13 5
1
2
3
4
Power input interface
Switch ON/OFF
Brightness adjustment knob: Rotate the
knob to adjust the brightness
Compound knob: Long press 2 seconds to
switch the light mode(CCT/SCENE), short
press can switch to the parameter to be
adjusted, turn the knob to adjust the
lighting parameter.
6 7 8 9 10
160.00 mm
120.00 mm
封底 封面
书本形式
2114
GVM-PR150D
5Mode button: switch control mode
(Rotate/Master/Slave/APP)
1
2
4
3
6LCD display: available to display the current
mode and parameters of the lamp
①Steplessly adjustable the lighting effect, the brightness and color temperature can be
controlled at will. The range of color temperature is 2700K~7500K. There is a high color
render index CRI97+ COB lamp bead in the light which helps to restore and enrich the
color of objects, providing you with natural and vivid shooting effects.
We believe that once using our product correctly, you can make huge progress when
shooting. Before using the product, you are strongly recommended to read the instructions
below carefully.
Lightning/Flash/Candlelight/TV/Bad Bulb/Explosion/Fireworks/Paparazzi
Welcome to "GVM-PR150D", this product is specially designed for senior photography
enthusiasts. The product is suitable for live streaming / outdoor / studio photography, and
also for YouTube video shooting. The main features of the product are:
② App intelligent control system, which can be controlled by your intelligent mobile device.
③ It has LCD display and a stable system, which supports 360° rotation and can
effectively control light. It is also equipped with a standard lampshade. After installation,
it makes the lighting become softer. Customized control fills the light, allowing you to
easily and easily shoot the desired results.
④ Can simulate 8 kinds of scene lights:
Vents
Diffuser Mount
Lamp holder fixing handle
U-frame
COB lamp bead
Bowens Mount
Lamp holder interface
Angle fixing handle
Buckle
Lamp holder interface
MODE
INTENSITY
CCT
ON/OFF
Lamp holder interface
Mode button
Compound knob
Brightness
adjustment
knob
Switch ON/OFF
Power input port
MO DE
INT EN S Y
TAB
ON/OFF
MODE
INTENSITY
CCT
ON/OFF
21
3 4
5
6
FacebookGVM Official
website
Download APP
Web: www.gvmled.com
B&H Email: bh @gvmled.com
GVM Email: support@gvmled. com
Amazon Email: amazonsupport@gvmled.com
Warehouse Add: 4301 N Delaware ave, unit D. PHILADELPHIA, PA1913 7, USA
Product introduction ------------------------------------------- Page 1
Disclaimers -------------------------------------------------------- Page 1
Product parameter --------------------------------------------- Page 2
Product structure analysis ------------------------------------ Page 3
Installation method ----------------------------------------- Page 4~5
Description of product control keys ----------------------- Page 6
Function introduction and instruction ---------------- Page 6~8
APP control -------------------------------------------------------- Page 9
Simple faults and troubleshooting ----------------------- Page 10
Precautions ------------------------------------------------------ Page 10
Use and preservation ----------------------------------------- Page 11
Packing list ------------------------------------------------------- Page 11
C O N T E N T S
PRODUCT INTRODUCTION
DISCLAIMERS
3. Design and specifications are subject to change without notice.
1. Before using this product, please read the instructions carefully and make sure to use
the product correctly. If you don't obey the instructions and warnings, you maybe cause
harm to yourself and the people around or even damage the product and other things
around.
2. Once you use this product, you are deemed to have read the disclaimer and warning
carefully, understand and acknowledge all the terms and contents of this statement,
and promise to take full responsibility for the use of this product and possible
consequences.
PRODUCT
PARAMETER
Brand : GVM
Product model : GVM-PR150D
Product Name : Photography lights
Product Type : Photography Fill Light
Functions/features: APP (Bluetooth connection), new LCD screen,
joint control, high display COB lamp beads, multi-scene mode
Lamp beads quantity : COB*1
Color rendering index : ≥97
Color temperature : 2700K~7500K
Lumen : 5910lux/1m, 23100lux/0.5
Light adjustment method : Stepless adjustment
Power :150W
Voltage : AC 100-240V
Power supply mode : DC input
Power supply : DC 30V5A
Cooling : Fan forced cooling
Product Weight : 1.5 KG
Product Size (mm) :220*160*290
Product material : Aluminum alloy + plastic
Commodity origin : Huizhou, China
PRODUCT STRUCTURE
ANALYSIS
INSTALLATION METHOD DESCRIPTION OF PRODUCT
CONTROL KEYS Press mode button to switch the control mode, including Rotate, Master, Slave,
APP mode
② Modetypesandfunctions：
Rotate mode: Through the knob to adjust the brightness, color temperature and
select the scene.
Master mode: Through the knob to adjust the brightness, color temperature,
channel and select the scene. The slaves of the same channel will also be
controlled synchronously.
Slave mode: Adjust the channel through the composite knob. When the channel
of the slave and the master are the same, they can be controlled by the master
synchronously.
APP mode: The channel can only be adjusted through the composite knob, and
the light can be adjusted through the APP.
③Adjust brightness (INTENSITY): Range 0%~100%
Master mode / Rotate Mode: Turn the brightness adjustment knob to adjust
the brightness.
APP mode: Connect to the APP and adjust the brightness through the APP.
④Adjustable color temperature (CCT): Range 2700K~7500K
In Master/Rotate mode, long press the composite knob for 2 seconds to
