English only (Australia, New Zealand, UK, Hong Kong, and Ireland)

www.insinkerator.com

Food waste disposers provide an environmentally responsible alternative to transporting food waste to landﬁlls. And they ca n help reduce

greenhouse gas emissions. At capable wastewater treatment plants, food waste can be converted to biosolids and used as fertilizer. Capable

plants can also capture methane gas and recycle it as an energy source. (Check the plant in your area.)

Read throu gh the entire Installation, Care & Use manual before installing the disposer. Determine which of the tools, materials, and

accessories you will need before you begin. Make sure you have all necessary disposer parts before installing the disposer.

NOTE: The Evolution models grind much ﬁner than any other disposer. For this reason you may notice that it takes a little longer to grind

some food waste. Due to the Evolu tion 200 model’s microprocessor, users will experience a fractional second delay when starting on all

Evolution 200 models. This is completely normal.

NOTE: must In Australia, all plumbing and electrical work be completed by a qualiﬁed tradesperson. This product may require approval of the

relevant regulator and/or the sewerage system operator. Disposer must be installed to AS/NZS 3500.2 standard requirements.

NOTE: Make sure that the installation of this appliance is allowed by the authorities.

TOOLS & MATERIALS YOU WILL NEED:

Slotted Screwdriver, Adjustable Pliers, Safety Glasses

TOOLS, MATERIALS, AND ACCESSORIES YOU MAY NEED:

Phillips Screwdriver, Drain Auger, 9.5 mm Electrical Clamp, Wire Nuts (2), 38 mm Drain Trap, 33 mm Hole Drill, Hammer, Hacksaw, Water Hose

Clamp, Pipe Wrench, Copper Earth Wire, Dishwasher Drain Connection Kit, Electrical On/Off Switch, Drain Tube Extension

MOUNTING ASSEMBLY

1a. Stra iner Basket and Plug

(Evolution models)

1b. Stopper (Models 65, 55, 45, LC-50)

2. Sink Flange

3. Rubber Gaskets (2)

4. Fiber Gasket (optiona l)

5. Backup Ring

6. Mounting Ring

7. Screws (3)

8. Snap Ring

DISPOSER

9. Sound Bafﬂe (Evolution models,

Model 65)

10. Mounting Gasket/Splash Bafﬂe

11. Lugs

12. Lower Mounting Ring

13. Dishwasher Inlet

14. Discharge Outlet

15. Wrenchette

DISCHARGE ASSEMBLY #4

(Australia Model LC-50 connected to

Caroma Connector not supplied)

26. Bolt (1) 19 mm 1/4-20 UNC

27. Metal Flange (Use to connect

to proper Caroma Connector)

28. Metal Washers (2)

29. Nuts (2)

30. Rubber Gasket

DISCHARGE ASSEMBLY #5

(Australia Models 65, 55, 45; connected to

Caroma Connector not supplied)

26. Bolts (2) 19 mm 1/4-20 UNC

28. Metal Washers (2)

30. Rubber Gasket

DISCHARGE ASSEMBLY #1

(Evolution models)

16. Hose Clamp

17. Black Elbow Discharge Tube

(38 mm diameter/Evolution ﬂange)

18. Straight Discharge Tube 40.3 mm OD

(Australia installation only)

DISCHARGE ASSEMBLY #2

(Models 65, 55, 45)

19. Bolts (2) 13 mm 1/4-20 UNC

20. Rubber Gasket

21. Metal Flange

22. White Elbow Discharge Tube

(38 mm diameter/non-Evolution ﬂange)

DISCHARGE ASSEMBLY #3

(LC-50 for household installation)

23. Bolt (1) 19 mm 1/4-20 UNC

24. Rubber Gasket

25. Metal Flange

22. White Elbow Discharge Tube

(38 mm diameter/non-Evolution ﬂange)

230-240V, 50Hz

for Australia and New Zealand

220-240V, 50Hz

for UK/Hong Kong/Ireland

Part No. 75978 REV. A

FOOD WASTE DISPOSER INSTALLATION, CARE & USE MANUAL

PARTS LIST (May vary depending on model)

Danger indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.

Warning indicates a potentially hazardous situ ation which, if not avoided, could result in death or serious injury.

Cau tion indicated a potentially hazardous situation, which, if not avoided, may result in minor or moderate injury.

