Intellinet 300N PoE Bedienungsanleitung

Intellinet Zugangspunkt 300N PoE

Lesen Sie kostenlos die 📖 deutsche Bedienungsanleitung für Intellinet 300N PoE (83 Seiten) in der Kategorie Zugangspunkt. Dieser Bedienungsanleitung war für 6 Personen hilfreich und wurde von 2 Benutzern mit durchschnittlich 4.5 Sternen bewertet

Download PDF

Seite 1/83

WIRELESS-N

ACCESS POINT

USER

MANUAL

MODELS:

524704

524728

524735

Shown: Model 524728

INT- 524728/524735- -08 -524704/ UM 09 01

Federal Communications Commission

Interference Statement

FCC Part 15

This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to Part 15 of FCC Rules. These limits are designed

to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment oﬀ and on, the user is

encouraged to try to correct the interference by one or more of the following

measures:

1. Reorient or relocate the receiving antenna.

2. Increase the separation between the equipment and receiver.

3. Connect the equipment into an outlet on a circuit diﬀerent from that

to which the receiver is connected.

4. Consult the dealer or an experienced radio technician for help.

FCC Caution

This equipment must be installed and operated in accordance with provided

instructions, and a minimum of 20 cm of space (approx. 8 inches) must be

provided between any computer-mounted antenna and a person’s body

(excluding hands, wrists and feet) during wireless modes of operation.

This device complies with Part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) This device may not cause harmful interference;

and (2) This device must accept any interference received, including

interference that may cause undesired operation.

Any changes or modiﬁcations not expressly approved by the party responsible

for compliance could void the authority to operate the equipment.

Federal Communications Commission (FCC) Radiation Exposure

Statement

This equipment complies with FCC radiation exposure set forth for an

uncontrolled environment. In order to avoid the possibility of exceeding the

FCC radio frequency exposure limits, human proximity to the antenna shall not

be less than 20 cm (8 inches) during normal operation.

The antenna(s) used for this transmitter must not be co-located or operating in

conjunction with any other antenna or transmitter.

The equipment version marketed in the U.S. is restricted to usage of

channels 1-11 only.

Produktspezifikationen

Marke:	Intellinet
Kategorie:	Zugangspunkt
Modell:	300N PoE
Gewicht:	800 g
AC-Netzadapter:	Ja
AC Eingangsspannung:	5 V
AC Eingangsfrequenz:	50 Hz
Gleichstrom-Anschluss (DC):	Ja
Antennentyp:	Extern
Betriebstemperatur:	0 - 40 °C
Unterstützte Sicherheitsalgorithmen:	128-bit WEP, 256-bit WEP, WPA, WPA2
Unterstützte Netzwerkprotokolle:	TCP/IP
Zertifizierung:	FCC - B, CE, RoHS
Stromverbrauch (Standardbetrieb):	4 W
Power over Ethernet (PoE):	Ja
Anzahl Ethernet-LAN-Anschlüsse (RJ-45):	1
Kabellänge:	1 m
Maximale Datenübertragungsrate:	300 Mbit/s
Ethernet LAN Datentransferraten:	10, 100 Mbit/s
2,4 GHz:	Ja
Zahl der Benutzer:	16 Benutzer
Anzahl Kanäle:	2 Kanäle
Antenne Zunahmeniveau (max):	3 dBi
Anzahl der Antennen:	2
Eingebaut:	Nein
LED-Anzeigen:	LAN, Power, Status, WLAN, Y
Temperaturbereich bei Lagerung:	-20 - 60 °C
Luftfeuchtigkeit bei Lagerung:	10 - 90 %
Energiebedarf:	5 V DC, 1.0 A
Rack-Einbau:	Nein
Frequenzband:	2.4 - 2.483 GHz
Netzteiltyp:	AC/DC
Prozessor:	Ralink RT3052
Web-basiertes Management:	Ja
VLAN-Unterstützung:	Ja
Abmessungen (BxTxH):	160 x 127 x 35 mm
Speicherkapazität:	16 MB
Wireless-Technologien:	WLAN
Unterstützte Protokolle:	-IEEE 802.1d\n-IEEE 802.11b\n-IEEE 802.11g\n-IEEE 802.11n\n-IEEE 802.1x\n-IEEE 802.3\n-IEEE 802.3af\n-IEEE 802.3u
Verkabelungstechnologie:	10/100BASE-T(X)
MAC Adressen Filtern:	Ja
DHCP-Server:	Ja
Eingebauter Prozessor:	Ja
Antennenfunktionen:	Dipol-Antenne
Fernauthentifizierungs-Einwähl-Benutzerdienst (RADIUS):	Ja
Flash-Speicher:	4 MB
Datenrate:	10/11/54/100/300 Mbit/s
Konnektivität LEDs:	Ja
Power-LED:	Ja
Drahtloser Standard:	IEEE 802.11b, g, n
Medien-Zugang Protokoll:	100Base-TX
