Seite 1/13

IMPORTANT SAFETY

INSTRUCTIONS

READ AND SAVE THESE

SAFETY INSTRUCTIONS

BEFORE USING THIS AIR

PURIFIER

When using electrical appliances, basic

precautions should always be followed to

reduce the risk of fire, electric shock, and

injury to persons, including the following:

1. Read all instructions before operating the

air purifier.

2. Place air purifier where it is not easily knocked

over by persons in the household.

3. Always turn the air purifier controls to the

OFF position and unplug from the wall outlet

when not in use.

4. To disconnect the air purifier, press the

Power button to turn the unit off, grip the

plug and pull it from the wall outlet. Never

pull by the cord.

5. Do not use any product with a damaged cord or

plug or if product malfunctions, is dropped or

damaged in any manner. Keep the cord away

from heated surfaces.

6. Do not use air purifier outdoors.

7. Never use air purifier unless it is fully

assembled.

8. Do not run power cord under carpets, and do

not cover with throw rugs. Arrange cord such

that it will not be tripped over.

QUIETCLEAN®

OSCILLATING TOWER

AIR PURIFIER

HFD230 MODEL SERIES

Honeywell is a trademark of Honeywell International Inc., used under license by Helen of Troy Limited.

Honeywell International Inc. makes no representation or warranties with respect to this product.

9. Do not use air cleaner where combustible

gases or vapors are present.

10. Do not expose the air purifier to rain, or use

near water, in a bathroom, laundry area or

other damp location.

11. The air purifier must be used in its upright

position.

12. Do not allow foreign objects to enter ventilation

or exhaust opening as this may cause electric

shock or damage to the air purifier. Do not

block air outlets or intakes.

13. Locate air purifier near the outlet and avoid

using an extension cord.

14. This appliance has a polarized plug (one blade

is wider than the other). To reduce the risk of

shock, this plug is intended to fit only one way

in a polarized outlet. If the plug does not fit fully

in the outlet, reverse the plug. If it still does not

fit, contact a qualified electrician.

DO NOT attempt to defeat this safety feature.

15. A loose fit between the AC outlet (receptacle)

and plug may cause overheating and a

distortion of the plug. Contact a qualified

electrician to replace loose or worn outlet.

16. Do not sit, stand or place heavy objects on the

air purifier.

17. Disconnect power supply before servicing.

Note: For FCC compliance information, please

see last page of this manual.

WARNING: To Reduce The Risk of Fire or

Electric Shock, Do Not Use This Air Purifier

With Any Solid-State Speed Control Device.

Owner’s Manual

HFD230B_OM_31IMH230190_r2_17NOV14.indd 1 11/17/14 6:10 PM

OPERATION

• Ensure the air purifier is plugged into a working electrica

• Press the power button ( ) once. The unit will start at

few seconds and then automatically change to low spee

• Press the power button again to select a different cleani

Portable air purifiers are more effective in rooms where all

are closed. In general, it is recommended that you run you

you are at home to clean the air.

YOUR AIR PURIFIER

HOW YOUR AIR PURIFIER WORKS

This model air purifier incorporates a 3-stage cleaning

system to help clean the air that passes through the filter

in the unit (Fig. 1).

Stage 1: Washable or Odor-reducing Pre-Filter

(not all models include optional replacement

K pre-filter)

Stage 2: Permanent Washable ifD

® Filter

Stage 3: Electronic Ionizer

Washable or

Odor Reducing

Pre-Filter

Fig. 1

SET-UP

• Select a firm, level and flat location. For best airflow, locate the unit 6 inches from any wall or furniture.

• When operating, large volumes of air are drawn toward the air purifier. Surrounding areas should be

cleaned and/or vacuumed frequently to prevent build-up of dust and other contaminates. This may

also help prolong the life of the filter. If the unit is placed on a light colored carpet, a small mat or rug

should be used underneath to prevent permanent staining. This is especially important in homes with

contamination from smoking or fireplaces.

ENERGY STAR®

This product earned the ENERGY STAR

® by m

the US EPA. US EPA does not endorse any m

the use of this product.

The energy efficiency of this ENERGY STAR

® q

between the model’s CADR for Dust and the e

Permanant

Washable

ifD® Filters

(2)

Rear

Grille

DIMMER OPTION

The Dimmer Option ( ) allows you to adjust the brightne

display on the control panel. You may wish to adjust the br

depending on the room where the unit is placed.

• The unit always turns on with brightness on HIGH

• Press the ( ) button once and LED display will dim (F

• The LED lights cannot be turned completely off

• Pressing the ( ) button a 2nd time will turn the LED l

back to HIGH.