31.8 cm 16.8 cm 6.4 cm 18.5 cm 13.1 cm

31.8 cm 16.8 cm 6.4 cm 17.3 cm 13.1 cm

31.8 cm 16.8 cm 6.4 cm 15.9 cm 13.1 cm

36.9 cm 19.3 cm 6.4 cm 20.6 cm 14.9 cm

34.4 cm 18.5 cm 6.4 cm 23.4 cm 16.8 cm

31.2 cm 17.1 cm 6.4 cm 20.5 cm 16.8 cm

(Evolution) 200-1, -3

(Evolution) 100-1, -3

Model 65-1B, -3B

Model 55-1B,

-1B A/S, -3B, -3B A/S

Model 45-1B,

-1B A/S, -3B

LC50-12, -13

CHECK INSTALLATION DIMENSIONS

1. Disposer Height

2. Distance from bottom of sink bowl to centerline of discharge outlet.

(Add 12 mm when stainless steel sink is used.)

3. Distance from centerline of the discharge outlet to end of

discharge tube.

4. Disposer Width

5. Distance from disposer vertical centerline to centerline of

trap connection.

To properly drain and prevent standing water in the disposer, the waste

pipe entering the wall must be lower than the disposer discharge outlet.

DISCONNECT SINK DRAIN

1. Loosen nut (1) at top of trap (4) with pipe wrench (see Figure 4.1).

2. Loosen nut (2) at top of extension pipe. Remove extension pipe.

3. Loosen nut (3) at base of sink ﬂange.

4. Push sink ﬂange up through sink hole and remove it (see Figure 4. 2).

5. Clean sink ﬂange area of any putty or other debris.

The sink hole may have to be enlarged to accept the disposer NOTE:

sink ﬂange. Sink hole enla rgement tools are available from your

InSinkErator Dealer.

2.1

4.33.3

2.31.3

2.41.4

5.1

1. Turn mounting assembly over (see Figu re 2.1) and loosen three

mounting screws (1) until you can access snap ring (2).

2. Use screwdriver to pry snap ring off of sink ﬂange. Mounting

assembly will now come apart.

3. Set mounting assembly aside. This will be used in Instruction 5.

IF REPLACING AN EXISTING DISPOSER,

CONTINUE WITH INSTRUCTION 3.

IF THIS IS A FIRST TIME INSTALLATION,

SKIP AHEAD TO INSTRUCTION 4.

DISASSEMBLE NEW DISPOSER

MOUNTING ASSEMBLY Reference Figure 5.1.

1. Place one of two rubber gaskets (2) under sink ﬂange (1). Ensure sink

hole area is clear of debris and place sink ﬂange/gasket into sink hole.

You may wish to place a weighted object in the sink to hold the sink

ﬂange in place. (Place a towel under object to prevent scratching.)

2. Working from under the sink, slip second rubber gasket (2), ﬁber

gasket (optional) (3) a nd metal backup ring (4) (ﬂat side up) over the

sink ﬂange.

3. Holding second rubber gasket, ﬁber gasket (optiona l) and metal

backup ring in place, slip mounting ring (5) over sink ﬂange so it seats

against backup ring.

4. With the rubber gasket, ﬁber gasket (optional), backup ring, and

mounting ring tight against sink bottom, slide snap ring (7) onto sink

ﬂange until it pops into groove on ﬂange.

5. Tighten three mounting screws (6) up to sink until mounting assembly

is seated tightly and evenly against sink.

ATTACH UPPER MOUNTING ASSEMBLY TO SINK

REMOVE EXISTING DISPOSER

PERSONAL INJURY

To avoid personal injury, do not position your head or body under

disposer; the unit could fall during installation.

ELECTRICAL SHOCK

• To avoid electrical shock, disconnect power before installing or

servicing disposer. Turn off electrical power at fuse box or circuit

breaker or if equipped unplug disposer electrical power plu g from

wall outlet.

• Improper connection of equ ipment earth (grounded) conductor

can result in electric shock.

1. If your disposer is equipped with an electric plug and cord

connection, unplug power plug from electrical wall outlet.

If your disposer is not equipped with an electrical plug and

cord connection, contact an electrician to disconnect the old

disposer plus install an earth (grounded) electrical wall outlet for

the new disposer connection that must be compliant to all local

electrical codes.

2. Disconnect drain trap from disposer waste discharge tube with

adjustable pliers (see Figure 3.1). Also disconnect dishwasher drain

connection, if applica ble.

