Seite 1/36
FN09, 12,16
MANUAL (p. 2)
Table fan
ANLEITUNG (S. 4)
Tischventilator
MODE D’EMPLOI (p. 7)
Ventilateur de table
GEBRUIKSAANWIJZING (p. 9)
Tafelventilator
MANUALE (p. 12)
Ventilatore da tavolo
MANUAL DE USO (p. 14)
Ventilador de mesa
HASZNÁLATI ÚTMUTATÓ (o. 17.)
Asztali ventilátor
KÄYTTÖOHJE (s. 19)
Pöytätuuletin
BRUKSANVISNING (s. 22)
Bordsfläkt
NÁVOD K POUŽITÍ (s. 24)
Stolní ventilátor
MANUAL DE UTILIZARE (p. 27)
Ventilator portabil
ΕΓΧΕΙΡΙΔΙΟ XPHΣ ΣH (σελ. 29)
Επιτραπέζιος ανεμιστήρας
BRUGERVEJLEDNING (s. 32)
Bordventilator
VEILEDNING (s. 34)
Bordvifte
2
ENGLISH
Table fan
Figure 1 illustrates the parts of this fan. After removing fan from the package, check to make sure all of the
parts are present.
1. Front grill
2. Fan blade
3. Nut
4. Sleeve (discard)
5. Oscillation knob (on top of motor casing)
6. Latch
7. Blade cap FN12,FN16( )
8. Rear grill
9. 3 speed switches
10. Base
11. Retaining Pin
ASSEMBLY
1. Attach the fan base to the fan body using the four screws included.
2. Place the fan base on a firm, stable surface, such as a table or counter top.
3. Remove the plastic sleeve from the shaft.
4. Secure the rear grill to the motor casing with the plastic nut. The handle should be at the top. Turn it
clockwise to tighten.
5. Slide the blade onto the shaft pin, pushing until it is firmly in place.
6. Test the blade operation by rotating it with your hand. There should be no friction with the other parts. If
blade does not rotate freely, repeat steps 4-5.
7. Place the blade cap on shaft pin and turn counter-clockwise until tight.( )FN12,FN16
8. Ensure that the latches on either side of the rear grill are open. Place the front and rear grills together and
close the side latches. If they do not fit securely together, repeat the procedure.
OPERATING INSTRUCTIONS
Place the fan on a safe flat surface where it cannot fall or be pulled by the cord. Plug the fan into a 220V/50Hz
outlet and follow the operating instructions:
This fan is equipped with three fan speeds to allow optimal air comfort.
0- Pressing this button will power the fan OFF.
1- Pressing this button will power the fan ON at a LOW speed setting.
Fig. 1
3
2- Pressing this button will power the fan ON at a MODERATE speed setting.
3- Pressing this button will power the fan ON at a HIGH speed setting.
ROTATE: To activate the rotate function for breeze distribution, simply press the rotate knob down (located on
top of the fan’s motor casing). To turn off the rotate function for a targeted breeze setting, pull the rotate pin up.
Controlling the rotation setting can be done while the fan is operating.
TILT: To tilt the fan head so that the breeze is targeted at an angle, steady the base of the fan with one hand
and grip the motor casing with another, then carefully tilt the head of the fan until it reaches the desired angle.
Be careful not to tilt the head back further than it is intended to go, as doing so will damage the unit.
SPECIFICATIONS
MODEL NUMBER FN 09 FN16
WATTAGE 21 40
VOLTAGE 220V AC, 50Hz 220V AC, 50Hz
WEIGHT(KG) 1.2 2. 3
CLEANING INSTRUCTIONS
• Always disconnect the cord from the electrical outlet when cleaning your fan.
• Light layers of dust may wiped away using a soft on the back grill of the fan.
• Occasionally wipe the exterior surfaces of the fan with a damp cloth (not dripping wet) and dry thoroughly
with a soft dry cloth before operating the fan.
• Do not use harsh cleaners or materials to clean this unit, as doing so will cause damages to it.
CAUTION: DO NOT ALLOW WATER TO RUN INTO THE INTERIOR OF THE FAN AS THIS COULD
CREATE A FIRE OR ELECTRIC SHOCK HAZARD. THE FAN MOTOR IS FACTORY LUBRICATED FOR
LIFE AND WILL REQUIRE NO FURTHER LUBRICATION. NO OTHER USER MAINTENANCE IS
REQUIRED OR RECOMMENDED.
STORING YOUR FAN
• Follow the cleaning instructions above. Make sure to disassemble and clean the fan before storing.
• Retain the original packaging to store your fan.
• Always store in a dry place.
• Never store while still plugged in.
• Never wrap the cord tightly around the fan or put any stress on the cord where it enters the fan as this could
cause the cord to fray or break.
Safety precautions:
To reduce risk of electric shock, this product should ONLY be
opened by an authorized technician when service is required.
Disconnect the product from mains and other equipment if a
problem should occur. Do not expose the product to water or
moisture.
Maintenance:
Clean only with a dry cloth. Do not use cleaning solvents or abrasives.
Warranty:
No guarantee or liability can be accepted for any changes and modifications of the product or damage caused
due to incorrect use of this product.
General:
- Designs and specifications are subject to change without notice.
- All logos brands and product names are trademarks or registered trademarks of their respective holders
and are hereby recognized as such.
- This manual was produced with care. However, no rights can be derived. can not accept HQ
liability for any errors in this manual or their consequences.
- Keep this manual and packaging for future reference.
FN 12
35
220V AC, 50Hz
1.8
