Hikoki WR 25SE Bedienungsanleitung


Lesen Sie kostenlos die 📖 deutsche Bedienungsanleitung für Hikoki WR 25SE (21 Seiten) in der Kategorie Nicht kategorisiert. Dieser Bedienungsanleitung war für 12 Personen hilfreich und wurde von 2 Benutzern mit durchschnittlich 4.5 Sternen bewertet

Seite 1/21
Handling instructions
Iнструкції щодо поводження з пристроєм
Инструкция по эксплуатации
WR 22SE WR 25SE
en
uk
ru
WR25SE
en
uk
ru
2
English
c) Prevent unintentional starting. Ensure the
switch is in the o-position before connecting
to power source and/or battery pack, picking up
or carrying the tool.
 Carryingpowertoolswith yournger on theswitch
or energising power tools that have the switch on
invitesaccidents.
d) Remove any adjusting key or wrench before
turning the power tool on.
 Awrenchora keyleft attachedto arotatingpartof
thepowertoolmayresultinpersonalinjury.
e) Do not overreach. Keep proper footing and
balance at all times.
This enables better control of the power tool in
unexpectedsituations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away
from moving parts.
 Looseclothes,jewelleryorlonghaircanbecaughtin
movingparts.
g) If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used.
Use of dust collection can reduce dust-related
hazards.
h) Do not let familiarity gained from frequent use
of tools allow you to become complacent and
ignore tool safety principles.
A careless action can cause severe injurywithin a
fractionofasecond.
4) Power tool use and care
a) Do not force the power tool. Use the correct
power tool for your application.
 Thecorrectpowertoolwilldothejobbetterandsafer
attherateforwhichitwasdesigned.
b) Do not use the power tool if the switch does not
turn it on and o.
Any power tool that cannot be controlled with the
switchisdangerousandmustberepaired.
c) Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from
the power tool before making any adjustments,
changing accessories, or storing power tools.
 Suchpreventivesafetymeasuresreducetheriskof
startingthepowertoolaccidentally.
d) Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions to
operate the power tool.
 Powertoolsaredangerousinthehandsofuntrained
users.
e) Maintain power tools and accessories. Check
for misalignment or binding of moving parts,
breakage of parts and any other condition
that may aect the power toolʼs operation. If
damaged, have the power tool repaired before
use.
Many accidents are caused by poorly maintained
powertools.
f) Keep cutting tools sharp and clean.
 Properlymaintainedcutting tools withsharpcutting
edgesarelesslikelytobindandareeasiertocontrol.
g) Use the power tool, accessories and tool bits
etc. in accordance with these instructions,
taking into account the working conditions and
the work to be performed.
Use of the power tool for operations dierent from
thoseintendedcouldresultinahazardoussituation.
h) Keep handles and grasping surfaces dry, clean
and free from oil and grease.
GENERAL POWER TOOL SAFETY
WARNINGS
WARNING
Read all safety warnings, instructions, illustrations and
specications provided with this power tool.
Failure to follow all instructions listed below may result in
electricshock,reand/orseriousinjury.
Save all warnings and instructions for future reference.
Theterm“powertool”inthewarningsreferstoyourmains-
operated(corded)powertoolorbattery-operated(cordless)
powertool.
1) Work area safety
a) Keep work area clean and well lit.
 Clutteredordarkareasinviteaccidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
ammable liquids, gases or dust.
 Powertoolscreatesparkswhichmayignitethedust
orfumes.
c) Keep children and bystanders away while
operating a power tool.
 Distractionscancauseyoutolosecontrol.
2) Electrical safety
a) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools.
Unmodiedplugs and matching outlets will reduce
riskofelectricshock.
b) Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators.
There is an increased risk of electric shock if your
bodyisearthedorgrounded.
c) Do not expose power tools to rain or wet
conditions.
 Waterenteringapowertoolwillincreasetheriskof
electricshock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts.
Damaged or entangled cords increase the risk of
electricshock.
e) When operating a power tool outdoors, use an
extension cord suitable for outdoor use.
Use ofacordsuitableforoutdoor usereducesthe
riskofelectricshock.
f) If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply.