3. Support disposer with one hand and insert end of wrenchette or

screwdriver into right side of one mounting lug on lower mounting

ring (see Figure 3.2). Lift disposer slightly and remove from mounting

by pushing or pulling wrenchette or screwdriver to left (disposer may

be heavy; provide support).

4. Loosen three mounting screws, pry snap ring off with screwdriver,

and remove old mounting assembly (see Figure 3.3). Some mounting

assembly removal requires additional tools.

5. Push old sink ﬂa nge up through sink hole (see Figure 3.4). Skip ahead

to Instruction 5.

7.1

7.37.2

Failure to clean sink waste pipe line may result in waste pipe blockage.

1. Remove trap. (See Figure 6.1)

2. With drain auger, clear away all hardened waste material in horizontal drain line running from drain trap to main pipe.

IF YOU ARE NOT CONNECTING A DISHWASHER TO DISPOSER, SKIP AHEAD TO INSTRUCTION 8.

DOES NOT APPLY TO AUSTRALIA/NEW ZEALAND In Australia, it is

suggested that the dishwasher units be connected to IPLEX/ COROMA

dishwasher spigot for maximum efﬁciency.

Wastewater from a dishwasher can be plumbed into the disposer

through the inlet access on the upper part of the disposer. There is a

plug on the inside of the inlet tube on all models. Once removed, the

knockout plug cannot be replaced.

NOTE: If the dishwasher connection is made without removing the plug,

the dishwasher may overﬂow. (Connections must comply with local

plumbing codes.)

REMOVE KNOCKOUT PLUG

1. Lay disposer on its side and insert screwdriver into dishwasher inlet so

tip rests on outer edge of knockout plug.

2. Tap end of screwdriver handle with hammer until molded plug brea ks

loose (see Figure 7.1).

3. Remove loose knockout plug from inside disposer.

DISHWASHER ATTACHMENT AND OVERFLOW CONNECTION

CLEAN SINK WASTE PIPE

THE SINK OVERFLOW

The sink overﬂow may be connected to the overﬂow tube on the

tailpipe (see Figure 7.2). Remove the overﬂow connector cap and

blue plastic seal from the end of the overﬂow tu be (see Figure 7.3).

Utilizing the nut, connect the overﬂow hose to the tailpipe.

NOTE: The straight discharge tu be for use in Australia does not

have an overﬂow connection tube. In the UK, waste trap kit, which

does not include the sink overﬂow kit, is available from your local

InSinkErator dealer.

6.1

(installation continued on reverse)

InSinkErator Division

Suite 6, Building 6

Hatters Lane,

Croxley Green Business Park

Watford HERTS WD18 8YH

United Kingdom

Sales Tel: (0) 1 923 297 880

Service Tel: (0) 800 389 3715

www.insinkerator.co.uk

Parex Industries Ltd.

5 Tolich Place, Henderson

P.O. Box 21-102

Auckland, New Zealand 0610

Sales Tel: 64 9 836 6566

Service Tel: 0800 200 510

www.parex.co.nz

InSinkErator Division

471 Mountain Highway

Bayswater Vic 3153, Australia

Sales Tel: 61 03 9720 5599

Service Tel: 1 300 136 205

www.insinkerator.com.au

InSinkErator Division

Emerson Electric Co.

4700 21st Street

Racine, WI 53406-5093

USA

Sales/Service Tel:

262-554-3652

www.insinkerator.com/

worldmap.html

KAL Group

4078 Kingswood Road,

Citywest Business Park

Dublin, Ireland

Tel: 01 413 6481,

01 413 6400

Fax: 01 413 6464

Email: info@kal.ie

PERSONAL INJURY

Wearing safety glasses is recommended during the installation of

the food waste disposer.

Evolution 100: Australia Pat. No. 307603, 307769, 308385, and other foreign patents pending

Evolution 200: Australia Pat. No. 307601, 307769, 308695, 308385, and other foreign patents pending

Air Switch (Evolution 200, Evolution 100, Model 65,

Model 55-1B A/S, 55-3B A/S and 45-1B A/S):

The Evolu tion 200, Evolution 100, and Model 65 disposers include a

built-in air switch (Satin Nickel and Chrome ﬁnishes). An air switch

activates/turns off the unit by sending a pulse of air to the control box.

