ENQuick Guide

FILLING THE SALT RESERVOIR

The use of salt prevents the formation of LIMESCALE on the dishes and on

the machine’s functional components.

• It is mandatory that THE SALT RESERVOIR NEVER BE EMPTY.

• It is important to set the water hardness.

The salt reservoir is located in the lower part of the dishwasher (see PRODUCT

DESCRIPTION) and must be lled when the SALT REFILL indicator light

in the control panel is lit.

1. Remove the lower rack and unscrew the reservoir cap

(anticlockwise).

2. Only the rst time you do this: ll the salt reservoir

with water.

3. Position the funnel (see gure) and ll the salt reservo-

ir right up to its edge (approximately 1 kg); it is not

unusual for a little water to leak out.

4. Remove the funnel and wipe any salt residue away from the opening.

Make sure the cap is screwed on tightly, so that no detergent can get into

the container during the wash program (this could damage the water so-

ftener beyond repair).

Whenever you need to add salt, it is mandatory to complete the proce-

dure before the beginning of the washing cycle to avoid corrosion.

FILLING THE RINSE AID DISPENSER

Rinse aid makes dish DRYING easier. The rinse aid

dispenser A should be lled when the RINSE AID

REFILL indicator light in the control panel is lit.

NEVER pour the rinse aid directly into the

appliance tub.

FILLING THE DETERGENT DISPENSER

To open the detergent dispenser use the opening device . Introduce the C

detergent into the dry dispenser only. Place the amount of detergent for D

pre-washing directly inside the tub.

The detergent dispenser automatically opens up at the right time

according to the program. If all-in-one detergents are used, we recommend

using the TABLET button, because it adjusts the program so that the best

washing and drying results are always achieved.

Usage of detergent not designed for dishwashers may cause malfunc-

tion or damage to the appliance.

WATER SOFTENING SYSTEM

Water softener automatically reduces water hardness, consequently

pre-

venting scale buildup on heater, contributing also to better cleaning

eciency.

This system regenerates itself with salt, therefore it is required to rell

salt container when empty.

Frequency of regeneration depends on water hardness level setting - regen-

eration takes place once per 6 Eco cycles with water hardness level set to 3.

Regeneration process starts in nal rinse and nishes in drying phase, be-

fore cycle ends.

• Single regeneration consumes: ~3.5L of water;

• Takes up to 5 additional minutes for the cycle;

• Consumes below 0.005kWh of energy.

CONTROL PANEL

FIRST TIME USE

Before using the appliance carefully read Safety Instructions guide.

PROGRAMS TABLE

PLEASE SCAN THE QR CODE ON YOUR

APPLIANCE IN ORDER TO HAVE MORE

DETAILED INFORMATION

1. On-O / Reset button with

indicator light

2. Program selection button with

indicator light

3. Half Load button with indicator

light / Tablet (Tab)

4. Eco program indicator light

5. Display

6. Program number and remain-

ing time indicator

7. Tablet (Tab) indicator light

8. Closed water tap indicator light

9. Rinse Aid rell indicator light

10. Salt rell indicator light

11. Push& button with indicator GO

light

12. Delay button with indicator

light

13. Start/Pause button with indica-

tor light / Drain out

965 7 8 1210 1311

Program Programs description

Drying

phase

Available

options *)

Duration

of wash

program

(h:min)**)

Water

consumption

(litres/cycle)

Energy

consumption

(kWh/cycle)

Eco 50°- Eco program is suitable to clean normally soiled tableware,

that for this use, it is the most ecient program in terms of its com-

bined energy and water consumption, and that it is used to assess

compliance with the EU Ecodesign legislation. 3:35 9.5 0.95

2. Intensive - 65° Program recommended for heavily soiled crocke-

ry, especially suitable for pans and saucepans (not to be used for

delicate items). 2:40 18.0 1.60

3. Mixed 55° - Mixed soil. For normally soiled dishes with dried food

residues. 2:15 16.0 1.40

4. Fast&Clean 28’

50° -

Program to be used for half load of lightly-so-

iled dishes with no dried food residues. Does not have drying phase. - 0:28 9.0 0.50

5. Night

50°

- Suitable for night-time operation of the appliance.

