Seite 1/4
INS_TER-F01[PD] 08/12/19 PAGE 1
INSTALLATION AND OPERATION MANUAL TER-F01 SERIES
TER-F01 Series
10/100 MBPS ETHERNET REPEATER WITH 60 W PASS-
THROUGH POE
The is an repeater to 60 watts of TER-F01 series Ethernet supporting up Pass-through
PoE, providing simple cost-effective extend signals a and way to Ethernet beyond
the standard 328 meter) TER-F01 used Ethernet foot (100 limit. The can be to
double distance (200 multiple units combined the to 656 feet meters) or can be in
series unit providing additional feet meters). with each an 328 (100 The TER-F01 is
powered pass-through a midspan injector, requiring by PoE from PoE switch or no
local power consumption ensures power power. Low that maximum is made
available remote to the PD device.
The through the to the next or as a standard configuration passes PoE device, PD
model, acts as the final PoE in the chain and does not the which unit pass through PoE.
This manual serves the following
Model Names:
TER-F01
TER-F01PD
INS_TER-F01[PD] 08/12/19 PAGE 2
INSTALLATION AND OPERATION MANUAL TER-F01 SERIES
FIGURE 1 – TER-F01[PD] EXTENDER
ETHERNET ETHERNET
Power: Supplied by PSE
Power Consumption: <1 W
FIGURE 3 – INDICATING LEDS
COPPER
GREEN Solid – No Activity
Blinking – Activity
YELLOW Highest Data Rate
(100Mb)
INSTALLATION CONSIDERATIONS
The TER-F01[PD] is supplied as a 3.3 × 1.25 × 1.25 in (8.4 × 3.2 × 3.2 cm) tube
module.
Units should be installed in dry locations protected from extremes of temperature
and humidity.
WARNING: Unit is to be used with a Listed Class 2 power supply.
IMPORTANT SAFEGUARDS:
A) Elevated Operating Ambient - If installed in a closed or multi-unit rack
assembly, the operating ambient temperature of the rack environment may
be greater than room ambient. Therefore, consideration should be given to
installing the equipment in an environment compatible with the maximum
ambient temperature (Tma) specified by the manufacturer.
B) Reduced Air Flow - Installation of the equipment in a rack should be such
that the amount of air flow required for safe operation of the equipment is not
compromised.
FIGURE 4 - DIMENSIONS
Dimensions are for a tube module
3.2 cm
[1.25 in]
3.2 cm
[1.25 in]
8.4 cm
[3.3 in]
Note: Ports are universal, and either can be used as in or out.
SPECIFICATIONS
Ethernet
Data Interface 10/100BaseT(X) Ethernet
IEEE 802.3 Compliant
Full Duplex or Half Duplex Electrical Ports
Standards IEEE: 802.3af PoE, 802.3at PoE+
RFC: 768 UDP, 2068 HTTP, 793 TCP, 791 IP, 1783
TFTP, 894 IP over Ethernet, 2544 TCP/IP Packet
Transmission
Transmission Distances1 See chart below
Connectors
Ethernet 2 × RJ-45
Power
Pass-Through Mode Operates on PoE Power
Power Consumption < 1 W
Protection High Impedance PoE Pass-Through with Start-up
Voltage Detection and Current Limiting
Mechanical
Indicating LEDs Ethernet Link and Activity
Circuit Board Meets IPC Standard
TER-F01[/PD] Size 3.3 × 1.25 × 1.25 in (8.4 × 3.2 × 3.2 cm)
Shipping Weight <1 lbs./0.5 kg
Environmental
MTBF >100,000 hours
Operating Temp – 40˚ C to +75˚ C
Storage Temp – 40˚ C to +80˚ C
Relative Humidity 0% to 95% (non-condensing)²
A
GENC MPLIANCEY CO
MAXIMUM TRANSMISSION DISTANCES1
Maximum Range & Repeaters for PoE Power (Watts)
PoE Source No PoE³ 5 W 20 W10 W 15W 25 W
15 W PoE Switch
2,625 t f
800 m
(Using 7 TER-F01)
1,476 t f
450 m
(Using 4 TER-F01)
984 ft
300 m
(Using 2 TER-F01)
328 ft4
100 m
4
(No ER-F01) T
N/A4N/A4
30 W PoE+ Switch
2,625 t f
800 m
(Using 7 TER-F01)
1,969 ft
600 m
(Using 5 TER-F01)
1,316 t f
400 m
(Using 3 TER-F01)
984 ft
300 m
(Using 2 TER-F01)
656 ft
200 m
(Using 1 TER-F01)
328 ft4
100 m
4
(No ER-F01) T
35 W PoE+ Injector
3,773 t f
1,150 m
(Using 11 TER-F01)
2,625 t f
800 m
(Using 7 TER-F01)
1,804 t f
550 m
(Using 5 TER-F01)
1,316 t f
400 m
(Using 3 TER-F01)
984 ft
300 m
(Using 2 TER-F01)
656 ft
200 m
(Using 1 TER-F01)
[1] Distance figures are based on 48V PSE PoE power source for PoE switches, 50V PSE PoE power source for PoE+ switches and 56V PSE PoE
power source for the injector as detailed in the table. Distance figures are obtained using in-house testing mirroring installations. Factors
such as cable quality, the number of connectors and splices in the cable run, the use of PoE, and environmental conditions encountered
within the installation might affect the actual transmission distance and should be taken into consideration.
[3] Non-PoE applications; using a TER-F01PD model at the end of the chain
[4] Extension is not at this PoE power level with this particular PoE power sourceneeded/possible at the distance listed
INS_TER-F01[PD] 08/12/19 PAGE 3
INSTALLATION AND OPERATION MANUAL TER-F01 SERIES
