Seite 1/28
SFN16
MANUAL (p. 2)
Stand fan
ANLEITUNG (S. 3)
Standventilator
MODE D’EMPLOI (p. 5)
Ventilateur sur pied
GEBRUIKSAANWIJZING (p. 7)
Staande ventilator
MANUALE (p. 9)
Ventilatore con supporto
MANUAL DE USO (p. 11)
Ventilador de pedestal
HASZNÁLATI ÚTMUTATÓ (o. 13.)
Állvånyos ventilåtor
KÄYTTÖOHJE (s. 15)
Jalustatuuletin
BRUKSANVISNING (s. 17)
Stüende fläkt
NÁVOD K POUŽITÍ (s. 19)
VentilĂĄtor s podstavcem
MANUAL DE UTILIZARE (p. 21)
Ventilator cu picior
ΕΓΧΕΙΡΙΔΙΟ XPHΣ ΣH (σελ. 23)
Ανεμιστήρας δαπέδου
BRUGERVEJLEDNING (s. 25)
Ventilator med fod
VEILEDNING (s. 26)
StĂĽende vifte
2
ENGLISH
Stand fan
Base and stand assembly:
1. Take out the base and stand parts from the box.
2. Turn the height adjustor counterclockwise, and draw the steel tube out of the stand. Then turn the height
adjustor clockwise to secure it.
3. Insert the stand into the base, fit the screw nut to the stand from the bottom of the base and fasten it.
4. Adjust the height to meet you requirements for the fan’s height.
Fan head and column assembly:
1. Unscrew the knob on the bottom of the fan body.
2. Put the extension column into the hole of the fan body, then tighten the knob to secure it.
3. Remove the spinner and the plastic nut from the front side of the motor shaft and then tighten the plastic
nut. (Figure 1)
1. Lock
2. Spinner
3. Grill Lock
4. Nut
5. Plastic
4. Insert the blade into the shaft, making sure the stopper pin is clipped into the groove of the blade. Screw
the spinner counterclockwise to tighten the blade. (Figure 2)
1. Spinner
2. Lock
3. Blades
4. Groove
5. Stopper pin
5. Put the front grill onto the rear grill and close the clips to tighten both the front and rear grills together.
Operating instructions
Speed function:
Use the “speed” switch to turn the fan “on/off” and adjust the speed by pressing the switch tone of the
following numbers:
0-Off 2-Medium
1-Low 3-High
Rotate function:
To start the fan rotating, press the rotate knob located at the top of the motor casing.
To get the directional airflow, pull the rotate knob.
Angle function:
Unscrew the angle knob, adjust the fan head to the desirable angle by holding the fan head, then tighten the
knob.
Maintenance:
• To keep the fan clean, wipe it with a soft cloth with a mild detergent. Be careful not to use abrasives to
clean the plastic parts of the fan.
• To ensure that the fan keeps functioning properly, apply drops of clean motor oil to the front and back
bearings of the motor every 12 months.
• Before storage, clean the fan completely, then put the plastic bag over the fan and store in a cool dry
place.
FIGURE 2
FIGURE 1
3
Caution:
• To understand fan operation, read all these instructions carefully before use.
• Always match the power with the rated voltage and frequency of fan.
• Don’t insert fingers, or any other objects through the grill when the fan is operating.
• Disconnect the power cord when relocating the fan.
• Unplug the fan before cleaning it.
Safety precautions:
To reduce risk of electric shock, this product should ONLY be
opened by an authorized technician when service is required.
Disconnect the product from mains and other equipment if a
problem should occur. Do not expose the product to water or
moisture.
Maintenance:
Clean only with a dry cloth. Do not use cleaning solvents or abrasives.
Warranty:
No guarantee or liability can be accepted for any changes and modifications of the product or damage caused
due to incorrect use of this product.
General:
- Designs and specifications are subject to change without notice.
- All logos brands and product names are trademarks or registered trademarks of their respective holders
and are hereby recognized as such.
- This manual was produced with care. However, no rights can be derived. can not accept HQ
liability for any errors in this manual or their consequences.
- Keep this manual and packaging for future reference.
Attention:
This product is marked with this symbol. It means that used electrical and electronic products should
not be mixed with general household waste. There is a separate collections system for these products.
This product has been manufactured and supplied in compliance with all relevant regulations and directives,
valid for all member states of the European Union. It also complies with all applicable specifications and
regulations in the country of sales.
Formal documentation is available upon request. This includes, but is not limited to: Declaration of Conformity
(and product identity), Material Safety Data Sheet and product test report.
Please contact our customer service desk for support:
via website: http://www.nedis.com/en-us/contact/contact-form.htm
via e-mail: service@nedis.com
via telephone: +31 (0)73-5993965 (during office hours)
NEDIS B.V., De Tweeling 28, 5215 MC ’s-Hertogenbosch, THE NETHERLANDS
DEUTSCH
Standventilator
Montage des Fußes und Ständers:
1. Nehmen Sie die Bauteile für den Fuß und den Ständer aus der Verpackung.
2. Drehen Sie die HÜheneinstellung im Gegenuhrzeigersinn und ziehen Sie das Stahlrohr aus dem Ständer.
Drehen Sie die Höheneinstellung anschließend im Uhrzeigersinn fest.
3. Stecken Sie den Ständer in den Fuß, schrauben Sie die Schraubenmutter von der Unterseite des Fußes
aus auf den Ständer und drehen Sie diese fest.
4. Stellen Sie die HĂśhe des Ventilators entsprechenden Ihren Anforderungen ein.
