User Manual
Slot PC
OPC51204
(OPC51204xx series)
M239B21
Function Frequency Maximum Output
Power (EIRP)
WiFi
2412-2472 MHz 19.32 dBm
5150-5250 MHz 20.72 dBm
5250-5350 MHz 20.81 dBm
5470-5725 MHz 21.00 dBm
5725-5850MHz 13.96 dBm
Bluetooth 2402-2480 MHz 8.96 dBm
RF&POWER
Before using and operating this device, please read
thoroughly and comply with the following precautions in
order to prevent accidents or mal-operations.
Do not charge or use the device in dusty or wet conditions,
to prevent internal circuit failure.
Keep the device away from heat sources such as an
electric heater.
This device and its parts may contain some small
components, so keep the product out of reach of children to
prevent accidents.
This device is not water-resistant, please keep it dry.
The normal working temperature for the product is
0°C~45°C, and the normal working humidity is 10%~95%.
Please contact professional service personnel for
maintenance services.
Do not insert any sharp or pointed object into the device.
Prevent the device from falls and collisions with other
objects, which may cause damages.
There are heating hole on back cover, do not spray water
to it or use damp cloth for cleaning;
Please call professional personnel for maintenance service.
STATEMENT
The image shown in this manual is indicative only. If there is
inconsistency between the image and the actual product, the
actual product shall govern.
SAFETY WARNING
xx: RAM and SSD size control code
Here, IIYAMA Corporation declares that the Slot PC
complies with Directive 2014/53/EU Radio Equipment
Directive, 2011/65/EU RoHS Directive, Radio Equipment
Regulation 2017 and The Restriction of the Use of Certain
Hazardous Substances in Electrical and Electronic Equipment
Regulations 2012.
The full text of the EU and UK declaration of the conformity is
available at the following internet address: https://iiyama.com
Please refer to https://iiyama.com to download the
User manual and driver.
We recommend recycling of used product.
Please contact your dealer or iiyama service
center. Recycle information is obtained via
the Internet, using the address:
https://iiyama.com
You can access the Web page of di erent
countries from there.
CHECKING THE CONTENTS OF THE PACKAGE
Slot PC x 1
Installation manual x 1 (this document)
OPS PC MODULE SPECIFICATION
INSTALLATION PROCEDURE
NOTE Before mounting and using the Monitor, please follow the steps below to install the Slot PC. The
installation should be performed by at least two adult persons to avoid danger and injuries.
Please make sure the power cable of the Monitor is disconnected before installation.
Do not plug or unplug the Slot PC while the monitor is powered on. Slot PC may be broken.
When using for the rst time, if the screen is blurred, ickering, no signal, etc. after booting, Slot PC
may not be installed correctly; please check the installation status or reinstall it.
1. Insert Slot PC into the panel slot 2. Press the power button to turn it on and operate like a
regular computer
Product Speci cation
Type Slot PC
CPU
12th Generation Intel
®
Core
TM
i5-12450H
RAM DDR4 3200MHz 8GB, Max. 32GB
SSD PCIe 256GB, Max. 1T
Graphics Integrated Intel® UHD Graphics for
12th Gen
Sound Card Integrated HS-100B
Ethernet Card Integrated 10M/100M/1000M
Adaption RTL8111H
Wi-Fi
Intel AX200 + BT5.2
Support 802.11a/b/g/n/ac/ax (Wi 6)
Speed: 2.4Gbps
Bluetooth 5.2
Operating system Windows 11 IoT Enterprise 64Bit
Security Device
Support TPM2.0
I/O Port
Antenna 2
USB3.2 Gen 1 (5Gbps, DC5V, 900mA) 4
USB3.2 Gen2 10Gbps Type-C(DC5V,
900mA) (Not Support DP ALT mode) 1
HDMI2.0 OUT
(Max resolution 3840 x 2160 60Hz) 1
DP1.4 OUT
(Max resolution 3840 x 2160 60Hz) 1
MIC IN 1
Audio OUT 1
RJ45 1
SSD LED (Running : Green LED blinking)
1
I/O Port
POWER LED (Power on : Red LED) 1
80 PIN Support
Kensington Lock 1
Power Button 1
System recovery Button 1
Power
Power Requirements 12-19Vdc, 8A
Max Power 80.7W
Standby Power 2.9W
Physical Speci cation
Dimension 180.0 x 119.0 x 30.0 mm (L x W x H)
Dimension(package) 267.0 x 192.0 x 72.0 mm (L x W x H)
Net Weight 0.60kg
Gross Weight 0.97kg
Environmental Condition
Operation Temperature
0 to 45
Operation Humidity 10% to 95% RH (non condensing)
Storage Temperature
-10 to 50
Storage Humidity 10% to 95% RH (non condensing)
Please ensure the Slot PC is inserted
correctly by making sure the Caution-
Label(yellow) and the fan are facing
outwards.
