ENQuick Guide
1
PROGRAMS TABLE
Program Programs description
Drying
phase
Auto Door
Available
options *)
Duration
of wash
program
(h:min)**)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
1.
Eco 50Ā° - Eco program is suitable to clean normally soiled tableware. that
for this use. it is the most eī˜Ÿcient program in terms of its combined ener-
gy and water consumption. and that it is used to assess compliance with
the EU Ecodesign legislation. 3:10 9.5 0.85
2. Intensive 65Ā° - Program recommended for heavily soiled crockery. espe-
cially suitable for pans and saucepans (not to be used for delicate items). 2:50 17.0 1.60
3.
Mixed 55Ā° - Mixed soil. For normally soiled dishes with dried food residues.
3:00 15.0 1.40
4. Fast&Clean 28ā€™ 45Ā° - Program to be used for half load of lightly-soiled
dishes with no dried food residues. Does not have drying phase. - 0:28 9.0 0.50
5. Pre-Wash - Use to refresh crockery planned to be washed later. No deter-
gent to be used with this program. - - 0:12 4.5 0.01
6. Push&Go - 50Ā° Everyday wash and dry cycle that ensures great cleaning
performance in a short time without the need to pre-treat dishes. 1:25 11.5 1.10
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020. Note for Test Laboratories: For information on
comparative EN testing conditions, please send an email to the following address: dw_test_support@whirlpool.com
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programs other than the program Eco are indicative only. The actual time may vary depending on many factors such as temperature and
pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and sensor cali-
bration. The sensor calibration can increase program duration up to 20 min.
CONTROL PANEL
1. On-Oī˜ž/Reset button with indicator
light
2. Program selection button with
indicator light
3. Half Load button with indicator light
4. Rinse Aid reī˜ll indicator light
5. Salt reī˜ll indicator light
6. Program indicator lights
7. Delay indicator light
8. Delay button with indicator
light
9. Push&GO button with indi-
cator light
10. Start/Pause button with
indicator light / Drain out
FIRST TIME USE
FILLING THE SALT RESERVOIR
The use of salt prevents the formation of LIMESCALE on the dishes and on
the machineā€™s functional components.
ā€¢ It is mandatory that the salt reservoir never be empty.
ā€¢ It is important to set the water hardness.
The salt reservoir is located in the lower part of the dishwasher and must be
ī˜lled when the SALT REFILL indicator light in the control panel is lit.
1. Remove the lower rack and unscrew the reservoir cap
(anticlockwise).
2. Position the funnel and ī˜ll the salt reservoir (see ī˜Ÿgure)
right up to its edge (approximately 1 kg); it is not unu-
sual for a little water to leak out.
3. Only the ī˜Ÿrst time you do this: ī˜Ÿll the salt reservoir
with water.
4. Remove the funnel and wipe any salt residue away from the opening.
Make sure the cap is screwed on tightly, so that no detergent can get into the
container during the wash program (this could damage the water softener be-
yond repair). Whenever you need to add salt, it is mandatory to complete the
procedure before the beginning of the washing cycle to avoid corrosion.
FILLING THE RINSE AID DISPENSER
Rinse aid makes dish DRYING easier. The rinse
aid dispenser should be ī˜lled when the A RINSE
AID REFILL indicator light in the control pan-
el is lit. NEVER pour the rinse aid directly into the
appliance tub.
A
C
D
FILLING THE DETERGENT DISPENSER
To open the detergent dispenser use the opening device . Introduce the C
detergent into the dry dispenser only. Place the amount of detergent for D
pre-washing directly inside the tub.
Usage of detergent not designed for dishwashers may cause malfunc-
tion or damage to the appliance.
WATER SOFTENING SYSTEM
Water softener automatically reduces water hardness, consequently pre-
venting scale buildup on heater, contributing also to better cleaning eī˜Ÿ-
ciency. This system regenerates itself with salt, therefore it is required
to reī˜Ÿll salt container when empty.
Frequency of regeneration depends on water hardness level setting - regen-
eration takes place once per 6 Eco cycles with water hardness level set to 3.
Regeneration process starts in ī˜nal rinse and ī˜nishes in drying phase, be-
fore cycle ends.