 UseofanRCDreducestheriskofelectricshock.
3) Personal safety
a) Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired
or under the inuence of drugs, alcohol or
medication.
 Amomentofinattentionwhileoperatingpowertools
mayresultinseriouspersonalinjury.
b) Use personal protective equipment. Always
wear eye protection.
 Protectiveequipmentsuchasadustmask,non-skid
safetyshoes,hardhatorhearingprotectionusedfor
appropriateconditionswillreducepersonalinjuries.
(Original instructions)
3
English
Slippery handles and grasping surfaces do not
allow for safe handling and control of the tool in
unexpectedsituations.
5) Service
a) Have your power tool serviced by a qualied
repair person using only identical replacement
parts.
Thiswillensure thatthesafety of thepower toolis
maintained.
PRECAUTION
Keep children and inrm persons away.
When not in use, tools should be stored out of reach of
children and inrm persons.
IMPACT WRENCH SAFETY
WARNINGS
Hold the power tool by insulated gripping surfaces,
when performing an operation where the fastener
may contact hidden wiring or its own cord.
Fasteners contacting a “live” wire may make exposed
metal parts of the power tool “live” and could give the
operator an electric shock.
ADDITIONAL SAFETY WARNINGS
1. When using the tool at a hight, make sure that there is
nobody below.
2. Use earplugs if using for a long time use.
3.
Switch the reversing switch only after the motor has stoped
when it is necessary to change the direction of the rotation.
4. Use a step up transformer when a long extension cable
is used.
5. Conrmthetighteningtorquebyatorquewrenchbefore
useinordertoassertainthecorrecttighteningtorqueto
be used.
6. Assemble the socket securely to the impact wrench with
the socket pin and ring.
7. Conrmwhetherthesockethasanycracksinit.
8. Always hold the handle and side handle of the impact
wrench rmly. Otherwise the counterforce produced
may result in inaccurate and even dangerous operation.
SYMBOLS
WARNING
The following show symbols used for the machine. Be
sure that you understand their meaning before use.
WR22SE / WR25SE : Impact Wrench
To reduce the risk of injury, user must read
instruction manual.
OnlyforEUcountries
Do not dispose of electric tools together with
household waste material!
In observance of European Directive 2012/19/EU
onwasteelectricalandelectronicequipmentand
its implementation in accordance with national law,
electric tools that have reached the end of their life
must be collected separately and returned to an
environmentally compatible recycling facility.
SwitchingON
SwitchingOFF
Clockwise rotation
Counterclockwise rotation
Disconnect mains plug from electrical outlet
Class toolII
STANDARD ACCESSORIES
In addition to the main unit (1 unit), the package
contains the accessories listed in the below.
○ Case ...........................................................................1
Standard accessories are subject to change without notice.
APPLICATIONS
○ Tighteningandloosingvariouskindsofboltandnut.
SPECIFICATIONS
Model WR22SE WR25SE
Voltage (by areas)* (110V, 120V, 230V, 240V)
Power input* 800 W 900 W
Noloadspeed/Impact
rate
1400 / 2000 min-1 1100 / 1500 min-1
Squaredrive 19 mm 25.4 mm
Capacities
(size of
bolts)
High
tension bolt M16―M22 M22―M24
Ordinary
bolt M14―M24 M22―M30
Tighteningtorque
(Max.)** 620N·m 1000N·m
Weight*** 5.2 kg 8.4 kg
* Be sure to check the nameplate on product as it is
subject to change by areas.
**
Tightening the bolt without extension cord at rated voltage.
*** Weight: According to EPTA-Procedure 01/2014
NOTE
Due to HiKOKI’s continuing program of research and
development, the specications herein are subject to
change without prior notice.
MOUNTING AND OPERATION
CAUTION
Toprevent accidents,make sureto turnthe switch o
and disconnect the plug from the receptacle.
Action Figure Page
Mounting the socket (1) 1 13
Mounting the side handle 2 13
Changing the rotation direction 3 13
Dismounting the hook hanger (WR25SE)
413
Selecting accessories* 15
* Selectaccessoriesthataresuitedtoaspecictask.
 FordetailscontactHiKOKIAuthorizedServiceCenter.
