User’s Guide • Benutzerhandbuch • Uživatelská příručka
•Instrukcja obsługi • Užívateľská príručka
i-tec SOLAR - Bluetooth
MULTIPOINT Handsfree CarKit
(BTHF-SOLAR)
Safe driving Mobile/PDA Personal
Computer
Up to
800h
standby time
Up to
13h
talk time
Solar Charge
I-TEC SOLAR - BLUETOOTH MULTIPOINT HANDSFREE CARKIT
Thank you for purchasing our product. Please kindly review the informations contained in the guide thoroughly.
i-tec SOLAR - Bluetooth MULTIPOINT Handsfree CarKit is equipped by a digital technology for wireless communication. This Handsfree device
contains a DSP processor (Digital Signal processor) that eliminates interference, improves a signal reception and guarantees exceptional
sound quality. Handsfree CarKit is portable, very compact, fully wireless; it could communicate with any mobile telephone that supports
and fulfils the Bluetooth protocol of the profile Headset or Handsfree.
i-tec SOLAR is designed as a portable handsfree, enabling the user to communicate freely without a need to hold the telephone in hand.
Do not forget: When driving, use the Handsfree safely and in compliance with valid legislative of given country.
Package contents
• Bluetooth® i-tec SOLAR
• Automotive power supply (12 / 24 V)
• Interconnecting cable for charging (USB A-USB Mini)
• Windscreen holder
• Guide
Specifications
• standard: Bluetooth v2.1+ EDR (BlueCore 5 chip)
• solar panel for charging
• frequency: 2,4-2,480 GHz
• maximum operating radius: Up to 10 m, Bluetooth Class2
• supported proles: Handsfree a Headset 1.5 (selectable when pairing)
• talk time: Up to 13 hours
• stand-by time: Up to 800 hours
• period of battery recharging:
USB cable: solar panel: approximately 3h (rst charging 3,5h); approximately 18h
• battery type: Li-ion 3,7V/550mAh
• car charger: input =12-24V / output =5V/400mA
• loudspeaker: 30 mm
• microphone: With function of suppressing echo cancellation
• weight: 133.3 g
• dimensions: 123 x 46 x 20 mm
• other:
- full duplex equipment
- compatible with all currently available telephones with Bluetooth
- integrated „smart“ DSP processor (Digital Signal Processor), eliminating interference and echo
- supporting voice dialing (provided it is supported by the telephone)
- supporting redial / only for the prole Handsfre
- possibility of pairing with more telephones
- one button for receipt and end of the call
- pushbutton for refusing the call
- controls of loudness
EN
1 - 2
IMPORTANT ADVICE
Prior to rst use, the Handsfree batteries’ kit must be charged at least 3,5 hours!
CHARGING THE HANDSFREE
Handsfree could be charged any time in your car with aid of vehicle power supply or, through the USB port PC/NB.
Handsfree indicates by blinking the red LED 1x/3s that batteries are at. Using solar power charge, the operation time (talk time and
standby time) will be extended continuously without any additional charge required by the car charger.
1. Connect the charger into a connector for the charger (6).
LED diode Charge (battery charging) (5):
a. lights red: Battery has still a low charge
b. red ceases to light (appx. after 3h of charging): Battery is fully charged
2. After the batteries are fully charged, disconnect the charger.
LED diode Bluetooth (5): Light is blinking blue (in case it is paired with mobile telephone).
Note: 1. You must charge Handsfree by power adaptor, if you do not use Handsfree for more than several months. Red LED will shine
only after 15-35 minutes charging time.
2. You can charge Handsfree CarKit owing to solar panel on the back side of Handsfree as well. If the Handsfree receives
sufficient sunlight for 2 hours, you can talk for duration of up 1 hour. Solar panel is able to charge internal battery from zero
capacity to full capacity for about 18 hours.
USE OF HANDSFREE
Description of Handsfree
1. Mute Button
2. Volume Up (VOL +)
3. Windscreen Holder
4. Microphone
5. Multi-function Button (MFB) / under this button is LED (blue and red)
6. Micro USB Charging Socket
7. Volume Down (VOL-)
8. Speaker
Installation into car
1. Use low pressure to input Handsfree into windscreen holder’s guiding clips (with mounted suction cups) up to utmost position. Release
Handsfree from holder – it is backward motion with low pressure again.
2. Press Handsfree with help suction cups on facies in a car (e.g. glass). Handsfree must be installed facing to user – then you can easily
use it while driving a car.
Note:
- We recommend to clear suction cups and glass before mounting of windscreen holder – then holder will firmly hold and it will not fall
off from glass during driving car
- Holder has foam plastic pillars also – when you want to use holder without suction cups; foam plastic pillars are primarily identified for
prevention of solar panel; please, foam don’t remove plastic pillars!