ā€¢ Single regeneration consumes: ~3.5L of water;
ā€¢ Takes up to 5 additional minutes for the cycle;
ā€¢ Consumes below 0.005kWh of energy.
1 2 43 5 6 7
8
9
10
THANK YOU FOR BUYING AN INDESIT PRODUCT.
In order to receive a more complete assistance, please register
your appliance on: www.indesit.com/register
Before using the appliance carefully read Safety Instructions
guide.
PLEASE SCAN THE QR CODE ON YOUR
APPLIANCE IN ORDER TO HAVE MORE
DETAILED INFORMATION
Quick GuideEN
2
Policies, standard documentation, ordering of spare parts and additional product information can be found by:
ā€¢ Using QR code on your product.
ā€¢ Visiting our website and docs.indesit.eu parts-selfservice.whirlpool.com
ā€¢ Alternatively, (See phone number in the warranty booklet). When contacting our After-contact our After-sales Service
sales Service, please state the codes provided on your productā€˜s identiī˜cation plate.
The model information can be retrieved using the QR-Code reported in the energy label. The label also includes the model
identiī˜er that can be used to consult the portal of the registry at https://eprel.ec.europa.eu.
IEC 436
:
TROUBLESHOOTING Please scan on your product in order to have more detailed information. the QR code
PROBLEMS POSSIBLE CAUSES SOLUTIONS
The dishwasher
does not ī˜ll the
water.
All LEDs are blink-
ing rapidly
No water in the water supply or the tap is
closed. Make sure there is water in the water supply or the tap running.
The inlet hose is bent. Make sure the inlet hose is not bent (see INSTALLATION) reprogram the dishwasher
and reboot.
The sieve in the water inlet hose is clogged; it
is necessary to clean it.
After having carried out the veriī˜cation and cleaning, turn oī˜ž and turn on the
dishwasher and restart a new program.
Dishwasher
ī˜nishes the cycle
prematurely.
Drain hose positioned too low or siphoning
into home sewage system.
Check if end of drain hose is placed at correct height (see INSTALLATION).Check for
siphoning into home sewage system, install air admittance valve if necessary.
Air in water supply. Check water supply for leaks or other issues letting air inside.
LOADING THE RACKS CAPACITY: 14 standard place-settings
UPPER RACK
(loading example for the upper rack)
Load delicate and light dishes: glass-
es, cups, saucers, low salad bowls.
FOLDABLE
FLAPS WITH
ADJUSTABLE
POSITION
LOWER RACK
(loading example for the upper rack)
For pots, lids, plates, salad bowls, cutlery etc. Large
plates and lids should ideally be placed at the
sides to avoid interferences with the spray arm.
CUTLERY BASKET
It is ī˜tted with top grids
for improved cutlery ar-
rangement. It must only
be positioned at the
front of the lower rack.
Knives and other
utensils with sharp
edges must be placed
in the cutlery basket
with the points facing downwards or they
must be positioned horizontally in the tip-
up compartments on the upper rack.
More information in the Daily Reference Guide on website.
CLEANING AND MAINTENANCE
CLEANING THE FILTER ASSEMBLY CLEANING THE SPRAY ARMS
A
A
B
C
In case you ī˜nd foreign objects (such as broken glass, porcelain, bones, fruit seeds etc.)
please remove them carefully.
NEVER REMOVE the wash-cycle pump protection (black detail) (Fig 4).
To remove the upper spray arm,
turn the plastic locking ring in a
clockwise direction.
The lower spray arm may be
removed by pulling it up-
wards.
DELAY - It is possible to delay the start time of the program by 2, 4 or
8 hours:
The DELAY function cannot be set once a wash cycle has been started.
PUSH&GO button is an easily distinguishable button that allows you
direct access to the Push&GO program, a wash and dry cycle that en-
sures great cleaning performance in a short time. You donā€™t have to worry
which program to choose, Push&GO cycle will do the work for you.
To select Push&GO program, switch on appliance, press only Push&GO
button for 3 seconds.
