If the problem continues, please visit www.cavius.
com for any trouble shooting.
7. OTHER INFORMATION:
Do not paint the alarm.
Complies to the Radio Equipment Directive
2014/53/EU
RF Frequency: 868 MHz.
Maximum radio-frequency power transmitted:
20 mW
Full DoC to 2014/53/EU (RED) can be down-
loaded at www.cavius.com
WARNING: All alarms should be assumed as
due to actual fire and the dwelling should be
evacuated immediately.
WARNING: To prevent injury, this apparatus
must be permanently fixed to the ceiling/wall in
accordance with the installation instructions.
WARNING: Batteries shall not be exposed to
excessive heat such as shine, fire, or the like.
Note the local country regulations regarding in-
stallation.
Disposal: please dispose properly at the end of life.
This is electronic waste which should be recycled.
Please note local regulations about information
to your insurance company regarding installed
smoke alarms.
Hereby, Cavius declares that the radio equipment
type 2106 is in compliance with Directive 2014/53/
EU.
The full text of the EU declaration of conformity is
available at the following internet address: www.
cavius.com
Carrier assumes no responsibility for any errors,
which may appear in this manual. Furthermore,
Carrier reserves the right to alter the hardware,
software, and/or specications detailed herein
at any time without notice, and Carrier does not
make any commitment to update the infor mation
contained herein.
Manufacturer: Carrier Fire & Security Danmark A/S,
EllekĂŚr 9A, 2. Th, DK-2730. Made in China.
400130 rev8
UK
The CE and RED declaration of conformity and DoP can be downloaded from: http//www.cavius.com
The paper version of the DoP is available free of charge upon request.
2
3
DoP no.: 102.0020
EN14604:2005 + AC:2008
Š2023 Carrier. All Rights Reserved.
All trademarks and service marks referred herein are property of their respective owners.
0370