switch the lighting mode to CCT→ Rotate the composite knob to adjust the
color temperature.
APP mode, connect to the APP and adjust the color temperature through the
APP.
⑤Adjust CH: Range 1~12
In Master/Rotate mode, rotate the compound knob to adjust the channel.
In APP mode, connect to the APP and set the value of the channel through
the APP.
⑥Adjust scene (SC):
There are 8 scenes in scene mode:
GVM-PR150D: 1 Lightning, 2 Flash, 3 Candlelight, 4 TV, 5 Bad Bulb,
6 Explosion, 7 Fireworks, 8 Paparazzi
Long press to switch light mode to SCENE → short press the compound knob
to switch → rotate the button can choose scene mode and adjust brightness,
color temperature, time parameter, etc
In APP mode, connect to the APP and adjust the scene lighting through the
APP.
⑦APP Control:
Switch the photography light to the APP mode, open APP GVM LED, after
registering and logging in, it will enter the Bluetooth search interface, find the
Bluetooth Name “BT_ LED” and then connect it, waiting for connecting. After
success, you can control the light by APP.
⑧Master & Slave control mode: Joint control between lamps
Prepare two or more photography lights, set one to Master mode, and the
others to Slave mode, and set the same channel (CH) of the master and
slave photography lights. Then it can be synchronously controlled the
brightness, color temperature through the master light.
You can also use APP to connect to the master, and control the slave through
the APP
Turn on the video light and set the mode to APP mode. Open the
“GVM_LED” application software on the phone ( The phone needs to
turn on Bluetooth and GPS), then enter the register and log in
interface → enter Bluetooth’s search interface → Find the Bluetooth
named “BT_LED” and connect → Wait for connection → After connect
success, it will automatically enter the app’s control interface. At this
time, the video light can be control by the APP.
APP CONTROL
Scan the QR code on the back of the manual to download the APP
You can save 6 custom light effects in “My Scenes”. After setting the
light effect parameters → click the “ ” icon in the right corner →
pop up the “Save Current Scenes” → click “OK”. The light effect can
be found in “My Scenes” at this time.
If there is a slave, the APP will synchronously control the slave of the
same channel as the connected APP mode machine.
Color temperature
control interface
Scene light
control interface
Save light
effect interface
PRECAUTIONS
The video light is not waterproof, please use it in a rain-proof environment.①
The video light is not anti-corrosion, please don’t let the light come into
contact with any corrosive liquid.
②
When you use the light, make sure that the light is placed firmly to prevent
the it from falling and being damaged.
③
When the light is not used for a long time, please turn off the power of it to
save energy consumption.
④
SIMPIE FAULTS
AND TROUBLESHOOTING
Phenomenon
Make sure the adapter is we ll
contacted with the power plug.
Check the product Solution
The switch
indicator does
not light up
Whe ther the con nection
bet ween the lam p and the
pow er s uppl y is norm al.
APP can't
connect / can't
control
Check if the product is "turned
off" by the APP.
Press the “ON/OFF” button once
again.
The product is
in the "ON" state,
the display and
lights are not on
Check whether the device is
in APP mode and whether
"BT_LED" is displayed on
the APP.
Normal steps:
① Switch to APP mode after booting;
② Turn on Bluetooth and GPS on the
phone;
③ Open the APP, search and connect
to Bluetooth BT_LED.
Do not put the light in a highly humid, strong electromagnetic field, direct sunlight,
high-temperature environment. If the light is not use for a long time, please disconnect
the power.
Clean：Before cleaning,please unplug the power plug. And use wet cloth rather than any
detergent or soluble liquid, avoiding damaging the surface layer.
USE AND PRESERVATION
Repairing：If there is fault or performance degradation, do not unpack the shell by yourself,
avoiding damage to the machine and lose the right of maintenance. When there is a fault, do
not hesitate to contact us, and we will do our best to deal with the problem.
Accessories：Please use the accessories provided by the manufacturer and approved ones,
In order to maximize the performance.
Guarantee：Do does not modify the product, or you will lose the right of maintenance.
Power：Make sure the power is in the demanded range, not too high or too low. Correctly
load the battery, in order not the damage to the machine.
Name
Photography light
Quantity Notes
1
Power cord 1
1
1
Adapter
Softbox
PACKING LIST
1
Instructions
The light can be installed and fixed on the bracket by rotating the knob
clockwise, and unloaded by rotating in the counterclockwise direction.
Insert the bayonet of the diffuser into the bayonet of the lamp, and then
turn it slightly clockwise.
Loosen the angle fixing handle, adjust the angle of the spotlight that you
need, and then turn the angle fixing handle tightly.
Connect the power cord to charge.
FUNCTION INSTRUCTION &
INSTRUCTION FOR USE
S C : C H :
Rotate
Slave
Master
APP
K
ms
CCT :
TIM :
Scene number
Brightness
Channel value
Control mode
CCT/Time parameters
(Only display current mode)
(Only display current adjustable
parameters of light mode)
(Only display when the
light mode is scene)
Display the current brightness, control mode, light mode, light parameters, scene
number, and channel value of the light.
①
Current adjustable
parameters of light mode
(Only display current adjustable parameter)
LCD Display：