OPTIONS AND FUNCTIONS
OPTIONS can be selected directly by pressing the corresponding button (see CONTROL PANEL). If an option is not compatible with the selected program
(see PROGRAMS TABLE), the corresponding LED ī˜œashes rapidly 3 times and beeps will sound. The option will not be enabled.
HALF LOAD - If there are not many dishes to be washed, a half load-
ing may be used in order to save water, electricity and detergent.
Remember to halve the amount of detergent.
Please scan the on your product in order to have more detailed information. QR code
AUTO DOOR is a convection drying system which automatically
opens the door during/after drying phase to ensure exceptional dry-
ing performance every day. Door opens at the temperature that is
safe to your kitchen furniture.
CSStručnĆ½ NĆ”vod
3
NAPLNĚNƍ ZƁSOBNƍKU SOLI
PoužitĆ­ soli vede k předchĆ”zenĆ­ usazovĆ”nĆ­ VODNƍHO KAMENE na nĆ”dobĆ­
a funkčnĆ­ch souÄĆ”stech myčky.
ā€¢ ZƁSOBNƍK NA SÅ®L NESMƍ NIKDY ZÅ®STAT PRƁZDNƝ.
ā€¢ NastavenĆ­ tvrdosti vody je dÅÆležitĆ©.
ZĆ”sobnĆ­k na sÅÆl se nachĆ”zĆ­ ve spodnĆ­ ÄĆ”sti myčky a je (viz POPIS SPOTŘEBIČE)
nutnĆ© jej naplnit, když na ovlĆ”dacĆ­m panelu svĆ­tĆ­ kontrolka DOPLNIT SÅ®L .
1. VytĆ”hněte spodnĆ­ koÅ” a odÅ”roubujte vƭčko zĆ”sobnĆ­ku
(proti směru hodinovĆ½ch ručiček).
2. NĆ”sledujĆ­cĆ­ kroky provĆ”dějte pouze při prvnĆ­m
použitĆ­: Naplňte zĆ”sobnĆ­k soli vodou.
3. UmĆ­stěte trychtĆ½Å™ ( ) a naplňte zĆ”sobnĆ­k viz obrĆ”zek
solĆ­ až po okraj (přibližně 1 kg); odtĆ©kĆ”nĆ­ určitĆ©ho
množstvĆ­ vody je přitom normĆ”lnĆ­.
4. Vyjměte trychtĆ½Å™ a otřete z otvoru přebytečnou sÅÆl.
Ujistěte se, že je vƭčko pevně dotaženo, aby se do zĆ”sobnĆ­ku nedostal při
mytĆ­ Å¾Ć”dnĆ½ mycĆ­ prostředek (to by mohlo vĆ©st k neopravitelnĆ©mu poÅ”koze-
nƭ změkčovače vody).
Pokud potřebujete doplnit sÅÆl, je nutnĆ© tento proces dokončit před
zaÄĆ”tkem mycĆ­ho cyklu aby se předeÅ”lo korozi.
DOPLNĚNƍ DƁVKOVAČE LEÅ TIDLA
DĆ­ky leÅ”tidlu nĆ”dobĆ­ lĆ©pe schne. ZĆ”sobnĆ­k leÅ”ti-
dla A by měl bĆ½t doplněn pokaždĆ©, když se na
ovlĆ”dacĆ­m panelu rozsvĆ­tĆ­ kontrolka ā€žNEDO-
STATEK LEÅ TIDLAā€œ .
NIKDY nelijte leÅ”tidlo pÅ™Ć­mo do myčky.
A
C
D
DOPLNĚNƍ DƁVKOVAČE MYCƍHO PROSTŘEDKU
K otevřenĆ­ zĆ”sobnĆ­ku mycĆ­ho prostředku použijte otevĆ­racĆ­ prvek . DĆ”vC-
kujte mycĆ­ prostředek vĆ½hradně do suchĆ©ho zĆ”sobnĆ­ku . Prostředek pro D
předmytĆ­ dĆ”vkujte pÅ™Ć­mo do prostoru myčky.