AIR SWITCH INSTALLATION

The air switch includes two different button ﬁnishes. If you wish to

change the button ﬁnish (optional), simply pry off the existing button

and snap the other button ﬁnish onto the bellows. (See Figure 11.2)

1. Drill a 33 mm wide hole into the kitchen work top, or the corner of

the sink u nit, at the most convenient point for use. Some sink units

may already have a suitable hole in them which can be exposed by

removing the cap.

2. Remove the nut from the push button bellows, while keeping the

stainless steel washer and rubber ga sket in place. Push one end of

the PVC tubing onto the spout of the push button bellows, feed the

other end of the tube through the hole in the work top and through

the nut underneath the work top. (See Figure 11.3)

3. Fit the push button bellows in the hole and then screw up the nut

underneath the work top until it is hand tight. Do not use a wrench

to tig hten the nut. (See Figure 11.4)

4. Ta ke the other end of the air tube and ﬁrmly push it over the spout

of the air switch, which is located on the underside of the waste

disposer. (See Figu re 11.5)

DISABLING THE AIR SWITCH

The air switch can be disabled if wall switch operation is preferred.

The disposer is shipped with the switch in the “off ” position.

1. Push one end of the PVC tu bing provided onto the spout of the push

button bellows. (See Figure 11.3)

2. Ta ke the other end of the air tube and push it over the spout of the

air switch, which is located on the u nderside of the waste disposer.

(See Figure 11.5)

3. Depress the air switch one time until you hear the switch “click.”

Remove and discard the push button bellows and PVC tubing. The

disposer may now be activated by a wall switch.

The disposer installation is complete. Read all operating and

safety instructions in Instruction 12 before operating the disposer.

Lastly, place stopper in sink in close position. Fill sink with water,

remove stopper, turn disposer on and check for leaks.

CONNECT DISPOSER TO ELECTRICAL SUPPLY

ELECTRICAL SHOCK

• To avoid electrical shock, disconnect power before installing or

servicing disposer.

• If you are not thoroughly familiar with electric power, contact a

qualiﬁed electrician to connect disposer to electrical circuit.

• If three-prong, earth (grounded) plug is used, plu g must be

inserted into three-hole, earth (grounded) receptacle.

• Do not modify plug provided with unit (if applicable).

• Improper connection of equipment earth (grou nded) conductor

can result in electric shock.

• All wiring must comply with local electrical codes.

• Do not attach earth wire (ground wire) to ga s supply pipe.

• Do not reconnect electrical current at main service panel until

proper earth (grounded) ou tlets are installed.

• If the supply cord is damaged, it must be replaced by the

manufacturer, its service a gent or similarly qualiﬁed-persons

in order to avoid a hazard.

8.3

8.2

8.1

8.4

MOD EL X X – XX

S/N X XXXX XXXX X

PUS H RED BUTTO N

TO RE SE T

Clear any objects from inside the disposer grind chamber before

mounting the disposer to the sink.

1. This product must be installed so that the motor reset button

located on the bottom of the disposer is readily accessible.

Keep this space clear of all objects.

2. Prior to connecting disposer to mou nting assembly, detach the

perforated portion of the speciﬁcation la bel found at the base

of the disposer, and set aside for Instruction 9 (See Figure 8.1).

3. Position disposer with three mounting tabs (1) aligned in

position to slide over mounting tracks (2). (See Figure 8. 2)

4. Lift disposer, insert top end (mounting gasket) into mounting

assembly, and turn lower mounting ring to right (with

wrenchette or adjustable pliers) until mounting tabs lock over

ridges (3) on mounting ring tracks (see Figure 8.3). Make sure

all three mounting tabs are locked over ridges. Disposer will

now hang by itself.

EVOLUTION 200 AND EVOLUTION 100, MODEL 65

Insert sound bafﬂe into sink opening, with ﬂat side upward. (See

Figure 8.4)

CONNECT DISPOSER TO MOUNTING ASSEMBLY

PERSONAL INJURY

To avoid personal injury, do not position your head or body

under disposer; the unit could fall during installation.

MODEL XX – XX

S/N XXXXXXXXXX

PUSH RED BUTTON

TO RESET

10.3 10.4

10.5 10.6

10.210.1

(FLANGED DISCHARGE

PIPE NOT PROVIDED)

(FLANGED DISCHARGE

PIPE NOT PROVIDED)

AUSTRALIA ONLY

DISCHARGE TUBE INSTALLATION (EVOLUTION 200 AND

EVOLUTION 100 )

1. Place discha rge tube (2) into Anti-Vibration Tailpipe Mount

™. Secure

with spring type hose clamp (1). (See Figu re 10.1)

UK, NEW ZEALAND, HONG KONG AND IRELAND DISCHARGE

TUB E INSTALLATION (MODELS 65, 55, 45)

1. Place metal ﬂange (6) over discharge tube (8). Insert rubber

gasket (5) with gasket lip facing the metal ﬂa nge into discharge

tube. (See Figu re 10.3)

2. Secure metal ﬂange and discharge tube to disposer with two

13 mm bolts (7).