Ensures optimal cleaning and drying performance with the lowest

noise emission. 3:35 16.6 1.30

6. Extra Hygiene - 65° Normally or heavily soiled crockery, with ad-

ditional antibacterial wash. Can be used to perform maintenance

of the dishwasher. 2:00 12.0 1.50

7. Prewash - Use to refresh crockery planned to be washed later. No

detergent to be used with this program. - 0:12 4.7 0.01

8. Self Clean 65°- Program to be used to perform maintenance of the

dishwasher, to be carried out only when the dishwasher is EMPTY

using specic detergents designed for dishwasher maintenance. - 0:50 10.0 0.80

9. Push&GO

50° -

Everyday wash and dry cycle that ensures great cleaning

performance in a short time without the need to pre-treat dishes. 1:30 11.5 1.30

THANK YOU FOR BUYING AN INDESIT PRODUCT.

In order to receive a more complete assistance, please register

your appliance on: www.indesit.com/register

Quick Guide

DELAY -The start of the program may be delayed for a period of time

between 0:30 and 24 hours

The DELAY function cannot be set once a wash cycle has been started.

TABLET (Tab) If you use powder or liquid detergent, this option -

should be o.

OPTIONS AND FUNCTIONS

OPTIONS can be selected directly by pressing the corresponding button (see CONTROL PANEL). If an option is not compatible with the selected

program (see PROGRAMS TABLE), the corresponding LED ashes rapidly 3 times and beeps will sound. The option will not be enabled.

HALF LOAD - If there are not many dishes to be washed, a half loading

may be used in order to save water, electricity and detergent.

Remember to halve the amount of detergent.

Please scan the on your product in order to have more detailed information. QR code

ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020. Note for Test Laboratories: For information on

comparative EN testing conditions, please send an email to the following address: dw_test_support@whirlpool.com

Pre-treatment of the dishes is not needed before any of the programs.

*) Not all options can be used simultaneously.

**) Values given for programs other than the program Eco are indicative only. The actual time may vary depending on many factors such as temperature and

pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and sensor cali-

bration. The sensor calibration can increase program duration up to 20 min.

LOADING THE RACKS CAPACITY: 14 standard place-settings

More information in the Daily Reference Guide on website.

CLEANING AND MAINTENANCE

CLEANING THE FILTER ASSEMBLY CLEANING THE SPRAY ARMS

n case you nd foreign objects (such as broken glass, porcelain, bones, fruit seeds etc.)

please remove them carefully.

NEVER REMOVE the wash-cycle pump protection (black detail) (Fig 4).

To remove the upper spray arm,

turn the plastic locking ring in a

clockwise direction.

The lower spray arm may

be removed by pulling it

upwards.

WATER TAP CLOSED – Alarm

Flashes when there is no inlet water or water tap is closed.

DRAIN OUT - To stop and cancel the active cycle, the Drain Out

function can be used. A long press of START/PAUSE button, will

activate the DRAIN OUT function. The active program will be stopped and

the water in the dishwasher will be drained out.

PUSH&GO - Push&Go button is an easily distinguishable button that

allows you direct access to the Push&Go program, a wash and dry cycle

that ensures great cleaning performance in a short time. You don’t have to

worry which program to choose, Push&Go cycle will do the work for you.

LOWER RACK

For pots, lids, plates, sa-

lad bowls, cutlery etc.

Large plates and lids

should ideally be pla-

ced at the sides to avo-

id interferences with

the spray arm.

The lower rack has tip-

-up supports which

can be used in a verti-

cal position when ar-

ranging plates or in a

horizontal position (lo-

wer) to load pans and

salad bowls easily.

(loading example for the

lower rack)

UPPER RACK

(loading example for the upper rack)

Load delicate and light dishes: glasses,

cups, saucers, low salad bowls.

FOLDABLE

FLAPS WITH

ADJUSTABLE

POSITION

CUTLERY BASKET

The basket is

equipped with top

grilles for impro-

ved cutlery arran-

gement. The cutle-

ry basket should

be positioned only

at the front of the

lower rack.

Knives and other utensils with sharp

edges must be placed in the cutlery

basket with the points facing down-

wards or they must be positioned

horizontally in the tip-up compart-

ments on the upper rack.

PROBLEMS POSSIBLE CAUSES SOLUTIONS

The dishwasher does

not ll the

water. Display shows:

and , both On/O F6

and START/Pause LEDs

are blinking rapidly.

No water in the water supply or the tap is closed. Make sure there is water in the water supply or the tap running.

The inlet hose is bent. Make sure the inlet hose is not bent (see INSTALLATION) reprogram the dishwasher and

reboot.

The sieve in the water inlet hose is clogged; it is

necessary to clean it.

After having carried out the verication and cleaning, turn o and turn on the dishwa-

sher and restart a new program.

Dishwasher nishes

the cycle prematurely.

Display shows: and F15

both On/O and START/

Pause LEDs are blinking

rapidly.

Drain hose positioned too low or siphoning into

home sewage system.