Washable

Pre-filter

(1)

Optional Odor

Reducing

Pre-filter K

Control Panel

with Integrated

Carry Handle

OSCILLATION OPTION

To help circulate fresher, cleaner air through the room, this

oscillation feature.

• To turn Oscillation on, simply press the Oscillation butto

• To turn Oscillation off, press the button again.

*The washable pre-filter came installed in your air purifier and removes larger particles from the air that passes through

the filter. You can use this washable pre-filter, or you have the choice to use the Optional Odor & VOC Reducing KPre-

filter that is packed in a bag that came with the air purifier. In addition to capturing larger particles, the

K Pre-filter

will also trap common household odors and gases. If you choose to use the K Pre-filter, note that it cannot be washed

and should be replaced every 3 months for optimum performance.

HFD230B_OM_31IMH230190_r2_17NOV14.indd 2-3

CLEANING THE IFD® FILTERS

To clean the ifD® filters:

• After removing the ifD® Filters from the air purifier, follow the steps below to

wash the ifD® filters.

Turn the power off and unplug the air purifier.

• Rinse the filter with clean tap water (Fig. 7)

• If the filter still appears dirty, proceed to “Washing,”

otherwise proceed to “Drying.”

Washing:

• Remove the ifD® filters from the unit.

• Fill a sink with lukewarm water and add a few drops of mild dish soap.

• Gently swish the filters in the soap solution to clean.

• Soak the filters for 2-3 minutes. Do not leave for an extended period of time.

• Rinse the filters with clean tap water (Fig. 7).

Fig.7

REMOVING THE FILTERS

The ifD® filters are supplied within the air purifier.

• Turn-off and unplug the air purifier. While pressing on the release tab at the

top of the rear grille, pull the grille towards you and remove it (See Fig. 6).

Gently push along the edge of the filter frame and pull forward. Repeat for the

second filter.

• After cleaning, place filters back into the air purifier housing and snap filter grille

back into place.

Fig. 6

ELECTRONIC FILTER CLEAN REMINDER

This model air purifier has an electronic filter check to remind you when to

check and clean the washable ifD® filter and washable pre-filter based on the air

purifier’s hours of use.

When the filters need to be cleaned, the CHECK FILTERS light will remain on until it

is RESET. You may unplug the air cleaner without interrupting the filter check.

A red LED light** will illuminate when it is time to clean the filters.

You should periodically check the filters. Depending on operating conditions, the

filters should be cleaned at least every 3 months.

To RESET the Electronic Filter Check:

After the ifD® filters and pre-filter have been cleaned and returned to the unit, with the unit still in POWER

OFF mode, press and hold the CHECK FILTERS button (see Fig. 5) for 3 seconds. The CHECK FILTERS red

LED will flash twice indicating the filter check has been reset. The red LED will no longer be illuminated.

These cleaning intervals are intended as guidelines only. Performance of any filter media is dependent

upon the concentration of contaminates going through the system. High concentrations of contaminates

such as dust, pet dander and smoking will reduce the useful performance of the filter.

Drying:

• Shake the filters to remove any excess water.

• Place the filters with the honeycomb side down on a plu

• Note that the filters may still be discolored even afte

This is acceptable and will not affect performance.

• Allow the ifD® filters to dry for a few hours or overnight.

• When the ifD

® filters are , place back intcompletely dry

CAUTION:

• Never place wet ifD® filters in your air purifier.

• The ifD® filters is NOT dishwasher safe. Do not place th

to other extreme hot water conditions.

• Do not use any solvents, strong cleaning agents or flam

CLEANING THE IFD® FILTERS (Cont)

The pre-filter helps pick up large airborne particles that

enter the rear grille. This pre-filter can be periodically

removed and shaken to clean it. Alternatively, it can be

rinsed by hand under warm water (Fig. 8). Let the

pre-filter air dry completely before inserting back into

the grille (Fig. 9). If you need to replace this item, please

call 1-800-477-0457 or visit www.kaz.com.

OPTIONAL: Changing the Odor Absorbing Pre-Filter

If you have chosen to use the odor absorbing

K pre-filter

effectiveness for odor adsorption over time and will need to

To insert it into the unit, simply place securely into the rear

of standard pre-filter as shown in Fig. 9.

If using the odor absorbing K pre-filter, it is recommende

original washable pre-filter in the event that you decide to

NOTE: The odor absorbing pre-filter is not washable.

MAINTAINING YOUR WASHABLE PRE-FILTER

We recommend that you clean the air purifier at least every

only a dry cloth to wipe the external surfaces of the air pur

ANY CHEMICAL SOLUTION.

CLEANING AND STORAGE

Fig. 5

HFD230B_OM_31IMH230190_r2_17NOV14.indd 4-5