ATTACH DISCHARGE TUBE TO WASTE DRAIN PIPE

This speciﬁcation label contains important information you will

need to know in the event service is required.

1. Apply the label to the front side of the disposer, where it can

be easily read.

ATTACH SPECIFICATION LABEL

OPERATING INSTRUCTIONS (EVOLUTION 200 AND EVOLUTION 100)

1. Remove strainer basket and plug from sink opening and run cold water.

2. Tu rn on wall switch or press air switch (see Figu re 12.1) to

start disposer.

3. Slowly insert food waste into disposer and position strainer basket

and plug in upright position (allowing water to run through) to

minimize noise and possible ejection of material while grinding

(See Figure 12.2).

4. After grinding is complete, tu rn disposer off and ru n water for a t

least 15 seconds to ﬂu sh drain line.

5. Strainer basket and plug also acts as a stopper in the lower position.

(See Figure 12.3)

OPERATING INSTRUCTIONS (MODELS 65, 55, 45, LC-50)

1. Remove stopper from sink opening and run cold water.

2. Tu rn on wall switch or press air switch (see Figu re 12.1) to

start disposer.

3. Slowly insert food waste into disposer and position stopper to

minimize noise and possible ejection of material while grinding.

(See Figure 12.4)

4. After grinding is complete, tu rn disposer off and ru n water for a t

least 15 seconds to ﬂu sh drain line.

DO...

• Grind food waste with minimum cold water ﬂow of 5.7 liters per

minute (1-1/2 G.P.M.).

• Grind hard material such as small bones and fru it pits to clean

inside of grind chamber.

• Grind citrus, melon rinds, vegetables, and coffee grounds.

• After grinding, ru n water for at least 15 seconds to ﬂush drain line.

• Switch off or unplug the appliance before attempting to free a

jammed rotor with an implement.

• Maintain the area undernea th the disposer of any objects to be sure

you have access to the disposer reset button.

DON’T...

• Don’t use hot water when grinding food waste (althou gh hot water

ca n be drained into disposer between grinding periods).

• Don’t turn off water or disposer u ntil grinding is completed and only

sound of motor a nd water running is heard.

• Don’t grind large amounts of egg shells or ﬁbrous materials like corn

hu sks, artichokes, etc., to avoid possible pipe blockage.

• Don’t grind non-food waste of any kind.

• Don’t use this appliance to dispose of hard materials such as glass

and metal.

• Don’t ever pour fats, oils or grease down the sink – it will block your

drains and the sewerage system.

INSTRUCTIONS PERTAINING TO RISK OF FIRE, ELECTRICAL SHOCK, OR INJURY TO PERSONS (SAVE THESE INSTRUCTIONS)

InSinkEra tor products are guaranteed against defects in material and

workmanship for the period of the guarantee from the date of purchase.

Evolution 200: 6 years Evolution 100: 5 years

Model 65: 4 years Model 55: 3 years

Model 45: 2 years LC-50: 1 year

SERVICE

If service is required, contact an InSinkEra tor Authorized Service

Center (see enclosed list) or your dealer. Guarantees are void if you

remove your disposer after installation and attempt to repair it, or if

the disposer is used for commercial purposes.

IN-HOME FULL SERVICE GUARANTEE

12.4 12.612.5

12.312.2

12.1

MO DEL XX – XX

S/N XXXXXXXXXX

PU SH RED BU TTONTO RESET

MODE L XX – X X

S/ N XX XXX XX XX X

PU SH RED B U T T ON

T O RE SET

Whe n using electronic appliances, basic precautions are always

to be followed, including:

• In Australia, product may require approval of the relevant regulator

and/or the sewerage system operator.

• If the air switch or wall switch fails to shut off or turn on disposer,

unplug power cord plug and contact your qualiﬁed trade person.

• This product is designed to dispose of normal hou sehold food

waste; inserting materia ls other than food waste into disposer

could cause personal injury and/or property damage. To reduce

the risk of injury, do not u se the sink containing the disposer for

purposes other than food preparation (such as baby bathing or

washing hair).