Check if end of drain hose is placed at correct height (see INSTALLATION).Check for

siphoning into home sewage system, install air admittance valve if necessary.

Air in water supply. Check water supply for leaks or other issues letting air inside.

TROUBLESHOOTING Please scan the on your product in order to have more detailed information. QR code

Policies, standard documentation, ordering of spare parts and additional product information can be found by:

• Using QR code on your product.

• Visiting our website docs.indesit.eu and parts-selfservice.whirlpool.com

• Alternatively, contact our After-sales Service (See phone number in the warranty booklet).

When contacting our After-sales Service, please state the codes provided on your product‘s identication plate.

The model information can be retrieved using the QR-Code reported in the energy label.

The label also includes the model identier that can be used to consult the portal of the registry at https://eprel.ec.europa.eu.

IEC 436

ESGuía Rápida

LLENADO DEL DEPÓSITO DE SAL

El uso de sal evita la formación de INCRUSTACIONES DE CAL en la vajilla

y en los componentes funcionales de la máquina.

• Es obligatorio que EL DEPÓSITO DE SAL NO ESTÉ NUNCA VACÍO.

• Es importante ajustar la dureza del agu

El depósito de sal se ubica en la parte inferior del lavavajillas (consulte -DES

CRIPCIÓN DEL PRODUCTO) y se debe rellenar cuando el indicador de RE-

CARGA DE SAL del panel de control se encienda.

1. Retire la bandeja inferior y desenrosque el tapón del

depósito (en sentido antihorario).

2. Pasos a seguir solo la primera vez: llene el depósito

de sal con agua.

3. Coloque el embudo (véase la gura) y llene el depósito

de sal hasta el borde (aproximadamente 1 kg); puede

derramarse un poco de agua.

4. Retire el embudo y limpie cualquier residuo de sal del oricio.

Asegúrese de que el tapón esté bien cerrado, de modo que el detergente

no pueda entrar en el depósito durante el programa de lavado (esto podría

estropear irremisiblemente el ablandador del agua).

Siempre que necesite añadir sal, es obligatorio completar el procedimiento

antes del inicio del ciclo de lavado para evitar la corrosión.

LLENADO DEL DISPENSADOR DEL ABRILLANTADOR

El abrillantador facilita el SECADO de la vajilla.

El dispensador de abrillantador se debe rellenar A

cuando el indicador luminoso de RECARGA

DE ABRILLANTADOR del panel de control

esté encendido. NUNCA eche el abrillantador

directamente en la cuba.

RELLENAR EL DISPENSADOR DE DETERGENTE

Para abrir el dispensador de detergente utilice el mecanismo de apertura

C. Introduzca el detergente solo en el dispensador seco. Eche la cantidad D

de detergente para el prelavado directamente dentro de la cuba.

Si se utilizan detergentes todo en uno, recomendamos usar el botón

de PASTILLAS, p3-ya que ajusta el programa de tal modo que siempre se

consigan los mejores resultados de lavado y secado.

El uso de detergente no diseñado para lavavajillas puede provocar

fallos de funcionamiento o daños en el aparato.

SISTEMA DE ABLANDAMIENTO DE AGUA

El ablandador del agua reduce automáticamente la dureza del agua,

evitando así la acumulación de incrustaciones en el calentador

y permitiendo también una mayor eciencia del lavado.

Este sistema se regenera con sal, por lo que es necesario rellenar

el depósito de sal cuando está vacío.

La frecuencia de la regeneración depende del ajuste del nivel de dureza del

agua. La regeneración se produce una vez cada ciclos Eco con la dureza 6

del agua ajustada en el nivel . 3

El proceso de regeneración comienza en el aclarado nal y termina

en la fase de secado, antes de que termine el ciclo.

• Una regeneración consume: ~3,5l de agua;

• Añade hasta 5 minutos adicionales al ciclo;

• Consume menos de 0,005kWh de energía.

PANEL DE CONTROL

PRIMER USO

TABLA DE PROGRAMAS

ESCANEE EL CÓDIGO QR DE SU APA-

RATO PARA OBTENER INFORMACIÓN

MÁS DETALLADA

1. Botón de Encender-Apagar / Reset con indicador luminoso

2. Botón de Selección de programas con indicador luminoso

3. Botón de Media Carga con indicador luminoso / Pastillas

4. Indicador luminoso de programa Eco

5. Pantalla

6. Indicador luminoso de número de programa y tiempo

restante

7. Indicador luminoso de Pastillas

8. Indicador luminoso de grifo cerrado

9. Indicador luminoso de recarga de abrillantador

10. Indicador luminoso de recarga de sal

11. Botón de Push&GO con indicador luminoso

12. Botón de aplazamiento con indicador luminoso

13. Botón de Inicio/Pausa con indicador luminoso / Vaciado

Program-

ma Descripción de programas

Fase

de secado

Duración del

programa

de lavado

(h:min)*)

