01/20 Model 8300-8309/8300CRP-8309CRP Page 1 of 5
1455 Kleppe Lane (775) 359-4712 Sparks, NV 89431-6467 Fax (775) 359-7424
E-mail: haws@hawsco.com website: www.hawsco.com
No. 0002080162 (25)
Model 8300-8309/8300CRP-8309CRP
Shower & Eye/Face Wash
INSTALLATION, OPERATION
&
MAINTENANCE INSTRUCTIONS
LIMITED WARRANTY
HAWS warrants that this specific product is guaranteed against defective material or poor
workmanship for a period of . HAWS liability under this one year from date of shipment
warranty shall be discharged by furnishing without charge F.O.B. HAWS Factory any
goods, or part thereof, which shall appear to the Company upon inspection to be of
defective material or not of first class workmanship, provided that claim is made in writing
to Haws within a reasonable period after receipt of the product. Where claims for defects
are made, the defective part or parts shall be delivered to the Company, prepaid, for
inspection. HAWS will not be liable for the cost of repairs, alterations or replacements, or
for any expense connected therewith made by the owner or his agents, except upon
written authority from HAWS, Sparks, Nevada. HAWS will not be liable for any damages
caused by defective materials or poor workmanship, except for replacements, as provided
above. Buyer agrees that Haws has made no other warranties either expressed or implied
in addition to those above stated, except that of title with respect to any of the products or
equipment sold hereunder and that HAWS shall not be liable for general, special, or
consequential damages claimed to arise under the contract of sale.
The emergency equipment manufactured by HAWS is warranted to function if installation
and maintenance instructions provided are adhered to. The units also must be used for the
purpose for which they were intended. This product is intended to supplement first-aid
treatment. Due to widely varying conditions, Haws cannot guarantee that the use of this
emergency equipment will prevent serious injury or the aggravation of existing or prior
injuries.
NO OTHER WARRANTIES EXPRESSED OR IMPLIED ARE AUTHORIZED, PROVIDED OR
GIVEN BY HAWS.
NOTE TO INSTALLER: Please leave this information with the Maintenance Department.
SHOULD YOU EXPERIENCE DIFFICULTY WITH THE INSTALLATION OF THIS
MODEL PLEASE CALL:
TECHNICAL SUPPORT: 1-800-766-5612
FOR CUSTOMER SERVICE: 1-888-640-4297
01/20 Model 8300-8309/8300CRP-8309CRP Page 2 of 5
LOCATION OF UNIT: The Model 8300/8300CRP/8309/8309CRP Emergency Shower
should be installed in close proximity to potential accident areas. It should be clearly
identied, free from obstructions and easy to access.
SUPPLY LINE: The minimum recommended line size is 1-1/4” IPS with 30-90 psi (2-6
ATM) flowing pressure. Where sediment or mineral content is a problem, an inlet filter is
recommended.
PLUMBING CONNECTIONS: Inlet supply is female 1-1/4” IPS. Waste outlet is female
1-1/4” IPS.
INSTALLATION PROCEDURE
Refer to Installation Drawing for clarification. Check parts list to insure all required parts
are included. Use pipe joint sealant PST #565 (Loctite) on all connections.
STEP 1: Prepare the emergency shower foundation by using the floor flange
assembly as a template. Locate the three holes for the 3/8-16 UNC x 6”
anchor bolts (not supplied). They should extend 1” above the floor level.
STEP 2: Once the concrete foundation is ready (dry), assemble the floor flange
assembly to the anchor bolts; then securely fasten with 3/8-16 UNC Hex
nuts and 3/8” washers (not supplied). Seal and tighten floor flange and
tee (1-1/4”) making certain the waste tee is facing the proper location and
the foot control holes are facing side to side.
STEP 3: Assemble nipple (1-1/4” x 21-1/2”) to the floor flange assembly and tighten
with a pipe wrench.
STEP 4: Assemble the eyewash loop assembly to the 21-1/2” nipple from Step
three. Connect the pipe wrench to the galvanized nipple between the two
tees to avoid damage.
STEP 5: Assemble in the following order:
-Attach nipple (1 1/4” x 24”) onto the loop assembly.
Attach nipple (1-1/4” x 24”) onto the tee (1-1/4”).
Attach tee (1-1/4” x 1-1/4” x 1”) onto nipple.
Attach nipple (1x 9”) valve assembly onto tee (1-1/4” x 1-1/4” x 1”).
Assemble the street elbow (1”) onto nipple (1” x 12-1/2”).
Attach nipple onto valve.
STEP 6: Assemble showerhead onto street elbow (1”).
STEP 7: Assemble the sign onto the unit. Use the strap, screws, washers and nuts
provided to mount the sign onto the upright. The sign should be positioned
for maximum visibility.
STEP 8: Insert the plug into the optional supply line tee that is not used. Before
connecting the supply water line to the emergency shower, FLUSH THE
LINE THOROUGHLY.
01/20 Model 8300-8309/8300CRP-8309CRP Page 3 of 5
TROUBLESHOOTING
PROBLEM REPAIR CHECKLIST
1. No flow. 1. Check the main shut-off valve.
2. Water leak between joints or fittings. 2. Tighten loose connections. If leak
persists, the application of hot water
will sometimes reseat improperly
applied joint compound. After 30
minutes wait and retest. A persistent
leak will necessitate reassembly and
additional sealant.
3. Insufficient water flow, shower and
eyewash.
3. Verify minimum 30 psi (2 ATM) flowing
supply line pressure.
4. Water does not drain properly. 4. Check your drain system for debris.
Check the main waste line of your
building to see if it does handle the
capacity required for the entire
drainage system.
5. Insufficient water flow on eyewash,
however, shower is sucient.
5.a.
Verify minimum 30 psi (2 ATM) flowing
supply line pressure.
b. Probable clogging of flow control due
to inadequate line flushing. Unscrew
eye/face wash head and remove the
four screws to disassemble head.
Clean flow control and reassemble
head. See SP65 Installation Drawing
for details.
c. Remove cap located on L – Strainer
using a 3/8” allen wrench to access
and clean filter screen.
6. Eyewash or face wash streams do not
meet at desired eye level or are not
balanced.
6. Possible blocked flow control see
above solution. (Possible non-leveled
eyewash assembly.)
7. Insufficient water flow at the
showerhead, however, eyewash is
sufficient.
7.a. Probable clogging of flow control inside
shower head. Unscrew shower head
off of elbow and clean rubber flow
control.
© 2020 Haws® Corporation – All Rights Reserved
HAWS® and other trademarks used in these materials are the exclusive property of Haws Corporation.