PouÅ¾Ć­vĆ”te-li tablety typu ā€žvÅ”e v jednomā€œ, doporučujeme stisknout tlačƭtko
TABLETA, čƭmž se program přizpÅÆsobĆ­, aby bylo možno dosĆ”hnout ideĆ”l-
nĆ­ch mycĆ­ch vĆ½sledkÅÆ.
PoužitĆ­ čisticĆ­ho prostředku, kterĆ½ nenĆ­ určenĆ½ pro myčky nĆ”dobĆ­,
mÅÆže zpÅÆsobit nesprĆ”vnĆ½ chod nebo poÅ”kozenĆ­ spotřebiče.
SYSTƉM PRO ZMĚKČOVƁNƍ VODY
Změkčovač vody automaticky snižuje tvrdost vody, aī˜™zabraňuje tak nahro-
maděnĆ­ vodnĆ­ho kamene na ohÅ™Ć­vači aī˜™přispĆ­vĆ” kī˜™vyÅ”Å”Ć­ Ćŗčinnosti mytĆ­.
Tento systĆ©m kī˜•regeneraci vyuÅ¾Ć­vĆ” sÅÆl, proto je nutnĆ© doplňovat zĆ”-
sobnĆ­k na sÅÆl, když se vyprĆ”zdnĆ­.
Četnost regenerace zĆ”leÅ¾Ć­ na nastavenĆ­ Ćŗrovně tvrdosti vody ā€“ s ĆŗrovnĆ­ tvr-
dosti nastavenĆ© na probĆ­hĆ” regenerace jednou za Eco cyklÅÆ. 3 6
RegeneračnĆ­ proces se spustĆ­ po zĆ”věrečnĆ©m oplachu aī˜™dokončƭ se během
suÅ”enĆ­ před skončenĆ­m cyklu.
ā€¢ Spotřeba během jednĆ© regenerace: ~ 3,5ī˜™l vody;
ā€¢ ProdlouženĆ­ cyklu až oī˜™5ī˜™minut;
ā€¢ Spotřeba mĆ©ně než 0,005ī˜™kWh energie.
OVLƁDACƍ PANEL
PRVNƍ POUŽITƍ
Před použitĆ­ spotřebiče si pečlivě přečtěte BezpečnostnĆ­ pokyny.
TABULKA PROGRAMÅ®
PRO ZƍSKƁNƍ PODROBNĚJÅ ĆCH IN-
FORMACƍ NASKENUJTE PROSƍM QR
KƓD NA VAÅ EM SPOTŘEBIČI.
1. Tlačƭtko Zap.-Vyp./Restart s kontrolkou
2. Tlačƭtko volby programu s kontrolkou
3. Tlačƭtko ā€žPolovičnĆ­ NĆ”plněā€œ s kontrolkou
4. Kontrolka množstvĆ­ leÅ”tidla
5. Kontrolka množstvĆ­ soli
6. Kontrolky programu
7. Kontrolka ā€žOdloženĆ½ startā€œ
Program Popis programÅÆ
FƔze
suÅ”enĆ­
Auto
Door
DostupnƩ
funkce *)
DĆ©lka
mycĆ­ho
programu
(h:min)**)
Spotřeba
vody
(litrÅÆ/cyklus)
Spotřeba
energie
(kWh/cyklus)
1.
