INSTALLATION & USER GUIDE
6-1/2” IN-WALL LOUDSPEAKER
LSW-6/6.5
For Accurate Music
and Voice Reproduction
from In-Wall Locations
LSW-6/6.5
6-1/2” IN-WALL LOUDSPEAKER
TABLE OF CONTENTS
Features............................................................................................................................1
Product Overview...........................................................................................................1
Package Contents ..........................................................................................................2
Preparing for Installation..............................................................................................2
Installation.......................................................................................................................2
Operation..........................................................................................................................7
Specifications .................................................................................................................7
Warranty...........................................................................................................................7
1
FEATURES: LSW-6
■6-1/2” talc filled polypropylene woofer
with a treated urethane surround
■3/4” pivoting liquid cooled polycarbonate
dome tweeter
â– Moisture and UV resistant
â– Rust proof aluminum grilles
Installation friendly design:
â– Suitable for painting
â– Connection terminals accept up to 12
gauge speaker wire
â– Quick mounting system for new
construction or retrofit installations
â– Includes hole template
FEATURES: LSW-6.5
■6-1/2” injection-molded polypropylene
woofer with butyl rubber surround
■1” pivoting liquid cooled soft dome
tweeter
â– Baffle mounted Bass and Treble controls
(0, -3dB)
â– Moisture and UV resistant
â– Rust proof aluminum grilles
Installation friendly design:
â– Suitable for painting
â– Connection terminals accept up to 12
gauge speaker wire
â– Quick mounting system for new
construction or retrofit installations
â– Includes hole template
Figure 1
New Construction Wings
Bracket
Frame
Speaker Baffle
IR Knockout (accommodates
JOBSITE IR-FMR IR Receiver)
Grille
PRODUCT OVERVIEW