• This appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental ca pabilities,

or lack of experience and knowledge, unless they have been given

supervision or instruction concerning use of applia nce by a person

responsible for their safety. Children should be supervised to

ensure that they do not play with disposer. To reduce the risk of

injury, close supervision is required when an appliance is used

near children.

• When attempting to loosen a jam in the food waste disposer,

switch off or u nplug the appliance before attempting to free a

jammed rotor. Use a self service wrenchette as described in

the Releasing Disposer Jam section.

• Use long-handled tongs or pliers to remove objects from disposer.

• To reduce the risk of injury by materials that are expellable by a waste

disposer, do not operate Evolution disposers without the sound

bafﬂe in place (See Figure 8.4). Place stopper in sink opening as shown

in Figure 12.2 or 12.4. Do not put the following into a disposer: clam

or oyster shells, caustic drain cleaners or similar products, glass,

china , or plastic, large (whole) bones, metal (such as bottle caps,

steel shot, tin cans, or utensils), hot grease or other hot liquids.

• Replace sound bafﬂe/mounting gasket/splash bafﬂe when worn to

help prevent entry or ejection of materia l and water.

• When not u sing disposer, leave stopper in place to reduce risk of

objects falling into disposer. Make sure disposer power switch is

turned off.

• Before pressing reset button, attempting to clear jam, or removing

objects from inside disposer, make sure disposer power switch is

turned off.

• Do not insert hands or ﬁngers into disposer.

• FIRE HAZARD: Do not store ﬂammable items such as rags, paper,

or aerosol cans near disposer. Do not store or use gasoline or other

ﬂammable vapors and liquids in vicinity of disposer.

• Do not dispose of the following in the disposer: paints, solvents,

household cleaners and chemicals, automotive ﬂuids, plastic wrap.

• Don’t ﬁll disposer with a lot of vegetable peels all at once. Instead, turn

the water and disposer on ﬁrst and then feed the peels in gradually.

• Don’t waste food. Nearly a quarter of the food we buy is thrown

away untou ched: salad, bread and ca kes and fruit head the list.

Three tips to stop waste and save you money: only buy, or cook,

the portions you need for the meal; check the fridge and cu pboard

for food you haven’t eaten–make it your next snack or freeze it;

and make sure you lea ve that food off your next shopping list!

CLEANING DISPOSER

Over time, grease/food particles may accu mulate in the grind

chamber and bafﬂe, causing a n unpleasant odor. To clean

the disposer:

1. Turn of f disposer and disconnect power supply.

2. Reach throu gh sink opening and clea n underside of splash

bafﬂe and inside upper lip of grind chamber with scouring pad.

3. Place stopper in sink opening and ﬁll sink halfway with

warm water.

4. Mix 60 ml baking soda with water. Turn disposer on and

remove stopper from sink at same time to wash away

loose particles.

RELEASING DISPOSER JAM

If the motor stops while the disposer is operating, the disposer

may be jammed. To release jam:

1. Tu rn disposer power and water off.

2. Insert one end of the self-service wrenchette into the center

hole on the bottom of the disposer (see Figure 12.5). Work the

wrenchette back and forth until it turns one full revolution.

Remove wrenchette.

3. Reach into the disposer with tongs and remove object(s). Allow

the disposer motor to cool for 3 - 5 minutes and lightly push

red reset bu tton on the disposer bottom (see Figure 12.6). (If

the motor remains inoperative, check the service panel for

tripped circuit breakers or blown fuses.)

UK, NEW ZEALAND, HONG KONG AND IRELAND DISCHARGE

TUBE INSTALLATION (LC-50)

1. Place metal ﬂange (11) over discharge tube (12). (See Figure 10.4)

2. Insert rubber gasket (9) with the gasket lip facing the metal ﬂange

into discharge tube (gasket may be pre-ﬁtted in discharge tube).

Secure metal ﬂa nge and discharge tube to disposer with one

19 mm bolt (10) (Gasket will hold in pla ce).

AUSTRALIA DISCHARGE T UBE INSTALLATION (MODELS 65, 55,

45) (Optional straight pipe connection; connection to Caroma

Connection not supplied. Attach discharge tube to waste pipe.)

1. Insert rubber gasket (13) into discharge outlet. (See Figu re 10.5)

2. Attach ﬂanged discharge pipe (not provided) using washers (14) and

19 mm 1/4 -20 bolts (15).