Produktspezifikationen

Marke: GVM
Kategorie: Erleichterung
Modell: PR150D

Brauchst du Hilfe?

Wenn Sie Hilfe mit GVM PR150D benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten


Bedienungsanleitung Erleichterung GVM

GVM

GVM YU200R Bedienungsanleitung

3 September 2024
GVM

GVM SD80D Bedienungsanleitung

3 September 2024
GVM

GVM SD300D Bedienungsanleitung

3 September 2024
GVM

GVM SD300S Bedienungsanleitung

3 September 2024
GVM

GVM B200C Bedienungsanleitung

3 September 2024
GVM

GVM PR150D Bedienungsanleitung

3 September 2024
GVM

GVM 12D Bedienungsanleitung

28 August 2024
GVM

GVM PRO-BD45R Bedienungsanleitung

28 August 2024

Bedienungsanleitung Erleichterung

Neueste Bedienungsanleitung für -Kategorien-

Goobay

Goobay 30780 Bedienungsanleitung

16 Oktober 2024
AFX

AFX Grace GRCP07CBBK Bedienungsanleitung

13 Oktober 2024
AFX

AFX Point PNTP0107L30D1BK Bedienungsanleitung

13 Oktober 2024
Smartwares

Smartwares 20.003.54 Bedienungsanleitung

9 Oktober 2024
Neewer

Neewer TL97C Bedienungsanleitung

8 Oktober 2024
Neewer

Neewer SRP18C Bedienungsanleitung

8 Oktober 2024
Qtx

Qtx Moonglow Bedienungsanleitung

7 Oktober 2024
Blumfeldt

Blumfeldt Shinecube XL Bedienungsanleitung

7 Oktober 2024
Qtx

Qtx HPWash100 Bedienungsanleitung

6 Oktober 2024
BeamZ

BeamZ DJ X5 Bedienungsanleitung

5 Oktober 2024