ƚspornĆ½ program 50Ā°- Program Eko je vhodnĆ½ kī˜™ mytĆ­ běžně zaÅ”pi-
něnĆ©ho nĆ”dobĆ­, kterĆ½ je pro tento Ćŗčel nejvĆ½hodnějÅ”Ć­m programem
sī˜™ohledem na spotřebu energie aī˜™vody aī˜™kterĆ½ se vyuÅ¾Ć­vĆ” kī˜™vyhodnoce-
nĆ­ shody spotřebiče sī˜™předpisy Ecodesign EU. 3:10 9,5 0,85
2. IntenzivnĆ­ 65Ā° - Program doporučenĆ½ pro velmi Å”pinavĆ© nĆ”dobĆ­, hlavně
hrnce aī˜™pĆ”nve (nepouÅ¾Ć­vat Ina jemnĆ© nĆ”dobĆ­). 2:50 17,0 1,60
3. SmĆ­Å”enĆ© - 55Ā° Mix nĆ”dobĆ­ sī˜™rÅÆznou nĆ”ročnostĆ­ odstraněnĆ­ znečiÅ”těnĆ­.
Pro běžně zaÅ”piněnĆ© nĆ”dobĆ­ se zaschlĆ½mi nečistotami. 3:00 15,0 1,40
4. Fast&Clean 28ā€™ 45Ā° - Program určenĆ½ pro polovičnĆ­ naplněnĆ­ lehce za-
Å”piněnĆ½m nĆ”dobĆ­m bez zaschlĆ½ch zbytkÅÆ. Nezahrnuje fĆ”zi suÅ”enĆ­. - 0:28 9,0 0,50
5. PředmytĆ­ - PouÅ¾Ć­vejte pro oplĆ”chnutĆ­ nĆ”dobĆ­, kterĆ© plĆ”nujete mĆ½t poz-
ději. V tomto programu se nepouÅ¾Ć­vĆ” Å¾Ć”dnĆ½ mycĆ­ prostředek. - - 0:12 4,5 0,01
6. Push&GO 50Ā°- KaždodennĆ­ mycĆ­ a suÅ”icĆ­ cyklus, kterĆ½ zajistĆ­ vynikajĆ­cĆ­
Ćŗčinnost mytĆ­ v krĆ”tkĆ©m čase bez potřeby nĆ”dobĆ­ předem oÅ”etřovat. 1:25 11,5 1,10
8. Tlačƭtko ā€žOdloženĆ½ startā€œ
s kontrolkou
9. Tlačƭtko ā€žPush&GOā€œ s
kontrolkou
10. Tlačƭtko ā€žSPUSTIT/Pauzaā€œ
s kontrolkou / VypouÅ”těnĆ­
DĚKUJEME VƁM, ŽE JSTE SI ZAKOUPILI VƝROBEK ZNAČKY
INDESIT. Pro zĆ­skĆ”nĆ­ komplexnějÅ”Ć­ asistence zaregistrujte
prosĆ­m svÅÆj spotřebič na: www.indesit.com/register
1 2 43 5 6 7
8
9
10
ƚdaje pro ā€žĆšSPORNƝ PROGRAMā€œ jsou měřeny v laboratornĆ­ch podmĆ­nkĆ”ch podle pokynÅÆ evropskĆ© normy EN 60436:2020.
PoznĆ”mka pro zkuÅ”ebnĆ­ laboratoře: Pro informace o zkuÅ”ebnĆ­ch podmĆ­nkĆ”ch srovnĆ”vacĆ­ zkouÅ”ky EN napiÅ”te na adresu: dw_test_support@whirlpool.com
Å½Ć”dnĆ½ z programÅÆ nevyžaduje jakĆ©koli předchozĆ­ oÅ”etřenĆ­ nĆ”dobĆ­.
*) Ne vÅ”echny možnosti lze pouÅ¾Ć­vat zĆ”roveň.
**) Hodnoty uvedenĆ© pro ostatnĆ­ programy kromě ā€žĆšspornĆ½ programā€œ jsou pouze přibližnĆ©. SkutečnĆ” doba se mÅÆže liÅ”it v zĆ”vislosti na mnoha vlivech, jako je
např. teplota, tlak vstupnĆ­ vody, teplota okolĆ­, množstvĆ­ mycĆ­ho prostředku, množstvĆ­ a typ nĆ”dobĆ­, vyvĆ”Å¾enĆ­ nĆ”dobĆ­, zvolenĆ© doplňkovĆ© možnosti a kalibrace
snĆ­mačÅÆ. Kalibrace snĆ­mačÅÆ mÅÆže program prodloužit až o 20min.


Produktspezifikationen

Marke: Indesit
Kategorie: SpĆ¼lmaschine
Modell: I3B L634 X

Brauchst du Hilfe?

Wenn Sie Hilfe mit Indesit I3B L634 X benƶtigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten




Bedienungsanleitung SpĆ¼lmaschine Indesit

Bedienungsanleitung SpĆ¼lmaschine

Neueste Bedienungsanleitung fĆ¼r -Kategorien-