AUSTRALIA DISCHARGE TUBE INSTALLATION (LC-50) (Optional

straight pipe connection; connection to Caroma Connection not

supplied. Attach discharge tube to waste pipe.)

1. Place rubber gasket (16) between disposer a nd ﬂange (17). (See

Figure 10.6)

2. Tighten ﬂ ange with one 19 mm bolt (18). Attach ﬂanged discharge

pipe (not provided) using washers (19) and nuts (20).

ALL DISPOSERS CONTINUE WITH STEPS 3-5

3. Rotate disposer so that discharge tube is aligned with drain trap.

(To prevent leaks, do not pull or bend discharge tu be to drain trap.)

If discharge tube is too short, you can purchase an extension from

ha rdware store. (Disposer must remain in vertical position to

prevent vibration.)

4. Place nut, then ferrule on discharge tube (not supplied) and tighten

on drain tra p. (If you have a dou ble sink, use separate drain traps for

both sides of sink.)

5. Ensure lower mounting ring is still securely locked over ridges on

mounting ﬂange. (See Figure 8.2)

NOT E: You must have access to a n earth (grounded) wall socket.

Any additional socket should be ﬁtted by a qu aliﬁed electrician and

properly earthed (grounded). T he disposer is ﬁtted with a molded plug

and cable.

ON/OFF CONTRO L

There are two types of controls for continu ous-feed disposers:

a double-pole switch and an air switch (built in for Evolution 200,

Evolution 100, and Model 65; available as an accessory on all

other models).

Double Pole Switch (1):

If a wall switch (not supplied) is required for your installation, it must

have on/off markings and be installed by a qualiﬁed tradeperson. It

should be located in a convenient position above the work surface

with a minimum of 3 mm contact separation between each pole (20

ADP switches to BS 3676). In New Zea land, please refer to AS/NZS

3000:2007 for electrical installation. Connect to a 13 amp earth

(grounded) wall socket (2) using a 13 amp cable. (See Figure 11.1)

11.1 11.3

11.4

33 mm

11.5

11.2

PROPERTY DAMAGE

• Wearing safety glasses is recommended during the installation

of the food waste disposer.

• All Evolution 200 and Evolution 100 models must be connected

to the supplied tailpipe with the supplied spring type hose clamp.

(See Figu re 10.1) In Australia it is required to use the supplied

straight discharge tube with supplied spring type hose clamp.

(See Figu re 10.2) Failure to use the supplied tubes and spring

type hose clamp will void the guarantee and possibly cause

premature failure of the Anti-Vibration Tailpipe Mount

™

• Do not use plumber’s putty on any other disposer connection

other than on sink ﬂange. Do not use thread sealants or pipe

dope. These may harm disposer and cause property da mage.

• Regularly inspect disposer and plumbing ﬁttings for water leaks,

as water leaks can cause property da mage. Manufactu rer cannot

be held responsible for property damage as a result of water leaks.

Produktspezifikationen

Marke:	InSinkErator
Kategorie:	Nicht kategorisiert
Modell:	Evolution 100

Brauchst du Hilfe?

Wenn Sie Hilfe mit InSinkErator Evolution 100 benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten

Ihren Namen*

Deine E-Mail*

Schreiben Sie hier Ihre Frage

Bedienungsanleitung Nicht kategorisiert InSinkErator

InSinkErator Evolution 250 Bedienungsanleitung

25 August 2024

InSinkErator Evolution 100 Bedienungsanleitung

17 August 2024

Bedienungsanleitung Nicht kategorisiert

Neueste Bedienungsanleitung für -Kategorien-

DAS Audio AX-112-5 Bedienungsanleitung

16 Oktober 2024

Ferplast Ergocomfort Freetime Bedienungsanleitung

16 Oktober 2024

AEG MECK52 Bedienungsanleitung

16 Oktober 2024

Makita UR012G Bedienungsanleitung

16 Oktober 2024

Stihl HT 70 Bedienungsanleitung

16 Oktober 2024

Ernesto H14270 Bedienungsanleitung

16 Oktober 2024

IFM AC901S Bedienungsanleitung

16 Oktober 2024

Nedis RFPOM120FBK Bedienungsanleitung

16 Oktober 2024

AEG E9KLCS01 Bedienungsanleitung

16 Oktober 2024

ART ProChannel II Bedienungsanleitung

16 Oktober 2024