Consumo

de agua

(litros/ciclo)

Consumo

de energía

(kWh/ciclo)

Energy

consumption

(kWh/cycle)

Eco 50°- E programa Eco es adecuado para lavar utensilios con suciedad

normal, para este uso es el programa más eciente en términos de consu-

mo combinado de energía y agua, y se utiliza para valorar el cumplimien-

to con la legislación de Ecodiseño de la UE. 3:35 9,5 0,95

2. Intensivo 65° - Programa recomendado para vajilla muy sucia, en espe-

cial para ollas o sartenes (no se debe utilizar para artículos delicados). 2:40 18,0 1,60

3. Mixta 55° - Suciedad mixta. Para vajilla con suciedad normal con residuos

de comida secos. 2:15 16,0 1,40

4. Fast&Clean 28’ - 50° Programa recomendado para media carga de vajilla

poco sucia sin restos de comida secos. No tiene fase de secado. - 0:28 9,0 0,50

Nocturno - 50° Adecuado para hacer funcionar el aparato de noche.

Garantiza una limpieza y un secado óptimos con las más bajas emisio-

nes de ruido. 3:35 16,6 1,30

Extra Hygiene - 65° Vajilla con suciedad normal o muy sucia, con acción

antibacteriana suplementaria. Puede utilizarse para realizar el manteni-

miento del lavavajillas. 2:00 12,0 1,50

7. Prelavado - Se utiliza para remojar la vajilla que planea lavar más tarde.

Con este programa no se debe utilizar detergente. - 0:12 4,7 0,01

Autolimpieza 65°-

Programa para realizar el mantenimiento del lavava-

jillas. Solo debe llevarse a cabo cuando el lavavajillas esté VACÍO usando

detergentes especícos diseñados para el mantenimiento de lavavajillas.

- 0:50 10,0 0,80

9. Push&GO 50° -

Lavado y ciclo de secado diario que garantiza una buena

limpieza en poco tiempo sin necesidad de tratar la vajilla con anterioridad.

1:30 11,5 1,30

Antes de usar el electrodoméstico, lea atentamente las Instruc-

ciones de seguridad.

GRACIAS POR COMPRAR UN PRODUCTO INDESIT.

Si desea recibir un servicio más completo, registre su aparato

en: www.indesit.com/register

965 7 8 1210 1311

Produktspezifikationen

Marke:	Indesit
Kategorie:	Spülmaschine
Modell:	D2F HD624 A

Brauchst du Hilfe?

Wenn Sie Hilfe mit Indesit D2F HD624 A benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten

Ihren Namen*

Deine E-Mail*

Schreiben Sie hier Ihre Frage

Bedienungsanleitung Spülmaschine Indesit

Indesit UNODUE Bedienungsanleitung

12 Oktober 2024

Indesit DG 6445 W Bedienungsanleitung

22 September 2024

Indesit IDP 147 Bedienungsanleitung

17 September 2024

Indesit DISR 57M96 Z UK Bedienungsanleitung

16 September 2024

Indesit DI 67 (UK) Bedienungsanleitung

11 September 2024

Indesit DG 6145 Bedienungsanleitung

9 September 2024

Indesit D2F HD624 A Bedienungsanleitung

6 September 2024

Indesit I3B L634 X Bedienungsanleitung

5 September 2024

Indesit I3I D741O Bedienungsanleitung

5 September 2024

Indesit Slimline DI9E 2B10 Bedienungsanleitung

4 September 2024

Bedienungsanleitung Spülmaschine

Neueste Bedienungsanleitung für -Kategorien-

Bauknecht GSXK 5011 A+ Bedienungsanleitung

16 Oktober 2024

Freggia DWI4108 Bedienungsanleitung

16 Oktober 2024

Neff S155EVX04E Bedienungsanleitung

16 Oktober 2024

Neff S255EVX04E Bedienungsanleitung

16 Oktober 2024

Neff S145EVS04E Bedienungsanleitung

16 Oktober 2024

V-ZUG GS60Ni3n Bedienungsanleitung

15 Oktober 2024

Grundig GNUP4530W Bedienungsanleitung

15 Oktober 2024

Grundig GNLP4620X Bedienungsanleitung

15 Oktober 2024

Grundig GNUP3540W Bedienungsanleitung

15 Oktober 2024

Royal Catering RCDW-06 Bedienungsanleitung

15 Oktober 2024
